3002922/01
OWNER'S GUIDE
A v i g n o n
&
A v i g n o n A s p i r e
Model BR650 VA
(G.C. 32-032-39)
AS SUPPLIED, THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
WHEN CONVERTED USING CONVERSION KIT NO. 0591149 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31)
THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND THE
REPUBLIC OF IRELAND (IE) ONLY.
This guide is intended to help you care for your Wonderfire gas fire. Please read
thoroughly before using and keep for future reference.
We trust that this Guide gives sufficient details to enable the appliance to be operated and
maintained satisfactorily. However, if further information is required, our Technical
Helpline will be pleased to help.
Please telephone 08706 061 065 (National call rates apply in the United Kingdom).
In the Republic of Ireland call 0044 08706 061 065.
Please keep this guide in a safe place for future reference
© Wonderfire
Advertisement
Related Manuals for Wonderfire avignon aspire BR650 VA
Summary of Contents for Wonderfire avignon aspire BR650 VA
- Page 1 THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE) ONLY. This guide is intended to help you care for your Wonderfire gas fire. Please read thoroughly before using and keep for future reference.
-
Page 2: Table Of Contents
C A R E Thank you for choosing Wonderfire. All Wonderfire gas fires are designed to meet the most stringent quality, performance and safety requirements to provide our customers with many years’ trouble-free service. Your owner guide aims to improve your understanding and appreciation of your Wonderfire gas appliance by providing simple and informative instructions to ensure that you benefit from the excellent performance and features it has to offer. -
Page 3: Safety
OWNER’S GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE – SEE YOUR LOCAL TELEPHONE DIRECTORY •... - Page 4 OWNER’S GUIDE • Always use a fireguard complying with BS6539 or BS6778 for the protection of young children, the elderly or infirm. • Wait three minutes before attempting to relight if the fire is switched off or the flames are extinguished for any reason. •...
-
Page 5: Appliance Dimensions
OWNER’S GUIDE APPLIANCE DIMENSIONS Figure 1. Appliance dimensions Page 5... -
Page 6: Operating Your Fire
OWNER’S GUIDE OPERATING YOUR FIRE PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after a few hours use. - Page 7 OWNER’S GUIDE Lighting the Main Burner • Once the pilot light is established, the main burner can be lit by depressing and turning the control knob anticlockwise to the “High” position. Selecting the Heat Setting • In order to change from one setting to another depress the control knob slightly and turn the knob to the required position.
-
Page 8: Cleaning
OWNER’S GUIDE CLEANING To maintain the high performance and quality finish of your Wonderfire appliance, please follow these guidelines: • Before attempting to clean the fire, please remember to turn off the fire and wait for the appliance to cool completely. The fire will retain heat for some time before cleaning can begin. -
Page 9: Refitting Ceramics
OWNER’S GUIDE Burner • The burner surface can be carefully cleaned to remove any loose particles after taking off the ceramic fuel effect pieces. Make sure that no particles are pushed into the burner slots. Note: Surface cracking of the burner is normal and no cause for concern. REFITTING CERAMICS Fitting Coals to models supplied with Coal Ceramic Fuel Effect. - Page 10 OWNER’S GUIDE Place a type “A” coal between the front and rear base coals with the letter “A” upright and so that the coal is against the left side of the firebox. See figure 5. Place a type “B” coal between Figure 5 the front and rear base coals as shown in figure 6.
- Page 11 OWNER’S GUIDE Place the remaining type “A” coal between the front and rear base coals. The letter “A” should be upside down with its rear face between the right and centre coals of the rear base coal. Angle the coal so that the gap between it and the type “B”...
- Page 12 OWNER’S GUIDE Install the 11 loose pebbles as follows. The underside of each pebble is marked with a letter ‘A’ to ‘K’ and an arrow. The pebbles should be positioned so that the arrows always point towards the back of the fireplace opening.
- Page 13 OWNER’S GUIDE Hold pebble ‘D’ upright with the arrow pointing to the top. Place pebble “D” on top of the base front pebble. It should rest against the moulded pebble to its right. (See figure 15). Hold pebble ‘E’ Figure 15 upright with the arrow pointing to the top.
- Page 14 OWNER’S GUIDE Hold pebble ‘H’ upright with the arrow pointing to the top. Place pebble ‘H’ between the front and rear base pebbles. It should rest in between pebbles ‘C’ & ‘D’ and against the moulded pebble in the rear pebble base. (See figure 19).
-
Page 15: Maintenance
We recommend that all gas appliances and their flues, wherever situated, are checked annually. Servicing • In the United Kingdom servicing can be carried out either by a Wonderfire service engineer or a CORGI registered installer. • If you require your fire to be serviced, please contact Wonderfire Service on 08706 090 081 and quote the following details;... - Page 16 • When fitting replacement parts, follow the instructions contained in this guide. It is important that only Wonderfire approved parts are used for maximum safety. • In the United Kingdom, for general advice about gas and your gas fire call our Technical Helpline 08706 061 065.
