PRESTIGIO NOBILE 1560
TECHNICAL SERVICE
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOBILE 1560 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prestigio NOBILE 1560

Summary of Contents for Prestigio NOBILE 1560

  • Page 1 PRESTIGIO NOBILE 1560 TECHNICAL SERVICE MANUAL...

  • Page 2: Revision History

    Revision History Please refer to the table below for the updates made on Prestigio Nobile 1560 service guide. Date Chapter Updates...
  • Page 3 Copyright Copyright © 2004 by Prestigio Technologies Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Prestigio Technologies Ltd.
  • Page 4 Conventions The following conventions are used in this manual: Denotes actual messages that Screen messages appear on screen. NOTE Gives bits and pieces of additional information related to the current topic. WARNING Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 5 Preface Before using this information and the product it supports, please read the following general information. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION decided for our "global" product offering. To better fit local market requirements and enhance product competitiveness, your regional office MAY have decided to extend the functionality of a machine (e.g.

  • Page 7: Table Of Contents

    Chapter 1 System Specifications Features............1 System Block Diagram .
  • Page 8 FRU (Field Replaceable Unit) List Prestigio Nobile 1560 Exploded Diagram ......96...

  • Page 9: System Specifications

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL System Specifications Features This computer was designed with the user in mind. Here are just a few of its many features: Performance Intel Dothan processor 15.0-inch TFT (Thin Film Transistor) LCD at 1024 x 768 XGA (eXtended Graphics Array) resolution, all displaying in 32-bit color depth.
  • Page 10 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 One RJ45 jack for Ethernet One RJ11 56Kbps fax / modem One DC-in jack for AC adapter One Speaker / Headphone-out jack (SPDIF) One Microphone-in / Line-in jack Three USB 2.0 ports One S-Video output port...

  • Page 11: System Block Diagram

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL System Block Diagram CLK GEN. CLK GEN. Thermal Sensor Thermal Sensor Cypress 28411ZC-1 Mobile CPU G792 Cypress 28411ZC-1 Mobile CPU G792 / IDT CV125 Dothan (one Fan for CPU) / IDT CV125 Dothan (one Fan for CPU)

  • Page 12: Board Layout

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Board Layout Top View PCB 04203-SD Line-in connector Micro OZ168T audio DJ controller Line-out connector Mini PCI connector USB connector Fan connector USB connector CD-ROM connector IEEE 1394 connector Touch pad connector LCD cable connector...

  • Page 13: Bottom View

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Bottom View North bridge Alviso-GM Express card slot connector MODEM MDC Power connector UltraMedia PCI7411 Lancom LF-H80P Transformer Battery connector Modem connector Memory connector ALC655 Audio Codec controller Memory connector...

  • Page 14: Outlook View

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Outlook View Front View Number Item Description Display cover latch Slide to the right to unlatch the display cover Optical drive Accepts a CD or DVD LED indicator Lights up when the optical is active...

  • Page 15: Top View

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Top View Number Icon Item Description Display screen Also called LCD (liquid-crystal display), displays computer output. Status indicators LEDs (light-emitting diode) that turn on and off to show the status of the computer, its functions and components.
  • Page 16 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Number Icon Item Description Click buttons (left and right) The left and right buttons function like the left and right mouse buttons. Palm rest Comfortable support area for your hands when you use the computer.

  • Page 17: Left Panel

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Left Panel Number Icon Item Description Volume control Adjusts the volume. 4-in1 card slot Accepts a Secure Digital (SD), Memory Stick (MS), xD- Picture Card (xD) or MultiMediaCard (MMC) memory card. Express card slot Accepts one ExpressCard/34 or one Express/54 module.

  • Page 18: Right Panel

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Right Panel Number Icon Item Description Security keylock Connects to a Kensington-compatible computer security lock.

  • Page 19: Rear Panel

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Rear Panel Number Icon Item Description DC-in jack Connects to an AC adapter. S-video out port Connects to a television or display device with S- video input. External monitor port Connects to a display monitor (up to 2048x1536 resolution).

  • Page 20: Bottom Panel

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Bottom Panel Number Icon Item Description Memory compartment Houses the computer’s main memory modules. Hard disk bay Houses the computer’s hard disk. Battery bay Houses the computer’s battery pack. Battery release latch Unlatches the battery to remove it.

  • Page 21: Indicators

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Indicators The computer has seven easy-to-read status icons on the bottom of the display screen. The Power and Standby indicators are visible even when you close the display cover so you can see the status of the computer while the cover is closed.

  • Page 22: Lock Keys

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Lock Keys The keyboard has three lock keys which you can toggle on and off. Lock Key Description Caps Lock When Caps Lock is on, all alphabetic characters typed are in uppercase. Num Lock When Num Lock is on, the embedded keypad is in numeric mode.

  • Page 23: Embedded Numeric Keypad

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Embedded Numeric Keypad The embedded numeric keypad functions like a desktop numeric keypad. It is indicated by small characters located on the upper right corner of the keycaps. To simplify the keyboard legend, cursor-control key symbols are not printed on the keys.

  • Page 24: Windows Keys

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Windows Keys The keyboard has two keys that perform Windows-specific functions. Icon Description Windows logo key Start button. Combinations with this key perform shortcut functions. Below are a few examples: Windows + Tab (Activates next task bar button)

  • Page 25: Hot Keys

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Hot Keys The computer employs hot keys or key combinations to access most of the computer’s controls like screen contrast and brightness, volume output and the BIOS Utility. To activate hot keys, press and hold the Fn key before pressing the other key in the hot key combination.

  • Page 26: Launch Keys

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Launch Keys Located on the left of the keyboard are five buttons. These buttons are called launch keys. They are designated as Wireless Communication, E-mail, Internet Browser, P1 and P2 buttons. Number Icon Function...

  • Page 27: Hardware Specifications And Configurations

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Hardware Specifications and Configurations Processor Item Specification CPU type Intel Dothan 1.6GHz to 2.0GHz processor with 2MB L2 on-die Cache up to FSB 533 / 400MHz CPU package Micro-FCPGA package CPU core voltage 1.05V CPU I/O voltage 1.05V...
  • Page 28 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 LAN Interface Item Specification Chipset Realtek RTL8100C Supports LAN protocol 10/100 Base T Ethernet / Giga Lan (option) LAN connector type RJ45 LAN connector location Rear side Modem Interface Item Specification Chipset Ambit MDC module with Lucent modem controller Fax modem data baud rate (bps) 14.4K...
  • Page 29 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Combo Interface Item Specification Vendor & model name Panasonic 24X UJDA750WS-A Rotational speed CD-ROM read: 5,413 rpm (24X, 1.3m/s) DVD-ROM read: 4,597 rpm (8X, single layer) CD-R Write: 5,200 rpm (Max.) US-RW Write: 5,200 rpm (Max.)
  • Page 30 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Super-Multi Interface Item Specification Applicable disc format CD: CD-DA, CD-ROM, CD-R/W, CD-R, CD-ROMXA, PhotoCD (muiltiSession), Video CD, CD-Extra(CD+), CD-text DVD: DVD-VIDEO, DVD-ROM, DVD-R (3.9GB, 4.7GB), DVD-RW (Ver.1.1), DVD-RAM, DVD+R, DVD+RW Loading mechanism Soft eject (with emergency eject hole)
  • Page 31 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Video Resolutions Mode 8 bits 16 bits 24 bits 32 bits Resolution (256 colors) (High color) (True color) (True color) 640x480 720x480 800x600 848x480 1024x768 (Maximum for: 15.0” TFT XGA, External CRT) 1152x864 1280x1024...
  • Page 32 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 PCMCIA Port Item Specification PCMCIA controller TI PCI7411 Supports card type Type-II Number of slots One Type-II Access location Left side Supports ZV (Zoomed Video) port No ZV support Supports 32 bit CardBus Yes (IRQ11)
  • Page 33 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL DC-AC LCD Inverter Item Specification Vendor & model name Sumida 15" TWS-058-029 Input voltage (V) 12 (typ.) Input current (mA) 310(min.) 360(typ.) 410(max.) Output voltage (Vrms, no load) 1600(min.) Output voltage frequency (kHz) 47(min.) 52(typ.)
  • Page 34 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 AC Adapter Item Specification Vendor & model name Liteon 70W 19V CCC PA-1700-02AB Input Requirements Maximum input current (A, @90Vac, 1.6 A @ 90Vac full load) @ 180Vac Nominal frequency (Hz) 47 - 63...
  • Page 35 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Power Management Power Saving Mode Phenomenon Standby Mode The Sleep indicator lights up Waiting time specified by the System Standby value or the operating system elapses without any system activity. When the computer is about to enter Hibernation mode (e.g., during a battery-low...
  • Page 36 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Mechanical Specification Item Specification Dimensions 330 (W) x 280 (D) x 34-54 (H) mm for 15.0” TFT Weight Less than 6.027 lbs for 15.0” TFT model I/O Ports Three USB ports, One Type II PCMCIA slot, One RJ-11 modem port, One RJ-45...
  • Page 37 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Memory Address Map Memory Address Size Function F6C00000-FABFFFFF Intel(R) 82801FB/FBM PCI Express Root Port -2660 FAC00000-FEBFFFFF Intel(R) 82801FB/FBM PCI Express Root Port -2660 FED20000-FED8FFFF 448K Motherboard Resources FF800000-FFFFFFFF Intel(R) 82802 Firmware Hub Device I/O Address Map...
  • Page 38 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 I/O Address Map I/O Address Function 000001F0-000001F7 Primary IDE channel 00000274-00000277 ISAPNP read data port 00000279-00000279 ISAPNP read data port 00000376-00000376 Secondary IDE channel 000003B0-000003BB Mobile Intel(R) 915GM/GMS, 910GML Express Chipset Family 000003C0-000003DF Mobile Intel(R) 915GM/GMS, 910GML Express Chipset Family...
  • Page 39 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL System IRQ Assignment Map Interrupt Channel Function IRQ19 Intel(R) 82801FB/FBM USB Universal Host Controller -265B IRQ20 Intel(R) PRO/Wireless 2200BG Network Connection IRQ20 Realtek RTL8139/810x Family Fast Ethernet NIC IRQ21 Agere Systems AC’97 Modem #2...
  • Page 40 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560...

  • Page 41: System Utilities

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL System Utilities BIOS Setup Utility The BIOS Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/ Output System). Your computer is already properly configured and optimized, and you do not need to run this utility. However, if you encounter configuration problems, you may need to run Setup.

  • Page 42: System Information

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 System Information The System Information screen displays a summary of your computer hardware information. PhoenixBIOS Setup Utility Information Main Advanced Security Boot Exit CPU Type Intel® Pentium® M processor 1.60GHZ CPU Speed 1600MHz System Memory...

  • Page 43: Main System Settings

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Main System Settings The Main System Settings screen allows you to set the system date and time. PhoenixBIOS Setup Utility Information Main Advanced Security Boot Exit System Time: [xx:xx:xx] Item Specific Help [xx/xx/xxxx] System Date:...

  • Page 44: Advanced Information

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Advanced Information The Advanced Information screen contains parameter values that define how your computer behaves on system startup. P hoenixB IO S Setup U tility Inform ation M ain Security B oot E xit...

  • Page 45: Primary Master

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Primary Master The Primary Master sub-menu contains parameters related to the primary hard disk. CAUTION: The parameters in this screen are for the advanced users only. Typically, you do not need to change the values in this screen. The default setting of Auto optimizes all the settings for your hard disk.

  • Page 46: Secondary Master

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Secondary Master The Secondary Master sub-menu contains parameters related to the Media bay drive. CAUTION: The parameters in this screen are for the advanced users only. Typically, you do not need to change the values in this screen. The default setting of Auto optimizes all the settings for your Media bay drive.

  • Page 47: System Security

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL System Security The System Security screen contains parameters that help safeguard and protect your computer from unauthorized use. P h o e n i x B I O S S e t u p U t i l i t y...
  • Page 48 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Setting a Password Follow these steps: Use the cursor keys to highlight a Password parameter (Supervisor Password, User Password, or Primary Hard Disk Password) and press the key. The password box appears as below if choosing...
  • Page 49 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Removing a Password Should you want to remove a password, do the following: Use the cursor up/ down keys to highlight a password parameter (Setup, User or Hard Disk) and press the key. The password box appears.
  • Page 50 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Press . Retype the password to verify your first entry and press Press to return to the main menu. Press . The following dialogue box appears. Setup C onfirm ation Setup C onfirm ation...

  • Page 51: Boot Options

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Boot Options Users can press F12 during POST to enter the Boot Options Menu. In this menu users can change boot device without entering BIOS SETUP utility. PhoenixBIOS Setup Utility Information Main Advanced Security...

  • Page 52: Exit Setup

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Exit Setup This menu contains exit options. PhoenixBIOS Setup Utility Information Main Advanced Security Boot Exit Exit Saving Changes Item Specific Help Exit Discarding Changes Load Setup Defaults Discard Changes Exit System Setup and...

  • Page 53: Bios Flash Utility

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL BIOS Flash Utility The BIOS flash memory update is required for the following conditions: New versions of system programs New features or options Executing Flash Program Create a bootable disk. Unzip the flash file, and save the three files (.bat, .exe, .wph) to the bootable disk.
  • Page 54 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560...

  • Page 55: Machine Disassembly And Replacement

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Machine Disassembly and Replacement This chapter contains step-by-step procedures on how to disassemble the notebook computer for maintenance and troubleshooting. To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge...

  • Page 56: General Information

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 General Information Before You Begin Before proceeding with the disassembly procedure, make sure that you do the following: Turn off the power to the system and all peripherals. Unplug the AC adapter and all power and signal cables from the system.

  • Page 57: Disassembly Procedure Flowchart

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Disassembly Procedure Flowchart The flowchart on the succeeding page gives you a graphic representation on the entire disassembly sequence and instructs you on the components that need to be removed during servicing. For example, if you want to remove the main board, you must first remove the keyboard, then disassemble the inside assembly frame in that order.
  • Page 58 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 LCD Module LCD Module J x 5 J x 5 J x 5 LCD Bezel LCD Bezel LCD Bezel J x 1 J x 1 J x 1 Inverter Board Inverter Board Inverter Board...

  • Page 59: Removing The Battery

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Removing the Battery Unlock the battery release button. Push the other battery release button in the arrow direction and lift up the battery out from the main unit. Remove the battery from the system.

  • Page 60: Removing The Hard Disk Drive Module

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Removing the Hard Disk Drive Module See “Removing the Battery” on page 51 Release the one screw on the hard disk drive cover, and then remove the hard disk drive cover. Step Size (Quantity)

  • Page 61: Removing The External Dimm Module

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Removing the External DIMM Module See “Removing the Battery” on page 51 Remove the four screws on the DIMM cover, then push the DIMM cover forward to remove it from the lower case. Step...

  • Page 62: Removing The Optical Disk Drive Module

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Removing the Optical Disk Drive Module See “Removing the Battery” on page 51 Remove the one screw on the bottom of the unit and pull gently to detach the optical drive module from the main unit .

  • Page 63: Disassembling The Main Unit

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Disassembling the Main Unit Remove the SD Dummy Card See “Removing the Battery” on page 51 Pull the SD dummy card to remove it from the unit. Remove the PCMCIA Dummy Card See “Removing the Battery” on page 51 Push the push bar twice to release the PCMCIA dummy card.

  • Page 64: Removing The Power Board

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Step Size (Quantity) Color Torque M2.5 x L8 (2) Black 3 kgf-cm Detach the middle cover by using the plastic flat screwdriver gently and turn it over. Disconnect the power cable, audio DJ cable, and speaker cable from the main board as shown.

  • Page 65: Removing The Speaker Bracket

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Step Size (Quantity) Color Torque M2 x L3 (2) Black 1.6 kgf-cm Removing the Speaker Bracket See “Removing the Battery” on page 51 See “Removing the Middle Cover” on page 55 Remove the two screws and detach the speaker bracket from the middle cover.

  • Page 66: Removing The Keyboard

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Step Size (Quantity) Color Torque M2 x L3 (1) Black 1.6 kgf-cm Disconnect the audio DJ cable from the audio DJ board. Removing the Keyboard See “Removing the Battery” on page 51 See “Removing the Middle Cover” on page 55 Lift the keyboard up, turn it over and put it on the upper case.

  • Page 67: Removing The Rtc Battery

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL See “Removing the Middle Cover” on page 55 See “Removing the Keyboard” on page 58 to lift up the keyboard, turn it over and put it on the upper case. Disconnect the two RF cables from the sockets on the wireless LAN board.
  • Page 68 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 NOTE: When reassembling, please arrange the inverter cable well as shown. Remove the two screws, disconnect the LCD coaxial cable from the main board, and release the cable from the latch as shown. Step...
  • Page 69 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Step Size (Quantity) Color Torque M2.5 x L5 (2) Silver 3 kgf-cm M2.5 x L8 (2) Black 3 kgf-cm Detach the antennas and release the RF cables from the latches. NOTE: When reassembling, please arrange the RF cables well as shown.

  • Page 70: Removing The Thermal Module

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Removing the Thermal Module See “Removing the Battery” on page 51 See “Removing the Middle Cover” on page 55 See “Removing the Keyboard” on page 58 to lift up the keyboard, turn it over and put it on the upper case.

  • Page 71: Removing The Fan

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Release the CPU socket by turning the screw counterclockwise using a flat screwdriver. Then remove the CPU. NOTE: After removing the CPU, use a flat screwdriver to lock the CPU socket well by securing the screw clockwise.

  • Page 72: Removing The Upper Case

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Removing the Upper Case See “Removing the Battery” on page 51 See “Removing the Hard Disk Drive Module” on page 52 See “Removing the External DIMM Module” on page 53 to remove the DIMM cover.
  • Page 73 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL 12. Remove the nine screws from the bottom of the main unit. Step Size (Quantity) Color Torque M2.5 x L6 (8) Black 3 kgf-cm M2 x L3 (1) Black 1.6 kgf-cm NOTE: When reassembling, please secure the screws in the sequence as shown above.

  • Page 74: Removing The Launch Board

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Removing the Launch Board See “Removing the Battery” on page 51 See “Disassembling the Hard Disk Drive Module” on page 52 See “Removing the External DIMM Module” on page 53 to remove the DIMM cover.

  • Page 75: Removing The Touch Pad Board

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL 10. See “Removing the Upper Case” on page 64 11. Remove the two screws as shown. Step Size (Quantity) Color Torque M2 x L3 (2) Black 1.6 kgf-cm 12. Disconnect the touch pad cable from the touch pad board and release the touch pad cable from the upper case.

  • Page 76: Removing The Microphone

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 See “Removing the Hard Disk Drive Module” on page 52 See “Removing the External DIMM Module” on page 53 to remove the DIMM cover. See “Removing the Optical Disk Drive Module” on page 54 See “Removing the Middle Cover”...

  • Page 77: Removing The Cover Switch Module

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Removing the Cover Switch Module See “Removing the Battery” on page 51 See “Removing the Hard Disk Drive Module” on page 52 See “Removing the External DIMM Module” on page 53 to remove the DIMM cover.

  • Page 78: Removing The Upper Case Plate

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Step Size (Quantity) Color Torque M2.5 x L5 (1) Silver 3 kgf-cm Removing the Upper Case Plate See “Removing the Battery” on page 51 See “Removing the Hard Disk Drive Module” on page 52 See “Removing the External DIMM Module”...

  • Page 79: Removing The Main Board

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Removing the Main Board See “Removing the Battery” on page 51 See “Removing the Hard Disk Drive Module” on page 52 See “Removing the External DIMM Module” on page 53 to remove the DIMM cover.
  • Page 80 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 See “Removing the LCD Module” on page 59 10. See “Removing the Thermal Module” on page 62 11. See “Removing the Upper Case” on page 64 12. See “Removing the CPU Thermal Plate” on page 69 13.

  • Page 81: Disassembling The 15" Tft Lcd Module

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Disassembling the 15î TFT LCD Module Removing the LCD Bezel See “Removing the Battery” on page 51 See “Removing the Middle Cover” on page 55 See “Removing the Keyboard” on page 58 See “Removing the Wireless LAN Board” on page 58 to disconnect the RF cables from the wireless LAN board.

  • Page 82: Removing The Inverter Board

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Removing the Inverter Board See “Removing the Battery” on page 51 See “Removing the Middle Cover” on page 55 See “Removing the Keyboard” on page 58 See “Removing the Wireless LAN Board” on page 58 to disconnect the RF cables from the wireless LAN board.
  • Page 83 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Step Size (Quantity) Color Torque M2.5 x L5 (4) Black 3 kgf-cm Remove the two screws on the LCD bracket. Step Size (Quantity) Color Torque M2 x L4 (2) Silver 1.6 kgf-cm 10. Remove the LCD with LCD brackets from the LCD panel carefully.

  • Page 84: Removing The Lcd Coaxial Cable

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Step Size (Quantity) Color Torque M2 x L3 (8) Black 1.6 kgf-cm Removing the LCD Coaxial Cable See “Removing the Battery” on page 51 See “Removing the Middle Cover” on page 55 See “Removing the Keyboard” on page 58 See “Removing the Wireless LAN Board”...

  • Page 85: Troubleshooting

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Troubleshooting Use the following procedure as a guide for computer problems. NOTE: The diagnostic tests are intended to test only our company’s products. Other brand’s products, prototype cards, or modified options can give false errors and invalid system responses.

  • Page 86: System Check Procedures

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 System Check Procedures Power System Check To verify the symptom of the problem, power on the computer using each of the following power sources: Remove the battery pack. Connect the power adapter and check that power is supplied.

  • Page 87: Touchpad Check

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL If the voltage is still less than 7.5 Vdc after recharging, replace the battery. To check the battery charge operation, use a discharged battery pack or a battery pack that has less than 50% of the total power remaining when installed in the computer.

  • Page 88: Phoenix Bios Error Code Messages

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Phoenix BIOS Error Code Messages The following are the list of messages that Phoenix BIOs can display. Most of them occur during POST. Some of them display information about a hardware device, e.g., and the amount of memory installed. Others may indicate a porblem with a device, such as the way it has been configured.
  • Page 89 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Error Codes Error Messages 0281 Memory Size found by POST differed from CMOS Memory size found by POST differed from CMOS 02B0 Diskette Drive Error 02B1 Diskette Drive B Error 02B2 Incorrect Drive A type - run Setup...
  • Page 90 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Error Codes Error Messages nnnn Cache SRAM Passed Where nnnn is the amount of shadow RAM in kilobytes successfully tested. nnnn KB Shadow RAM Passed Where nnnn is the amount of shadow RAM in shadow in kilobytes successfully tested.

  • Page 91: Power-On Self-Test (Post) Error Message

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Power-On Self-Test (POST) Error Message The POST error message index lists the error message and their possible causes. The most likely cause is listed first. NOTE: Perform the FRU replacement or actions in the sequence shown in FRU/Action column, if the FRU replacement does not solve the problem, put the original part back in the computer.
  • Page 92 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Error Message List Error Messages FRU/Action in Sequence Memory size found by POST differed from Run “Load Default Settings” in BIOS Setup Utility. CMOS DIMM Main Board Diskette drive A error Check the drive is defined with the proper diskette type in BIOS...

  • Page 93: Index Of Symptom-To-Fru Error Message

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Index of Symptom-to-FRU Error Message Error Message List No beep Error Messages FRU/Action in Sequence No beep, power-on indicator turns off and LCD is Power source (battery pack and power adapter). See “Power blank.
  • Page 94 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Indicator-Related Symptoms Symptom / Error Action in Sequence Indicator incorrectly remains off or on, but system Reconnect the inverter board runs correctly Inverter board Main Board Power-Related Symptoms Symptom / Error Action in Sequence Power shuts down during operation Power source (battery pack and power adapter).
  • Page 95 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Power Management-Related Symptoms Symptom / Error Action in Sequence The system will not enter hibernation Keyboard (if control is from the keyboard) Hard disk drive Main Board The system doesn't enter hibernation mode and Press Fn+ and see if the computer enters hibernation mode.
  • Page 96 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Keyboard/Touchpad-Related Symptoms Symptom / Error Action in Sequence Keyboard (one or more keys) does not work. Reconnect the keyboard cable. Keyboard Main Board Touchpad does not work. Reconnect touchpad cable. Touchpad board Main Board...

  • Page 97: Intermittent Problems

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Intermittent Problems Intermittent system hang problems can be caused by a variety of reasons that have nothing to do with a hardware defect, such as: cosmic radiation, electrostatic discharge, or software errors. FRU replacement should be considered only when a recurring problem exists.

  • Page 98: Index Of Pqa Diagnostic Error Code, Message

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Index of PQA Diagnostic Error Code, Message Error Code Message Action in Sequence 16XXX Backup battery error Backup battery 01XXX CPU or main board error Reload BIOS default setting. Main Board 02XXX Memory error...

  • Page 99: Jumper And Connector Locations

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Jumper and Connector Locations Top View PCB 04203-SD LIN1 Line-in connector Micro OZ168T audio DJ controller LOUT1 Line-out connector MINI1 Mini PCI connector USB1 USB connector FAN1 Fan connector USB2 USB connector CDROM1 CD-ROM connector...

  • Page 100: Jumper Settings

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Jumper Settings Jumper/Switch Setting ON*: Enable BootBlock Erasable OFF*: Disable BootBlock Erasable ON*: Clear CMOS RTC setup OFF: CMOS setup ON*: Clear system password OFF: Disable clear system password NOTE: * Default setting...

  • Page 101: Bottom View

    Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Bottom View North bridge Alviso-GM SKT4 Express card slot connector TRING1 MODEM MDC Power UltraMedia PCI7411 connector Lancom LF-H80P Transformer BAT1 Battery connector MDC1 Modem connector Memory connector ALC655 Audio Codec Memory connector controller...
  • Page 102 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560...

  • Page 103: Fru (Field Replaceable Unit) List

    TECHNICAL SERVICE MANUAL FRU (Field Replaceable Unit) List This chapter gives you the FRU (Field Replaceable Unit) listing in global configurations of Nobile 1560. Refer to this chapter whenever ordering for parts to repair or for RMA (Return Merchandise Authorization).

  • Page 104: Prestigio Nobile 1560 Exploded Diagram

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Prestigio Nobile 1560 Exploded Diagram...
  • Page 105 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Picture Partname Description ADAPTER ADAPTER 70W 19V ADPT 70W 19V CCC PA-1700-02AB LITEON PA-1700-02AB BATTERY RTC BATTERY BATTERY RTC E2U BATTERY PACK LI+ 8CELL ASSY BTY PK SMP LI+8CELL E2U MAINBOARD MAINBOARD E2V W/O E2V GM PD W/O CPU MB CPU W/MODEM &...
  • Page 106 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Picture Partname Description AUDIO BOARD AUDIO DJ BOARD B2M MODEM BOARD LITEON MODEM LITEON MDC-003#/A1A MDC-003#/A1A INVERTER BOARD 15" INVERTER 15" TWS-058-029 SUMIDA LCD 15" HITACHI LCD 15" TX38D81VC1CAB REV.C TX38D81VC1CAB REV.C CABLES TOUCHPAD CABLE...
  • Page 107 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Picture Partname Description LCD COAXIAL CABLE 15" C.A. COAXIAL 15"XGA LCD E2U LAUNCH CABLE W/BOARD C.A. LAUNCH PCB /W WIRE E2U COVER SWITCH CABLE C.A. COVER SWITCH 5OMM E2V POWER CABLE W/BOARD CABLE POWER PCB/W WIRE E2 MODEM CABLE C.A.
  • Page 108 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Picture Partname Description PCMCIA DUMMY CARD CARD DUMMY PCMCIA PA+ABS TM330 THERMAL CLIPPER THERMAL CLIPPER D2W SD MEMORY DUMMY SD DUMMY CARD J1 CARD TOUCHPAD BRACKET BRACKET TOUCH PAD B2I LOWER CASE W/FOOT ASSY LCASE E2V (AO)
  • Page 109 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Picture Partname Description HINGE PACK 15" HINGE PACK 15" LCD BEZEL 15" A ASSY LCD BEZEL 15" E2V-A LCD BEZEL 15" SILVER ASSY LCD BEZEL 15" E2V-J LCD PANEL 15" A ASSY LCD PANEL E2V-A LCD PANEL 15"...
  • Page 110 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Picture Partname Description DIMM COVER ASSY DIMM COVER E2U UPPER CASE A W/O ASSY UPPER CASE E2V-A TOUCHPAD MODULE W/ COVER SWITCH CABLE & LAUNCH CABLE & LAUNCH BRACKET UPPER CASE SILVER W/O ASSY UPPER CASE E2-J TOUCHPAD MODULE W/ COVER SWITCH CABLE &...
  • Page 111 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Picture Partname Description MIDDLE COVER BLACK W/ ASSY MIDDLE COVER E2V-Q POWER CABLE & SPEAKER & SPEAKER BRACKET MIDDLE COVER SILVER ASSY MIDDLE COVER E2V-J W/POWER CABLE & SPEAKER & SPEAKER BRACKET MIDDLE COVER A W/ ASSY MIDDLE COVER E2V-A POWER CABLE &...
  • Page 112 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Picture Partname Description WIRELESS ANTENNA ANTENNA (L) B2X LEFT WIRELESS ANTENNA ANTENNA (R) D2W RIGHT CPU FAN 5V FAN 5V UDQFWZH06CAR HEATSINK CPU THERMAL PLATE BRKT CPU THERMAL SUPPORT E2V CPU FANSINK W/FAN ASSY CPU HEATSINK W/FAN...
  • Page 113 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Picture Partname Description MICROPHONE MICROPHONE TS-60A-W28-280 E2V MISCELLANEOUS LOGO PLATE LBL LOGO PLATE AL JW2 A-OPEN MICROPHONE RUBBER RUBBER MIC 610 LCD SCREW RUBBER RUB SCREW COVER MAXDATA SILVER SILVER LCD SCREW MYLAR MYLAR SCREW COVER B2I...
  • Page 114 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Picture Partname Description SCREW SCREW SCW HEX NYL I#R-40/O#4-40 L5.5 SCREW SCRW M4H MSN +CBZ M2*L3 #1 SCREW SCRW MACH PAN NYLOK M2.5*10 NI SCREW SCRW MACH FLT M2*L3BK-NI NYLOK SCREW WCH MSN+CZ SCREW M2.5X5...
  • Page 115 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Picture Partname Description SCREW SCRW M2.5*5 WAFER B-ZN SCREW SCREW M2.5X6 SCREW SRW M2.5*8L B/ZN NYLOK 700 SCREW SCRW M2*4 WAFER NI SCREW SCREW M2.5*4L NI...
  • Page 116 TECHNICAL SERVICE MANUAL Prestigio Nobile 1560...

  • Page 117: Appendix A Test Compatible Components

    Windows XP and 2000. Refer to the following lists for components, adapter cards, and peripherals which have passed these tests. Regarding configuration, combination and test procedures, please refer to the Prestigio Nobile 1560 Compatibility Test Report released by the Mobile System Testing Department.

  • Page 118: Microsoft Windows Xp Environment Test

    TECHNICAL SERVICE MANUAL Prestigio Nobile 1560 Microsoft Windows XP Environment Test Item Specifications Intel Dothan 1.6GHz Mainboard E2V MB (Alviso GM)) LCD 15” XGA -HTC Inverter Inverter 15” TWS-058-029 -Sumida 2.5” SATA 40GB -Fujitsu Optical COMBO 24X -QSI/SBW-242B Keyboard KB SUNREX K020830M1US US...
  • Page 119 Prestigio Nobile 1560 TECHNICAL SERVICE MANUAL Item Specifications BlueTooth Card IBM Community Bluetooth PC Card Toshiba Bluetooth PC Card PABTC001 Token Ring Card IBM Token ring 16/4 Adapter II I/O Peripheral I/O - External CRT Acer 211c 21” ViewSonic PF790, 19”...
