Icom IC-M502 Service Manual page 23

[MAIN UNIT]
REF ORDER
NO. NO.
C206 4030007090 S.CERAMIC
C207 4030006860 S.CERAMIC
C208 4030006850 S.CERAMIC
C209 4030006900 S.CERAMIC
C210 4030006850 S.CERAMIC
C212 4030011810 S.CERAMIC
C213 4030007090 S.CERAMIC
C214 4030008900 S.CERAMIC
C215 4030006850 S.CERAMIC
C217 4030006900 S.CERAMIC
C218 4030011600 S.CERAMIC
C219 4030011600 S.CERAMIC
C222 4030011600 S.CERAMIC
C223 4030011600 S.CERAMIC
C224 4030007050 S.CERAMIC
C225 4030006860 S.CERAMIC
C226 4030010770 S.CERAMIC
C227 4030007120 S.CERAMIC
C228 4030008470 S.CERAMIC
C229 4030007090 S.CERAMIC
C231 4030006900 S.CERAMIC
C232 4510004630 S.ELECTROLYTIC
C233 4030011600 S.CERAMIC
C234 4030006900 S.CERAMIC
C235 4510004630 S.ELECTROLYTIC
C236 4030011600 S.CERAMIC
C238 4030006900 S.CERAMIC
C239 4030012600 S.CERAMIC
C240 4030012600 S.CERAMIC
C241 4030006860 S.CERAMIC
C242 4030011600 S.CERAMIC
C243 4510004590 ELECTROLYTIC
C244 4510004590 ELECTROLYTIC
C245 4030011600 S.CERAMIC
C246 4030011810 S.CERAMIC
C248 4030008890 S.CERAMIC
C249 4030007010 S.CERAMIC
C250 4030007070 S.CERAMIC
C251 4030009650 S.CERAMIC
C252 4030009650 S.CERAMIC
C253 4030011600 S.CERAMIC
C254 4030006900 S.CERAMIC
C255 4030011600 S.CERAMIC
C256 4510004630 S.ELECTROLYTIC
C257 4030011600 S.CERAMIC
C258 4030011600 S.CERAMIC
C259 4030011600 S.CERAMIC
C262 4030011600 S.CERAMIC
C263 4030006880 S.CERAMIC
C274 4030006860 S.CERAMIC
C275 4030006860 S.CERAMIC
C276 4030006860 S.CERAMIC
C278 4030006860 S.CERAMIC
C279 4030006860 S.CERAMIC
C282 4030011600 S.CERAMIC
C283 4030006860 S.CERAMIC
C284 4030009510 S.CERAMIC
C285 4030006860 S.CERAMIC
C286 4030011600 S.CERAMIC
C287 4030006980 S.CERAMIC
C288 4030009910 S.CERAMIC
C289 4030009530 S.CERAMIC
C290 4030009500 S.CERAMIC
C291 4030009500 S.CERAMIC
C292 4550006130 S.TANTALUM
C293 4030011600 S.CERAMIC
C294 4550006560 S.TANTALUM
C295 4550006810 S.TANTALUM
C296 4550006810 S.TANTALUM
C297 4030009510 S.CERAMIC
C298 4030009520 S.CERAMIC
C299 4030009910 S.CERAMIC
C300 4030006860 S.CERAMIC
C301 4030011600 S.CERAMIC
C302 4030009560 S.CERAMIC
C303 4030006860 S.CERAMIC
C304 4030011810 S.CERAMIC
C305 4030011810 S.CERAMIC
C306 4030011600 S.CERAMIC
C307 4030011810 S.CERAMIC
C308 4030011600 S.CERAMIC
C309 4030011810 S.CERAMIC
DESCRIPTION
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1A 224K-T-N
C1608 CH 1H 470J-T-A
C1608 JB 1C 333K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 CH 1H 220J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 392K-T-A
C1608 CH 1H 820J-T-A
C1608 JB 1H 272K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1E 103K-T-A
ECEV1CA100SR
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
ECEV1CA100SR
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C2012 JB 1A 105M-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
16 MV 470 HC
16 MV 470 HC
C1608 JB 1C 104KT-N
C1608 JB 1A 224K-T-N
C1608 JB 1C 273K-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 330J-T-A
C1608 CH 1H 240J-T-A
C1608 CH 1H 240J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
ECEV1CA100SR
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 CH 1H 010B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 070D-T-A
C1608 CH 1H 040B-T-A
C1608 CH 1H 030B-T-A
C1608 CH 1H 0R5B-T-A
C1608 CH 1H 0R5B-T-A
ECST1VY224R
C1608 JB 1C 104KT-N
ECST1CY225R
ECST1VY473R
ECST1VY473R
C1608 CH 1H 010B-T-A
C1608 CH 1H 020B-T-A
C1608 CH 1H 040B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H R75B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1A 224K-T-N
C1608 JB 1A 224K-T-N
C1608 JB 1C 104KT-N
C1608 JB 1A 224K-T-N
C1608 JB 1C 104KT-N
C1608 JB 1A 224K-T-N
[MAIN UNIT]
REF ORDER
NO. NO.
C312 4030006900 S.CERAMIC
C314 4550006700 S.TANTALUM
C315 4030006860 S.CERAMIC
C316 4030006860 S.CERAMIC
C317 4550006700 S.TANTALUM
C318 4550006700 S.TANTALUM
C319 4030011600 S.CERAMIC
C321 4030007090 S.CERAMIC
C326 4030006900 S.CERAMIC
C327 4030006860 S.CERAMIC
C328 4030011600 S.CERAMIC
C330 4030006860 S.CERAMIC
C331 4030006900 S.CERAMIC
C332 4030009510 S.CERAMIC
C333 4030012600 S.CERAMIC
C334 4030011600 S.CERAMIC
C335 4030006900 S.CERAMIC
C337 4510004630 S.ELECTROLYTIC
RL1 6330001620 RELAY
RL2 6330001620 RELAY
J1 6510021300 S.CONNECTOR
J2 6510018960 S.CONNECTOR
J3 6510022020 S.CONNECTOR
J4 6510022020 S.CONNECTOR
J6 6510016430 S.CONNECTOR
J7 6510018920 S.CONNECTOR
J8 6510018960 S.CONNECTOR
W1 8900010210 CABLE
W5 7030003860 S.JUMPER
W6 7030003860 S.JUMPER
EP1 0910053352 PCB
[PWR-CORD UNIT]
REF ORDER
NO. NO.
C1 4030006860 S.CERAMIC
C2 4030006860 S.CERAMIC
J1 6510003130 CONNECTOR
EP1 0910053340 PCB
6 - 6
DESCRIPTION
C1608 JB 1E 103K-T-A
ECST1AY106R
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
ECST1AY106R
ECST1AY106R
C1608 JB 1C 104KT-N
C1608 CH 1H 470J-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 010B-T-A
C2012 JB 1A 105M-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
ECEV1CA100SR
FTR-F3AA012E
FTR-F3AA012E
52365-1091
B2B-PH-SM3-TB
14FLT-SM1-TB
14FLT-SM1-TB
53307-1491
B8B-PH-SM3-TB
B2B-PH-SM3-TB
OPC-1026
ERJ3GE JPW V
ERJ3GE JPW V
B 5545B
DESCRIPTION
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
SB4P-HVQ-22
B 5559
S.=Surface mount
