Icom IC-M502 Service Manual page 24

6-2 HM-126
[MAIN UNIT]
REF ORDER
NO. NO.
R1 7010006890 RESISTOR
R2 7010006880 RESISTOR
R3 7010006900 RESISTOR
R4 7010006910 RESISTOR
R5 7070000860 RESISTOR
C1 4010000460 CERAMIC
J1 6510003550 CONNECTOR
MC1 7700001600 MICROPHONE
S1 2260000980 SWITCH
S2 2260000080 SWITCH
S3 2260000080 SWITCH
S4 2260000080 SWITCH
SP1 2510000930 SPEAKER
EP1 0910052553 PCB
EP2 9029701901 TUBE
DESCRIPTION
R20J 12 kΩ
R20J 6.8 kΩ
R20J 15 kΩ
R20J 33 kΩ
ERG2SJ 150
DD104 B 471K 50V
S07B-EH-S
KUC2123-030245
SKHHLP014A
SKHHAM024A
SKHHAM024A
SKHHAM024A
SU-36W08040C
B 5431C
IRRAX 0.7 (d) L=4 mm
6-3 HM-127
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1140009280 S.IC
IC2 1110001810 S.IC
IC3 1110004490 S.IC
IC4 1120002830 S.IC
IC5 1180000420 S.IC
IC6 1180001250 S.IC
IC7 1110004710 S.IC
IC8 1130007420 S.IC
IC9 1130006220 S.IC
Q1 1560000810 S.FET
Q2 1520000460 S.TRANSISTOR
Q3 1530002850 S.TRANSISTOR
Q4 1590001390 S.FET
Q5 1590000430 S.TRANSISTOR
Q6 1590000980 S.TRANSISTOR
Q9 1560000810 S.FET
Q10 1530002060 S.TRANSISTOR
Q11 1510000510 S.TRANSISTOR
Q12 1530002850 S.TRANSISTOR
D1 1750000130 S.DIODE
D2 1160000060 S.DIODE
D3 1750000550 S.DIODE
X1 6060000750 S.CERAMIC
R1 7030000270 S.RESISTOR
R2 7030000270 S.RESISTOR
R3 7030000280 S.RESISTOR
R6 7030003560 S.RESISTOR
R7 7030003560 S.RESISTOR
R8 7030003560 S.RESISTOR
R9 7030003560 S.RESISTOR
R10 7030003680 S.RESISTOR
R11 7030003680 S.RESISTOR
R12 7030003680 S.RESISTOR
R13 7030003680 S.RESISTOR
R14 7030003680 S.RESISTOR
R15 7030003680 S.RESISTOR
R16 7030003680 S.RESISTOR
R17 7030003680 S.RESISTOR
R18 7030003680 S.RESISTOR
R19 7030003800 S.RESISTOR
R20 7030003540 S.RESISTOR
R21 7030003630 S.RESISTOR
R22 7030004120 S.RESISTOR
R23 7030003560 S.RESISTOR
R24 7030003450 S.RESISTOR
R25 7030003560 S.RESISTOR
R26 7510001150 S.THERMISTOR
R27 7030003560 S.RESISTOR
R28 7030004120 S.RESISTOR
R29 7030003560 S.RESISTOR
R30 7030003590 S.RESISTOR
R31 7030003560 S.RESISTOR
R32 7030004120 S.RESISTOR
R33 7030003560 S.RESISTOR
R34 7030003440 S.RESISTOR
R35 7030003440 S.RESISTOR
R36 7030003560 S.RESISTOR
R37 7030003600 S.RESISTOR
R38 7030003580 S.RESISTOR
R39 7030003680 S.RESISTOR
R40 7030003760 S.RESISTOR
R41 7030003680 S.RESISTOR
R42 7030003570 S.RESISTOR
R43 7030003490 S.RESISTOR
R44 7030003680 S.RESISTOR
R45 7030003680 S.RESISTOR
R46 7030003620 S.RESISTOR
R47 7030003760 S.RESISTOR
R50 7030003680 S.RESISTOR
R51 7030003610 S.RESISTOR
R52 7030003630 S.RESISTOR
R53 7030003680 S.RESISTOR
6 - 7
DESCRIPTION
µPD78F9418AGK-9EU
TA7368F (TP1)
M62429FP 700C
NJM2125F-TE1
TA78L05F (TE12R)
TA7808F (TE16L)
S-80928ANMP-DDR-T2
TC7W14FU (TE12L)
TC4W53FU (TE12L)
2SK1069-4-TL
2SB1132 T100 R
2SC4116-BL (TE85R)
2SJ144-Y (TE85R)
DTC144EUA T106
DTB123EK T147
2SK1069-4-TL
2SC4081 T107 R
2SA1576A T106R
2SC4116-BL (TE85R)
DA204U T107
DAN202U T107
1SS355 TE-17
CSTCC4.91MG
MCR10EZHJ 120 Ω (121)
MCR10EZHJ 120 Ω (121)
MCR10EZHJ 150 Ω (151)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
NTCCM1608 4BH 103KC
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 203 V (20 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
S.=Surface mount
