Summary of Contents for PICO Lasermax
- Page 2 LaserMax Laser or Light housing. Visit Beretta.com to purchase grip housing separately. LASERMAX INSTALLATION Please refer to your Beretta PICO manual for grip housing removal and installation. LASERMAX OPERATION There is a tap-on/tap-off activation switch on either side of the grip housing.
-
Page 3: Battery Installation
BATTERY INSTALLATION LIGHT: Remove battery cover with Phillips head screwdriver (not included). Insert CR2 Lithium battery and reinstall battery cover. TIP: Battery cover tab must line up with grip housing notch. LASER: Remove battery cover with Phillips head screwdriver (not included). Only remove the screw labeled “BATTERY.”... -
Page 4: Aligning The Laser
ALIGNING THE LASER WARNING: Make sure the pistol is unloaded. If not, unload it following the “UNLOADING” instructions in this manual (pages 22-23). While pointing the muzzle in a safe diretion, turn windage screw clockwise for right, counterclockwise for left. Turn elevation screw clockwise (as viewed from above firearm) for down, counterclockwise for up. -
Page 5: Spare Parts
For best results, it is recommended that the laser or light lens be cleaned along with your firearm after each use. SPARE PARTS LMS-AT50 Adjustment tool (for laser) LMS-2x13N 1/3N battery (2 pack for laser) LMS-CR2 CR2 battery (for light) For patent information, please visit: www.lasermax.com/sevice/patents.aspx. 01785-0-54 5/14... - Page 6 AN ISSUE WITH YOUR PICO, PLEASE DO NOT RETURN IT TO THE STORE. For firearm function issues, contact Beretta: 1-800-237-3882 For light/laser function issues, contact LaserMax: 1-800-527-3703 DANGER LMS-PICO-L Laser radiation is emitted from the 70 Lumen LED front aperture of the laser when Vison Advisory Claim the switch is activated.
- Page 7 Some States by LaserMax to have become defective after the do not allow limitations on how long an implied date of purchase due to abuse, misuse, etc.
- Page 8 Beretta USA Corp. 17601 Beretta Drive Accokeek, MD 20607 Tel. (301) 283-2191 www.beretta.com UD6A0382...
