Mean Well PB-230 Instruction Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

PB-230
Instruction
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB-230 and is the answer not in the manual?

Questions and answers

Related Manuals for Mean Well PB-230

Summary of Contents for Mean Well PB-230

  • Page 1 PB-230 Instruction Manual...
  • Page 2 PB-230 Instruction Manual 115cm 5cm AD1 (optional) DC output connector (standard) DC output connector (optional) UNICABLE 89M103-4P or equivalent [ housing: Anderson 1327FP(red), 1327G6FP(black) PIN NO. OUTPUT contacts: Anderson 261G2 (45A) or equivalent ] Red(+V) Black(-V) WARNING : Please make sure the polarity of the battery is connected correctly! Assembly Procedure 1.Make sure the charger is shut off and choosing suitable wires to connect the charger and batteries based on the rating of charging...
  • Page 3 Charge Voltage 100% Charge Current stage 1 stage 2 stage 3 Constant Current Constant Voltage Float Green Color of LED State PB-230-12 PB-230-24 PB-230-48 14.4V 28.8V 57.6V boost 13.6V 27.2V 54.4V Charging Current and Ambient Temperature When ambient temperature below 45 , the charging current will carry on the charge by the maximum current surpasses 45 the charge current will reduce automatically.
  • Page 4 To reduce risk of injury, charge only one, 12V Lead-Acid type rechargeable battery for Model PB-230- 12 ; charge only two, 12V Lead-Acid type rechargeable batteries, which were connected in series, for Model PB-230- 24 ; charge only four, 12V Lead-Acid type rechargeable batteries, which were connected in series, for Model PB-230- =blank or AD1.
