[VOL UNIT]

REF ORDER
NO. NO.
R1 7210003080 VARIABLE
J1 6510009470 CONNECTOR
W1 8900009860 CABLE
EP1 0910053363 PCB

[SQL UNIT]

REF ORDER
NO. NO.
R1 7210002360 VARIABLE
W1 8900009870 CABLE
EP1 0910053372 PCB

[DIAL UNIT]

REF ORDER
NO. NO.
S1 2250000220 ENCODER
EP1 0910053382 PCB
CTRL UNIT]
REF ORDER
NO. NO.
IC1 1130005640 S.IC
D4 1730002360 S.ZENER
R1 7030003680 S.RESISTOR
R2 7030003680 S.RESISTOR
R3 7030003800 S.RESISTOR
R4 7030003800 S.RESISTOR
R5 7030003800 S.RESISTOR
R6 7030003680 S.RESISTOR
C7 4030006900 S.CERAMIC
C9 4030006900 S.CERAMIC
C10 4510004630 S.ELECTROLYTIC
C11 4030012600 S.CERAMIC
C12 4030012600 S.CERAMIC
C13 4030012600 S.CERAMIC
C14 4030006900 S.CERAMIC
C15 4030006900 S.CERAMIC
J1 6510022440 CONNECTOR
J2 6510022020 S.CONNECTOR
EP1 0910052823 PCB
DESCRIPTION
TP96N97-15F-10KA-2345
S3B-ZR
OPC-970
B 5428C
DESCRIPTION
TP96N97-15F-10KB-1301
OPC-971
B 5429B
DESCRIPTION
TP90N937E20-15F-1540
B 5430B
DESCRIPTION
TC4W53F (TE12L)
MA8062-M (TX)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
ECEV1CA100SR
C2012 JB 1A 105M-T-A
C2012 JB 1A 105M-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
LTW-8MP-C
14FLT-SM1-TB
B 5471C
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1110003200 S.IC
IC2 1130007610 S.IC
IC3 1150001540 IC
IC4 1110003750 S.IC
IC5 1110003650 S.IC
IC6 1130007420 S.IC
IC8 1110002030 IC
IC9 1180001070 S.IC
IC10 1130007690 S.IC
IC11 1110003750 S.IC
IC12 1130007690 S.IC
IC13 1110003750 S.IC
IC14 1110003090 IC
IC15 1110004710 S.IC
IC16 1140009270 S.IC
IC17 1140008650 S.IC
IC18 1130007420 S.IC
IC19 1170000280 S.IC
IC20 1120002830 S.IC
IC21 1120002830 S.IC
Q2 1580000700 S.FET
Q3 1580000490 S.FET
Q4 1530002360 S.TRANSISTOR
Q5 1530002600 S.TRANSISTOR
Q6 1560000540 S.FET
Q7 1560000330 S.FET
Q8 1560000330 S.FET
Q9 1530002600 S.TRANSISTOR
Q10 1530002600 S.TRANSISTOR
Q11 1530002240 S.TRANSISTOR
Q12 1530002340 S.TRANSISTOR
Q14 1520000380 TRANSISTOR
Q15 1590000430 S.TRANSISTOR
Q16 1590000670 S.TRANSISTOR
Q17 1590000430 S.TRANSISTOR
Q18 1530002850 S.TRANSISTOR
Q20 1520000460 S.TRANSISTOR
Q21 1590000430 S.TRANSISTOR
Q22 1520000460 S.TRANSISTOR
Q23 1590000430 S.TRANSISTOR
Q24 1530002850 S.TRANSISTOR
Q25 1530002850 S.TRANSISTOR
Q26 1590001390 S.FET
Q27 1590001390 S.FET
Q28 1560000810 S.FET
Q29 1590000430 S.TRANSISTOR
Q30 1530002850 S.TRANSISTOR
Q31 1590000430 S.TRANSISTOR
Q32 1530002850 S.TRANSISTOR
Q33 1560000810 S.FET
Q34 1590000720 S.TRANSISTOR
Q35 1590000720 S.TRANSISTOR
Q36 1590000660 S.TRANSISTOR
Q37 1590000660 S.TRANSISTOR
Q38 1530002060 S.TRANSISTOR
Q39 1510000510 S.TRANSISTOR
Q40 1560000810 S.FET
Q41 1590000720 S.TRANSISTOR
Q42 1590000720 S.TRANSISTOR
Q44 1530002850 S.TRANSISTOR
Q45 1530002850 S.TRANSISTOR
Q46 1590001390 S.FET
Q47 1530002550 S.TRANSISTOR
D1 1720000260 S.VARICAP
D2 1720000260 S.VARICAP
D3 1720000260 S.VARICAP
D4 1720000260 S.VARICAP
D5 1790001330 S.ZENER
D6 1790000640 S.VARICAP
D7 1790000640 S.VARICAP
D8 1790000640 S.VARICAP
D9 1790000640 S.VARICAP
D10 1790000640 S.VARICAP
D11 1790000620 S.DIODE
D12 1790000620 S.DIODE
D13 1750000550 S.DIODE
D14 1790000690 S.DIODE
D15 1790000690 S.DIODE
6 - 2
DESCRIPTION
TA31136FN (EL)
µPD3140GS-E1 (DS8)
M57710-A/SC-1302
M5218AFP 600C
NJM2211M-TE1
TC7W14FU (TE12L)
TA7808S
TA7805F (TE16L)
BU4066BCF-T1
M5218AFP 600C
BU4066BCF-T1
M5218AFP 600C
LA4425A
S-80928ANMP-DDR-T2
MB90F583BPFV-G
HN58X2464TI
TC7W14FU (TE12L)
TLP121 (GB-TPL)
NJM2125F-TE1
NJM2125F-TE1
3SK292 (TE85R)
3SK166A-2-T7
2SC2714-Y (TE85R)
2SC4215-O (TE85R)
2SK880-Y (TE85R)
2SK210-GR (TE85R)
2SK210-GR (TE85R)
2SC4215-O (TE85R)
2SC4215-O (TE85R)
2SC3775-3-TB
2SC2954-T2B
2SB1143 S
DTC144EUA T106
FMW1 T148
DTC144EUA T106
2SC4116-BL (TE85R)
2SB1132 T100 R
DTC144EUA T106
2SB1132 T100 R
DTC144EUA T106
2SC4116-BL (TE85R)
2SC4116-BL (TE85R)
2SJ144-Y (TE85R)
2SJ144-Y (TE85R)
2SK1069-4-TL
DTC144EUA T106
2SC4116-BL (TE85R)
DTC144EUA T106
2SC4116-BL (TE85R)
2SK1069-4-TL
DTA144EUA T106
DTA144EUA T106
DTC144TU T107
DTC144TU T107
2SC4081 T107 R
2SA1576A T106R
2SK1069-4-TL
DTA144EUA T106
DTA144EUA T106
2SC4116-BL (TE85R)
2SC4116-BL (TE85R)
2SJ144-Y (TE85R)
2SC3326-B (TE85R)
1SV214 (TPH2)
1SV214 (TPH2)
1SV214 (TPH2)
1SV214 (TPH2)
MA8036-L (TX)
MA363B (TX)
MA363B (TX)
MA363B (TX)
MA363B (TX)
MA363B (TX)
MA77 (TX)
MA77 (TX)
1SS355 TE-17
HSM88ASR-TR
HSM88ASR-TR
S.=Surface mount
