Summary of Contents for PICO EL040
- Page 1 Current Monitoring Kit QUICK START GUIDE...
-
Page 3: Table Of Contents
Pico Technology EL040 Current Monitoring Kit Quick Start Guide CONTENTS Introduction ............... 1 Kit contents ..............3 Installation..............3 Connecting the system together ........3 Installing the software and instruction manual ....3 Technical specifications ..........4 EL005 – stand-alone data logger ........4 EL040 –... - Page 4 EL040 Current Monitoring Kit Quick Start Guide Pico Technology Issues: 2.10.02 WP A4 format 2.10.02 Added safety warning 17.3.06 Word A5 format. S1: Removed relay modules. S2: Added MI010. S4.1: added EL041, RS-232. 25.1.07 New logo & title font. 1.9.08 New address.
-
Page 5: General Safety Warnings
Maximum input range The maximum input range and, where applicable, overload protection for the EL040 is ±30 V. Always operate the product within this specified input range. Operation outside the range of the overload protection is likely to cause permanent damage to the unit. -
Page 6: Introduction
EL040 Current Monitoring Kit Quick Start Guide Pico Technology Introduction The current monitoring kit from Pico Technology contains everything needed to start logging current consumption data from up to three separate circuits. It is ideal for measuring and balancing three-phase supplies as well as machine monitoring and energy efficiency studies. -
Page 7: Kit Contents
Connect the EL040 current monitor to the EL005 data logger using the EL003 network cable provided. See sections 3.2.2 and 3.2.3 of the EnviroMon User Manual if the EL005 is more than 5 metres from the EL040. The maximum length of conventional cable between the two units is 400 m. -
Page 8: Technical Specifications
EL040 Current Monitoring Kit Quick Start Guide Pico Technology To run the software: Press the Start button Select Programs Select Pico Technology Select EnviroMon for Windows After this you will have the option to take a guided tour for further software assistance. -
Page 9: Technical Support
Answers to the most common questions and problems can be found in the technical support section of the product manual, which is installed with the software and accessible from the help menu. The Pico Technology web site also contains regularly updated technical support information at: http://www.picotech.com Contact information for our technical support team can be found on our website and at the back of this manual. -
Page 10: Do090
EL040 Current Monitoring Kit Quick Start Guide Pico Technology Pico Technology James House Colmworth Business Park St. Neots Cambridgeshire PE19 8YP United Kingdom Tel: +44 (0)1480 396395 Fax: +44 (0)1480 396296 Email: sales@picotech.com Manufactured in UK DO090-6... - Page 12 DO090-6...
