resIdentIal Gas water heaters
Low Lead Content
Keep thIs Manual In the pocKet on heater for future reference
whenever MaIntenance adjustMent or servIce Is requIred.
Gas Models power vent lvl07580(s), lvn07580(s)
Thank you for buying this energy efficient water heater. We
appreciate your confidence in our products.
You should thoroughly read this manual before installation and/or
operation of this water heater. Please pay particular attention
to the important safety and operating instructions as well as the
WARNINGS and CAUTIONS.
•

for Your safety

AN ODORANT IS ADDED TO THE GAS USED
BY THIS WATER HEATER.
1
Instruction Manual
wIth hot surface IGnItIon
•
322923-000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LVL07580 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lochinvar LVL07580

Summary of Contents for Lochinvar LVL07580

  • Page 1: For Your Safety

    Instruction Manual resIdentIal Gas water heaters Gas Models power vent lvl07580(s), lvn07580(s) wIth hot surface IGnItIon 300 Maddox Simpson Parkway Lebanon, TN 37090 Phone: 615-889-8900 • Fax: 615-547-1000 Technical Service email: 2tech@lochinvar.com www.lochinvar.com Low Lead Content Thank you for buying this energy efficient water heater. We appreciate your confidence in our products.
