Simoco SRM9030 plus Brief User's Manual

DISPLAY ICON DETAILS
Rotating arrow icon. Indicates that the radio is in Scan, Vote
PMR or MultiAx Mode. It will disappear when the radio is locked
on a channel.
Rotating arrow icon. Indicates that the radio is registering
TRUNK with the Trunk Network. It will disappear when the radio is in-
service.
The solid speaker icon indicates that speaker audio is enabled, e.g.
during a Call.
Indicates a signal is present and the radio is muted. This could be
another user group, for instance.
Envelope Icon. Indicates there are one or more stored calls.
The Chevron. Shown against a function to show that it is turned ON
►
This symbol indicates whether the radio has been "CALLED" or if it is in
the "ON-CALL" state. (PMR only).
This icon indicates Call Pending, i.e. there is an outgoing call waiting for
*
the radio to be In-Service. (TRUNK only).
Do NOT operate your mobile radio, without a hands-free kit,
whilst driving a vehicle.
Do NOT operate your radio in an explosive atmosphere –
unless the radio's level of IECEx approval is approved for
use in that atmosphere.
Obey the 'Turn Off Two-way Radios' signs where these are
posted, e.g. on a petrol station forecourt.
Do NOT touch the antenna while the radio is transmitting.
Do NOT operate the radio if the antenna has become
disconnected or damaged.
Simoco is committed to continuous improvement, for this reason,
specifications may vary without prior notice.
WARNINGS
4
© SIMOCO 2013
plus
SRM9030
Simoco Group, Field House, Uttoxeter Old Road, Derby DE1 1NH
Tel: +44 (0) 1332 375500. Fax: +44 (0) 1332 375501. www.simocogroup.com.
TNM-U-E-0087, ISSUE 5.0
BRIEF USER GUIDE
