Sony KP-FS57M31 Service Manual

Ag-3x chassis
Hide thumbs Also See for KP-FS57M31:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
SERVICE MANUAL
MODEL
COMMANDER
KP-FS57M31
RM-997
KP-FS57M61
RM-997
KP-FS57M90
RM-997
KP-FS57M91
RM-997
DEST. CHASSIS NO.
AUS
SCC-XXX-A
GE
SCC-XXX-A
HK
SCC-XXX-A
ME
SCC-XXX-A
VIDEO
DRC-MF
A/B
V CENTER
HD/DVD
1
2
3
4
5
6
7
8
9
0
JUMP
PROG
OPTION
RESET
TV
RM-997
AG-3X
MODEL
COMMANDER
KP-FS57M31/M61/M90/M91
PROJECTION TV
CHASSIS
DEST. CHASSIS NO.

Advertisement

Table of Contents
loading

Related Manuals for Sony KP-FS57M31

Summary of Contents for Sony KP-FS57M31

  • Page 1 SERVICE MANUAL AG-3X CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KP-FS57M31 RM-997 SCC-XXX-A KP-FS57M61 RM-997 SCC-XXX-A KP-FS57M90 RM-997 SCC-XXX-A KP-FS57M91 RM-997 SCC-XXX-A VIDEO DRC-MF V CENTER HD/DVD JUMP PROG OPTION RESET RM-997 KP-FS57M31/M61/M90/M91 PROJECTION TV...
  • Page 2 VIEWS AND IN THE PARTS LIST ARE CRITICAL TO REMOVING THE ANODE. SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS AP- PEAR AS SHOWN IN THIS MANUAL OR IN SUPPLE- MENTS PUBLISHED BY SONY. – 2 –...

  • Page 3: Table Of Contents

    KP-FS57M31/M61/M90/M91 RM-997 TABLE OF CONTENTS Section Title Page Section Title Page 1. SELF DIAGNOSIS FUNCTION 3-11. Service List ............1-1. Diagnostic Test Indicators ......... 3-12. Registration Adjustment 1-2. Display of STANDBY/TIMER 3-12-1. Adjustment Flow ..........Light Flash Count ..........3-12-2. Setup for Adjustment ........
  • Page 4 KP-FS57M31/M61/M90/M91 RM-997 Section Title Page 6-5. Printed Wiring Boards ........144 6-6. Wave Forms ............168 6-7. IC Block Diagrams ..........172 6-8. Semiconductors ..........178 7. EXPLODED VIEWS 7-1. Front Panel Block ..........181 7-2. Cabinet Block (KP-FS53) ........ 182 7-3.

  • Page 5: Self Diagnosis Function

    KP-FS57M31/M61/M90/M91 RM-997 SECTION 1 SELF DIAGNOSIS FUNCTION The unit in this manual contain a self-diagnostic function. If any error occurs, the STANDBY/TIMER lamp will automatically begin to flash. The number of times the lamp flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER lamp flash indicators is listed in the instruction manual for the user's knowledge and reference.

  • Page 6: Display Of Standby/Timer Light Flash Count

    KP-FS57M31/M61/M90/M91 RM-997 1-2. DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT 2 times 3 times Lamp ON 0.3 sec. Lamp OFF Lamp OFF 3 sec. 0.3 sec. 4 times 5 times 6 times 7 times Diagnostic Item Flash Count * +B overcurrent...

  • Page 7: Self-Diagnostic Screen Display

    KP-FS57M31/M61/M90/M91 RM-997 1-4. SELF-DIAGNOSTIC SCREEN DISPLAY For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurrences of failure for confirmation on the screen:...

  • Page 8: Self-Diagnostic Circuit

    KP-FS57M31/M61/M90/M91 RM-997 1-6. SELF-DIAGNOSTIC CIRCUIT From IC1203,1204 (A board) To H1 board From G board IC4300 IC001 SYSTEM Y/C JUNGLE From CRT (IK) 24 IKIN 5 OCP LED1 22 From IC8005,8006 57 XRAY 8 OVP IC003 (D board) MEMORY Q1209-1211...

  • Page 9: Disassembly

    KP-FS57M31/M61/M90/M91 RM-997 SECTION 2 DISASSEMBLY 2-2. MAIN BRACKET REMOVAL 2-1. REAR COVER REMOVAL 1 Optical shield 2 Rear board 2 Two screws (tapping screw hexagon head) 3 Main bracket section 1 Ten screws (Hexagon head) 2-3. SERVICE POSITION 2 Eight screws...

  • Page 10: Front Panel Removal

    KP-FS57M31/M61/M90/M91 RM-997 2-4. FRONT PANEL REMOVAL 2 Two screws (tapping screw hexagon head) 3 Two screws 4 Side panel L(57) assy (tapping screw hexagon head) 3 Two screws (tapping screw 1 three screws hexagon head) (BVTP 4x16) 2 Two screws...

  • Page 11: Beznet And Mirror Cover Removal

    KP-FS57M31/M61/M90/M91 RM-997 2-6. BEZNET AND MIRROR COVER REMOVAL 1 Three screws (BVTP 4X25) 3 Mirror cover 7 Ten screws 1 Three screws (BVTP 4X12) 2 Two screws (BVTP 4X25) (Hexagon head) 8 Screen holder 1 Three screws 6 Screen short...

  • Page 12: G Board Removal

    KP-FS57M31/M61/M90/M91 RM-997 2-8. G BOARD REMOVAL 1 Four holder PWB Main bracket section 2 G board 2-9. CONNECTOR COVER REMOVAL 3 Connector cover section RF Connector 2 Screw (PSW 2.6X6) 1 Tow screws (BVTP 4X16) Main bracket section – 12 –...

  • Page 13: J Board Removal

    KP-FS57M31/M61/M90/M91 RM-997 2-10. J BOARD REMOVAL 3 Four screws 5 Connector cover (BVTP X12) 4 J board 2 J board cover 1 Four screws (BVTP 3X12) 2-11. A1, E, B4, AND V2 BOARDS REMOVAL 3 Four screws (Hexagon head) 2 E board...

  • Page 14: A, Ad And D Boards Removal

    KP-FS57M31/M61/M90/M91 RM-997 2-12. A, AD AND D BOARDS REMOVAL 1 A board 3 Five screws 2 AD board (BVTP 3X12) 4 D board 2-13. PICTURE TUBE REMOVAL 1 Two screws 2 Three screws (BVTP 4X16) (Hexagon head) 2 Three screws...

  • Page 15: High-Voltage And Cable Installation Removal

    KP-FS57M31/M61/M90/M91 RM-997 2-14 HIGH-VOLTAGE CABLE 2-15. MECHASEAL INSTALLATION AND REMOVAL (1) Remover Removing the arrow-marked screw is strictly inhibited. If removed, it may cause liquid spill. 1 Rubber cap 7 Two screws 2 HV cable turn 90° (BVTP 4X16) 8 Heat sink...

  • Page 16: Set-Up Adjustments

    KP-FS57M31/M61/M90/M91 RM-997 SECTION 3 SET-UP ADJUSTMENTS 3-1. SCREEN VOLTAGE ADJUSTMENT 5. Rotate the green lens and align to obtain the best lens focus (ROUGH ALIGNMENT) at the center area. 6. Rotate the green focus VR on the focus pack and align to 1.

  • Page 17: 2-Pole Magnet Adjustment

    KP-FS57M31/M61/M90/M91 RM-997 3-5. 2-POLE MAGNET ADJUSTMENT 3-8. DEFOCUS ADJUSTMENT (BLUE) 1. Receive the Dot signal. 1. Receive the Dot signal. 2. Place the caps on the red and blue lens so that only the green 2. Cover the both red and green picture lenses with the lens color is shown.

  • Page 18: Adjustment With Commander

    KP-FS57M31/M61/M90/M91 RM-997 3-10. ADJUSTMENTS WITH COMMANDER 3-10-1. How to Select Each Mode Service adjustment to this model can performed with the supplied remote commander RM-998 50 Hz 60 Hz WIDE 60 Hz WIDE 50 Hz (PAL) (NTSC) (NTSC) (PAL) DRC1250...

  • Page 19: Method Of Cancellation From Service Mode

    KP-FS57M31/M61/M90/M91 RM-997 3-10-3. Method of Cancellation from Service 3-10-5. How to Write the Data Mode 1. Set in the service mode. 1. Set the standby mode (Press “ (TV STANDBY)” button on 2. Press “1” or “4” button on the commander, select the ad- justment item, and press “3”...

  • Page 20: Service List

    KP-FS57M31/M61/M90/M91 RM-997 3-11. SERVICE LIST – 20 –...
  • Page 21 KP-FS57M31/M61/M90/M91 RM-997 – 21 –...
  • Page 22 KP-FS57M31/M61/M90/M91 RM-997 – 22 –...
  • Page 23 KP-FS57M31/M61/M90/M91 RM-997 – 23 –...
  • Page 24 KP-FS57M31/M61/M90/M91 RM-997 – 24 –...
  • Page 25 KP-FS57M31/M61/M90/M91 RM-997 – 25 –...
  • Page 26 KP-FS57M31/M61/M90/M91 RM-997 – 26 –...
  • Page 27 KP-FS57M31/M61/M90/M91 RM-997 – 27 –...
  • Page 28 KP-FS57M31/M61/M90/M91 RM-997 – 28 –...
  • Page 29 KP-FS57M31/M61/M90/M91 RM-997 – 29 –...
  • Page 30 KP-FS57M31/M61/M90/M91 RM-997 – 30 –...
  • Page 31 KP-FS57M31/M61/M90/M91 RM-997 – 31 –...
  • Page 32 KP-FS57M31/M61/M90/M91 RM-997 – 32 –...
  • Page 33 KP-FS57M31/M61/M90/M91 RM-997 – 33 –...
  • Page 34 KP-FS57M31/M61/M90/M91 RM-997 – 34 –...
  • Page 35 KP-FS57M31/M61/M90/M91 RM-997 – 35 –...
  • Page 36 KP-FS57M31/M61/M90/M91 RM-997 – 36 –...
  • Page 37 KP-FS57M31/M61/M90/M91 RM-997 – 37 –...
  • Page 38 KP-FS57M31/M61/M90/M91 RM-997 – 38 –...
  • Page 39 KP-FS57M31/M61/M90/M91 RM-997 – 39 –...
  • Page 40 KP-FS57M31/M61/M90/M91 RM-997 – 40 –...
  • Page 41 KP-FS57M31/M61/M90/M91 RM-997 – 41 –...
  • Page 42 KP-FS57M31/M61/M90/M91 RM-997 – 42 –...
  • Page 43 KP-FS57M31/M61/M90/M91 RM-997 – 43 –...
  • Page 44 KP-FS57M31/M61/M90/M91 RM-997 – 44 –...
  • Page 45 KP-FS57M31/M61/M90/M91 RM-997 – 45 –...
  • Page 46 KP-FS57M31/M61/M90/M91 RM-997 – 46 –...

  • Page 47: Registration Adjustment

    KP-FS57M31/M61/M90/M91 RM-997 3-12. REGISTRATION ADJUSTMENT 3-12-2. Setup for Adjustment 1. Marking 1) At the 4 insides of the screen, locate the middle. Use a tape 3-12-1.ADJUSTME FLOW measure to identify the middle. START : midlle Turn on the power and wait for 10 minutes...

  • Page 48: Operation Method For Projector Engine (Pje) Mode

    KP-FS57M31/M61/M90/M91 RM-997 1. Functions of Keys on Commander 6. Write “VPS, VSZ and HSZ” adjusted data to other mode • 1 : Changes adjustment item. (item No. moves up) service data. : Marker moves clockwise from center to outside. <Write “VPS”,“VSZ”,“HSZ”>...

  • Page 49: Method Of Projector Engine Adjustment

    KP-FS57M31/M61/M90/M91 RM-997 4) In the GRN, BLU, or RED mode, move “ ” up or down to • Fine adjustment can be made on the basis of marker position change the data in vertical direction, or move “ ” to the left using joystick key.
  • Page 50 KP-FS57M31/M61/M90/M91 RM-997 6) Select “GRN SKEW”, and correct the tilt of horizontal lines 9) Select “GRN MSIZ”, and correct the space intervals for the and vertical lines. horizontal section of the screen are equal. • GRN SKEW (horizontally/vertically) • GRN MSIZ (horizontally)
  • Page 51 KP-FS57M31/M61/M90/M91 RM-997 2. Red Adjustment 5. Size and Linearity Adjustment for DRC1250 NTSC W/Z mode by same 1) Place a cap on the blue lens so that green and red colors are prucedure as1~4. displayed. 2) Press “3” button on the commander to select RED mode.

  • Page 52: Auto Convergence Setting

    KP-FS57M31/M61/M90/M91 RM-997 3-13. AUTO CONVERGENCE SETTING 3-15. WHITE BALANCE ADJUSTMENT This adjustment must be performed after the registration adjust- 1. Enter the monoscope signal. ment was made or after readjustment was made by any reason. 2. Set in the service mode.

  • Page 53: Auto Convergence Error Code List

    KP-FS57M31/M61/M90/M91 RM-997 3-16. AUTO CONVERGENCE ERROR CODE LIST If an error code is displayed after the set has been fully adjusted, correctly, plese check the following items : position, tilt and sizing. If either of these adjustments are off, even slightli, the auto registration pattern will not hit the four sensors properly. This occurs when the internal generator patterns is being flashed on the screen for the sensor to read.

  • Page 54: Safety Related Adjustment

    KP-FS57M31/M61/M90/M91 RM-997 SECTION 4 SAFETY RELATED ADJUSTMENT 4-1. HV ADJUSTMENT REGULATION 4-3.+B MAX VOLTAGE CONFIRMATION When replacing the following components marked with ] The following adjustments should always be performed on the schematic diagram, always check hold-down volt- when replacing IC6503.

  • Page 55: Electrical Adjustments

    KP-FS57M31/M61/M90/M91 RM-997 SECTION 5 ELECTRICAL ADJUSTMENTS 5-1. Picture Quality Adjustment Original Condition 5-1-1. Preparation DRC-MF : DRC1250 1. Set in the service mode. PICTURE MODE : HI-FINE 2. Set respective items as follows. 3D-NR MODE : OFF Adjustment Condition ECO MODE...

  • Page 56: Ntsc Video Input

    KP-FS57M31/M61/M90/M91 RM-997 5-1-2. NTSC Video Input 5-1-3. NTSC RF Input 1. Enter the NTSC video color bar (White & color 75%) signal. 1. Enter the NTSC RF color bar (White & color 75%) signal. 2. Enter the service mode, and set respective items as follows.

  • Page 57: Pal Video Input

    KP-FS57M31/M61/M90/M91 RM-997 5-1-4. PAL Video Input 5-1-5. PAL RF Input 1. Enter the PAL video color bar (White & color 75%) signal. 1. Enter the PAL RF color bar (White & color 75%) signal. (i) SUB CONTRAST (i) SUB CONTRAST...

  • Page 58: Diagrams

    KP-FS57M31/M61/M90/M91 RM-997 SECTION 6 DIAGRAMS 6-1. BLOCK DIAGRAMS (1) A AND H2 BOARDS BLOCK DIAGRAMS TO J BOARD TO V2 BOARD TO B4 BOARD CN8304 CN1118 CN502 CN1121 Q105 VIDEO BUFFER +7.5V 7.5V TO V2 BOARD TU101(MAIN) CN5803 Q101 DET OUT...
  • Page 59 KP-FS57M31/M61/M90/M91 RM-997 (2) A1, V2, AND H3 BOARDS BLOCK DIAGRAMS IC8205 IC8207 CN1932 AUDIO CONTROL J1931 HP GND IC8200 L HP AUDIO L CN8102 HEAD R HP TO A BOARD PHONE AUDIO R L-SW 1 LIN LOUT OUTa CN1293 AUDIO L...
  • Page 60 KP-FS57M31/M61/M90/M91 RM-997 (3) AD AND SR BOARDS BLOCK DIAGRAMS (PJED-CPU,PHOTO SENSOR BUFFER) IC9422 3.3V REG IC9400 IC9401 +3.3V D+5V PJED-CPU CONV DSP IC9414(1/2) IC9416(1/2) 1V CONV. CN9603 CN9400 PEAK HOLD UPPER Q9402 UPPER I SEN R IN R OUT RE-R...
  • Page 61 KP-FS57M31/M61/M90/M91 RM-997 (4) B4(1/2) BOARD BLOCK DIAGRAM IC702 IC601 IC801 IC901 MID-XA D/A CONVERTER CN502(1/2) CN502(2/2) Q501,521 Q901,908 Y MAIN IN FL501 199 DIY0 DY02 CRCYIN0 DSPY0 FL901 Y 100 OUT Y0-7 DY0-7 G0-7 BUFF BUFF DIY7 DY09 CRCYIN7 DSPY7...
  • Page 62 KP-FS57M31/M61/M90/M91 RM-997 (5) B4(2/2) AND HM BOARDS BLOCK DIAGRAMS IC7201 IC403 CN7202 CN402 LVDS RECEIVER LVDS RECEIVER CN7201 +3.3V 3.3VD +3.3V 3.3VD DIN1 DOUT2- MS BS+ MS-BS MS BS+ CN401 L7201 MS BS- L405 MS BS- MS-SDIO MS SDIR+ VCLK...
  • Page 63 KP-FS57M31/M61/M90/M91 RM-997 (6) CR, CG, CB, E, AND VM BOARDS BLOCK DIAGRAMS (R OUTPUT) (Y/C/J) CN9107 IC9101 TO FOCUS CN4300 VIDEO OUT BLOCK J9101 CN9103 Q9105 CN4301 CN4305 V IN V OUT Q4313 BUFF Y 100 47 V IN R OUT 32...
  • Page 64 KP-FS57M31/M61/M90/M91 RM-997 (7) G AND H1 BOARDS BLOCK DIAGRAMS (POWER SW) AC IN L6702 L6703 110-240V F6701 50/60Hz CN6701 CN6703 CN1701 (POWER SUPPLY) 6.3A AC(L) AC OUT AC(W) AC OUT T6703 D6535 D6538 D6536 RECT S1700 D6534 CN6704 CN1700 POWER SW...
  • Page 65 KP-FS57M31/M61/M90/M91 RM-997 (8) J BOARD BLOCK DIAGRAM IC2004 3D COMB VIDEO Q2018,2019,FL2004 Q2014 88 AYI B.P.F BUFF VIDEO Q2011,2013,2015 BUFF Q2012,2016,FL2003 96 ACI B.P.F IC8302 Q8304 Q2004,2005,2008 AV SW BUFF Q2010,FL2002 84 AYO B.P.F Q2003,2006,2007 Q2009,FL2001 83 ACO B.P.F 5 C1...
  • Page 66 KP-FS57M31/M61/M90/M91 RM-997 (9) D BOARD BLOCK DIAGRAM IC8001,8002,CONV OUT IC8001(3/3) CN8012 CN8026(1/2) RH OUT (HV,H/V-DEF,DY DRIVE) RV OUT TO DY(R) RV RET RH RET IC8001(2/3) CN8011 H SHIFT GH OUT TO AD BOARD RE-YS GV OUT CN9400 RE-B IC8002(3/3) TO DY(G)
  • Page 67 KP-FS57M31/M61/M90/M91 RM-997 (10) BM1C BOARD BLOCK DIAGRAM IC101 SCAN CONVERTER Q105 OPEN CORECTOR 64 P24 67 P23 IC121 CN104 BUS SW Q202,Q203 LEVEL SHIFT XTAL X102 3.3V EXTAL Q201 IC106 BUFF EEPROM VUV0 CLK 7 Q101 VUV1 VUV2 VUV3 VUV4...

  • Page 68: Frame Schematic Diagram

    KP-FS57M31/M61/M90/M91 RM-997 6-2. FRAME SCHEMATIC DIAGRAM UPPER +12V +12V +12V +12V CN9103 CN9205 CN9309 CN9204 CN9203 CN9102 :S-MICRO SENSOR CN9901 :S-MICRO :S-MICRO :S-MICRO RIGHT :S-MICRO :S-MICRO :S-MICRO +210V LEFT CN9303 CN9209 CN9107 CN9308 :ONE TOUCH CN9301 :ONE TOUCH :ONE TOUCH...

  • Page 69: Circuit Boards Location

    KP-FS57M31/M61/M90/M91 RM-997 6-3. CIRCUIT BOARDS LOCATION 6-4. SCHEMATIC DIAGRAMS Note: Terminal name of semiconductors in silk screen • All capacitors are in µF unless otherwise noted. (pF: µµF) printed circuit ( Capacitors without voltage indication are all 50 V. • Indication of resistance, which does not have one for rating...

  • Page 70: Schematic Diagram Of A Board

    KP-FS57M31/M61/M90/M91 RM-997 (1) Schematic Diagram of A(1/3) Board CN1195 CN1190 CN1161 :S-MICRO :S-MICRO TO G BOARD TO H2 BOARD TO H2 BOARD CN6505 CN1800 CN1800 CN1160 TO A1/3,A2/3,3/3_1 10.5V +10.5V A(1/3) 10.5V D007 D009 RD5.6SB3 RD5.6SB3 PROTECTOR PROTECTOR TO A1/3,A2/3_2...
  • Page 71 KP-FS57M31/M61/M90/M91 RM-997 (2) Schematic Diagram of A(2/3) Board IC2607 BA09T +9V REG +9V-E TO A2/3,A1/3_4 C2634 C2633 C2635 TO A2/3,A1/3,3/3_6 B:CHIP B:CHIP IC2605 TO A2/3,A1/3_5 BA09T +9V REG +10.5V VIDEO/AUDIO L,R L1301 L1300 C2618 C2604 C2602 C2603 10µH 10µH TU3301...
  • Page 72 KP-FS57M31/M61/M90/M91 RM-997 (3) Schematic Diagram of A(3/3) Board TO H3 BOARD CN1932 TO SPEAKER CN1293 :S-MICRO TO H2 BOARD CN1800 AUDIO L R2200 D2200 AUDIO R R2201 C2200 4.7k RD9.1SB :CHIP :CHIP PROTECT L1201 100µH R2207 3.9k TO A3/3,A1/3,2/3_6 C1284...

  • Page 73: Schematic Diagram Of A1 Board

    KP-FS57M31/M61/M90/M91 RM-997 (4) Schematic Diagram of A1 Board IC8207 NJW1139 AUDIO CONT. C8280 AUDIO L 0.01 (ADD:82H) C8232 B:CHIP C8276 F:CHIP C8208 0.047 16V B:CHIP C8277 C8285 F:CHIP 0.047 16V B:CHIP 0.0047 B:CHIP R8220 C8279 C8284 :CHIP 0.01 25V B:CHIP 0.0047 B:CHIP...
  • Page 74 KP-FS57M31/M61/M90/M91 RM-997 (5) Schematic Diagram of AD (1/4) Board FB9414 C9434 RB9401 RB9402 BLM11A601S 100*4 100*4 :1608 RE_YS C9419 C9424 IC9407 +3.3V CD0031AM C9495 F:1608 F:1608 CONV DAC 0.0047 B:1608 RE_B R9429 R9432 2.2k BCLK MUTED 1/10W 1/10W :CHIP :CHIP...
  • Page 75 KP-FS57M31/M61/M90/M91 RM-997 (6) Schematic Diagram of AD(2/4) Board TO AD2/4,AD1/4_15 TO AD2/4,AD1/4_14 TO AD2/4,AD1/4,3/4_1 Q9416 R9412 FB9411 R9444 R9554 1.5k BLM11A601S :1608 2SK2036 R9572 1/10W 1/10W LEVEL SHIFT 1/10W 1/10W :CHIP :CHIP :CHIP :CHIP R9414 Q9407 RE_YS 1.5k 1/10W 2SC2412K...
  • Page 76 KP-FS57M31/M61/M90/M91 RM-997 (7) Schematic Diagram of AD(3/4) Board R9470 R9452 2.2k 2.2k 1/16W R9482 C9505 1/16W :RN-CP 2.2k 680p :RN-CP 1/16W :RN-CP CH:1608 C9472 C9442 680p C9478 680p C9448 C9512 R9451 R9469 R9481 2.2k IC9405 CH:1608 IC9409 CH:1608 2.2k 2.2k...
  • Page 77 KP-FS57M31/M61/M90/M91 RM-997 (8) Schematic Diagram of AD (4/4) Board R9546 R9548 R9549 C9549 100k 0.001 1/16W 1/16W 1/16W CH:1608 :RN-CP :RN-CP :RN-CP C9552 0.01 C9546 F:1608 FB9404 BLM11A601S F:1608 :1608 DF_V 0 0.3 C9408 CH:1608 IC9420 NJM2068V DF FILTER TO AD4/4,2/4_8...
  • Page 78 KP-FS57M31/M61/M90/M91 RM-997 (9) Schematic Diagram of B4 (1/7) Board CN502 :BTOB TO B4 1/7,B4 6/7_1 L501 1µH :CHIP MS5V R5503 100 :CHIP ADPSV TO B4 1/7,B4 6/7,7/7_10 ADPSV FB507 BLM11A102SPT MS RST MS_RST TO B4 1/7,B4 7/7_98 PWRINT PWRINT MSDIR...
  • Page 79 KP-FS57M31/M61/M90/M91 RM-997 (10) Schematic Diagram of B4 ( 2/7) Board IC605 PQ07VZ012ZP 1.8V-REG D5V-1 TO B4 2/7,B4 1/7_5 R687 Q601 :CHIP 2SC4081T-106R TO B4 2/7,B4 1/7,5/7_27 VP IN BUFFER R689 R647 R648 R601 2.2k :CHIP :CHIP :CHIP :CHIP FL601 CKD510JB1A105ST +1.8V...
  • Page 80 KP-FS57M31/M61/M90/M91 RM-997 (11) Schematic Diagram of B4 ( 3/7) Board TO B4 3/7,B4 6/7,7/7_39 ADOUT VDOCRCLVL VDOCBCLVL TO B4 3/7,B4 6/7_41 VDOYCLVL C823 C821 0.01 R817 0.01 25V B:CHIP B:CHIP :CHIP C824 0.01 C822 C820 0.01 0.01 B:CHIP B:CHIP B:CHIP +3.3V...
  • Page 81 KP-FS57M31/M61/M90/M91 RM-997 (12) Schematic Diagram of B4 (4/7) Board +3.3V TO B4 4/7,B4 1/7_3 D3.3V-1 +5.5V R952 R916 R951 R914 4.7k 2.2k 2.2k 4.7k :CHIP :CHIP :CHIP :CHIP D901 SDA-MID ISS300-TE85L Q904 R909 1k :RN-CP 2SK2034-TE85L LEVEL SHIFT R908 1k :RN-CP...
  • Page 82 KP-FS57M31/M61/M90/M91 RM-997 (13) Schematic Diagram of B4 (5/7) Board TO B4 5/7,B4 1/7,2/7_17 XRST D702 MA2S111 RB709 RB710 RB711 :CHIP :CHIP :CHIP TO B4 5/7,B4 2/7_30 ADTB TO B4 5/7,B4 1/7,2/7_27 C707 VP IN U MAIN B:CHIP C739 TO B4 5/7,B4 1/7_16...
  • Page 83 KP-FS57M31/M61/M90/M91 RM-997 (14) Schematic Diagram of B4 (6/7) Board +3.3V L8606 10µH +3.3V RB8603 :CHIP D3.3V-MID TO B4 6/7,B4 1/7_4 C8634 :CHIP L8602 10µH +3.3V +3.3V B:CHIP :CHIP A3.3V TO B4 6/7,B4 1/7_7 R8662 R8661 R8660 R8651 C8020 C8638 L8604...
  • Page 84 KP-FS57M31/M61/M90/M91 RM-997 (15) Schematic Diagram of B4 (7/7) Board CN402 TO HM BOARD CN7202 FB410 FL401 FB403 IC405 TC7S126FU BUS SW FB417 R421 100k R418 VCLK R422 VCLK VPEN VPEN C405 R419 L401 L402 L403 L404 L405 MSVS R420 TO B4 7/7,B4 3/7_99 VUV7 +3.3V...

  • Page 85: Schematic Diagram Of Cr,Cg And Cb Boards

    KP-FS57M31/M61/M90/M91 RM-997 (16) Schematic Diagrams of CR, CG, and CB Boards V901 PICTURE V903 HV BLOCK PICTURE TUBE HV BLOCK TUBE TO F.BLOCK TO F.BLOCK FGND CN9110 J9101 R9121 (R OUTPUT) :FASTON FGND TO F.BLOCK 1/2W (B OUTPUT) J9301 R9324...
  • Page 86 KP-FS57MM31/M61/M90/M91 RM-997 (17) Schematic Diagram of D(1/3) Board CN8008 CN8009 CN8012 CN8007 CN8010 CN8011 CN8013 :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO TO DY(B) TO DY(R) TO DY(G) TO DY(B) TO DY(R) TO DY(G) TO G BOARD CN6503 CN8025 R8114 R8116 R8101 :S-MICRO IC8010...
  • Page 87 KP-FS57MM31/M61/M90/M91 RM-997 (18) Schematic Diagram of D(2/3) Board HV(R) TO PICTURE TUBE R V901(R) HV(G) TO PICTURE TUBE G V902(G) HV(B) TO PICTURE TUBE B CN8015 CN8016 V903(B) CN8006 :LARGE (HV BLOCK) :S-MICRO :S-MICRO TO D BOARD TO VM BOARD T5103 CN9001 +135V...
  • Page 88 KP-FS57MM31/M61/M90/M91 RM-997 (19) Schematic Diagram of D(3/3) Board +15V TO D3/3,D1/3_2 DF VCC R8030 TO D3/3,D1/3_3 +12V L8009 L8010 10µH 47µH TO D3/3,D1/3_4 R8037 :LHL08 :LAV35 D8005 R8068 R8034 1SS355 70.8 1/10W RECT 1/10W Q8007 C8045 :CHIP :CHIP 2SC4634LS-CB11 DF V AMP C8047 C8050 C8053...

  • Page 89: Schematic Diagram Of E Board

    KP-FS57MM31/M61/M90/M91 RM-997 (20) Schematic Diagram of E Board CN4302 CN4303 CN4304 TO VM BOARD TO VM BOARD TO VM BOARD CN9002 CN9002 CN9002 (FOR B) (FOR G) (FOR R) C4328 R4346 C4335 C4337 L4304 4.7k 10µH CH:1608 1/10W :LB2016 :CHIP F:1608 R4333 C4325...

  • Page 90: Schematic Diagram Of G Board

    KP-FS57MM31/M61/M90/M91 RM-997 (21) Schematic Diagram of G Board D6503 FB6501 D4SBS6 JW(10) L6504 C6516 10µH FB6502 :LHL08 JW(10) C6514 4700 TO A(1/2) BOARD C6703 R6702 CN1160 +10.5V 0.0047 CN6502 250V D6701 1/2W 10.5V ERC04-06SE D6502 :S-MICRO D6538 C6702 D4SBS6 R6701 D6702 C6704 1SS355TE...

  • Page 91: Schematic Diagram Of H1,H2 And H3 Boards

    KP-FS57MM31/M61/M90/M91 RM-997 (22) Schematic Diagrams of H1, H2, and H3 Boards CN1932 CN1934 CN1701 CN1700 WHT-L WHT-L WHT-L WHT-L :S-MICRO :S-MICRO TO A(3/3)BOARD TO J(1/4)BOARD TO G BOARD TO G BOARD CN6704 CN6703 CN1293 CN8301 D1930 RD9.1ES-T1B PROTECTOR S1700 POWER R1952 R1934 2.2k...
  • Page 92 KP-FS57MM31/M61/M90/M91 RM-997 (23) Schematic Diagram of J(1/5) Board CN8302 :TAB C8330 R8351 4.7k :CHIP F:CHIP R IN R8352 C8331 4.7k 1 10V F:CHIP :CHIP L IN C8300 0.47 10V B:CHIP Y IN C8349 4.7 10V F:CHIP CV IN R8348 2.2k :CHIP S IN C8382 0.1 16V B:CHIP...
  • Page 93 KP-FS57MM31/M61/M90/M91 RM-997 (24) Schematic Diagram of J(2/5) Board R8362 R8211 R8212 JL8302 :CHIP :CHIP :CHIP APCN R8353 TO J2/5,J1/5_20 :CHIP MAIN-C2 TO J2/5,J5/5_23 C-IN R8512 47 :CHIP MAIN-CV2 R8210 R8213 TO J2/5,J5/5_24 COMP V IN FL8303 :CHIP :CHIP TO J2/5,J1/5_2 +5VA R8410 C8372...
  • Page 94 KP-FS57MM31/M61/M90/M91 RM-997 (25) Schematic Diagram of J(3/5) Board C8892 (AUDIO OUT) J8306 R8887 R8885 0.47 :CHIP :CHIP B:CHIP VD8304 R8889 7.5V 2.2k :1608 :CHIP R8888 R8886 C8893 COMP L TO J3/5,J1/5_15 COMP R TO J3/5,J1/5_14 :CHIP :CHIP R8802 L8803 R8801 R8890 10µH VD8305...
  • Page 95 KP-FS57MM31/M61/M90/M91 RM-997 (26) Schematic Diagram of J(4/5) Board C8520 C8521 R8509 R8511 R8513 :CHIP B:CHIP :CHIP B:CHIP :CHIP Q8410 Q8409 2SA1576A Q8408 2SA1576A 2SA1576A Q8406 Q8407 2SC4081-R 2SC4081-R Q8405 2SC4081-R R8519 R8518 :RN-CP R8506 R8504 :RN-CP R8505 :CHIP R8516 :CHIP :CHIP R8515 :RN-CP...
  • Page 96 KP-FS57MM31/M61/M90/M91 RM-997 (27) Schematic Diagram of J(5/5) Board L2306 10µH :CHIP TO J5/5,J1/5_1 R2311 R2313 Q2302 R2312 2SC4081-R :CHIP Q2304 :CHIP BUFF :CHIP 2SA1576A-T106 C2327 IC2300 C2321 BUFF R2309 C2326 R2308 TC90A69F L2304 1.2k 27µH :B2H C2300 C2312 :CHIP B:CHIP :CHIP B:CHIP Q2303...
  • Page 97 KP-FS57MM31/M61/M90/M91 RM-997 (28) Schematic Diagram of SR, V2, and VM Boards CN9901 :S-MICRO SB9901 D9902 TO AD(4/4)BOARD SOLAR UDZSTE-17-5.6B BATTERY CN9603 SENSOR (VELOCITY MODULATION) TO D BOARD CN8006 CN9001 CN9003 R9001 :S-MICRO :B TO B-P 1/4W FB9001 +135V :FPRD MPZ2012S331 +135V VM COIL +135V...
  • Page 98 KP-FS57MM31/M61/M90/M91 RM-997 (29) Schematic Diagrams of HM Boards CN7202 R7231 1/16W D7210 :PHD :CHIP UDZSTE-173.9B +3.3VD +3.3VD +3.3VD +3.3VD C7213 C7214 IC7201 D7205 FB7201 SN65LVDS32DR MA153-TX BK1608TS601 6.3V LVDS RECEIVER B:CHIP :AL-CP D7213 R7206 MS_BS+ L7201 MA153-TX PLW3216S261SQ 1/16W MS_BS- :CHIP MS_SDIR+ C7208...
  • Page 99 KP-FS57MM31/M61/M90/M91 RM-997 (30) Schematic Diagrams of BM1C(1/2) Boards IC101(2/4) RB107 MD2406 22*4 SCAN CONVEROTOR :1005 RB108 22*4 :1005 RB109 VUV7 22*4 :1005 VUV6 IC101(1/4) VUV5 3.3V MD2406 VUV4 SCAN CONVERTOR VUV3 /CCS1 R101 10 1/16W :CHIP RB110 VUV2 22*4 /CCS0 :1005 R102 10 1/16W :CHIP...
  • Page 100 KP-FS57MM31/M61/M90/M91 RM-997 (31) Schematic Diagram of BM1C(2/2) Board RB131 10k*4 R201 R208 3.3V Q201 :1005 100k 100k 1/16W 2SA1576A-T106-QR 1/16W :CHIP :CHIP FB109 IC101(4/4) BK1608TS601 IC104 MD2406 3.3V AD_DIS TO BM1C2/2,BM1C1/2_9 BA033FP-E2 SCAN CONVERTER R209 3.3V REG 100k 3.3V C135 0.01 25V B:CHIP VDDP7 1/16W...

  • Page 101: Printed Wiring Boards

    KP-FS57M31/M61/M90/M91 6-5. PRINTED WIRING BOARDS RM-997 — A BOARD (COMPONENT SIDE) — [SYSTEM CONTROL, AUDIO AMP,TUNER] • A BOARD SEMICONDUCTOR LOCATION Q1207 Q1209 Component Conductor Q1210 Side Side Q1211 IC001 Q2200 IC002 Q2201 IC003 Q2603 IC005 Q2604 IC100 Q3300 IC1203...
  • Page 102 KP-FS57M31/M61/M90/M91 RM-997 [AUDIO CONTROL] — A1 BOARD (COMPONENT SIDE) — A1 BOARD Terminal name of semiconductors in silk screen printed circuit ( Ref. D8217 Q8101-Q8103 Q8218 : Refer to Terminal name of semicon- ductors in silk screen printed circuit (see page 81) —...
  • Page 103 KP-FS57M31/M61/M90/M91 RM-997 [CONV DSP, PJED-CPU, PHOTO SENSOR] — AD BOARD (COMPONENT SIDE) — — AD BOARD (CONDUCTOR SIDE) — • AD BOARD SEMICONDUCTOR LOCATION TRANSISTORQ DIODE Component Conductor Component Conductor Component Conductor Side Side Side Side Side Side IC9400 Q9400...
  • Page 104 KP-FS57M31/M61/M90/M91 RM-997 [YUV AMP, YUV CON., VDRC, MID, D/A CONV., MID ENGINE, DNR] — B4 BOARD (COMPONENT SIDE) — — B4 BOARD (CODUCTOR SIDE) — • B4 BOARD SEMICONDUCTOR LOCATION Q601 Q901 Component Conductor Side Side Q902 Q903 IC503 Q904...
  • Page 105 KP-FS57M31/M61/M90/M91 RM-997 [B OUTPUT] [R OUTPUT] [G OUTPUT] — CR BOARD (CONDUCTOR SIDE) — — CB BOARD (CONDUCTOR SIDE) — — CG BOARD (CONDUCTOR SIDE) — • CR BOARD • CG BOARD • CB BOARD SEMICONDUCTOR LOCATION SEMICONDUCTOR LOCATION SEMICONDUCTOR LOCATION Ref.
  • Page 106 KP-FS57M31/M61/M90M91 RM-997 [HV-DEF., HV. DY DRIVE] — D BOARD (CONDUCTOR SIDE) — • D BOARD SEMICONDUCTOR LOCATION Q8043 C-4 1 Q8044 Component Conductor Q8101 D-7 1 Side Side IC8001 DIODE IC8002 IC8003 Component Conductor Side Side IC8004 D8001 IC8005 D8002...
  • Page 107 KP-FS57M31/M61/M90M91 RM-997 [ Y/C/J ] — E BOARD (COMPONENT SIDE) — • E BOARD SEMICONDUCTOR LOCATION Ref. Q4300-Q4303, Q4305- Q4307, Q4309, Q4311, Q4313, Q4316, Q4317, Q4319 D4300-D4302, D4304, D4305, D4312 : Refer to Terminal name of semiconductors in silk screen printed circuit (see page 81) —...
  • Page 108 KP-FS57M31/M61/M90M91 RM-997 [ POWER SUPPLY ] — G BOARD (CODUCTOR SIDE) — • G BOARD SEMICONDUCTOR LOCATION Component Conductor Side Side IC6501 IC6502 IC6503 IC6504 IC6701 TRANSISTOE Component Conductor Side Side Q6502 Q6503 Q6504 Q6506 Q6701 Q6702 DIODE Component Conductor...
  • Page 109 KP-FS57M31/M61/M90M91 RM-997 [ AV INPUT ] [ POWER SW ] — H3 BOARD (CODUCTOR SIDE) — — H1 BOARD (CODUCTOR SIDE) — • H3 BOARD SEMICONDUCTOR LOCATION Ref. D1930 : Refer to Terminal name of semiconductors in silk screen printed circuit (see page 70) [ KEY INPUT, SIRCS ] —...
  • Page 110 KP-FS57M31/M61/M90M91 RM-997 [ AV SW, COLOR DECODER, CONPONENT I/F, 3D COMB FILTER ] — J BOARD (COMPONENT SIDE) — — J BOARD (CODUCTOR SIDE) — • J BOARD SEMICONDUCTOR LOCATION Q8308 Q8403 D8304 Q2005 Q2006 Q8309 Q8404 D8305 Component Conductor !º...
  • Page 111 KP-FS57M31/M61/M90M91 RM-997 [ VELOCITY MODULATION ] [ TEXT ] [ PHOTO SENSOR ] — VM BOARD (CODUCTOR SIDE) — — V2 BOARD (CODUCTOR SIDE) — — SR BOARD (COMPONENT SIDE) — — SR BOARD (CODUCTOR SIDE) — • SR BOARD SEMICONDUCTOR LOCATION Ref.
  • Page 112 KP-FS57M31/M61/M90M91 RM-997 BM1C [ SCAN CONVERTER ] [ MEMORY STICK ] — BM1C BOARD (COMPONENT SIDE) — — BM1C BOARD (CODUCTOR SIDE) — — HM BOARD (COMPONENT SIDE) — — HM BOARD (CODUCTOR SIDE) — • BM1C BOARD • HM BOARD...

  • Page 113: Waveforms

    KP-FS57M31/M61/M90/M91 RM-997 6-6. WAVEFORMS (2) B4 Board Wave Forms (3) CR, CG, and CB Boards Wave Forms (1) A Board Wave Forms •B4(1/7)BOARD WAVEFORMS •CR BOARD WAVEFORMS •A(1/3)BOARD WAVEFORMS NTSC SECAM NTSC SECAM PAL 0.6VP-P(H) 3.3V 3.3V 0.5V 0.5V 0.7V 1.0V...
  • Page 114 KP-FS57M31/M61/M90/M91 RM-997 (4) D Board Wave Forms (6) J Board Wave Forms (5) E Board Wave Forms •E BOARD WAVEFORMS •J(1/5)BOARD WAVEFORMS •D(1/3) BOARD WAVEFORMS NTSC SECAM 4.5V 3.6V 1.7V 0.5V 0.5V 1.0V 2.0V 1.7V 1.7V 0.5V NTSC SECAM PAL 1.2VP-P(H) PAL1.2VP-P(H)

  • Page 115: Ic Block Diagrams

    KP-FS57M31/M61/M90/M91 RM-997 6-7. IC BLOCK DIAGRAMS • A(1/3) BOARD IC002 : MM1482BFBE • AD(1/4) BOARD IC9407 : CD0031AM • A(2/3) BOARD IC100 : S-80743AL-A7-T1 • AD(2/4) BOARD IC9422 : NJM2391DL1-33(TE1) FINE R-MATRIX DIN1 SWITCH OUT1 CONTROL COARSE R-MATRIX REFERENCE VOLTAGE...
  • Page 116 KP-FS57M31/M61/M90/M91 RM-997 • B4(4/7) BOARD IC901 : CXD2309 • CR BOARD IC9101 : TDA6120Q/N2/S1 • J(1/5) BOARD IC8302 : CXA2069Q CG BOARD IC9201 : TDA6120Q/N2/S1 CB BOARD IC9301 : TDA6120Q/N2/S1 (LSB) R0 I IN 4LSB’S CURRENT CELLS VOUT1 10 VDD...
  • Page 117 KP-FS57M31/M61/M90/M91 RM-997 • J(1/5) BOARD IC8304, 8305 : LF50CDDT-TR • J(2/5) BOARD IC8310 : TDA9178 • J(4/5) BOARD IC8871 : SN74LV4053ANSR S OU CURRENT LUMINANCE VECTOR PROCESSING SPECTRAL PROCESSING LIMIT SMART PEAKING LUMINANCE START REFERENCE Y OU INHIBIT VOLTAGE INPUT...

  • Page 118: Semiconductors

    KP-FS57M31/M61/M90M91 RM-997 6-8. SEMICONDUCTORS CXD9509AQ M12L16161A-7T BA05T NJM7812FA S-80743AL-A7-S MT48LC1M16A1TG-6S BA09T S-80743AL-A7-T1 W981616BH-7-EL10 BA12T TOP VIEW 240pin QFP TOP VIEW CXP961048-003Q 50pin SOP MB94918RPF-G- 149-BND TC90A90F(BH,DRY) M24128-BWMN6T NJW1139GK1-TE2 STK392-560 BA9759F-E2 UPD64083GF-3BA M24C32-WMN6T(A) MM1115XFBE MM1482BFBE NJM2068V-TE2 NJM2521M-TE1 NJM2903M INDEX TOP VIEW...
  • Page 119 KP-FS57M31/M61/M90M91 RM-997 DTA114EKA-T146 DTC114EU 2SA2005 DTC114EUA-T106 2SC5511 DTC144EKA DTC144EKA-T146 UN2213 UN2213-TX UN5213 UN5213-TX 2SA1037AK-T146-QR 2SA1037AK-T146-R 2SA1226-E4 2SA1226-T1E4 2SC2688(5)-LK 2SA1576A-T106-QR LETTER SIDE 2SB709A-QRS-TX 2SC1623-L5L6 2SC2412K-T-146-QR 2SC2712 2SC4081-R 2SC4081-S 2SC4081T106R 2SC4081T106S 2SD1782K-T146-R 2SD601A-Q 2SD601A-QRS-TX 2SC4634LS-CB11 DTC144ESA DTC144ESA-TP LETTER SIDE 2SC5778-YB FQPF12P20XDTU 2SJ585LS-CC11...
  • Page 120 KP-FS57M31/M61/M90M91 RM-997 D1NS4-TR D10SC4M MA111-TX SPR-325MVW EL1Z D10SC4M-F MMDL914T1 GP08D RD5.6SB3 GP08DPKG23 RD5.6SB3-T1 MTZJ-T-77-20B RD5.6SB-T1 MTZJ-T-77-22B RD9.1SB MTZJ-T-77-5.1B RD9.1SB-T1 MTZJ-T-77-5.6B UDZSTE-1718B RGP02-17EL-6433 UDZSTE-1727B RGP02-17PKG23 UDZSTE-1733B RGP10GPKG23 UDZSTE-174.7B ANODE ANODE 10ERA60-TP UDZSTE-175.1B (GREEN) (RED) 1SS83 UDZSTE-175.6B CATHODE 1SS83TD UDZSTE-176.2B D10SC4MR UDZSTE-177.5B UDZ-TE-17-7.5B...

  • Page 121: Exploded Views

    KP-FS57M31/M61/M90/M91 RM-997 SECTION 7 EXPLODED VIEWS NOTE: • Items marked " * " are not stocked since The components identified by shading they are seldom required for routine • Items with no part number and no ¡ and mark are critical for safety.

  • Page 122: Cabinet Block (Kp-Fs53)

    KP-FS57M31/M61/M90/M91 RM-997 7-2. CABINET BLOCK PICTURE TUBE BLOCK ASSY MAIN BLOCK ASSY REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK * 4-090-367-01 SKIRT (57), FRONT 4-030-850-03 SOCKET, CASTER 4-378-522-31 SCREW, TAPPING, HEXAGON HEAD ! 1-223-925-71 RESISTOR ASSY (FOCUS PACK)

  • Page 123: Bezenet And Mirror Cover Block (Kp-Fs53)

    KP-FS57M31/M61/M90/M91 RM-997 7-3. BEZENET AND MIRROR COVER BLOCK REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK X-4040-867-2 SCREEN (57) ASSY, CONTRAST 4-088-598-01 MIRROR (57) 4-088-611-11 PLATE (57WL), DIFFUSION * 4-088-599-01 COVER (57), MIRROR 4-088-610-11 PLATE (57WF), DIFFUSION 4-378-522-01 SCREW, TAPPING, HEXAGON HEAD...

  • Page 124: Main Bracket And Picture Tube Block

    KP-FS57M31/M61/M90/M91 RM-997 7-4. MAIN BRACKET AND PICTURE TUBE BLOCK The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK * A-1401-390-A CB BOARD, MOUNT...

  • Page 125: Electrical Parts List

    KP-FS57M31/M61/M90/M91 RM-997 SECTION 8 ELECTRICAL PARTS LIST •The components identified by [ in this • Items marked " * " are not stocked since NOTE: they are seldom required for routine manual have been carefully factory- The components identified by shading selected for each set in order to satisfy service.
  • Page 126 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK <SPARK GAP> <NEON LAMP> SG9101 1-517-729-31 GAP, SPARK NL9202 1-517-778-21 LAMP, NEON...
  • Page 127 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C9314 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V R9306 1-218-682-11 METAL CHIP 0.5%...
  • Page 128 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. VM G Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C9012 1-137-528-11 MYLAR 0.1UF 10.00% 250V *************************************************************************************** C9013 1-164-156-11 CERAMIC CHIP 0.1UF...
  • Page 129 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C6714 1-162-974-11 CERAMIC CHIP 0.01UF D6702 8-719-022-99 DIODE D6SB60L D6704...
  • Page 130 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK L6513 1-412-533-21 INDUCTOR 47UH R6528 1-216-837-11 METAL CHIP 1/10W L6514...
  • Page 131 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK VD6702 ! 1-803-830-11 VARISTOR (ERZV14D621) <DIODE> VD6703 ! 1-801-058-51 VARISTOR (ERZV14D271) D8217 8-719-081-97 DIODE MMDL914T1 ************************************************************************************** D8218 8-719-081-97 DIODE MMDL914T1 * A-1300-507-A A1 BOARD, COMPLETE ******************** <IC> IC8200 8-759-100-96 IC UPC4558G2 <CAPACITOR>...
  • Page 132 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C2008 1-126-933-11 ELECT 100UF 20.00% 16V C2304 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C2009 1-164-156-11 CERAMIC CHIP 0.1UF C2305 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C2010 1-162-975-11 CERAMIC CHIP 24PF 5.00%...
  • Page 133 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C8425 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C8343 1-126-947-11 ELECT 47UF 20.00% 16V C8344 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C8437 1-126-963-11 ELECT 4.7UF 20.00% 50V C8438 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V...
  • Page 134 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C8882 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V FB2013 1-414-228-11 FERRITE C8885 1-125-837-91 CERAMIC CHIP 1UF 6 .3V FB2301 1-414-228-11 FERRITE C8886 1-164-156-11 CERAMIC CHIP 0.1UF FB2302 1-414-234-22 FERRITE C8887 1-164-156-11 CERAMIC CHIP 0.1UF...
  • Page 135 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK L2301 1-412-032-11 INDUCTOR 100UH Q8328 8-729-421-19 TRANSISTOR UN2213 L2302 1-412-032-11 INDUCTOR 100UH Q8329 8-729-905-35 TRANSISTOR 2SC4081-R L2303 1-412-031-11 INDUCTOR 47UH Q8330 8-729-905-35 TRANSISTOR 2SC4081-R Q8331 8-729-905-35 TRANSISTOR 2SC4081-R...
  • Page 136 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R2042 1-216-825-11 METAL CHIP 2.2K 1/10W R2337 1-216-864-11 SHORT CHIP R2043 1-216-829-11 METAL CHIP 4.7K 1/10W R2338 1-216-821-11 METAL CHIP 1/10W R2044 1-218-845-11 METAL CHIP 0.5% 1/10W R8210...
  • Page 137 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R8356 1-216-864-11 SHORT CHIP R8429 1-216-820-11 METAL CHIP 1/10W R8357 1-216-805-11 METAL CHIP 1/10W R8430 1-216-810-11 METAL CHIP 1/10W R8358 1-216-805-11 METAL CHIP 1/10W R8436 1-216-817-11 METAL CHIP...
  • Page 138 KP-FS57M31/M61/M90/M91 RM-997 BM1C REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R8511 1-216-817-11 METAL CHIP 1/10W R8842 1-218-716-11 METAL CHIP 0.5% 1/10W R8843 1-216-864-11 SHORT CHIP R8512 1-216-805-11 METAL CHIP 1/10W R8844 1-216-809-11 METAL CHIP 1/10W R8513 1-216-817-11 METAL CHIP...
  • Page 139 KP-FS57M31/M61/M90/M91 RM-997 BM1C REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK IC106 8-759-661-55 IC 24LC21AT/SN C130 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V IC107 8-759-331-27 IC MM1096AFF C131 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C132 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V...
  • Page 140 10.00% 25V ***************************************************************************************** C172 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C173 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V * A-1300-705-A A BOARD, COMPLETE (KP-FS57M31) *************************** C174 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V * A-1300-933-A A BOARD, COMPLETE C175 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V...
  • Page 141 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C1217 1-126-943-11 ELECT 2200UF 20.00% 25V C2609 1-126-935-11 ELECT 470UF 20.00% 10V C1219 1-126-961-11 ELECT 2.2UF 20.00% 50V C2610 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C1220 1-126-961-11 ELECT 2.2UF...
  • Page 142 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK IC1203 8-759-553-45 IC TDA7481 D001 8-719-081-97 DIODE MMDL914T1 IC1204 8-759-553-45 IC TDA7481...
  • Page 143 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R033 1-216-809-11 METAL CHIP 1/10W Q001 8-729-905-35 TRANSISTOR 2SC4081-R R034 1-216-813-11 METAL CHIP 1/10W Q002 8-729-905-35 TRANSISTOR 2SC4081-R R035 1-216-813-11 METAL CHIP 1/10W Q003 8-729-905-35 TRANSISTOR 2SC4081-R R036...
  • Page 144 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R109 1-216-817-11 METAL CHIP 1/10W R1275 1-216-837-11 METAL CHIP 1/10W R110 1-216-818-11 METAL CHIP 1/10W R1276 1-216-837-11 METAL CHIP 1/10W R111 1-216-864-11 SHORT CHIP R1277 1-216-833-11 METAL CHIP...
  • Page 145 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C611 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C612 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V RV3300 1-241-761-11 RES, ADJ, CARBON 1K C613 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C614 1-162-970-11 CERAMIC CHIP 0.01UF...
  • Page 146 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C738 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C954 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V C955 1-162-925-11 CERAMIC CHIP 68PF 5.00% C739 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V C956 1-162-925-11 CERAMIC CHIP 68PF 5.00%...
  • Page 147 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK D702 8-719-046-91 DIODE MA2S111 D801 8-719-046-91 DIODE MA2S111 <IC> D802 8-719-801-78 DIODE 1SS301 IC401 8-759-698-08 IC SN74CBTLV1G125DCKR D803 8-719-024-81 DIODE 1SS300-TE85L IC402 6-701-762-11 IC DS90LV018ATMX D901 8-719-024-81 DIODE 1SS300-TE85L...
  • Page 148 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R506 1-216-809-11 METAL CHIP 1/10W Q304 8-729-905-35 TRANSISTOR 2SC4081-R Q401 8-729-905-35 TRANSISTOR 2SC4081-R R507 1-216-809-11 METAL CHIP 1/10W Q501 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR R508 1-216-809-11 METAL CHIP 1/10W Q502...
  • Page 149 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R872 1-216-809-11 METAL CHIP 1/10W R689 1-216-825-11 METAL CHIP 2.2K 1/10W R873 1-216-809-11 METAL CHIP 1/10W R701 1-216-864-11 SHORT CHIP R874 1-216-809-11 METAL CHIP 1/10W R702 1-216-864-11 SHORT CHIP...
  • Page 150 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R942 1-216-815-11 METAL CHIP 1/10W R8609 1-216-821-11 METAL CHIP 1/10W R943 1-216-813-11 METAL CHIP 1/10W R8610 1-216-821-11 METAL CHIP 1/10W R946 1-216-809-11 METAL CHIP 1/10W R8611 1-216-821-11 METAL CHIP...
  • Page 151 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C4332 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V RB402 1-233-575-11 RES, CHIP NETWORK C4333 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V RB403 1-233-575-11 RES, CHIP NETWORK RB404 1-233-575-11 RES, CHIP NETWORK C4334 1-107-826-11 CERAMIC CHIP 0.1UF...
  • Page 152 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R4346 1-216-829-11 METAL CHIP 4.7K 1/10W Q4300 8-729-905-35 TRANSISTOR 2SC4081-R R4347 1-216-809-11 METAL CHIP 1/10W Q4301 8-729-905-35 TRANSISTOR 2SC4081-R R4348 1-216-823-11 METAL CHIP 1.5K 1/10W Q4302 8-729-905-35 TRANSISTOR 2SC4081-R...
  • Page 153 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R4498 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W R4499 1-216-809-11 METAL CHIP 1/10W C8054 1-162-974-11 CERAMIC CHIP 0.01UF C8055 1-164-156-11 CERAMIC CHIP 0.1UF C8056 1-107-652-11 ELECT 10UF 20.00% 250V <CRYSTAL>...
  • Page 154 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C8116 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V CN8028 1-564-507-11 PLUG, CONNECTOR 4P C8117 1-162-318-11 CERAMIC 0.001UF 10.00% 500V C8118 1-136-189-00 MYLAR 0.1UF 10.00% 250V CN8029 * 1-564-510-11 PLUG, CONNECTOR 7P C8120 1-107-826-11 CERAMIC CHIP 0.1UF...
  • Page 155 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK <IC LINK> FB8021 1-410-397-21 FERRITE 1.1UH FB8021 1-410-397-21 FERRITE 1.1UH PS800 ! 1-533-595-31 IC LINK 3.15A...
  • Page 156 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R8016 1-216-829-11 METAL CHIP 4.7K 1/10W R8084 1-216-833-11 METAL CHIP 1/10W R8085 1-214-808-11 METAL 1/2W R8017 1-216-829-11 METAL CHIP 4.7K 1/10W R8086 1-214-808-11 METAL 1/2W R8018 1-216-821-11 METAL CHIP...
  • Page 157 KP-FS57M31/M61/M90/M91 RM-997 • The components identified by [ in this manual have been carefully The components identified by shading factory-selected for each set in order to satisfy regulations ¡ regarding X-ray radiation. Should replacement be required, replace and mark are critical for safety.
  • Page 158 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK C9416 1-164-156-11 CERAMIC CHIP 0.1UF C9503 1-164-315-11 CERAMIC CHIP 470PF 5.00% C9419 1-164-156-11 CERAMIC CHIP 0.1UF C9505 1-115-412-11 CERAMIC CHIP 680PF 5.00% C9422 1-164-156-11 CERAMIC CHIP 0.1UF C9506 1-164-156-11 CERAMIC CHIP 0.1UF...
  • Page 159 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK Q9417 8-729-028-28 TRANSISTOR 2SK2036(TE85L) <FERRITE BEAD> FB9401 1-414-445-11 FERRITE <RESISTOR> FB9402 1-414-445-11 FERRITE FB9403 1-414-445-11 FERRITE R9400 1-216-841-11 METAL CHIP 1/10W FB9404 1-414-445-11 FERRITE R9401 1-216-809-11 METAL CHIP...
  • Page 160 KP-FS57M31/M61/M90/M91 RM-997 REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK R9461 1-218-724-11 METAL CHIP 0.5% 1/10W R9557 1-216-821-11 METAL CHIP 1/10W R9558 1-216-821-11 METAL CHIP 1/10W R9462 1-218-724-11 METAL CHIP 0.5% 1/10W R9463 1-218-716-11 METAL CHIP 0.5% 1/10W...
  • Page 161 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK <CONNECTOR> <CONNECTOR> CN1800 * 1-564-525-11 PLUG, CONNECTOR 10P CN1700 * 1-580-844-11 PIN, CONNECTOR (POWER) CN1701 * 1-580-844-11 PIN, CONNECTOR (POWER) <DIODE>...
  • Page 162 KP-FS57M31/M61/M90/M91 RM-997 The components identified by shading ¡ and mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK <JACK> FB7204 1-414-921-11 FERRITE J1931 1-691-293-31 JACK (HEADPHONE) J1932 1-750-517-11 JACK BLOCK, PIN 3P (VIDEO IN4) <IC>...
  • Page 163 KP-FS57M31/M61/M90/M91 RM-997 English Sony EMCS Corporation 2002JR08-1 9-965-347-01 Ichinomiya Tec © 2002. 10 – 223 –...

This manual is also suitable for:

Kp-fs57m91Kp-fs57m61Kp-fs57m90

Table of Contents
