SERVICE MANUAL
MODEL
COMMANDER
KP-FX432M90
RM-1014
KP-FX532M90
RM-1014
DRC-MF
RM-1014
DEST. CHASSIS NO.
CH
SCC-M14H-A
CH
SCC-M14G-A
HD/DVD
1
2
3
4
5
6
7
8
9
0
JUMP
MENU
PIC
SOUND
WIDE
SURROUND
MODE
MODE
MODE
PROGR
RESET
TV
AX-1
MODEL
COMMANDER
KP-FX432M90
KP-FX532M90
PROJECTION TV
CHASSIS
DEST. CHASSIS NO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KP-FX532M90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony KP-FX532M90

Summary of Contents for Sony KP-FX532M90

  • Page 1 SERVICE MANUAL AX-1 CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KP-FX432M90 RM-1014 SCC-M14H-A KP-FX532M90 RM-1014 SCC-M14G-A HD/DVD JUMP MENU DRC-MF SOUND WIDE SURROUND MODE MODE MODE PROGR RESET RM-1014 KP-FX432M90 KP-FX532M90 PROJECTION TV...
  • Page 2 VIEWS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS REMOVING THE ANODE. WITH SONY PARTS WHOSE PART NUMBERS AP- PEAR AS SHOWN IN THIS MANUAL OR IN SUPPLE- MENTS PUBLISHED BY SONY. – 2 –...

  • Page 3: Table Of Contents

    KP-FX432M90/FX532M90 RM-1014 TABLE OF CONTENTS Section Title Page Section Title Page 1. SELF DIAGNOSIS FUNCTION 3-8-3. Method of Cancellation from Service Mode . 1-1. Diagnostic Test Indicators ......... 3-8-4. How to Adjustments ........1-2. Display of STANDBY/TIMER 3-8-5. How to Write the Data ........Light Flash Count ..........
  • Page 4 KP-FX432M90/FX532M90 RM-1014 7. EXPLODED VIEWS 7-1. FRONT PANEL BLOCK ........167 7-2. CABINET BLOCK (KP-FX532) ....... 168 7-3. CABINET BLOCK (KP-FX432) ....... 169 7-4. BEZENET AND MIRROR COVER BLOCK (KP-FX532) ............170 7-5. BEZENET AND MIRROR COVER BLOCK (KP-FX432) ............171 7-6.

  • Page 5: Self Diagnosis Function

    KP-FX432M90/FX532M90 RM-1014 SECTION 1 SELF DIAGNOSIS FUNCTION The unit in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER LED will automatically begin to flash. The number of times the LED flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER LED flash indicators is listed in the instruction manual for the user's knowledge and reference.

  • Page 6: Display Of Standby/Timer Light Flash Count

    KP-FX432M90/FX532M90 RM-1014 1-2. DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT Diagnostic items Flash count +B Overcurrent 2 tims Low +B Overvoltage 3 tims Vert. deflection stopped 4 tims 5 tims White balance failure Low +B OVP/OCP 6 tims Horiz. deflection stopped 7 tims Audio protection 8 tims...

  • Page 7: Self-Diagnostic Screen Display

    KP-FX432M90/FX532M90 RM-1014 1-4. SELF-DIAGNOSTIC SCREEN DISPLAY For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurrences of failure for confirmation on the screen: [To Bring Up Screen Test] In standby mode, press buttons on the remote commander sequentially in rapid succession as shown below: Self-Diagnosis screen display...

  • Page 8: Self-Diagnostic Circuit

    KP-FX432M90/FX532M90 RM-1014 1-6. SELF-DIAGNOSTIC CIRCUIT MG BOARD AKB 24 IC0001 V PROT 56 VDY- MAIN MICRO +12V STBY-LED HG PROT 57 Q5202 22 STBY-LED +15V CLKO 14 53 SCL < H PLS DATO 13 52 SDA 5 OCP 6 OVP 87 LOW B ERR RY6000 AC RLY 36...

  • Page 9: Disassembly

    KP-FX432M90/FX532M90 RM-1014 SECTION 2 DISASSEMBLY 2-1. REAR BOARD REMOVAL (1) KP-FX432 (2) KP-FX532 2 Rear board 2 Rear board 1 Fourteen screws 1 Thirteen screws (Hexagon head) (Hexagon head) 2-2. MAIN BRACKET REMOVAL 2-3. SERVICE POSITION 1 Optical shield 2 Two screws (Tapping screw hexagon head) 2 Thirteen screws...

  • Page 10: Front Panel Assy Removal

    KP-FX432M90/FX532M90 RM-1014 2-4. FRONT PANEL ASSY REMOVAL (1) KP-FX432 2 Three screws (tapping screw hexagon head) 3 Side panel (43L) assy 2 Two screws (tapping screw hexagon head) 5 Two screws 1 Three screws (tapping screw (BVTP 4x16) hexagon head) 4 Three screws (BVTP 4X16) 5 Three screws...

  • Page 11: Mirror Cover And Beznet Block Removal

    KP-FX432M90/FX532M90 RM-1014 2-5. HC, HA AND HB1 BOARDS REMOVAL 2 HC bracket 4 Three screws (BVTP 3x12) 1 Two screws 3 HC board (BVTP 3x12) 6 Two screws 8 Two screws (BVTP 3x12) 5 HA board (BVTP 3x12) 9 HB1 board 6 Two screws (BVTP 3x12) 7 Control button...

  • Page 12: Beznet Assy Removal

    KP-FX432M90/FX532M90 RM-1014 (2) KP-FX532 1 Six screws (BVTP 4X16 ) 3 Mirror cover 1 Six screws (BVTP 4X16) 2 Four screws (Hexagon head) 5 Beznet block 1 Six screws (BVTP 4X16) 4 Six screws (Hexagon head) 2-7. BEZNET ASSY REMOVAL (1) KP-FX432 Mirror cover 2 Holder Bracket(43L)

  • Page 13: Terminal Bracket Removal

    KP-FX432M90/FX532M90 RM-1014 (2) KP-FX532 Mirror cover 1 Six screws (BVTP 4X16) 2 Screen 3 Screen holder (SIDE) holder (TOP) 1 Fourteens screws (BVTP 4X16) 6 Diffusion plate (F) 7 Diffusion plate (L) 1 Six screws 8 Contrast screen (BVTP 4X16) 9 Beznet assy 4 Screen holder (SIDE)

  • Page 14: Ug Board Removal

    KP-FX432M90/FX532M90 RM-1014 2-9. UG BOARD REMOVAL 1 Two screws (PSW 3x8) 2 B bracket 3 UG board Main bracket section 2-10. AD, BM, DS AND MG BOARDS REMOVAL 3 Two screws (BVTP 3x12) 4 AD Board 4 DS board 2 BM board 1 MG Board Main bracket section –...

  • Page 15: A And D Boards Removal

    KP-FX432M90/FX532M90 RM-1014 2-11. A AND D BOARDS REMOVAL 1 Three screws 3 Five screws (BVTP 3x12) (BVTP 3x12) 5 Six screws (BVTP 3x12) 2 G1 bracket 4 A board 6 D board Main bracket section 2-12. CRT AND PWB BLOCK REMOVAL (1) KP-FX432 1 Two screws (BVTP 4X16)

  • Page 16: High-Voltage Cable Installation And Removal

    KP-FX432M90/FX532M90 RM-1014 (2) KP-FX532 1 Two screws (BVTP 4X16) 2 Three screws (Hexagon head) 2 Three screws (4X20) (Hexagon head) (4X20) 1 Two screws (BVTP 4X16) 3 Picture tube block assy 2 Two screws (Hexagon head) (4X20) PWB block assy 2-13 HIGH-VOLTAGE CABLE 2-14.

  • Page 17: Set-Up Adjustments

    KP-FX432M90/FX532M90 RM-1014 SECTION 3 SET-UP ADJUSTMENTS 4. Adjust electric focus. (roughly) 3-1. SCREEN VOLTAGE ADJUSTMENT 5. Rotate the green lens and adjust to obtain the best lens focus. (ROUGH ALIGNMENT) 6. Rotate the green focus volume on the focus pack and adjust to obtain best electrical focus.

  • Page 18: 2-Pole And 4-Pole Magnet Adjustment

    KP-FX432M90/FX532M90 RM-1014 3-5. 2-POLE and 4-POLE MAGNET ADJUST- 3-6. BLUE DEFOCUS ADJUSTMENT MENT 1. Receive 1080i/50Hz dot signal from HD/DVD 1 terminal. 2. Set "Hi Fine" and PICTURE 100%, other 50% and white 3-5-1. Adjustment of 2-pole magnets balance "COOL"(VM OFF). 1.

  • Page 19: Adjustments With Commander

    KP-FX432M90/FX532M90 RM-1014 3-8. ADJUSTMENTS WITH COMMANDER 3-8-1. How to Select Each Mode Service adjustment to this model can performed with the supplied remote commander RM-1014. 50 Hz 60 Hz WIDE 60 Hz WIDE 50 Hz (PAL) (NTSC) (NTSC) (PAL) DRC1250 DRC100 1.

  • Page 20: Method Of Cancellation From Service Mode

    KP-FX432M90/FX532M90 RM-1014 3-8-3. Method of Cancellation from Service Mode 3-8-5. How to Write the Data 1. Set in the service mode. 1. Set the standby mode (Press “ (TV STANDBY)” button on 2. Press “1” or “4” button on the commander, select the ad- the commander), then press “...

  • Page 67: Registration Adjustment

    KP-FX432M90/FX532M90 RM-1014 3-10. REGISTRATION ADJUSTMENT 3-10-2.Setup for Adjustment 1. Marking 1) At the 4 insides of the screen, locate the middle. Use a tape 3-10-1.ADJUSTME FLOW measure to identify the middle. START × : middle Turn on the power and wait for 10 minutes Set to the PAL Full mode Check the deflection yokes, the centering magnets, 2 pole/4 pole magnets Set to the service mode...

  • Page 68: 3-10-4.Operation Method For Projector

    KP-FX432M90/FX532M90 RM-1014 1. Functions of Keys on Commander 6. Write “VPS, VSZ and HSZ” adjusted data to other mode • 1 : Changes adjustment item. (item No. moves up) service data. : Marker moves clockwise from center to outside. <Write “VPS”,“VSZ”,“HSZ”> (in fine adjustment mode) DRC1250 DRC100...

  • Page 69: 3-10-5.Method Of Projector Engine Adjustment

    KP-FX432M90/FX532M90 RM-1014 • Fine adjustment can be made on the basis of marker position 4) In the GRN, BLU, or RED mode, move “ ” up or down to using joystick key. change the data in vertical direction, or move “ ”...
  • Page 70 KP-FX432M90/FX532M90 RM-1014 6) Select “GRN SKEW”, and correct the tilt of horizontal lines 9) Select “GRN MSIZ”, and correct the space intervals for the and vertical lines. horizontal section of the screen are equal. • GRN SKEW (horizontally/vertically) • GRN MSIZ (horizontally) Move the joystick Move the joystick to the right.
  • Page 71 KP-FX432M90/FX532M90 RM-1014 2. Red Adjustment 5. Confirm registration of each mode and touch- 1) Place a cap on the blue lens so that green and red colors are displayed. 1) Receive PAL signal. Select DRC1250 50Hz normal mode. 2) Press “3” button on the commander to select RED mode. (PAL) by "MENU"...

  • Page 72: Auto Convergence Setting

    KP-FX432M90/FX532M90 RM-1014 3-11. AUTO CONVERGENCE SETTING 3-13. WHITE BALANCE ADJUSTMENT This adjustment must be performed after the registration adjustment was made or after readjustment was made by any 1. Connect the W/B adjustment jig(12C BUS). reason. 2-1.Set "PICTURE MODE" TO "DYNAMIC", and adjust PIC 00 PIC (100) = 0 1.

  • Page 73: Auto Convergence Error Code List

    KP-FX432M90/FX532M90 RM-1014 3-14. AUTO CONVERGENCE ERROR CODE LIST If an error code is displayed after the set has been fully adjusted, correctly, plese check the following items : position, tilt and sizing. If either of these adjustments are off, even slightli, the auto registration pattern will not hit the four sensors properly. This occurs when the internal generator patterns is being flashed on the screen for the sensor to read.

  • Page 74: Adjustment

    KP-FX432M90/FX532M90 RM-1014 SECTION 4 ADJUSTMENT 4-3. +B OVP CONFIRMATION 4-1. HV REGULATION ADJUSTMENT (D Board) 1. Supply 220V AC to variable autotransformer. 2. Turn on set. When replacing the following components marked with ] 3. Receive dot signal pattern. on the schematic diagram, always check hold-down volt- 4.

  • Page 75: Electrical Adjustments

    KP-FX432M90/FX532M90 RM-1014 SECTION 5 ELECTRICAL ADJUSTMENTS 5-1. Picture Quality Adjustment Original Condition 5-1-1. Preparation DRC-MF : DRC1250 1. Set in the service mode. PICTURE MODE : HI-FINE 2. Set respective items as follows. 3D-NR MODE : OFF ECO MODE : OFF Adjustment Condition DRC-MF : DRC1250...

  • Page 76: Ntsc Video Input (Main Picture)

    KP-FX432M90/FX532M90 RM-1014 5-1-2. NTSC Video Input (Main Picture) 5-1-3. NTSC RF Input (Main Picture) 1. Enter the NTSC video color bar (White & color 75%) signal. 1. Enter the NTSC RF color bar (White & color 75%) signal. 2. Enter the service mode, and set respective items as follows. 3.

  • Page 77: Pal Video Input (Mainpicture)

    KP-FX432M90/FX532M90 RM-1014 5-1-5. PAL RF Input (Main Picture) 2 If still “Sub HUE” can not adjust, Change HUOF data from “2” to “1”. 1. Enter the PAL RF color bar (White & color 75%) signal. Repeat (ii). (i) SUB CONTRAST If “Sub HUE”...

  • Page 79: Diagrams

    KP-FX432M90/FX532M90 RM-1014 SECTION 6 DIAGRAMS 6-1. BLOCK DIAGRAMS (1) A(1/2), D(1/2) AND HC BOARDS BLOCK DIAGRAMS CN6007 CN6000 CN6400 L901 RECT + RECT + RECT RECT D6508 STBY 7V CN2015(1/2) CN5019(1/2) IC6100 D6005 MAIN 9V 135V 135V D6113 5V REG TO UG BOARD TO VM BOARD STBY 5V...
  • Page 80 KP-FX432M90/FX532M90 RM-1014 (2) A(2/2) BOARD BLOCK DIAGRAM TO D(2/2)BOARD TO D(2/2)BOARD TO MG BOARD TO BM BOARD TO MG BOARD CN5004 CN5005 CN0001 CN3001 CN0002 CN2015(2/2) VIDEO MT_CV MT_VIDEO M_SDAT M_SDAT M_SCLK M_SCLK ST_CV(N.C) AUDIO L/R L_MUTE L_MUTE ST L(N.C) BYPASSSW/ST_R AUDIO L MT_L...
  • Page 81 KP-FX432M90/FX532M90 RM-1014 (3) D(2/2) BOARD BLOCK DIAGRAM HV BLOCK IC8002 T8001 DRIVE PICTURE TUBE Q8014 V901,V902,V903 CONVERTER L8002 Q8011 Q8021 Q8028 Q8034 Q8035 HV PROT SOFT START D8015 AC HOP VCC Q8013 IC8004 CONVERTER BS9V BUFFER TO 1/2 PH8003 HV FEED BACK D8022 +15V VSENSE...
  • Page 82 KP-FX432M90/FX532M90 RM-1014 (4) AD AND SR BOARDS BLOCK DIAGRAMS IC9613 (PJED-CPU,PHOTO SENSOR BUFFER) -5V REG -17V IC9607 IC9606 PJED-CPU CONV DSP IC9601(1/2) CN9601 Q9605 CN9600 RE-R BUFF I SEN U UPPER SENSOR IC9415(1/2) Q9607 Q9603 RE-G BUFF I SEN LO LOWER BOTTOM SENSOR...
  • Page 83 KP-FX432M90/FX532M90 RM-1014 (5) BM BOARD BLOCK DIAGRAM IC3104 IC3101 CN3001 OP AMP. AD CONV. MS3.3V DET(N.C) Q3112 Q3101 ,Q3102 FF SW BUFFER IC3201 IC3301 IC3303 FFSW FL3101 LINE W -128 DRC MF CONVERTER L.P.F DRC LW (MY0-MY7) FILM DRC FILM Q3111 -220 Q3103...
  • Page 84 KP-FX432M90/FX532M90 RM-1014 (6) DS, HA AND HB1 BOARDS BLOCK DIAGRAM (SIRCS,KEY) CN9400 IC9400 -17VB -17V CONV.OUT1 CN1000 +17VB +17V STBY5V /REGI MUTE CN9405 S1000-1005 KEY1 D1006 BH-OUT KEY2 D1007 BV-OUT SIRCS TO DY(B) BV-RET LED G TO MG(1/2)BOARD BH-RET LED R CN0004 S1006,1007 KEY WAKE...
  • Page 85 KP-FX432M90/FX532M90 RM-1014 (7) MG(1/2) BOARD BLOCK DIAGRAM CN0002 MAIN R CN0004 MAIN L KEY1 L MUTE KEY2 SUB BYPASS SW SIRCS IC0001 M SCLK M SCLK POWER-LED M SDAT M SDAT STBY-LED TO HA BOARD MT AGE CN1000 MT AGC O-AGC-ATT KEY WAKE MT AFT...
  • Page 86 KP-FX432M90/FX532M90 RM-1014 (8) MG(2/2), CR, CG, CB AND VM BOARDS BLOCK DIAGRAMS MG(2/2) (R OUTPUT) ( Y/C/J) CN9107 Q0411-0412 IC9101 CLAMP TO FOCUS IC0401(2/2) VIDEO OUT BLOCK J9101 CN9103 Q9105 CN0001(2/2) CN0401 V IN V OUT Q0419 BUFF MID-Y Y IN R OUT R DRV BUFF...
  • Page 87 KP-FX432M90/FX532M90 RM-1014 UG BOARD BLOCK DIAGRAM IC1501 IC1701 AV SW MAIN COLOR DECODER Q1713,Q1714 YOUT3 CVBS/V2 COUT3 IN6-CV J1502 IN9-CR CrOUT Q1707 (VIDEO IN 2) Q1711 BUFF IN9-CB CbOUT Q1502 ,Q5124 Q1705 Q1712 IN5-S IN9-Y YOUT BUFFER IN5-V IC1703 CVBS/V1 IN5-Y IN5-C J1501...

  • Page 88: Frame Schematic Diagram

    KP-FX432M90/FX532M90 RM-1014 6-2. FRAME SCHEMATIC DIAGRAM (R)CRT (G)CRT (B)CRT FOCUS 07MVC31 07MVC31 07MVC31 +12V +12V +12V +12V CN9103 PACK CN9205 CN9204 CN9203 CN9102 CN9309 :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO +210V CN9209 CN9303 CN9107 CN9308 :ONE TOUCH :ONE TOUCH CN9301 :ONE TOUCH :S-MICRO +200V...

  • Page 89: Circuit Boards Location

    KP-FX432M90/FX532M90 RM-1014 6-3. CIRCUIT BOARDS LOCATION 6-4. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS Terminal name of semiconductors in silk screen Note: • All capacitors are in µF unless otherwise noted. (pF: µµF) printed circuit ( Capacitors without voltage indication are all 50 V. Circuit Device Printed symbol...

  • Page 90: Schematic Diagram Of A Board

    KP-FX432M90/FX532M90 RM-1014 (1) Schematic Diagram of A Board CN6000 TO D(3/3)BOARD CN6400 L6002 100µH RECT+ RECT- D6113 KBP153G C6127 STBY7V 0.0022 B:1608 C6002 JW6006 STBY 7V 2200p C6115 CN6001 R6120 250V TO(3/3) JW6007 1000 Q6110 F6000 1/10W T6.3A MSB709-RT1 :CHIP ZERO_DET 250V .BLK05FA...
  • Page 91 KP-FX432M90/FX532M90 RM-1014 CN2019 TU2000 TU2001 WG442(30) R2085 R2102 R2066 IC2002 C2091 C2092 C2090 C2029 S-80843CLUA 470p R2101 C2023 :1608 R2057 C2058 R2063 R2114 B:1608 0.0022 R2108 C2076 B:1608 :1608 :1608 C2066 1 6.3V R2084 C2089 :1608 B:1608 C2099 R2099 L2003 R2069 R2100 C2082...
  • Page 92 KP-FX432M90/FX532M90 RM-1014 CN2004 CN2006 CN2007 CN2005 :BTOB :BTOB :BTOB :B TO B TO D(3/3)BOARD TO D(3/3)BOARD TO MG(1/3)BOARD TO BM(1/4)BOARD CN5004 CN5005 CN0001 CN3001 CN2015 :B TO B TO UG(2/2)BOARD CN1502 TO(2/3) VIDEO TO(2/3) MT_CV MT_VIDEO M_SIIC CN2003 MAIN 9V MAIN 9V MAIN 9V TO(2/3)(3/3)
  • Page 93 KP-FX432M90/FX532M90 RM-1014 •A(3/3) BOARD WAVE FORMS • A BOARD SEMICONDUCTOR LOCATION NTSC SECAM NTSC SECAM NTSC SECAM Q6102 D6115 Q6105 D6116 Component Conductor Side Side Q6107 D6117 IC2000 Q6108 D6118 IC2002 Q6109 D6119 IC6100 Q6110 D6120 2.5V 2.5V 2.5V 2.5V 0.6V 0.6V IC6200...

  • Page 94: Schematic Diagram Of Ad Board

    KP-FX432M90/FX532M90 RM-1014 (2) Schematic Diagram of AD Board IC9603 NJM2391DL1-33(TE1) C9622 3.3V REG +3.3V C9618 C9621 C9709 R9658 R9662 R9666 1608 6.3V 1608 +3.3V 1/10W 1/10W 1/10W 1608 C9657 CHIP CHIP CHIP 6.3V C9650 FB9617 FB9602 C9649 R9607 C9607 RN-CP C9613 C9647 1608...
  • Page 95 KP-FX432M90/FX532M90 RM-1014 [CONV DSP, PJED-CPU] — AD BOARD (COMPONENT SIDE) — — AD BOARD (CONDUCTOR SIDE)— • AD BOARD SEMICONDUCTOR LOCATION TRANSISTER DIODE Component Conductor Component Conductor Component Conductor Side Side Side Side Side Side IC9600 Q9602 D9600 IC9601 Q9603 D9601 IC9602 Q9604...

  • Page 96: Schematic Diagram Of Bm Board

    KP-FX432M90/FX532M90 RM-1014 (3) Schematic Diagram of BM Board CN3402 R3481 R3482 :1608 :1608 C3412 B:1608 9V-1 FL3401 FB3402 FB3401 R3023 :1608 MS_VDD 9V-2 C3032 CN3001 CN3401 F:1608 TO A(3/3)BOARD CN2004 C3036 C3035 FL3000 C3039 R3430 CKD510JB1A105ST :1608 F:1608 :AL-CP F:1608 MAIN_9V DCLK VCLK...
  • Page 97 KP-FX432M90/FX532M90 RM-1014 C3186 100p CH:CHIP L3101 RB3101 10µH C3100 :CHIP 1000p B:1608 FB3101 BK2125HM601 C3101 R3181 R3182 1000p R3187 R3191 B:1608 1/10W 1/10W RB3114 RB3115 RB3116 RB3117 :CHIP :CHIP C3102 R3101 R3102 47 1/10W :CHIP :AL-CP 1/10W R3190 :CHIP R3186 X3101 :1608 79.99MHz...
  • Page 98 KP-FX432M90/FX532M90 RM-1014 FL3200 CKD510JB1A105ST C3206 C3256 L3204 0.01 3.3V TO(2/4)(4/4) 1µH +3.3V :CHIP :AL-CP B:1608 MAIN_CCP M-VS C3208 IC3205 0.01 PQ70XZ01ZP M-HS D3201 2.5V REG B:1608 M-CLK C3211 C3215 C3212 C3213 C3214 0.01 0.01 0.01 0.01 C3209 0.01 R3201 B:1608 B:1608 22 1/10W :CHIP B:1608...
  • Page 99 KP-FX432M90/FX532M90 RM-1014 IC3310 PQ70XZ01ZP 2.5V REG C3304 Q3301 R3302 R3303 FL3304 CKD510JB1A105ST 3.3V 1/10W 1/10W C3392 B:1608 Y_CL :CHIP :CHIP C3354 C3358 3.3V L3317 FL3306 C3305 0.01 6.3V 1µH CKD510JB1A105ST C3306 C3398 Y_CL C3308 6.3V B:1608 B:1608 :AL-CP :CHIP 0.01 C3307 L3314 0.01...
  • Page 100 KP-FX432M90/FX532M90 RM-1014 •BM(1/4) BOARD WAVE FORMS • BM(4/4) IC3303 : CXD2309AQ SECAM NTSC NTSC SECAM NTSC SECAM (LSB) R0 4LSB’S CURRENT CELLS 0.9V 2.5V 2.5V 0.9V 0.6V 0.6V SECAM NTSC 6LSB’S LATCHES CURRENT DECODER CELLS DECODER CLOCK GENERATOR 0.6V 0.6V 4.0V 4.0V (MSB) R9...

  • Page 101: Schematic Diagram Of Cr Board

    KP-FX432M90/FX532M90 RM-1014 (4) Schematic Diagram of CR Board • CR IC9101 : TDA6120Q/N2/S1 I IN 10 VDD MIRROR CASCODE V901 PICTURE OUTC TUBE MIRROR TO HV BLOCK OUTM OUT 1x OUT 4x CURRENT CASCODE INPUT TO FOCUS BLOCK (R OUTPUT) CN9110 J9101 :FASTON...

  • Page 102: Schematic Diagram Of Cb Board

    KP-FX432M90/FX532M90 RM-1014 (5) Schematic Diagram of CB Board • CB IC9201 : TDA6120Q/N2/S1 I IN 10 VDD MIRROR CASCODE V903 PICTURE OUTC TUBE MIRROR HV BLOCK OUTM OUT 1x OUT 4x CASCODE CURRENT INPUT TO FOCUS BLOCK (B OUTPUT) J9301 CN9310 TO FOCUS BLOCK VIN+...

  • Page 103: Schematic Diagram Of Cg Board

    KP-FX432M90/FX532M90 RM-1014 (6) Schematic Diagram of CG Board • CG IC9301 : TDA6120Q/N2/S1 I IN V902 10 VDD PICTURE TUBE MIRROR CASCODE TO HV BLOCK OUTC MIRROR OUTM OUT 1x OUT 4x CASCODE CURRENT TO FOCUS BLOCK TO FOCUS BLOCK INPUT CN9209 (G OUTPUT)

  • Page 104: Schematic Diagram Of D Board

    KP-FX432M90/FX532M90 RM-1014 (7) Schematic Diagram of D Board R5243 1/10W R5247 :CHIP 4.7k 1/10W Q5203 :CHIP C5223 R5241 Q5201 MSD601RT1 FQPF12P20YDTU BUFF 1/10W R5202 +135V SW D5209 C5201 R5201 B:1608 :CHIP R5203 R5204 1PS184-115 0.01 TO(2/3)(3/3) H_PLS 1/10W 1/10W :RN-CP :RN-CP R5245 1/10W...
  • Page 105 KP-FX432M90/FX532M90 RM-1014 +135V TO(1/3)(3/3) +135V R8166 C8037 0.056 1/10W +12V 800V MAIN :CHIP :MPP TP8001 CN8001 Q8003 FB8002 FB8003 0.45UH 0.45UH MSD601RT1 T8001 (CONTACT) RHT(NX-6030) D8038 IC8002 Q8014 JL8016 MM3Z15VT1 FB8001 D8024 MCZ3001DA 2SK2842 R8056 0.45UH MM3Z6V2ST1 JL8021 DRIVER TO HV BLOCK 9.1k 279.4 R8146...
  • Page 106 KP-FX432M90/FX532M90 RM-1014 CN5017 :S-MICRO TO A(3/3)BOARD CN2017 AUDIO-14V-22V -22V AUDIO-14V-22V AUDIO_GND AUDIO_GND AUDIO+14V+22V +22V AUDIO+14V+22V CN5004 CN5016 :B TO B TO A(3/3)BOARD :S-MICRO CN2006 DF_PARA DF_PARA TO(2/3) DF_DRV DF_DRV H DRV H_DRV TO(1/3) V_SHIFT V_SHIFT TO(1/3) HC_PARA HC_PARA HV PROT HV_PROT -0.4 TO(2/3)
  • Page 107 KP-FX432M90/FX532M90 RM-1014 • D(3/3) IC5101 : LA78045 [H/V OUT, H CENTER, HV LEG, POWER SUPPLY] — D BOARD (CONDUCTOR SIDE)— R5577 Q5521 R5576 JR1003 R5578 C5560 R5579 R8062 R5595 C5561 R5592 Q5526 Q5528 R5597 R5591 Q5527 Q5525 R8166 Q8004 Q8003 R8057 R8056 C8007...

  • Page 108: Schematic Diagram Of Ds Board

    KP-FX432M90/FX532M90 RM-1014 (8) Schematic Diagram of DS Board CN9407 CN9405 CN9406 CN9408 :S-MICRO :S-MICRO :S-MICRO :S-MICRO TO DY(R) TO DY(G) CN9401 :S-MICRO -17V R9473 TO D(1/3)BOARD -17VB DY(RED) CN5015 R9471 DS-GND +17V R9466 +17VB R9472 R9474 R9467 V DEF V_PULSE C9426 C9427 MAIN...
  • Page 109 KP-FX432M90/FX532M90 RM-1014 •DS BOARD WAVE FORMS • DS BOARD SEMICONDUCTOR LOCATION DIODE Component Conductor Component Conductor Side Side Side Side IC9400 D9407 IC9401 D9409 6.5V 6.0V 2.0V 2.0V 1.1V 21.2V : Refer to Terminal name of semiconductors in silk screen printed circuit (see page 100) 37.4V [H/V CONV.

  • Page 110: Schematic Diagram Of Ha And Hb1 Boards

    KP-FX432M90/FX532M90 RM-1014 (9) Schematic Diagram of HA and HB1 Boards C1105 IC1000 R1013 R1107 D1104 RPM7140-H8 ST5V MM3Z10VT1 1/4W SIRCS 1/10W PROTECT D1008 :RN-CP CN1000 R1003 R1008 R1005 PROTECT WHT-L 1/10W 1/10W :S-MICRO :CHIP 1/10W :CHIP R1012 :CHIP TO MG BOARD 1/10W :CHIP CN0004...

  • Page 111: Schematic Diagram Of Hc Board

    KP-FX432M90/FX532M90 RM-1014 (10) Schematic Diagram of HC Board CN1050 CN1051 WHT-L WHT-L TO A(1/3)BOARD TO A(1/3)BOARD CN6005 CN6006 S1050 (POWER) (P.SWITCH) B-SS997<CH.>-HC. [P. SWITCH] — HC BOARD (CONDUCTOR SIDE)— – 143 – – 144 –...

  • Page 112: Schematic Diagram Of Mg Board

    KP-FX432M90/FX532M90 RM-1014 (11) Schematic Diagram of MG Board CN0004 CN0007 :S-MICRO :S-MICRO TO HA BOARD TO DS BOARD CN1000 CN9403 JR1001 0 :1608 JR1002 0 :1608 JR1005 FB0005 0 :1608 BK1608TS601 JR1006 0 :1608 JR1007 R0084 0 :1608 Q0008 REGI_SIGNAL 1/10W MSB709-RT1 :CHIP...
  • Page 113 KP-FX432M90/FX532M90 RM-1014 PF_IIC TO (1/3)(3/3) FB0301 BK1608TS601 PF_SCLK PF_SDAT C0316 R0333 C0345 R0340 C0339 2200 :1608 R0332 F:1608 C0331 C0323 C0327 R0327 C0317 0.0033 0.001 R0325 2.2k B:1608 B:1608 1/10W C0320 C0333 AUDIO R C0325 C0329 1/10W :CHIP 33000p MAIN_R :MPS :CHIP AUDIO_GND...
  • Page 114 KP-FX432M90/FX532M90 RM-1014 R0513 R0520 1/10W 1/10W :CHIP :CHIP C0462 TEXT_CV FB0401 BK1608TS601 TO (1/3) M_SCLK B:1608 M_SDATA FB0402 TO (1/3) BK1608TS601 REGI_SIGNAL Q0431 MSD601-RT1 BUFF R/G/B R0519 R0512 1/10W 1/10W :CHIP :CHIP R0521 L0401 10µH R0440 L0405 :GLF2012 10µH :GLF2012 C0432 R0430 C0436...
  • Page 115 KP-FX432M90/FX532M90 RM-1014 •MG(1/3) BOARD WAVE FORMS • MG(1/3) IC0050 : MM1482BFBE • MG(2/3) IC0301 : NJM4560M NTSC SECAM NTSC – – 3 4 5 6 7 3.4V 1.5V 1.5V 2.5V 2.5V 0.6V NTSC SECAM SECAM THERMAL PROTECT RESET 0.6V 0.6V 0.6V 4.0V 4.0V...

  • Page 116: Schematic Diagram Of Sr Board

    KP-FX432M90/FX532M90 RM-1014 (12) Schematic Diagram of SR Board (13) Schematic Diagram of VM Board CN9901 VM(B) (VELOCITY MODULATION) :S-MICRO CN9001 SB9901 TO AD BOARD R9001 SENSOR CN9600 :S-MICRO CN9003 TO D(3/3)BOARD 1/4W FB9001 +135V :FPRD MPZ2012S331 +135V CN5019 :B TO B-P SENSOR +135V +135V...

  • Page 117: Schematic Diagram Of Ug Board

    KP-FX432M90/FX532M90 RM-1014 (14) Schematic Diagram of UG Board VD1534 VD1535 VD1536 JR1502 VD1537 :CHIP J1509 L1508 R1634 VD1538 (COMPONENT IN1) 10µH C1590 R1633 2.2M VD1533 +5VA L1501 2.2M 1/10W VD1539 V5 Y 10µH 1/10W :CHIP B:1608 :CHIP VD1540 R1655 R1656 1/10W 1/10W C1524...
  • Page 118 KP-FX432M90/FX532M90 RM-1014 R1751 R1745 1/10W C1599 T1501 :CHIP 1/16W J1505 :RN-CP CH:1608 VD1543 JL1501 CENTER R1747 R1748 JL1502 1/4W 1/4W :FPRD :FPRD C1600 R1749 R1750 CH:1608 R1746 1/4W 1/4W 1/16W R1752 :FPRD :FPRD :CHIP 1/10W R1816 :CHIP FB1801 1/10W :CHIP :CHIP SUB_Y L1801...

  • Page 119: Semiconductors

    KP-FX432M90/FX532M90 RM-1014 • UG BOARD SEMICONDUCTOR LOCATION DIODE Q1511 D1529 Q1512 D1530 Component Conductor Component Conductor Side Side Side Side Q1513 D1531 IC1501 Q1514 D1501 D1532 IC1502 Q1515 D1502 D1533 IC1701 Q1516 D1503 D1534 IC1703 Q1517 D1507 D1535 IC1801 Q1523 D1508 D1538 IC1802...
  • Page 120 KP-FX432M90/FX532M90 RM-1014 6-5. SEMICONDUCTORS CXA2189Q-TL LA78045 NJM79L05A SN65LVDT14PWR 2SA1208S-TP 2SK2036(TE85L) TRANSISTOR NJM79L05A-T3 SN65LVDT41PWR AK4352VT-E2 DTA144EE-TL CY27027ZCT DTC144EE-TL TOP VIEW DTC144EUA-T106 TOP VIEW V IN MSB709-RT1 80Pin QFP V OUT MSD601-RT1 20Pin SOP 2SK2251-01-F19 UN2211-TX CXD2095AQ NJU7223F50 2PB709AR-115 STK392-560 2SA1162-G TOP VIEW LMH6658MM/NOPB 2SA1358-Y 2SA1226-E4...
  • Page 121 KP-FX432M90/FX532M90 RM-1014 D1NS4 EC31QS03L-TE12L RD33EB3T DIODE D2L20U D2L20U-F ANODE CATHODE D2L20U-TA MTZJ-33C DAN202K-T-146 MTZJ-T-77-10B MTZJ-T-77-15B MTZJ-T-77-33C CATHODE RB441Q-40T-77 RD10ESB2 F10P04Q ANODE RD15ESB1 RD15ESB2 1PS181-115 RD15ES-T1B RD33ES-T1B3 RD5.1ESB2 DTZ10B DTZ5.1B CATHODE HZU10BTRF MA111-TX MMDL914T1 PDZ15B-115 PDZ5.6B-115 HN1D03FU-TE85R RD5.6SB3 1PS184-115 RD5.6SB3-T1 ANODE RD5.6SB-T1 RD6.2SB3-T1 D1NS4-TR2...

  • Page 123: Exploded Views

    18 19 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK 4-086-336-02 PANEL, SIDE (53R) (KP-FX532M90) * X-4042-353-1 PANEL, FRONT (53) ASSY 2-6,17-23 4-089-880-01 LABEL, TERMINAL (A) (KP-FX532M90) 4-089-154-01 LABEL (INDICATION), TERMINAL * X-4042-354-1 PANEL (43) ASSY, FRONT 2-6,17-23...

  • Page 124: Cabinet Block (Kp-Fx532)

    KP-FX432M90/FX532M90 RM-1014 7-2. CABINET BLOCK (KP-FX532) The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. PICTURE TUBE BLOCK ASSY MAIN BLOCK ASSY REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK 4-378-522-01 SCREW, TAPPING, HEXAGON HEAD * X-4042-346-1 CABINET (53), BOTTOM ASSY 51,52,53...

  • Page 125: Cabinet Block (Kp-Fx432)

    KP-FX432M90/FX532M90 RM-1014 7-3. CABINET BLOCK (KP-FX432) The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. PICTURE TUBE BLOCK ASSY MAIN BLOCK ASSY REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK 4-378-522-01 SCREW, TAPPING, HEXAGON HEAD 4-076-577-11 FOOT...

  • Page 126: Bezenet And Mirror Cover Block (Kp-Fx532)

    KP-FX432M90/FX532M90 RM-1014 7-4. BEZENET AND MIRROR COVER BLOCK (KP-FX532) REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK 4-089-284-11 SCREEN (53), CONTRAST * 4-086-645-01 HOLDER (SL), MIRROR 4-089-285-11 PLATE (53L), DIFFUSION 4-378-522-01 SCREW, TAPPING, HEXAGON HEAD 4-089-286-11 PLATE (53F), DIFFUSION * 4-086-334-02 COVER, MIRROR (53) * X-4042-348-1 BEZEL (53) ASSY * 4-095-695-01 HOLDER (B), SENSER...

  • Page 127: Bezenet And Mirror Cover Block (Kp-Fx432)

    KP-FX432M90/FX532M90 RM-1014 7-5. BEZENET AND MIRROR COVER BLOCK (KP-FX432) REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK 4-089-287-11 SCREEN (43), CONTRAST * 4-086-648-01 HOLDER (TOP), MIRROR 4-089-288-11 PLATE (43L), DIFFUSION 4-089-324-01 MIRROR (43) 4-089-289-11 PLATE (43F), DIFFUSION * 4-086-645-01 HOLDER (SL), MIRROR * X-4042-349-1 BEZEL (43) ASSY * 4-086-646-01 HOLDER (SR), MIRROR * 4-095-698-01 HOLDER (43 SIDE), SCREEN...

  • Page 128: Main Bracket And Picture Tube Block

    * A-1405-767-A CR BOARD, MOUNT * A-1302-776-A MG BOARD, COMPLETE * A-1405-770-A VM BOARD, MOUNT * A-1302-483-A A BOARD, COMPLETE ! A-1604-487-A MECHA SEAL (B) ASSY (KP-FX532M90) ! 1-451-537-14 DEFLECTION YOKE ! A-1604-506-A MECHA SEAL (B) ASSY (KP-FX432M90) ! 1-451-535-13 COIL ASSY, VM...

  • Page 129: Electrical Parts List

    KP-FX432M90/FX532M90 RM-1014 SECTION 8 ELECTRICAL PARTS LIST • The components identified by in this manual RESISTORS NOTE: have been carefully factory-selected for each set in • All resistors are in ohms order to satisfy regulations regarding X-ray • F : nonflammable The components identified by shading radiation.
  • Page 130 KP-FX432M90/FX532M90 RM-1014 The components identified by shading and mark!are criti-cal for safety. CG CB Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1405-768-A CG BOARD, MOUNT <TRANSISTOR> ************************ Q9201 8-729-010-25 TRANSISTOR MSD601-RT1 4-382-854-11 SCREW (M3X10), P, SW (+)
  • Page 131 KP-FX432M90/FX532M90 RM-1014 The components identified by shading and mark!are criti-cal for safety. CB VM Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CONNECTOR> R9314 1-218-864-11 METAL CHIP 5.1K 0.50% 1/10W R9315 1-218-851-11 METAL CHIP 1.5K...
  • Page 132 KP-FX432M90/FX532M90 RM-1014 VM A REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CONNECTOR> * A-1302-483-A A BOARD, COMPLETE *************************** CN9001 * 1-564-508-11 PLUG, CONNECTOR 5P CN9002 * 1-564-506-11 PLUG, CONNECTOR 3P 4-382-854-01 SCREW (M3X8), P, SW (+) CN9003 * 1-770-723-11 CONNECTOR, BOARD TO BOARD 8P 4-382-854-11 SCREW (M3X10), P, SW (+) <FERRITE BEAD>...
  • Page 133 KP-FX432M90/FX532M90 RM-1014 The components identified by shading and mark!are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C2072 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V CN2014 * 1-564-506-11 PLUG, CONNECTOR 3P C2073 1-164-156-11 CERAMIC CHIP 0.1UF CN2015 * 1-793-495-11 CONNECTOR, BOARD TO BOARD 50P...
  • Page 134 KP-FX432M90/FX532M90 RM-1014 The components identified by shading and mark!are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <IC> JR6206 1-216-295-91 SHORT CHIP JR6207 1-216-864-11 SHORT CHIP IC2000 6-704-233-01 IC TDA7490 JR6209 1-216-864-11 SHORT CHIP...
  • Page 135 KP-FX432M90/FX532M90 RM-1014 The components identified by shading and mark!are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R2008 1-216-839-11 METAL CHIP 1/10W R6004 ! 1-240-303-31 CEMENTED 0.22 R2009 1-216-815-11 METAL CHIP 1/10W...
  • Page 136 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C5015 1-216-864-11 SHORT CHIP C6407 1-130-495-00 MYLAR 0.1UF 5.00% 50V C5016 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C6409 1-126-947-11 ELECT 47UF 20.00% 35V C5017 1-104-987-11 MYLAR 0.001UF 5.00% 200V C6411...
  • Page 137 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C8045 1-130-471-00 MYLAR 0.001UF 5.00% 50V D6503 8-719-060-88 DIODE D4SBS6 C8046 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V D6508 8-719-062-40 DIODE D4SBL20UF3 D6509 8-719-052-90 DIODE D1NL40-TA2 C8048 1-130-495-00 MYLAR 0.1UF 5.00% 50V...
  • Page 138 KP-FX432M90/FX532M90 RM-1014 The components identified by shading and mark!are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK IC5402 8-759-803-42 IC LA6500-FA L6502 1-412-525-31 INDUCTOR 10UH IC5403 8-759-701-01 IC NJM2904M L6503 1-412-525-31 INDUCTOR 10UH...
  • Page 139 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R5003 1-243-709-21 METAL OXIDE 4.7K R5421 1-216-821-11 METAL CHIP 1/10W R5010 1-243-801-21 METAL OXIDE 0.22 R5424 1-215-906-21 METAL OXIDE R5019 1-216-829-11 METAL CHIP 4.7K 1/10W R5427 1-243-713-21 METAL OXIDE R5430 1-216-833-11 METAL CHIP...
  • Page 140 KP-FX432M90/FX532M90 RM-1014 • The components identified by in this manual have been carefully factory-selected for each set in The components identified by shading order to satisfy regulations regarding X-ray and mark!are criti-cal for safety. radiation. Should replacement be required, replace Replace only with part number specified.
  • Page 141 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1302-396-A AD BOARD, COMPLETE C9666 1-125-837-91 CERAMIC CHIP 1UF 6.3V ***************************** C9668 1-125-837-91 CERAMIC CHIP 1UF 6.3V C9672 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V <CAPACITOR> C9676 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V...
  • Page 142 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK FB9622 1-414-445-11 FERRITE R9622 1-216-821-11 METAL CHIP 1/10W R9623 1-216-821-11 METAL CHIP 1/10W FB9623 1-414-445-11 FERRITE R9626 1-216-809-11 METAL CHIP 1/10W FB9624 1-414-445-11 FERRITE R9627 1-216-809-11 METAL CHIP 1/10W FB9625 1-414-445-11 FERRITE...
  • Page 143 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R9692 1-218-871-11 METAL CHIP 0.50% 1/10W C3104 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V R9693 1-218-868-11 METAL CHIP 7.5K 0.50% 1/10W C3105 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C3106 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V...
  • Page 144 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3167 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C3253 1-164-156-11 CERAMIC CHIP 0.1UF C3168 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C3254 1-164-156-11 CERAMIC CHIP 0.1UF C3255 1-127-760-11 CERAMIC CHIP 4.7UF 6.3V C3169 1-126-206-11 ELECT CHIP...
  • Page 145 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3395 1-124-779-00 ELECT CHIP 10UF 20.00% 16V IC3301 8-759-672-57 IC CXD9509AQ C3396 1-124-779-00 ELECT CHIP 10UF 20.00% 16V IC3302 6-702-953-01 IC K4S643232F-TC60T C3397 1-125-837-91 CERAMIC CHIP 1UF 6.3V IC3303 8-752-409-20 IC CXD2309AQ...
  • Page 146 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3032 1-216-864-11 SHORT CHIP R3145 1-218-841-11 METAL CHIP 0.50% 1/10W R3034 1-216-864-11 SHORT CHIP R3146 1-218-841-11 METAL CHIP 0.50% 1/10W R3035 1-543-949-22 FERRITE R3147 1-218-855-11 METAL CHIP 2.2K 0.50% 1/10W R3148...
  • Page 147 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3235 1-216-864-11 SHORT CHIP R3387 1-211-985-11 METAL CHIP 0.50% 1/10W R3238 1-216-864-11 SHORT CHIP R3388 1-216-864-11 SHORT CHIP R3389 1-216-864-11 SHORT CHIP R3242 1-216-864-11 SHORT CHIP R3391 1-216-829-11 METAL CHIP 4.7K...
  • Page 148 KP-FX432M90/FX532M90 RM-1014 BM MG REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK RB3205 1-233-576-11 RES, CHIP NETWORK 100 C0047 1-126-933-11 ELECT 100UF 20.00% 16V RB3206 1-233-576-11 RES, CHIP NETWORK 100 C0048 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V RB3207 1-233-576-11 RES, CHIP NETWORK 100 RB3208 1-233-576-11 RES, CHIP NETWORK 100 C0049...
  • Page 149 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C0337 1-125-889-91 CERAMIC CHIP 2.2UF C0456 1-164-156-11 CERAMIC CHIP 0.1UF C0338 1-165-908-11 CERAMIC CHIP 1UF C0458 1-126-933-11 ELECT 100UF 20.00% 16V C0339 1-126-768-11 ELECT 2200UF 20.00% 16V C0340 1-165-908-11 CERAMIC CHIP 1UF C0459...
  • Page 150 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK L0404 1-469-559-21 INDUCTOR 47UH <FILTER> L0405 1-400-397-11 INDUCTOR 10UH L0406 1-400-397-11 INDUCTOR 10UH FL0001 1-239-895-11 FILTER, EMI (SMD) L0407 1-400-397-11 INDUCTOR 10UH FL0002 1-239-895-11 FILTER, EMI (SMD) L0408 1-400-397-11 INDUCTOR 10UH...
  • Page 151 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK Q0430 8-729-029-14 TRANSISTOR DTC144EUA-T106 R0085 1-216-841-11 METAL CHIP 1/10W Q0431 8-729-010-25 TRANSISTOR MSD601-RT1 R0086 1-216-821-11 METAL CHIP 1/10W Q0433 8-729-029-04 TRANSISTOR DTC123JUA-T106 R0088 1-216-833-11 METAL CHIP 1/10W Q0434 8-729-029-14 TRANSISTOR...
  • Page 152 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R0198 1-216-825-11 METAL CHIP 2.2K 1/10W R0341 1-216-809-11 METAL CHIP 1/10W R0199 1-216-809-11 METAL CHIP 1/10W R0200 1-216-821-11 METAL CHIP 1/10W R0342 1-216-864-11 SHORT CHIP R0201 1-216-813-11 METAL CHIP 1/10W R0343...
  • Page 153 KP-FX432M90/FX532M90 RM-1014 MG UG REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R0466 1-216-825-11 METAL CHIP 2.2K 1/10W <CRYSTAL> R0468 1-216-825-11 METAL CHIP 2.2K 1/10W R0469 1-216-825-11 METAL CHIP 2.2K 1/10W X0001 1-781-282-51 VIBRATOR, CERAMIC (4MHz) R0470 1-216-829-11 METAL CHIP 4.7K...
  • Page 154 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CONNECTOR> C1569 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V C1573 1-164-505-11 CERAMIC CHIP 2.2UF CN1501 * 1-564-526-31 PLUG, CONNECTOR 11P C1574 1-164-505-11 CERAMIC CHIP 2.2UF CN1502 * 1-793-498-11 CONNECTOR, BOARD TO BOARD 50P C1575 1-126-961-11 ELECT 2.2UF...
  • Page 155 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK J1509 1-774-358-11 JACK BLOCK, PIN R1508 1-216-811-11 METAL CHIP 1/10W J1510 1-816-597-11 PIN JACK BLOCK 2P R1509 1-216-811-11 METAL CHIP 1/10W R1510 1-216-811-11 METAL CHIP 1/10W R1511 1-216-853-11 METAL CHIP 470K...
  • Page 156 KP-FX432M90/FX532M90 RM-1014 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R1581 1-216-809-11 METAL CHIP 1/10W R1681 1-216-809-11 METAL CHIP 1/10W R1582 1-216-811-11 METAL CHIP 1/10W R1689 1-216-813-11 METAL CHIP 1/10W R1690 1-216-845-11 METAL CHIP 100K 1/10W R1583 1-216-809-11 METAL CHIP 1/10W...
  • Page 157 KP-FX432M90/FX532M90 RM-1014 The components identified by shading and mark!are criti-cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <IC LINK> * A-1405-771-A DS BOARD, MOUNT ************************ PS9400! 1-533-595-31 IC LINK 3.15A PS9401! 1-533-595-31 IC LINK 3.15A...
  • Page 158 KP-FX432M90/FX532M90 RM-1014 DS HA HC REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R9462 1-214-808-11 METAL 1/2W <SWITCH> R9463 1-214-808-11 METAL 1/2W R9464 1-214-808-11 METAL 1/2W S1000 1-572-198-11 SWITCH, KEYBOARD (VOLUME –) S1001 1-572-198-11 SWITCH, KEYBOARD (VOLUME +) R9465 1-214-808-11 METAL 1/2W...
  • Page 159 1-565-665-12 TERMINAL, S 4P ! A-1604-483-A MECHA SEAL (G) ASSY J1102 1-750-517-11 JACK BLOCK, PIN 3P ! A-1604-485-A MECHA SEAL (R) ASSY (KP-FX532M90) ! A-1604-487-A MECHA SEAL (B) ASSY (KP-FX532M90) ! A-1604-504-A MECHA SEAL (R) ASSY (KP-FX432M90) <RESISTOR> ! A-1604-506-A MECHA SEAL (B) ASSY (KP-FX432M90)
  • Page 160 Sony EMCS Corporation 2003KR08-1 9-965-381-01 © 2003. 11 Ichinomiya Tec – 204 –...
