Extech Instruments EX330 User Manual page 14

5.000Hz
Frequency
50.00Hz
500.0Hz
5.000kHz
50.00kHz
500.0kHz
5.000MHz
10.00MHz
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz; 5Vrms min @ 20% to
80% duty cycle and > 100kHz.
Duty Cycle 0.1 to 99.9%
For duty cycle the pulse width range is 100µs - 100ms (Frequency: 5Hz to 150kHz)
Temp (type-K)
-4 to 1382°F
-20 to 750°C
NOTES:
Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital converter.
Accuracy is stated at 65
0.001Hz
0.01Hz
0.1Hz
0.001kHz
0.01kHz
0.1kHz
0.001MHz
0.01MHz
0.1%
1°F
1°C
o o o o
F to 83 F (18 C to 28
14
±(0.1% reading + 1 digits)
±(1.2% reading + 2 digits)
±(3.0% reading + 8 digits)
(probe accuracy not included)
C) and less than 75% RH.
Model EX330 - Version 4.0 – 05/06
