- Page 1 WINDOW AIR CONDITIONER INSTALLATION OPERATION CATALOG NO. PRODUCT CODE WAC6115R 420-0005 WAC8115R 420-0008 950-0075-revD Page 1 of 15 9 May 2007...
-
Page 2: Table Of Contents
TABLE OF CONTENTS AIR CONDITIONER SAFETY………………………………………………….….2 INSTALLATION REQUIREMENTS………………………………………………3 ELECTRICAL REQUIREMENTS…………………………………………………4 INSTALLATION INSTRUCTIONS………………………………………………..6 AIR CONDITIONER USE…………………………………………………………8 AIR CONDITIONER CARE……………………………………………………….11 TROUBLESHOOTING………………………………………………………….…11 SPECIFICATIONS………………………………………………………………….13 WARRANTY………………………………………………………………………...15 TECHNICAL SUPPORT IF YOU NEED TECHNICAL SUPPORT, PLEASE CALL (705) 504-8590 BETWEEN THE HOURS OF 8:00 A.M. and 5:00 P.M. EST. PLEASE HAVE THE MODEL NUMBER AND SERIAL NUMBER OF YOUR EQUIPMENT AVAILABLE WHEN YOU CALL. -
Page 3: Installation Requirements
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock, or injury when using your air conditioner, follow these basic precautions: • • Plug into a grounded 3 prong outlet. Do not use an extension cord • • Do not remove ground prong Unplug air conditioner before servicing •... -
Page 4: Electrical Requirements
ELECTRICAL REQUIREMENTS Window Installation Window opening measurements: • 25” min to 38” max (63.5 cm to 95.5cm) opening width. • 14” min. (35.6 cm) opening height. Ground wire must be connected to ground screw located in lower right corner of air conditioner when air conditioner is in cabinet. The electrical ratings for your air conditioner are listed on the model and serial number label. - Page 5 Recommended Ground Method This air conditioner must be grounded. This air conditioner is equipped with a power supply cord having a grounded 3 prong plug. To minimize possible shock hazard, the cord must be plugged into a mating, grounded 3 prong outlet, grounded in accordance with all local codes and ordinances.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS UNPACKING Prepare Air Conditioner for Installation 1. Location provided bags of screws. 2. Place the top channel on top of the air conditioner, lining up the holes in top channel with the holes on top of air conditioner. 3. - Page 7 ________________________________________________________ Attach foam adhesive seal ________________________________________________________ Attach foam adhesive seal along the bottom of the curtain Bottom channel. Position the Air Conditioner 1. Center air conditioner in window. Check that lower rail of air conditioner is behind and against back side of windowsill. Lower window sash to hold cabinet in place.
-
Page 8: Air Conditioner Use
6. Press PESET on the power supply cord. 4. Attach window-lock bracket to window sash with one of the #8 x 3/4 slotted wood screws to secure window in place. 5. Plug into a grounded 3 prong outlet. __________________________________________________________________________________________________________________ AIR CONDITIONER USE Operating your air-conditioner properly helps you obtain the Do not try to operate your air conditioner in the cooling mode when best possible results. - Page 9 7. Press the plus or minus button to change delay time (1 to 24 _______________________________________________________ hours). TEMPERATURE _______________________________________________________ 8. Press TIMER again or wait 10 seconds. Timer indicator light will remain on. Display will show current room temperature. Press the plus TEMP button to raise the temperature. Display shows the temperature control setting.
- Page 10 To raise the temperature: 3. Press TIMER again or wait 10 seconds. Indicator light on air Press the plus button to raise the temperature. Each time you press conditioner control panel will remain on. or hold the plus button, the temperature will go up 1ºF until it reaches 86ºF (30ºC).
-
Page 11: Air Conditioner Care
______________________________________________________________________________________________________________________ AIR CONDITIONER CARE _______________________________________________________ Cleaning the Front Panel Your new air conditioner is designed to give you many years of dependable service. This section tells you how to clean and care for your air conditioner properly. Call your local authorized dealer for an 1. - Page 12 _______________________________________________________ There is excessive heat or moisture (open container cooking, Air conditioner power supply cord trips (Reset button pops out) showers, etc.) in the room. Use a fan to exhaust heat or moisture _______________________________________________________ from the room. Try not to use heat producing appliances during the hottest part of the day.
-
Page 13: Specifications
SPECIFICATIONS SPECIFICATIONS WAC6115R COOLING BTU 6000 HEATING BTU DEHUMIDIFICATION (pints/hr) 1.94 AIRFLOW CFM MAX VOLTAGE/FREQ 115 VAC 60 HZ COOLING AMPS 7.53 HEATING AMPS COOLING WATTS HEATING WATTS PLUG TYPE type A POWER CORD RATING (amps) POWER CORD TYPE LCDI POWER CORD LENGTH MIN. - Page 14 SPECIFICATIONS WAC8115R COOLING BTU 8000 HEATING BTU DEHUMIDIFICATION (pints/hr) AIRFLOW CFM MAX VOLTAGE/FREQ 115 VAC 60 HZ COOLING AMPS HEATING AMPS COOLING WATTS HEATING WATTS PLUG TYPE type A POWER CORD RATING (amps) POWER CORD TYPE LCDI POWER CORD LENGTH MIN.
-
Page 15: Warranty
WARRANTY International Refrigeration Products warrants that the product supplied is free from defects in material and workmanship. This warranty is valid as long as this product is properly handled, installed, operated and serviced in accordance with the Installation and Operating Instructions shipped with this unit, and the warranty card is completed and mailed no later than 30 days after date of purchase.
