MATERIALS INCLUDED IN THIS PACKAGE:

1) ADV100S/ADV100P Video Monitor (1 pc)
2) Trim Ring (1 pc)
3) Hardware Package:
♦
♦
♦
4) Remote Control (P/N 136B3469) (1 pc)
5) 2 Pin Power Wire Harness with choke (P/N 112B3143) (1 pc)
6) Dome Light Harness (P/N 112B3110) (1 pc)
1
PO W ER
PL AY ST O P
ON OFF AUTO
5

TOOLS REQUIRED:

#2 Phillips Screwdriver
#1 Phillips Screwdriver
Utility or Razor Knife or Shears
Wire Strippers
Upholstery Hook Tool (for removal of panels as necessary)
Electrical Tape
Masking Tape
Multimeter (to verify 12 volt DC and continuity: Do not use a test light or logic probe)
Marker – to mark headliner
Scribe (to mark trim ring if used)
Misc. Electrical Connectors (to connect to vehicle power source. Requirements will vary from vehicle to vehicle)
#4 x 5/16" Screws (8 pcs)
#8 x 5/8" Self Drilling Screws (4 pcs)
#8 Washers (4 pcs)
2
EJ EC T
3
6
