Summarization of Contents
General Installation Requirements
Compliance Standards for Appliances up to 70kW
Details BS5440-1:2008 for flueing and ventilation of gas appliances up to 70kW.
Compliance Standards for Appliances over 70kW
Details IGEM/UP/10 for flued gas appliances in commercial/industrial premises.
High Heat Input Installation Rules
Rules for horizontal flue terminations for appliances exceeding 333kW net heat input.
Clean Air Act Compliance
Governs installations exceeding 333kW nett input.
Concentric Flue Systems
Standard Concentric Horizontal and Vertical Flue
Details components and specifications for standard concentric flue assemblies.
Maximum Flue Lengths for Concentric Systems
Specifies maximum equivalent flue length and number of bends allowed.
Concentric Flue Ancillary Items
Lists ancillary items for concentric flue systems with item numbers and descriptions.
Plume Kit for Horizontal Concentric Flue
Maximum Flue Lengths for Plume Kits
Defines maximum flue length and number of additional bends for plume kits.
Additional Plume Kit Ancillary Items
Lists additional ancillary items for plume kits with item numbers and dimensions.
Twin-Pipe Flue Systems
Twin Pipe Horizontal Flue Assembly
Details components for twin-pipe horizontal flue assemblies.
Twin Pipe Vertical Flue Assembly
Details components for twin-pipe vertical flue assemblies.
Twin Pipe Horizontal Flue Assembly with Separate Air Inlet
Details components for horizontal twin-pipe flue using separate air inlet/outlet.
Maximum Flue Lengths for Twin-Pipe Systems
Specifies maximum equivalent flue length and bend equivalencies for twin-pipe systems.
Twin-Pipe Flue Ancillary Items
Lists ancillary items for twin-pipe flue systems with item numbers and descriptions.
Conventional (Exhaust Only) Flue Systems
Conventional Vertical Flue Assembly Components
Lists components included in the conventional vertical flue assembly.
Maximum Flue Lengths for Conventional Systems
Specifies maximum equivalent flue length and bend equivalencies for conventional systems.
Conventional Flue Ancillary Items
Lists ancillary items for conventional flue systems with item numbers and descriptions.
Common Flue Systems
Common Flue System Pressure Loss Figures
Provides pressure loss figures for common flue systems (C63) for different model ranges.
