Operation:
The Multi-Functional Intersection Control System will allow the user to obtain Takedown, Intersection and Alley functions with
a single pair of intersection modules. The operation is as follows;
NOTE: Wiring Colors May Vary, Refer To Wire Tag For Exact Colors.
Passenger Side Alley - When the ( YEL/BLK ) wire is connected to a source of +12VDC the passenger's side intersection module will
move to the alley position.
Driver Side Alley - When the ( YEL ) wire is connected to a source of +12VDC the driver's side intersection module will move to the alley
position.
Intersection - When the ( WHT/BLK ) wire is connected to a source of +12VDC both intersection modules will oscillate. When Intersec-
tion mode is selected the Passenger side and Driver side Alley mode will be overridden. The user cannot obtain Alley
functions while in Intersection mode.
Takedown - When the ( ORG/BLK ) wire is connected to a source of +12VDC both intersection modules will move to the takedown
position. When in Takedown mode, the Alley and Intersection modes are overridden.
NOTE: ALL DEVICES USED TO SWITCH +12VDC TO EACH CONTROL WIRE
PROBLEM
Lighthead oscillates when selecting
Alley and/or Takedown modes.
Lighthead doesn't move when Alley
and/or Takedown mode is selected,
but moves in Intersection mode
Lighthead does not move when any
mode is selected.
Lighthead operates properly,
but lamp is not on
Driver side lighthead oscillates and
Passenger side lighthead does not
move when Takedown is selected.
Note: In Takedown mode,Passenger
side lighthead will not move until
Driver side lighthead has located
Intersection mode selected, Driver
and Passenger side Alley modes
do not function
Takedown mode selected, no
other modes operational
MUST BE RATED FOR A MINIMUM OF 10A.
POSSIBLE CAUSE
Lighthead not sensing position.
Check the following:
Bad wiring harness
Bad connection
Failed position sensor
Failed lighthead assembly
Bad motor wire to module
Failed light bar wire harness
No power to control module
Failed lighthead assembly
Failed control module
Lamp burnt out
Bad lamp wire to module
Driver side lighthead not sensing
Check for the following:
Bad wiring harness
Bad wiring harness connection
Failed position sensor
No problem
No problem
1 6
SOLUTION
Replace wiring harness
Check connections (Figure 10 & 11)
Replace lighthead assembly
Replace lighthead assembly
Check connections / Replace wire
Check light bar wiring harness
Check +12VDC switching control
Replace lighthead assembly
Replace control module
Replace lamp (50W maximum)
Check connections / Replace wire
Replace wiring harness
Check connections (Figure 10 & 11)
Replace lighthead assembly
Normal operation, Intersection mode
overrides Alley mode.
Normal operation, Takedown mode
overrides all other modes
