Summary of Contents for Prestigio Nobile 159W
- Page 2 This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited. PRESTIGIO NOBILE 159W...
-
Page 3: Protecting Your Computer
Contact your dealer or see your service technician if any of the following occurs: Computer has been dropped or the body has been damaged. Liquid has been spilled into the product. The computer does not operate normally. PRESTIGIO NOBILE 159W... -
Page 4: Performance Features
TV Tuner / Video Capturing Module (Optional) The optional MiniPCI-based TV Tuner module allows user to watch TV or cable programs, record TV, and capture analog video signals to the hard drive or to the recordable optical drive (optional device). PRESTIGIO NOBILE 159W... -
Page 5: System At A Glance
The LED Status indicators reveal the status of these functions: Numeric keypad, cap lock, scroll lock, WLAN module enabling and disabling and also the ODD, HDD activities. The LED Status indicators also reveal the status of the system power state and battery-charging state. See the LED Status Indicator Section for details. PRESTIGIO NOBILE 159W... -
Page 6: Front And Rear View
TV broadcast or capture video input sources such as a camcorder. You need to connect the multimedia input cable to this port. The cable has five different connectors for Antenna (or Cable TV box), S-Video input, Video input, and Audio input. PRESTIGIO NOBILE 159W... -
Page 7: Side Views
This is where you plug the phone jack (RJ-11) for fax/modem functions. 3. Optical Drive and Disk Eject Button and Manual Eject Key Hole If your computer comes with the Combo drive, DVD-RW, DVD+RW, or DVD-Dual drive, you may save data onto a CD-R / CD- PRESTIGIO NOBILE 159W... - Page 8 The S-Video port permits you to redirect the screen output to a television set or any analog video playback device. This TV Port is copyright protected; when DVD movie is played, the output is scrambled to prevent analog recording. PRESTIGIO NOBILE 159W...
-
Page 9: Bottom View
Warning: Do not block the Fan Grill outlet. Place the machine on hard surface only. The bottom case may get very hot. AC Adapter 1. DC-out Connector The DC-out connector docks to the power jack (DC-in) on the computer. PRESTIGIO NOBILE 159W... -
Page 10: Led Status Indicator
Green light indicates the cap-lock is activated. Green light indicates the scroll-lock is activated. Note: When the system power is initially turned on, the Scroll-lock, Cap-lock, and Numeric keypad LED indicators will light up momentarily to indicate the start of the Power-On sequence. PRESTIGIO NOBILE 159W... -
Page 11: Keyboard Features
This key allows you to pull up the Windows Start Menu at the bottom of the taskbar. 2. Application Menu Key This key brings up the popup menu for the application, similar to a click of the right mouse button. PRESTIGIO NOBILE 159W... -
Page 12: Embedded Numeric Keypad
2. Keep your fingers dry and clean when using the touch pad. Also keep the surface of touch pad clean and dry to prolong its life. 3. The touch pad is sensitive to finger movements. Hence, the lighter the touch, the better the response. Heavy touch does not produce better response. PRESTIGIO NOBILE 159W... -
Page 13: Graphic Subsystem
3. To temporarily silence the speaker without changing the volume setting, click Mute. Voice Recording A built-in microphone allows you to record sound. You will need to use audio processing software to enable the built-in microphone. For example, you may use Microsoft Sound Recorder. PRESTIGIO NOBILE 159W... -
Page 14: Connecting The Modem
The following restrictions should be observed for 100BASE-TX networks: The maximum cable run length is 100 meters(m) (328 feet[ft]). For 100-Mbps operations, use Category 5 wiring and connections. Note: Consult Windows manual and / or Novell Netware user’s guide for the software installation, PRESTIGIO NOBILE 159W... - Page 15 Selects the next field. Select an item Selects the next upper item. Select an item Selects the next lower item. Lower value Selects the next value within a field. Higher value Selects the next value within a field. PRESTIGIO NOBILE 159W...
-
Page 16: Modifying The Bios Settings
You may have to enter “N” several times to prevent the boot sector write. Boot Sector Write!!! Possible VIRUS: Continue (Y/N)? _ The following warning message appears when a program attempts to format the hard disk drive. Format!!! Possible VIRUS: Continue (Y/N)? _ PRESTIGIO NOBILE 159W... -
Page 17: Using Password Protection
You may choose CD/DVD, Hard Drive, or Realtek Boot Agent as the first storage device to boot from. If you have already connected a USB Floppy Disk Drive before powering up, it will appear as a Removable Device in the Boot Device selection menu PRESTIGIO NOBILE 159W... -
Page 18: Exit Setup
Very Low battery condition occurs at 3 % power remaining. The red battery status LED indicator blinks and the system beeps at 4-second interval. When the notebook warns you of its low battery condition, you will have about 3-5 minutes to save your current work. PRESTIGIO NOBILE 159W... -
Page 19: Installing And Removing The Battery Pack
Alternatively, you can access the power meter by clicking the Power Options icon in the Windows Control Panel. Prolonging the Battery’s Life and Usage Cycles There are ways you can do to prolong the use of battery. PRESTIGIO NOBILE 159W... -
Page 20: Using Windows Power Options
For example, Max Battery mode lowers the processor’ s speed and voltage to conserve power as much as possible. In this dialog box, you can manually set the LCD and hard drive’ s time-out values in the Plugged in column and in the Running PRESTIGIO NOBILE 159W... -
Page 21: Suspend Mode
Warning: In the When I close the lid of my portable computer pull-down menu, DO NOT select Do nothing – otherwise the system will still run at high speed while the processor’s fan grill is fully blocked by the closed LCD panel. The heat will damage the LCD panel. PRESTIGIO NOBILE 159W... -
Page 22: Low Battery Warning
Select Max Battery if you want the system to enter suspend mode more often. Or, select Always On if your notebook PC is plugged into an AC power source. Note: Actual dialogue box shown above may appear slightly different. PRESTIGIO NOBILE 159W... -
Page 23: Troubleshooting
Sound cannot be recorded - Double-click the speaker icon on the lower right corner of the taskbar to see if the microphone has been muted. 1. Click Options and select Properties. 2. Select Recording and click the OK button. PRESTIGIO NOBILE 159W... -
Page 24: Hard Disk Problems
After you have inserted a CD-ROM disk, it may take a moment before you can access its content. The drive dose not read any disks - The CD may not be properly seated in the tray. Make sure the disk is firmly seated onto the spindle. The disk is damaged or not readable. PRESTIGIO NOBILE 159W... -
Page 25: Display Problems
CMOS battery. If so, you need to replace the battery. This battery normally lasts two to five years. The battery is of type CR2032 (3V). You may replace it by yourself. The battery is located next to the MiniPCI WLAN Module socket. PRESTIGIO NOBILE 159W... -
Page 26: Memory Problems
Replace or update the device driver from the factory CD-ROM disk or consult Windows manual on how to solve the resource conflict problem. Make sure the physical connections on both ends of the cable are good. PRESTIGIO NOBILE 159W... -
Page 27: Pc Card (Pcmcia) Problems
You may be running too many applications. Try to close some applications or increase system memory for higher perfor- mance. The processor may have been overheated due to the system’ s inability to regulate its internal heat. Make sure the computer’ s ventilation grills are not blocked. PRESTIGIO NOBILE 159W... -
Page 28: Firewire (Ieee1394) And Usb2.0 Problems
2.6 Choose “Do Not format this partition” and click Finish. Now, this partition is ready for Power Cinema to be installed. 3. Installation. 3-1 Before installing Linux system, please make sure you have followed and performed the pre-installation instruction in PRESTIGIO NOBILE 159W... -
Page 29: Finding And Playing Content
Click a track to play it or click Play All to play all of the tracks displayed. Click Stop to stop music playback. To navigate in the list of tracks, click Next or Prev. Note: When you exit this function, music playback stops. PRESTIGIO NOBILE 159W... -
Page 30: Music Clips
When this option is not selected, the slideshow plays only the photos in the directory you have selected. Press the Backspace key on the keyboard to exit the slideshow. PRESTIGIO NOBILE 159W... -
Page 31: Hardware Installation
Bluetooth CD disc into the optical drive and follow the on-screen instructions to install the Bluetooth driver and utility program properly. Hardware Installation: The internal USB slot is located under the Internal USB Slot Door on the bottom of the notebook. PRESTIGIO NOBILE 159W... - Page 32 Bluetooth Icon Indicates Bluetooth Status Enabled Disabled Connected Blue with White Blue with Red Blue with Green Create A Connection Using The Bluetooth Setup Wizard From the Folders pane of Windows Explorer, right-click My Bluetooth Places and select Bluetooth Setup Wizard. PRESTIGIO NOBILE 159W...
- Page 33 Bluetooth fax service. Some services are hardware dependant; this computer cannot provide the fax service unless it has a physical fax modem, for example. Note: For detailed Bluetooth operations, use the Help button on the Bluetooth application dialogue box. PRESTIGIO NOBILE 159W...
-
Page 34: Product Specification
Direct3D compatible, DirectX compatible S-Video TV-out Encoder Audio Chipset Intel (ICH4M) integrated audio controller Audio Codec VT1612A Sound Capabilities DirectSound 3D, EAX 1.0 & 2.0 compatible A3D, I3DL2 compatible AC97 V2.3 compatible 2 Stereo Speakers with 1 Subwoofer PRESTIGIO NOBILE 159W... -
Page 35: Wireless Lan
Note: In some models, Firewire/1394 function may note be available. Storage Hard Drive 2.5-inch format hard disk drive Combo Drive 5.25-inch format (12.7mm height) fixed module (Optional Purchase) DVD±R/±RW or DVD-Dual or DVD-Multi Standards 5.25-inch format (12.7mm height) fixed module (Optional Purchase) PRESTIGIO NOBILE 159W... -
Page 36: Keyboard & Touch Pad
Uniwill SmartPower Power Management Smart Battery Compliant; low battery warning beep Adapter AC-Input / DC-Output Autosensing AC-in 100~240V, DC-out 20V, 90W Note: For SmartPower II to work correctly, the system must be installed with Windows XP SP2 or later edition. PRESTIGIO NOBILE 159W... -
Page 37: Physical Specification
6.6 lbs / 2.75 KG (with 15”LCD, DVD-ROM Drive, and 6-cell battery pack) Environmental Limits Operating Temperature: 5 to 30 C (41 to 86 Operating Humidity: 20 to 80 percent RH (5 to 35 Storage Temperature: -15 to 50 C (5 to 122 PRESTIGIO NOBILE 159W...
