Camera
Microphone

Raise and Lower Monitor Screen

To raise or lower screen, place a hand on each side of the monitor and lift or lower to the desired height (Figure RL.1).
NOTE:
Handle with care when raising or lowering the monitor screen.
Tilt
Grasp both sides of the monitor screen with your hands and adjust the tilt as desired (Figure TS.1).
NOTE:
Handle with care when tilting the monitor screen.

Flexible Arm Installation

This LCD monitor is designed for use with a flexible arm.
To prepare the monitor for alternate mounting purposes:
Follow the instructions provided by the manufacturer of the display mount.
To meet the safety requirements, the mounting stand must be able to support the weight of the monitor and be UL-certified.
LED
The white light is lit up while
the camera is in operation.
Microphone
Figure E.1
Figure RL.1
Figure TS.1
English-8
UP
LED
DOWN
Indicates that the
power is on or off.
AUTO
MENU
POWER
