Installation of Indoor Unit
Connect the drain hose to the outlet pipe of the indoor unit.
1.
Bind the joint with rubber belt.
2.
Put the drain hose into insulating tube.
3. Wrap the insulating tube with wide rubber belt to prevent
the shift of insulating tube. Slant the drain hose downward
slightly for smooth drainage of condensate.
Note: The insulating tube should be connected reliably with
the sleeve outside the outlet pipe. The drain hose should be
slanted downward slightly, without distortion, bulge or
fluctuation. Do not put the outlet in the water.
Connecting Indoor and Outdoor Electric Wires
1.Open the front panel.
2.Remove the wiring cover as shown in Fig 6.
3.Make the power connection cord and pass through the hole at the back of indoor unit.
4.Reinstall the cord anchorage and wiring cover.
5.Reinstall the front panel.
NOTE:
All wires between indoor and outdoor units must be connected by the qualified electric
contractor.
Electric wires must be connected correctly. Improper connection may cause malfunction.
●
Tighten the terminal screws
●
After tightening the screws, pull the wire slightly to confirm whether
●
Make sure that the electric connections are earthed properly to prevent electric shock.
●
Make sure that all wiring connections are secure and the cover plates are reinstalled
●
properly. Poor installation may cause fire or

Installation of Drain Hose

Wiring cover
securely.
electric shock.
5
outlet pipe of
indoor unit
rubber belt
outlet pipe of
indoor unit
outlet pipe of
indoor unit
bulge
yellow-
brown
green
outdoor unit connection
it's firm
outlet pipe of
indoor unit
drain hose
drain hose
rubber belt
insulating tube
rubber belt
insulating tube
connected
distortion
Flooded
Fig.6
or not.
