940TM Pendant Microphone

Features

1
5 6
7
6
front
2
3
4
bottom
8 9
back
6
11
12
1. Neck strap
2. Infrared emitter diodes
(Do not block)
3. Indicator Light
4. Mute button
(Push to mute)
5. Channel selector
( Select Channel A or Channel B.
Cannot have two microphones on the
same channel in the same room)
6. Microphone ports (4)
(Do not block)
7. A ux-in audio jack
(Use aux-in audio adaptor cord to
send audio from a secondary audio
source such as an MP3 player, portable
radio/CD/tape player to the receiver)
8. External microphone jack (optional)
(Connect a boom microphone)
9. Charge jack
(When not using 950C charger)
6 10
10. On/off switch
11. B attery compartment
( 1) AA (LR6) NiMH rechargeable battery
(FrontRow "silver sleeve", auto-sensing)
12. Charge contacts
940TM only. 930TM is not supported by
950C charger.
