Flash Pattern
Cycle Flash
Steady-Burn
Five Flash
Quad Flash
Triple Flash
Double Flash
Fast Double Flash
NFPA
Quad Pop Flash
Triple Pop Flash
Double Pop Flash
PCB
Flash Pattern Header for OPTIX/LEDX
Directional module Flash Pattern - Table 2
Description
Cycles through various patterns @ 70 fpm
Steady-Burn
Five Pulses per flash @ 70 fpm
Four Pulses per flash @ 70 fpm
Three Pulses per flash @ 70 fpm
Two Pulses per flash @ 70 fpm
Two Pulses per flash @ 85 fpm
Four Pulses, 70% Duty Cycle @ 75 fpm
Four Pulses per flash ( 3 equal, 1 extended) @ 70 fpm
Three Pulses per flash ( 2 equal, 1 extended) @ 70 fpm
Two Pulses per flash ( 1 equal, 1 extended) @ 70 fpm
FIGURE 5
1 0
Momentarily short and release
to change patterns
J1
