OPERATING INSTRUCTIONS FOR
MINI-SPLIT HEAT PUMP SYSTEM
MODEL
MSC49HP13115A
MSC412HP13115A
950-0021-revB 11-29-06
Copyright IRP 2006

Advertisement

loading
Need help?

Need help?

Do you have a question about the MSC49HP13115A and is the answer not in the manual?

Questions and answers

Summary of Contents for Thermal Zone MSC49HP13115A

  • Page 1 OPERATING INSTRUCTIONS FOR MINI-SPLIT HEAT PUMP SYSTEM MODEL MSC49HP13115A MSC412HP13115A 950-0021-revB 11-29-06 Copyright IRP 2006...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS USER INSTRUCTIONS..................................1 PARTS IDENTIFICATION............................2 REMOTE CONTROL OPERATION AND INDICATORS........................3 MAINTENANCE....................................9 TROUBLESHOOTING..................................9 WARRANTY.......................................10 TECHNICAL ASSISTANCE................................10...
  • Page 3: User Instructions

    USER INSTRUCTIONS AND INFORMATION In this manual, you will find safety information for installation and operation. For your safety and the safety of others, please read and understand all cautions located throughout this manual. WARNINGS AND CAUTIONS WARNING This symbol refers to a hazard or unsafe practice which can result in severe personal injury or death. CAUTION This symbol refers to a hazard or unsafe practice which can result in personal injury or property damage.
  • Page 4: Parts Identification

    PARTS IDENTIFICATION AND FUNCTIONS AIR RETURN INDOOR UNIT AIR FILTER (UNDER COVER) AIR OUTLET CONDENSATE POWER ON DRAIN LIGHT TIMER ON LIGHT Line-set and cables WHEN: RUN light is on - Unit is operating in the set mode. i.e. Cool, Dehumidify, Fan. TIMER light is on - Unit is in AUTOSTART mode and will start at the set time.
  • Page 5: Remote Control Operation And Indicators

    TO OPEN FRONT COVER Press inward on the sides of the cover near the bottom to release, then pull bottom of cover outwards To close the cover, press the corners inward to latch. DO NOT OVEREXTEND THE FRONT COVER. REMOTE CONTROL OPERATION OPERATION MODE Indicator OPERATION MODE Indicator OPERATION MODE Indicator...
  • Page 6 NOTE: When changing functions, please allow 3 - 4 minutes for the condensor unit to restart. USE OF THE REMOTE CONTROL (AUTO SELECT MODE) USE OF THE REMOTE CONTROL (DEHUMIDIFIER MODE) In the AUTOSELECT mode, the system functions as described below: During the de-humidification process, the outdoor compressor and the inside When the room temperature is below...
  • Page 7 USE OF THE REMOTE CONTROL (COOL MODE) USE OF THE REMOTE CONTROL (HEAT MODE) The HEAT mode activates the outdoor compressor as necessary to satisfy the selected room temperature. 1) Press the ON/OFF Button to turn the unit ON The COOL mode activates the outdoor compressor as necessary to satisfy the selected room temperature.
  • Page 8 USE OF THE REMOTE CONTROL (SLEEP MODE) USE OF THE REMOTE CONTROL (CLOCK SET - BATTERIES) 1) Remove the battery In the SLEEP mode, the system cover on the back lowers the fan speed, and raises of the remote the setpoint temperature slightly. CLK Button (to set clock) 1) Press the SLEEP Button to...
  • Page 9 USE OF THE REMOTE CONTROL (AUTOSTART MODE) USE OF THE REMOTE CONTROL (AUTOSTOP MODE) The Autostart function will stop the The Autostart function will start the unit in the last selected mode. unit in the last selected mode. The Autostart function will turn the The Autostart function will turn the unit OFF when the selected time unit ON when the selected time...
  • Page 10 LOUVER ADJUSTMENTS (Air Flow Direction) By operating the VANE CONTROL and SWING buttons, you may direct the airflow to maximize the cooling effectiveness 1) Press the ON/OFF Button to turn the unit ON 2) Press the MODE Button and select the desired mode (AUTO, COOL, DRY, or FAN) 3) Press the VANE CONTROL 5) Press the SWING...
  • Page 11: Maintenance

    MAINTENANCE OF YOUR UNIT Beginning of Season • Turn the unit off. In the OFF mode, the unit still comsumes about 5 watts of power. If you wish to completely turn the unit PRIOR TO OPERATION off, turn off the breaker to the unit. •...
  • Page 12: Warranty

    If the unit exhibits a defect in normal use and it is determined to be within the warranty period, THERMAL ZONE will, at its option, either repair or replace the unit free of charge within a reasonable time after the unit is returned.
