LSTR
Direct Storage Vessel
Installation, Commissioning,
User & Maintenance Instructions
Models:
LSTR 66 G E
LSTR 100 G E
LSTR 110 G E
LSTR 130 G E
LSTR 165 G E
LSTR 220 G E
LV 313762 | August 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSTR 66 G E and is the answer not in the manual?

Questions and answers

Summary of Contents for Lochinvar LSTR 66 G E

  • Page 1 LSTR Direct Storage Vessel Installation, Commissioning, User & Maintenance Instructions Models: LSTR 66 G E LSTR 100 G E LSTR 110 G E LSTR 130 G E LSTR 165 G E LSTR 220 G E LV 313762 | August 2021...
  • Page 2 IMPORTANT INFORMATION These instructions must be read and understood before installing, commissioning, operating or maintaining the equipment.
  • Page 3 Read this manual Warning carefully Read this manual carefully before starting with the installation of the storage vessel. Failure to read the manual and to follow the printed instructions may lead to personal injury and damage to the storage vessel. Copyright ©...
  • Page 4: Table Of Contents

    Warranty ........................13 General warranty ......................13 Tank warranty ....................... 13 Conditions for installation and use ................13 Exclusions ........................14 Scope of warranty ......................14 Claims .......................... 14 Obligations of Lochinvar Ltd ..................14 Installation, Commissioning, User & Maintenance Instructions...
  • Page 5: Technical Specifications

    Technical specifications 1.1 Floor load Allow for the storage vessels weight and the maximum floor load; refer to the table (1.5 "General specifications"). 1.2 Working clearance For access to the storage vessel it is recommended that the following clearances are observed: ...
  • Page 6: Dimensions

    1.6 Dimensions Unit LSTR 66 LSTR 100 LSTR 110 LSTR 130 LSTR 165 LSTR 220 Total height 1375 1710 2045 1840 2035 2005 Diameter (without insulation) Diameter (with insulation) 1100 Height connection 1041 1375 1135 1330 1255 Height connection 1115 1455 1220 1415...
  • Page 7: Installation

    Installation Note These products can be installed as vented and unvented. This manual only discusses unvented installations. For information about vented installations please contact your supplier. 2.1 Installation diagram The figures below show the installation diagrams. These diagrams are referred to in the sections describing the actual connection procedure.
  • Page 8 3. Fit a non-return valve (5) and an expansion vessel (16). 4. Fit an expansion valve (15) and connect the overflow side to an open waste water pipe. 2.2.2 Hot Water side See (B) in the installation diagram (2.1 "Installation diagram"). Note Insulating long hot water pipes prevents unnecessary energy loss.
  • Page 9: Filling And Draining

    Filling and draining Note These products can be installed as vented and unvented. This manual only discusses unvented installations. For information about vented installations please contact your supplier. Installation Diagram Legend 1. pressure relief valve (mandatory if mains water pressure is too high) 3.
  • Page 10: Draining

    3.2 Draining 1. Close the stop valve (4) between the cold water head tank and the cold water inlet (A). 2. Open the drain valve (9). 3. Bleed the water heater (or installation) so that it drains completely. Installation, Commissioning, User & Maintenance Instructions...
  • Page 11: Maintenance

    Maintenance Warning Maintenance may only be carried out by a competent person. At each service, the storage vessel undergoes maintenance on water side. The maintenance must be carried out in the following order. 1. Preparation for maintenance 2. Water-side maintenance 3.
  • Page 12 4.2.2 Checking anode Anode ensure the protection of the tank by sacrificing themselves. Insufficient anode material may lead to poor protection and, hence, leakage of the tank. 1. Loosen the anodes one by one. 2. Check the diameter of each anode in different places. The diameter must be at least 60% of the original diameter.
  • Page 13: Warranty

    Ltd, the enamel-lined steel tank proves to be leaking due to rust or corrosion occurring on the water side, then Lochinvar Ltd shall offer to replace the defective storage vessel with an entirely new storage vessel of equivalent size and quality The warranty period given on the replacement storage vessel shall be equal to the remaining warranty period of the original storage vessel that was supplied.
  • Page 14: Exclusions

    (assemblies or parts of) storage vessels supplied for replacement, other than the warranty expressly set out in these conditions. Under the terms of the supplied warranty, Lochinvar Ltd is not liable for damage to persons or property caused by (assemblies or parts, or the glass-lined steel tank of) a (replacement) storage vessel that it has supplied.
  • Page 16 Lochinvar Ltd reserves the right to change 7 Lombard Way, The MXL Centre, Banbury, Oxon, OX16 4TJ specifications without prior notice Tel: +44(0) 1295 269 981, Fax:+44(0) 1295 271 640, Email: info@lochinvar.ltd.uk www.lochinvar.ltd.uk...
