Chapter 8 Using Pass-Around Microphone - FrontRow 5301R User Manual

8
950H Pass-Around Microphone
Using
5
1
4
5in. (13cm)
12
2
3
3in. (7cm)
6
1. Turn microphone on
2. Note indicator light
Green = On and transmitting
Blinking red = Low battery
3. Keep top of microphone approximately
3 - 4in. (7.5 – 10cm) from mouth when
using as a hand-held microphone
4. To allow hands-free use (for example,
when reading aloud and turning pages),
attach the lavaliere clip. Adjust neck strap
to position microphone approximately
4 - 5in (10 - 13cm) from mouth.
5. Do not block emitter diodes
6. Turn off microphone and place microphone
in charger at the end of the day
NOTe: The 950H is factory set on Channel B.
If you are using two microphones, they must
be on different channels.
A
A
B
+ B
+ A
+ B
