- Page 1 KOBE Brand Range Hood Model No. CH9630SQB (30”) CH9636SQB (36”) CH9642SQB (42”) CH9648SQB (48”) CH-196 SERIES – 10” HEIGHT INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ...1 COMPONENTS OF PACKAGE ...3 INSTALLATION...4 UNDER THE CABINET INSTALLATION ... 6 STAND ALONE INSTALLATION ... 9 OPERATION INSTRUCTIONS ...13 MAINTENANCE ...15 SPECIFICATIONS...17 MEASUREMENTS & DIAGRAMS...18 PARTS LIST...23 CIRCUIT DIAGRAM...27 DISCLAIMER ...29 WARRANTY...30 PRODUCT REGISTRATION...32... -
Page 3: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 4 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
{G} Rubber Stand {H} Oil Tunnel 3/16" X 1/2" (8 pcs) FOR MORE INFORMATION, PLEASE VISIT OUR W EBSITE OR CONTACT KOBE RANGE HOODS AT (626) 350-1355. Duct Cover Box (Sold Separately) {I} KOBE Duct Cover (Model No. CH1120DC) {J} Inner Duct Cover-Mounting Bracket... -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1 or TABLE 2. (All calculation in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended 27”... - Page 7 SAFETY WARNING HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF IT IS NECESSARY TO REMOVE ANY PARTS FOR INSTALLING, CLEANING OR SERVICING. NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY OCCUR. Installation Contents UNDER THE CABINET INSTALLATION ...6 REPARATION BEFORE NSTALLATION...
-
Page 8: Under The Cabinet Installation
UNDER THE CABINET INSTALLATION Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe • from the hood to the outside. Refer to Figure 1. A straight, short vent run will allow the •... -
Page 9: Ductwork Installation
4. Draw electrical wires access opening. From inside of the hood, place screw (not provided) into the exact center of each knockout hole and secure to cabinet bottom. Once all mounting screws are in place, finish tightening screws CAUTION MAKE SURE THE HOOD IS SECURE BEFORE RELEASING. -
Page 10: Accessories
Accessories 9. Drop oil tunnel into recess support near rear of hood. Refer to Figure 6. 10. Install baffle filters and stainless spacer(s). Refer to Measurements and Diagrams on page 22 for baffle filter and stainless spacer placement. Angle baffle filter toward back of hood . -
Page 11: Stand Alone Installation
*** This installation only applies if installing with the CH1120DC duct cover. Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe • from the hood to the outside. (Figure 8) A straight, short vent run will allow the •... -
Page 12: Wiring To Power Supply
1. Using references Measurements and Diagrams on pages 19-21, mark the leveling point of the hood. Position two mounting screws (not provided) on the wall, leaving 1/8” space away from the wall. 2. Puncture the knockout wire access hole at the back of the hood and draw the electrical wires through as shown in Figure 12. -
Page 13: Duct Cover Installation
Duct Co ver Installation 6. Mark the position of the inner duct cover- mounting bracket reference from Measurements and Diagrams on page 20-21. Attach and secure inner duct cover-mounting bracket {J} with two screws (not provided) to the wall. Refer to Figure 15. NOTE: Inner duct cover will be attached to the mounting bracket. -
Page 14: Final Assembly
Final Assembl y 14. Turn power ON in control panel. Check all light and fan operation. 15. Make sure to leave this manual for the homeowner. Figure 19... -
Page 15: Operation Instructions
OPERATION INSTRUCTIONS This KOBE hood is equipped with six electronic controls, two powerful centrifugal squirrel cages with stainless steel oil tunnel, stainless steel baffle filters and spacer(s), and bright 12- volt 20-watt halogen lights (2 for 30” & 36” and 3 for 42” & 48”). The six electronic buttons control the Light, Speed (QuietMode™, Low, Medium &... - Page 16 Figure 21 Turning Fan OFF: The 3-Minute Delay function will only turn off fans. The light settings will not be affected by the delay function. 3-Minute Delay - Press Power Control (On/Off) button once, the LED light for the active speed will flash and fans will shut off after 3 minutes.
-
Page 17: Maintenance
MAINTENANCE SAFETY WARNING NEVER PUT YOUR HAND INTO AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. For optimal operation, clean range hood and all baffle/spacer/filter/oil tunnel/oil container regularly. To Clean Hood Surface CAUTION NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve the appearance of the hood. - Page 18 To Replace Light Bulb CAUTION HALOGEN LIGHT UNIT MAY BE HOT! WAIT UNTIL UNIT IS COOL. 1. Make sure all controls are off, and range hood is unplugged. 2. Place a flat-head screwdriver between light cover and housing 3. Gently pull defective bulb straight out maximum.
-
Page 19: Specifications
Seamless / Satin Finish Vertical Squirrel Cage Top 7” Round Six Electronic Buttons CH9630SQB - 12V 20W x 2 CH9636SQB - 12V 20W x 2 CH9642SQB - 12V 20W x 3 CH9648SQB - 12V 20W x 3 (CH9630SQB) 29-3/4” x 22” x 10”... -
Page 20: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS All ( ) are in millimeter. All inch measurements are converted from millimeters. Inch measurements are estimated. MODEL NO: CH9630SQB CH9636SQB CH9642SQB CH9648SQB - FOR UNDER THE CABINET -... - Page 21 All ( ) are in millimeter. All inch measurements are converted from millimeters. Inch measurements are estimated. - FOR STAND ALONE (WITH OPTIONAL DUCT COVER) - MODEL NO: CH9630SQB CH9636SQB CH9642SQB CH9648SQB...
- Page 22 Rear Knockout Holes...
- Page 23 Hood-Mounting Bracket 9" (228) 8-5/8" (220) 9" (228) 10-1/4" (260) DUCT COVER-MOUNTING BRACKET Inner Duct Cover-Mounting Bracket Outer Duct Cover-Mounting Bracket 1/8" ( 3.4)
- Page 24 BAFFLE FILTER & STAINLESS STEEL SPACERS 30 ″ H00D 42 ″ H00D 36 ″ H00D 48 ″ H00D...
-
Page 25: Parts List
PARTS LIST MODEL NO.: CH9630SQB CH9636SQB CH9642SQB CH9648SQB Body Components DESCRIPTION Screws (3/16” x 3/8”) Hood Casing Hood-Mounting Bracket Screws (3/16” x 3/8”) Stainless Steel Oil Tunnel Blower Assembly Halogen Light Panel Gasket Screws (3/16” x 3/8”) Halogen Light Gasket... - Page 27 Blower Assembly DESCRIPTION Air Chamber Screw Cap Left Squirrel Cage Left Locknut Air Flow Grill Screws (3/16” x 3/8”) Right Locknut Right Squirrel Cage Gasket Screws (3/16” x 3/8”) Left Motor Right Motor Safety Screen MODEL/SIZE PART NO. CH196-6.1 CH196-6.2 CH196-6.3 CH196-6.4 CH196-6.5...
- Page 28 Electrical Assembly DESCRIPTION Electrical Box Screws (3/16” x 3/8”) Processor Board Electrical Box Cover Setup Board Gasket Screws (3/16” x 3/8”) Transformer Screws (3/16” x 3/8”) Capacitor Screws (3/16” x 3/8”) MODEL/SIZE PART NO. CH196-15.1 CH196-15.2 CH196-15.3 CH196-15.4 CH196-15.5 CH196-15.6 CH196-15.2 CH196-15.7 CH196-15.2...
-
Page 29: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: CH9630SQB CH9636SQB PROCESSOR BOARD 120V 60Hz CONTROL BOARD MOTOR MOTOR TRANSFORMER CAPACITOR CAPACITOR 10uF/450V 10uF/450V BLACK HALOGEN LIGHT... - Page 30 MODEL NO.: CH9642SQB CH9648SQB PROCESSOR BOARD 120V 60Hz CONTROL BOARD MOTOR MOTOR TRANSFORMER CAPACITOR CAPACITOR 10uF/450V 10uF/450V BLACK HALOGEN LIGHT...
-
Page 31: Disclaimer
DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. -
Page 32: Warranty
WARRANTY KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective. -
Page 33: Consequential Damage
KOBE Range Hoods Agent as applicable, for any traveling expenses and any costs of transporting the range hood or parts thereof to and from the... -
Page 34: Product Registration
KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection. - Page 35 KOBE Range Hoods 10505 Valley Blvd Suite # 302 El Monte, CA 91731 USA http://www.KOBERangeHoods.com This KOBE hood is manufactured for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country.
