Summary of Contents for Ford MKX 2008

  • Page 1: Table Of Contents

    Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems AM/FM stereo with CDX6/MP3 Auxiliary input jack (Line in) USB port Satellite radio information Family entertainment system Navigation system SYNC Climate Controls Automatic temperature control Rear window defroster Lights Headlamps Turn signal control...
  • Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction Control™/AdvanceTrac Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch...
  • Page 3 Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2007 Ford Motor Company...

  • Page 4: Introduction

    For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com •...
  • Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
  • Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
  • Page 7 Introduction To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority.

  • Page 8: Vehicle Symbol Glossary

    Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
  • Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...

  • Page 10: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work.
  • Page 11 Instrument Cluster Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Powertrain malfunction/reduced power: Illuminates when a powertrain or a AWD fault has been detected.
  • Page 12 Instrument Cluster Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated. Airbag readiness: If this light fails to illuminate when the ignition is turned to ON, continues to flash or...
  • Page 13 Instrument Cluster Low tire pressure warning: Illuminates when your tire pressure is low. If the light remains ON at start up or while driving, the tire pressure should be checked. Refer to Inflating your tires in the Tires, Wheels and Loading chapter. When the ignition is first turned to ON, the light will illuminate for 3 seconds to ensure the bulb is working.

  • Page 14: Gauges

    Instrument Cluster Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.
  • Page 15 Instrument Cluster Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
  • Page 16 Instrument Cluster Odometer: Registers the total miles (kilometers) of the vehicle. Refer to Message center in the Driver Controls chapter on how to switch the display from Metric to English. Trip odometer: Registers the miles (kilometers) of individual journeys. Press and release the message center INFO button until “TRIP”...

  • Page 17: Entertainment Systems

    Entertainment Systems AUDIO SYSTEMS AM/FM In-dash six CD/MP3 satellite compatible sound system Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window controls, radio and moon roof (if equipped) may be used for up to ten minutes after the ignition is turned off or until either front door is opened.
  • Page 18 Entertainment Systems In satellite Radio mode (if equipped), there are 18 available presets, six each for SAT1, SAT2 and SAT3. To save satellite channels in your memory presets, tune to the desired channel then press and hold a preset control until sound returns. Satellite radio is available only with a valid SIRIUS subscription.
  • Page 19 Entertainment Systems • CATEGORY: Press OK to enter category mode. Press scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.) Press OK when the desired category appears in the display. After a category is selected, press SEEK to search for that specific category of channels only (i.e.
  • Page 20 Entertainment Systems Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability. RBDS ON/OFF: Press to turn RBDS ON or OFF. Program Type: If RBDS is ON, press to find the desired program type, then use SEEK or SCAN to search for FM radio...
  • Page 21 Entertainment Systems Occupancy mode (if equipped): Use to select and optimize sound for ALL SEATS, DRIVERS SEAT or REAR SEATS. Compression: Available in CD mode, this feature brings soft and loud CD passages together for a more consistent listening level. Press MENU until compression status is displayed.
  • Page 22 Entertainment Systems 9. TEXT/SCAN: In radio mode, when listening to a RBDS-equipped station, press and hold for a brief sampling of radio stations. In CD/MP3 mode, press and release to view the track title, artist name or disc title. Press and hold for a brief sampling of all tracks on the current disc.
  • Page 23 Entertainment Systems CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.

  • Page 24: Auxiliary Input Jack (Line In)

    Auxiliary input jack (Line in) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.

  • Page 25: Usb Port

    USB port (if equipped) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 26 Entertainment Systems Your vehicle may be equipped with a USB port inside your center console. This feature allows you to plug in media playing devices, memory sticks, and also to charge devices. For further information on this feature, refer to Using your USB port in the SYNC supplement.
  • Page 27 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.

  • Page 28: Satellite Radio Information

    Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
  • Page 29 Entertainment Systems Satellite Radio Electronic Serial Number (ESN): This 12–digit Satellite Serial Number is needed to activate, modify or track your satellite radio account. You will need this number when communicating with SIRIUS. While in Satellite Radio mode, you can view this number on the radio display by pressing AUX and Preset 1 control simultaneously.

  • Page 30: Family Entertainment System

    FAMILY ENTERTAINMENT DVD SYSTEM (IF EQUIPPED) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 31 Entertainment Systems Your vehicle may be equipped with a Family Entertainment System (FES) which allows you to listen to audio CDs, MP3 discs, watch DVDs and to plug in and play a variety of standard video game systems. The DVD player is capable of playing standard DVDs, CDs, MP3s and is compatible with CD-R/W, CD-R and certain CD-ROM media.
  • Page 32 Entertainment Systems Press the power button to turn the system OFF. The indicator light will turn off indicating the system is off. Note: The audio from the DVD system will play over all vehicle speakers and can be adjusted by the radio volume control. To play a CD in the DVD system: The DVD system can play audio CDs, CD-R and CD-R/W, CD-ROM and video CDs.
  • Page 33 Entertainment Systems 3. The disc will begin to play and the ’MP3 Audio Disc’ screen will display and allow you to access the COMPRESSION, SHUFFLE, SCAN and FOLDER MODE features. To play an auxiliary source through the DVD system The DVD system can be used to connect and play auxiliary electronic devices such as game systems, personal camcorders, video cassette recorders, etc.
  • Page 34 Entertainment Systems To listen to audio over the headphones (Dual play mode): 1. You may listen to channels A and B over wired or wireless headphones. Refer to Using the infrared wireless headphones and Using wired headphones for further information. •...
  • Page 35 Entertainment Systems 2. Adjust the volume levels using the volume controls on the DVD system. To adjust display brightness: To decrease/increase the brightness level on the display screen, press the brightness control on the DVD system. A display will appear at the bottom of the screen indicating the brightness level.
  • Page 36 Entertainment Systems Note: Headphone A can access any possible media (AM, FM1, FM2, SAT (if equipped), CD, DVD, DVD-AUX). Headphone B can only access DVD and DVD-AUX. For further information, refer to Single play/Dual play later in this section. (Stop/Eject): Press once to stop and press a second time to eject a disc from the DVD system.
  • Page 37 Entertainment Systems 9. LCD screen: The eight inch diagonal screen rotates down to view and up into housing to store when not in use. Ensure that the screen is latched into the housing when being stored. 10. Volume: When in Single Play, press to increase ( ) or decrease ) the volume over all speakers.
  • Page 38 Entertainment Systems 15. ENTER: Press to select/confirm the current selection. 16. Cursor /Brightness controls: Use the cursor controls to make various selections when in any menu. When not in a menu, and in DVD mode, press to adjust the brightness. A display bar will appear at the bottom of the screen indicating the brightness levels.
  • Page 39 Entertainment Systems 1. Power control: Press to turn the FES (Family Entertainment System) ON/OFF. 2. Cursor controls: Use in various active menus to advance the cursor up/down/left/right. When not in a Menu, the left and right cursor controls decrease and increase the display brightness. 3.
  • Page 40 Entertainment Systems 8. Fast Forward/Next: In DVD mode, press and hold for a quick advance within the DVD. Press and release to advance to the next chapter. In CD/MP3 mode, press to access the next track. 9. Play/Pause: Press to play or pause a DVD. 10.
  • Page 41 Entertainment Systems Battery replacement Batteries are supplied with the remote control unit. Since all batteries have a limited shelf life, replace them when the unit fails to control the DVD player. Remove the screw and unlatch the battery cover to access the batteries. The remote control unit uses two AAA batteries which are supplied with the unit.
  • Page 42 Entertainment Systems Headphones Wireless headphones The driver should never use the headphones while driving the vehicle. Using headphones may prevent the driver from hearing audible warnings such as horns or emergency sirens, which could result in a crash causing serious injury. Give your full attention to driving and to the road.
  • Page 43 Entertainment Systems To install the batteries, remove the screw at the bottom of the cover. Then, lightly press down on top and slide the cover off. When replacing the batteries, use two new batteries (alkaline recommended) and install them with the correct orientation as indicated in the battery housing.
  • Page 44 Entertainment Systems To operate the headphones: • Press POWER on the ear piece to turn on the headphones. A red indicator light will illuminate indicating the headphones are ON. Press POWER again to turn the headphones off. • Adjust the headphones to comfortably fit your head using the headband adjustment.
  • Page 45 Entertainment Systems Wired headphones Do not leave children unattended in the vehicle and do not let children operate the system while unsupervised. If wired headphones or auxiliary systems are used, children may become entangled in the cords and seriously injure themselves. The driver should never use the headphones while driving the vehicle.
  • Page 46 Entertainment Systems Single Play: Single play consists of all occupants in the vehicle listening to the same playing media over the front and rear speakers. When the DVD system is on, and the same source is playing through the front and rear speakers, SINGLE PLAY will appear in the front radio display.
  • Page 47 Operation with an aftermarket audio system (Headphone only mode) When the Family Entertainment System (FES) detects that the original radio supplied by Ford Motor Company has been removed from the vehicle, the Family Entertainment System will work in a state referred to as “Headphone Only Mode”.
  • Page 48 Entertainment Systems This is disc dependent — some DVD discs may have more viewing angles to select from. Once you have made your selection, press ENTER to confirm. The system default is Angle 1. Aspect ratio Select ASPECT RATIO to select the viewing size and shape of the video displayed on the LCD screen.
  • Page 49 Entertainment Systems Once you have made your selection, press ENTER to confirm. The system default is English. Subtitles Select SUBTITLES to turn the subtitle option on or off. The system default is OFF. Once you have made your selection, press ENTER to confirm. This is disc dependent.
  • Page 50 Entertainment Systems 4. The track and elapsed time will appear in the status bar. Use the DVD cursor controls on the bezel to highlight which track you would like to play. You can also use the cursor controls to highlight COMPRESSION, SHUFFLE or SCAN.
  • Page 51 Entertainment Systems MP3 disc quality factors Several factors can effect disc playback quality: • Disc capacity — Each disc contains about 650 MB of storage capacity. We do not recommend using high capacity discs containing 700MB of storage. • Disc type — Some CD-RW discs may operate inconsistently and may cause an error message to appear.
  • Page 52 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD and DVD players. Irregular shaped CDs or DVDs, CDs or DVDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the FES DVD system.
  • Page 53 Entertainment Systems Press to adjust volume levels. Slow play 1. With a DVD playing, press pause. 2. Press and hold the reverse or advance button to enter into slow play mode. Once in slow play mode, press and release the reverse or advance button repeatedly to cycle through 1/4 and 1/2.
  • Page 54 Entertainment Systems On the left side of the system is the Headphone A input jack. This headphone will listen to the media selected on the Channel A source. When you need to make any adjustments to the media, volume, etc, ensure that the Channel A source is highlighted.
  • Page 55 Entertainment Systems Audio interaction You can then also use the front audio controls to advance, reverse, play and pause a DVD. While a DVD is playing you may use the following controls on the front radio: • SEEK: Press to advance to the previous ( ) or next ( ) DVD chapters.
  • Page 56 Safety information Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 57 Entertainment Systems Do not attempt to service, repair or modify the Family Entertainment System (FES). See your dealer. Do not insert foreign objects into the DVD compartment. Do not leave children unattended in the vehicle and do not let children operate the system while unsupervised. If wired headphones or auxiliary systems are used, children may become entangled in the cords and seriously injure themselves.
  • Page 58 Entertainment Systems Federal Communication Commission (FCC) Compliance Changes or modifications not approved by Ford Lincoln-Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 59: Navigation System

    Compatibility with aftermarket audio systems (headphone only mode) When the Family Entertainment System (FES) detects that the original radio supplied by Ford Motor Company has been removed from the vehicle, the FES will work in a state referred to as “Headphone Only Mode.”...

  • Page 60: Climate Controls

    Climate Controls DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) SYSTEM WITH HEATED AND COOLED SEATS (IF EQUIPPED) Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Driver Controls chapter. MAX A/C setting: In order to achieve maximum cooling performance, press , A/C, , and set the temperature to 60°F (16°C) and the...
  • Page 61 Climate Controls Passenger cooled seat: Press to control the passenger cooled seat. Refer to Heated and cooled seats in the Seating and Safety Restraints chapter for more information. Manual override controls: Allows you to manually select where airflow is distributed. Press to toggle through the air distribution modes listed below.
  • Page 62 Climate Controls 15. Driver side temperature control: Press to increase/decrease the temperature on the driver side of the vehicle in dual zone or the temperature of both the driver and passenger sides in single zone. 16. AUTO: To engage automatic temperature control, press AUTO and select the desired temperature using the temperature control.

  • Page 63: Rear Window Defroster

    Climate Controls 4. Set the fan speed to the highest setting. 5. Direct the outer instrument panel vents towards the side windows. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. REAR WINDOW DEFROSTER The rear defroster control is located on the climate control panel and works to clear the rear window of fog and thin ice.

  • Page 64: Lights

    Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to turn on the headlamps. Adaptive headlamps (if equipped) The headlamp beams move in the same direction as the steering wheel which provides more visability when driving around curves.
  • Page 65 Lights Fog lamp control The headlamp control also operates the fog lamps. The fog lamps can be turned on when the headlamp control is in the positions and the high beams are not turned on. Pull headlamp control towards you to turn fog lamps on.
  • Page 66 Lights Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system does not activate the tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
  • Page 67 Lights • (1) 8 feet (2.4 meters) • (2) Center height of lamp to ground • (3) 25 feet (7.6 meters) • (4) Horizontal reference line 2. Measure the height of the headlamp bulb center from the ground and mark an 8 foot (2.5 meter) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well).

  • Page 68: Turn Signal Control

    Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Front row map lamps (if equipped) To turn on the map lamps, press the outer edge of the clear lens. The front row map lamp lights when: •...

  • Page 69: Bulb Replacement

    Lights Rear courtesy lamp Located in the rear cargo area, the courtesy lamp lights when: • any door is opened. • any of the remote entry controls are pressed and the ignition is OFF. BULB REPLACEMENT Headlamp Condensation The headlamps are vented to equalize pressure. When moist air enters the headlamp(s) through the vents, there is a possibility that condensation can occur.
  • Page 70 Lights Trade Function Number of bulbs number Fog lamp (if equipped) Front row map lamp 1600XB Second row dome/reading 1600XB lamp Rear courtesy lamp 1600XB Visor vanity lamp - Slide on Rail system (SOR) (if equipped) All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your authorized dealer.
  • Page 71 Lights Lowbeam bulb 4. Remove the bulb cover. Note: The left side has a side access bulb cover instead of a back access bulb cover 5. Remove the bulb by turning it counterclockwise and then pulling it straight out. 6. Disconnect the electrical connector from the bulb.
  • Page 72 Lights 4. Remove the bulb cover. 5. Rotate the bulb socket counterclockwise and remove from the lamp assembly. 6. Carefully pull the bulb out of the socket and push in the new bulb. 7. Install the bulb socket into the lamp assembly and rotate clockwise.
  • Page 73 Lights Replacing tail/stop/turn/sidemarker/backup lamp bulbs The tail/stop/turn/sidemarker/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb. Note: Your vehicle is equipped with a backup lamp assembly containing integral multiple light emitting diodes (LED).
  • Page 74 Lights Replacing license plate lamp bulbs 1. Make sure the headlamp switch is in the OFF position. 2. Remove the two screws and the license plate lamp assembly from the liftgate. 3. Carefully pull the bulb straight out from the lamp assembly. Install new bulb(s) in reverse order.

  • Page 75: Driver Controls

    Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.

  • Page 76: Steering Wheel Adjustment

    Driver Controls Rear window wiper/washer controls For rear wiper operation, rotate the rear window wiper and washer control to the desired position. Select: 2 — Normal speed operation of rear wiper. 1 — Intermittent operation of rear wiper. OFF — Rear wiper and washer off. For rear wash cycle, rotate (and hold as desired) the rear wiper/washer control to either position.
  • Page 77 Driver Controls ILLUMINATED VISOR MIRROR Lift the mirror cover to turn on the visor mirror lamp. Slide on rod feature The visor will slide back and forth on the rod for increased sunlight coverage. Rotate the visor towards the side window and extend it rearward for additional sunlight coverage.
  • Page 78 Driver Controls CENTER CONSOLE Your vehicle may be equipped with a variety of console features. These include: 1. Cupholders 2. Tissue box holder (if equipped) (located on underside of console lid) 3. Rear power point 4. Utility compartment with a Secondary storage bin with coin holder slots (on hinges inside utility compartment), power point, AIJ...
  • Page 79 Driver Controls To have full capacity usage of your power point, the engine is required to be running to avoid unintentional discharge of the battery. To prevent the battery from being discharged: • do not use the power point longer than necessary when the engine is not running, •...

  • Page 80: Power Windows

    Driver Controls POWER WINDOWS Do not leave children unattended in the vehicle and do not let children play with the power windows. They may seriously injure themselves. When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings.
  • Page 81 Driver Controls Bounce-Back When the window is moving upward and an obstacle or a rough road condition interferes with the window’s movement, the window will automatically reverse direction and move down. This is known as “bounce-back”. If the ignition is turned OFF (without accessory delay being active) during bounce-back, the window will move down until the bounce back position is reached.

  • Page 82: Mirrors

    Driver Controls Automatic dimming interior rear view mirror Your vehicle is equipped with an interior rear view mirror which has an auto-dimming function. The electronic day/night mirror will change from the normal (high reflective) state to the non-glare (darkened) state when bright lights (glare) reach the mirror.

  • Page 83: Speed Control

    Driver Controls To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror. 2. Move the control in the direction you wish to tilt the mirror. 3. Return to the center position to lock mirrors in place. Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow...
  • Page 84 Driver Controls Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release 2. Accelerate to the desired speed. 3. Press the SET + control and release it.
  • Page 85 Driver Controls Resuming a set speed Press the RESUME control and release it. This will automatically return the vehicle to the previously set speed. Increasing speed while using speed control There are two ways to set a higher speed: • Press and hold the SET + control until you get to the desired speed, then release the control.
  • Page 86 STEERING WHEEL CONTROLS Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 87 Driver Controls In Radio mode: • Press to access the next/previous preset station. In CD mode: • Press to listen to the next track on the disc. In Satellite radio mode (if equipped): • Press to advance through preset channels. In any mode: •...
  • Page 88 Driver Controls SYNC system hands free control feature (if equipped) Press briefly to use the voice command feature. You will hear a tone and LISTENING will appear in the radio display. Press and hold to exit voice command. Press to activate phone mode or answer a phone call.
  • Page 89 Driver Controls Note: Do not attempt to move the panoramic power sunshades manually or sunshade damage or malfunction may occur. The sunshade track clips are designed to release the sunshade crossbar in order to prevent damage to the system. If this occurs the sunshade crossbar ends may just need to be slid back into position to regain proper function.
  • Page 90 Driver Controls Note: If the panoramic Vista Roof™ is excessively operated, the glass and shade motors will automatically go into a fail-safe jog mode (manual intermittent operation) to prevent overheating and/or damage to the motor. The motors will revert back to normal operation after a period of idle time.
  • Page 91 Driver Controls 1. Position the end of your hand-held transmitter 1–3 inches (2–8 cm) away from the HomeLink button you wish to program (located on your visor) while keeping the indicator light in view. 2. Simultaneously press and hold both the chosen HomeLink and hand-held transmitter buttons until the HomeLink indicator light changes from a slow to a rapidly blinking light.
  • Page 92 Driver Controls Gate Operator & Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting — not allowing enough time for HomeLink to accept the signal from the hand-held transmitter. After completing Step 1 outlined in the “Programming” section, replace Step 2 with the following: Note: If programming a garage door opener or gate operator, it is advised to unplug the device during the “cycling”...

  • Page 93: Message Center

    Driver Controls Erasing HomeLink buttons To erase the three programmed buttons (individual buttons cannot be erased): • Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds.
  • Page 94 Driver Controls Selectable features Reset Press this control to select and reset functions shown in the INFO menu and SETUP menu. Info menu This control displays the following control displays: • Odometer • Trip Odometer A or B • Distance to Empty •...
  • Page 95 Driver Controls Average fuel economy (AFE) Select this function from the INFO menu to display your average fuel economy in miles/gallon or liters/100 If you calculate your average fuel economy by dividing 100 miles traveled by gallons of fuel used (kilometers traveled by liters used), your figure may be different than displayed for the following reasons: •...
  • Page 96 Driver Controls Most geographic areas (zones) have a magnetic north compass point that varies slightly from the northerly direction on maps. This variation is four degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error.
  • Page 97 Driver Controls 6. Release the RESET control, then slowly press RESET down again. 7. Press the SETUP control repeatedly until the correct zone setting for your geographic location is displayed on the message center. To exit the zone setting mode press and release the RESET control.
  • Page 98 Driver Controls • Power Liftgate (if equipped) • Easy entry/exit seat (if equipped) • Reverse sensing system (Park Assist) (if equipped) • Language System check Selecting this function from the SETUP menu causes the message center to cycle through each of the systems being monitored.
  • Page 99 Driver Controls 1. To disable/enable the autolamp delay feature, select this function from the SETUP control for the current display mode. 2. Press the RESET control to select the new Autolamp delay values of 0, 10, 20, 30, 60, 90, 120 or 180 seconds. Autolock This feature automatically locks all vehicle doors when the vehicle is shifted into any gear, putting the vehicle in motion.
  • Page 100 Driver Controls Power Liftgate (if equipped) This feature allows users to open/close the rear liftgate at the touch of a button. 1. To disable/enable the power liftgate feature, select this function from the SETUP control for the current display mode. 2.
  • Page 101 Driver Controls In the event of a multiple warning situation, the message center will cycle the display to show all warnings by displaying each one for several seconds. The message center will display the last selected feature if there are no more warning messages.
  • Page 102 Driver Controls REAR LEFT DOOR AJAR. Displayed when the rear left door is not completely closed. REAR RIGHT DOOR AJAR. Displayed when the rear right door is not completely closed. PARK BRAKE ENGAGED. Displayed when the manual park brake is set, the engine is running and the vehicle is driven more than 3 mph (5 km).
  • Page 103 Driver Controls POSITIVE RETENTION FLOOR MAT (IF EQUIPPED) Do not install additional floor mats on top of the factory installed floor mats as they may interfere with the accelerator or the brake pedals. To install floor mats that have a retention post: Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to...
  • Page 104 Driver Controls Make sure that the liftgate is closed to prevent exhaust fumes from being drawn into the vehicle. This will also prevent passengers and cargo from falling out. If you must drive with the liftgate door open, keep the vehicle well ventilated so outside air comes into the vehicle.
  • Page 105 Driver Controls Do not attempt to manually force the liftgate to travel faster than the power system will permit. This will activate the obstacle detection feature. Exercise care, when power opening or closing the liftgate in a garage or other enclosed area with a low ceiling or close to a wall/garage door. The liftgate could be damaged from the contact.
  • Page 106 Driver Controls To power open the liftgate with outside liftgate control button: 1. To open, unlock the liftgate with the integrated keyhead transmitter or power door unlock control. 2. Push the control button located above the liftgate outside handle to unlatch and power open the liftgate.
  • Page 107 Driver Controls Obstacle detection: The power liftgate system is equipped with an obstacle detection feature. If the power liftgate is closing, the system will reverse to full open when it detects an obstacle. A chime will sound 3 times when an obstacle is detected as the liftgate begins to reopen.
  • Page 108 Driver Controls LUGGAGE RACK (IF EQUIPPED) The load must be placed directly on the luggage rack. The vehicle’s roof panel is not designed to carry a load. When loading the luggage rack, it is recommended to evenly distribute the load, as well as maintain a low center of gravity. Ensure that the load is securely fastened.

  • Page 109: Locks And Security

    Locks and Security KEYS Your vehicle is equipped with two Integrated Keyhead Transmitters (IKTs). The IKT functions as both a programmed ignition key that operates all the locks and starts the vehicle, and a remote keyless entry transmitter. Vehicles with a power liftgate will have a four-button IKT while vehicles without a power liftgate will have a three-button IKT.
  • Page 110 Locks and Security Recommended handling of the Integrated Keyhead Transmitter (IKT) To avoid inadvertently activating the remote entry functions of your vehicle, it is recommended that the Integrated Keyhead Transmitter (IKT) be handled properly when starting and turning off your vehicle. When inserting the IKT into the ignition cylinder, place your thumb on the center thumb rest of the IKT...

  • Page 111: Locks

    Locks and Security POWER DOOR LOCKS • Press the control to unlock all doors. • Press the control to lock all doors. Smart locks This feature helps to prevent you from locking yourself out of the vehicle if your key is still in the ignition. When you open one of the front doors or the liftgate and you lock the vehicle with the power door lock control (on the driver or passenger door trim panel), all the doors will lock, then all doors will automatically...
  • Page 112 Locks and Security Deactivating/activating autolock feature Your vehicle comes with the autolock features activated; there are four methods to enable/disable this feature: • Through your authorized dealer, • by using a power door unlock/lock procedure, • using a keypad procedure (if equipped), or •...
  • Page 113 Locks and Security Keyless entry key pad autolock enable/disable procedure 1. Turn the ignition to the 1 (LOCK) position. 2. Close all the doors. 3. Enter factory–set 5–digit entry code. 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5.
  • Page 114 Locks and Security Power door lock switch autounlock enable/disable procedure Before starting, ensure the ignition is in the 1 (LOCK) position and all vehicle doors are closed. You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, wait a minimum of 30 seconds before beginning again.
  • Page 115 Locks and Security CHILDPROOF DOOR LOCKS • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
  • Page 116 Locks and Security There are 2 possible types of IKTs: • Vehicles equipped with a power liftgate • Vehicles not equipped with a power liftgate The typical operating range for your IKT is approximately 33 feet (10 meters). A decrease in operating range could be caused by: •...
  • Page 117 Locks and Security The IKT allows you to: • remotely unlock the vehicle doors. • remotely lock all the vehicle doors. • remotely open the power liftgate (if equipped). • activate the personal alarm. • arm and disarm the perimeter anti-theft system. •...
  • Page 118 Locks and Security • The control can then be released and the windows and panoramic roof will complete the opening operation. • If any other remote entry transmitter control is pressed during the opening operation, both windows and panoramic roof movement will stop.
  • Page 119 Locks and Security Note: The panic alarm will only operate when the ignition is in the 1 (LOCK) position. Memory feature The Integrated Keyhead Transmitter allows you to recall the memory seat/mirror feature. Press to automatically move the seat/mirrors to the desired memory position.
  • Page 120 Locks and Security To replace the battery: 1. Twist a thin coin in the slot of the IKT near the key ring in order to remove the battery cover. 2. Do not wipe off any grease on the battery terminals on the back surface of the circuit board.
  • Page 121 Locks and Security Illuminated entry The interior lamps and puddle lamps (if equipped) illuminate when the Integrated Keyhead Transmitter or the keyless entry system keypad is used to unlock the door(s). The illuminated entry system will turn off the interior lights if: •...
  • Page 122 Locks and Security 1. Place the key in the ignition and turn the ignition to the 3 (RUN) position. 2. Press the power door unlock control on the door panel three times. 3. Turn the ignition from the 3 (RUN) position to the 1 (LOCK) position.
  • Page 123 Locks and Security KEYLESS ENTRY SYSTEM You can use the keyless entry keypad to: • lock or unlock the doors without using a key. • recall memory seat/power mirrors positions. The keypad can be operated with the factory set 5–digit entry code; this code is located on the owner’s wallet card in the glove box and is available from your authorized dealer.

  • Page 124: Anti-Theft System

    Locks and Security Erasing personal code 1. Enter the factory set 5–digit code. 2. Within five seconds, press the 1 • 2 on the keypad and release. 3. Press and hold the 1 • 2 for two seconds. This must be done within five seconds of completing Step 2.
  • Page 125 Note: The SecuriLock™ passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
  • Page 126 Locks and Security The theft indicator will flash every two seconds to act as a theft deterrent when the vehicle is armed. Automatic disarming The vehicle is disarmed immediately after the ignition is turned to the 3 (RUN) position. The theft indicator will illuminate for three seconds and then go out. If the theft indicator stays on for an extended period of time or flashes rapidly, have the system serviced by your authorized dealer.
  • Page 127 Locks and Security • If two previously programmed coded keys are not available, you must take your vehicle to your authorized dealer to have the spare key(s) programmed. Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition.
  • Page 128 Locks and Security PERIMETER ALARM SYSTEM The perimeter anti-theft system will help protect your vehicle from unauthorized entry. If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL Integrated Keyhead Transmitters are brought to the authorized dealer to aid in troubleshooting. Arming the system When armed, this system will respond if unauthorized entry is attempted.
  • Page 129 Locks and Security Each door, the hood, and the liftgate is armed individually, and if any are open, they must be closed before the open entry point (door, hood, or liftgate) can enter the 20 second countdown. The turn signal lamps will flash once when all doors, the hood and the liftgate are closed indicating the vehicle is locked and entering the 20 second countdown.

  • Page 130: Seating And Safety Restraints

    Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
  • Page 131 Seating and Safety Restraints Push release button to lower head restraint. Adjusting the front power seat Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
  • Page 132 Seating and Safety Restraints To reduce the risk of possible serious injury: Do not hang objects off seat back or stow objects in the seatback map pocket (if equipped) when a child is in the front passenger seat. Do not place objects underneath the front passenger seat or between the seat and the center console (if equipped).
  • Page 133 Seating and Safety Restraints Using the power lumbar support The power lumbar control is located on the outboard side of the seat. Press one side of the control to adjust firmness. Press the other side of the control to adjust softness. Memory seat and mirrors This system allows automatic positioning of the driver seat and...
  • Page 134 Seating and Safety Restraints Easy-entry/easy-exit feature This feature automatically moves the driver’s seat rearward 2 inches (5 cm) when: • the transmission is in N (Neutral) or P (Park) • the key is removed from the ignition cylinder The seat will move forward (to the original position) when: •...
  • Page 135 Seating and Safety Restraints To operate the cooled seats: Press once to activate the high cool setting (3 indicator lights). Continue pressing to scroll through the other settings; medium cool (2 indicator lights), low cool (1 indicator light) or off. The cooled seats will turn off after 30 minutes.
  • Page 136 Seating and Safety Restraints • Remove filter. To install a filter: • First, position the filter in it’s housing making sure that the far forward end is all the way up in the housing. Then push in on the center of the outside edge of the filter and rotate up into the housing until it clips into position.
  • Page 137 Seating and Safety Restraints Push release button to lower head restraint. Folding down the 60/40 rear seats Note: The head restraints should be placed in the full down position before folding the seatback down. Note: Ensure that no objects such as books, purses, or briefcases are on the floor in front of, on or under the second row seat cushion before actuating the release lever to cycle the seats to the load-floor position.
  • Page 138 Seating and Safety Restraints 2nd row EasyFold™ seatback release Ensure that the seat is unoccupied when folding it down. Folding the seat while occupied could result in damage to the seat or injury. Note: The power feature is operational when the vehicle is in park and the lifgate has been open for less than 10 minutes.
  • Page 139 Seating and Safety Restraints Adjusting the second row seatback Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. The second row seat reclines for additional comfort.
  • Page 140 Seating and Safety Restraints To access the cup holders, lift up one of the slotted areas on the cover. Use only soft cups in the cupholder. Hard objects can injure you in a collision. Returning the 2nd row armrest to the upright position Close the cover on the cup holders.

  • Page 141: Safety Restraints

    Seating and Safety Restraints To operate the heated seats: • Push the indicated side of the control for maximum heat. • Push again to deactivate. • Push the indicated side of the control for minimum heat. • Push again to deactivate. The heated seat module resets at every ignition run cycle.
  • Page 142 Seating and Safety Restraints • Front crash severity sensors. • Restraints Control Module (RCM) with impact and safing sensors. • Restraint system warning light and back-up tone. • The electrical wiring for the airbags, crash sensor(s), safety belt pretensioners, front safety belt usage sensors, driver seat position sensor, front passenger sensing system, and indicator lights.
  • Page 143 Seating and Safety Restraints Driver’s seat position sensor The driver’s seat position sensor allows your Personal Safety System™ to tailor the deployment level of the driver dual-stage airbag based on seat position. The system is designed to help protect smaller drivers sitting close to the driver airbag by providing a lower airbag output level.
  • Page 144 Seating and Safety Restraints Front safety belt pretensioners The safety belt pretensioners at the front outboard seating positions are designed to tighten the safety belts firmly against the occupant’s body during frontal collisions, and in rollover and side collisions when the Safety Canopy is activated.
  • Page 145 Seating and Safety Restraints Safety belt precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving.
  • Page 146 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
  • Page 147 Seating and Safety Restraints All safety restraints in the vehicle are combination lap and shoulder belts. All of the passenger combination lap and shoulder belts have two types of locking modes described below: Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
  • Page 148 How to disengage the automatic locking mode Ford Motor Company recommends that all passenger safety belt assemblies and attaching hardware should be inspected by an authorized dealer after any collision to verify that the automatic locking retractor feature for child seats is still working properly.
  • Page 149 Seating and Safety Restraints Safety belt height adjustment Your vehicle has safety belt height adjustments at the front outboard seating positions. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To adjust the shoulder belt height, pull on the center button and slide the height adjuster up or down.
  • Page 150 Seating and Safety Restraints To adjust the comfort guide: 1. Slip the shoulder belt into the belt guide. 2. Slide the guide up or down along the webbing so that the belt is centered on the occupant’s shoulder. Position the safety belt comfort guide so that the belt rests across the middle of your shoulder.
  • Page 151 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
  • Page 152 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition switch illuminates 1-2 minutes and the is turned to the ON position... warning chime sounds 4-8 seconds.
  • Page 153 Seating and Safety Restraints If... Then... The driver’s and front The Belt-Minder feature will not passenger’s safety belts are activate. buckled before the ignition switch is turned to the ON position or less than 1-2 minutes have elapsed since the ignition switch has been turned ON...
  • Page 154 Seating and Safety Restraints The following are reasons most often given for not wearing safety belts (All statistics based on U.S. data): Reasons given... Consider... “Crashes are rare events” 36700 crashes occur every day. The more we drive, the more we are exposed to “rare”...
  • Page 155 Seating and Safety Restraints Reasons given... Consider... “I have an airbag” Airbags offer greater protection when used with safety belts. Frontal airbags are not designed to inflate in rear and side crashes or rollovers. “I’d rather be thrown clear” Not a good idea. People who are ejected are 40 times more likely to DIE.
  • Page 156 Seating and Safety Restraints The driver and front passenger Belt-Minder features can be deactivated/activated by performing the following procedure: Before following the procedure, make sure that: • The parking brake is set • The gearshift is in N (Neutral) (manual transmission) •...

  • Page 157: Airbags

    Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important supplemental restraint system precautions Airbags DO NOT inflate slowly or gently and the risk of injury from a deploying airbag is greatest close to the trim covering the airbag module. All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag supplemental restraint system (SRS) is provided.
  • Page 158 Seating and Safety Restraints Never place your arm over the airbag module as a deploying airbag can result in serious arm fractures or other injuries. Steps you can take to properly position yourself away from the airbag: • Move your seat to the rear as far as you can while still reaching the pedals comfortably.
  • Page 159 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
  • Page 160 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
  • Page 161 Seating and Safety Restraints • a readiness light and tone • and the electrical wiring which connects the components • Side curtain airbag system. Refer to Safety Canopy™ system later in this chapter. • Front passenger sensing system. Refer to Front passenger sensing system.
  • Page 162 Seating and Safety Restraints The front passenger sensing system uses a passenger airbag off or pass airbag off indicator which will illuminate and stay lit to remind you that the front passenger frontal airbag is disabled. The indicator lamp is located in the center stack of the instrument panel above the climate controls.
  • Page 163 Seating and Safety Restraints • If the indicator lamp remains lit even after this, the person should be advised to ride in the rear seat. Pass Airbag Off Occupant Passenger Airbag Indicator Lamp Empty seat Unlit Disabled Small child in child Disabled safety seat or booster Small child with safety...
  • Page 164 Seating and Safety Restraints Pass Airbag Off Objects Passenger Airbag Indicator Lamp Small (i.e. 3 ring Unlit Disabled binder, small purse, bottled water) Medium (i.e. heavy Disabled briefcase, fully packed luggage) Empty seat, or small Disabled to medium object with safety belt buckled If you think that the status of the passenger airbag off indicator lamp is incorrect, check for the following:...
  • Page 165 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Guide.
  • Page 166 Seating and Safety Restraints A difficulty with the system is indicated by one or more of the following: • The readiness light (same light for front and side airbag system) will either flash or stay lit. • The readiness light will not illuminate immediately after ignition is turned on.
  • Page 167 Seating and Safety Restraints How does the side airbag system work? The design and development of the side airbag system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
  • Page 168 Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the side airbag has deployed, the airbag will not function again. The side airbag system (including the seat) must be inspected and serviced by an authorized dealer.
  • Page 169 Seating and Safety Restraints Safety Canopy™ system Do not place objects or mount equipment on or near the headliner at the siderail that may come into contact with a deploying Safety Canopy™. Failure to follow these instructions may increase the risk of personal injury in the event of a collision.
  • Page 170 Seating and Safety Restraints How does the Safety Canopy™ system work? The design and development of the Safety Canopy™ system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
  • Page 171 Seating and Safety Restraints The Safety Canopy™ system is designed to activate when the vehicle sustains lateral deceleration sufficient to cause the side crash sensor to close an electrical circuit that initiates Safety Canopy™ inflation or when a certain likelihood of a rollover event is detected by the rollover sensor. The Safety Canopy™...

  • Page 172: Child Restraints

    Seating and Safety Restraints Any difficulty with the system is indicated by one or more of the following: • The readiness airbag light (same light as for front airbag system) will either flash or stay lit. • The readiness light will not illuminate immediately after ignition is turned on.
  • Page 173 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
  • Page 174 Seating and Safety Restraints Booster seats should be used until you can answer YES to ALL of these questions: • Can the child sit all the way back against the vehicle seat back with knees bent comfortably at the edge of the seat without slouching? •...
  • Page 175 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
  • Page 176 80 lb (36 kg) using an upper torso harness and a belt-positioning booster. Ford Motor Company recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
  • Page 177 Seating and Safety Restraints Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
  • Page 178 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
  • Page 179 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
  • Page 180 Seating and Safety Restraints Attaching child safety seats with tether straps Most new forward-facing child safety seats include a tether strap which goes over the back of the seat and hooks to an anchoring point. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap.
  • Page 181 Seating and Safety Restraints 3. Locate the correct anchor behind the gap cover for the selected seating position. 4. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision.
  • Page 182 Seating and Safety Restraints Your vehicle has LATCH anchors for child seat installation at the seating positions marked with the child seat symbol. The anchors at the center of the rear seat are further apart than the sets of lower anchors for child seat installation at other seating positions.
  • Page 183 Seating and Safety Restraints If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat.

  • Page 184: Tires, Wheels And Loading

    Tires, Wheels and Loading NOTICE TO CROSSOVER VEHICLE OWNERS Crossover vehicles handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Crossover vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
  • Page 185 Tires, Wheels and Loading driving surfaces are relatively level, obstruction-free and otherwise similar to normal on-road driving conditions. Operating your vehicle under other than those conditions could subject the vehicle to excessive stress which might result in damage which is not covered under your warranty.

  • Page 186: Tire Information

    Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
  • Page 187 Tires, Wheels and Loading The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.

  • Page 188: Tire Inflation

    (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
  • Page 189 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
  • Page 190 Tires, Wheels and Loading Note: If you have to drive a distance to get air for your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump. It is normal for tires to heat up and the air pressure inside to go up as you drive.
  • Page 191 Tires, Wheels and Loading Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Inspect all your tires, including the spare, frequently, and replace them if one or more of the following conditions exist: Tire wear When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to help prevent your vehicle from skidding and...
  • Page 192 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
  • Page 193 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your Tire Pressure Monitoring System.
  • Page 194 Tires, Wheels and Loading • Do not run over curbs or hit the tire against a curb when parking If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires; spinning the tires can tear the tire and cause an explosion.
  • Page 195 Tires, Wheels and Loading • Front Wheel Drive (FWD)/ All Wheel Drive vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
  • Page 196 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
  • Page 197 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
  • Page 198 Tires, Wheels and Loading 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
  • Page 199 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below. Note: Tire Quality Grades do not apply to this type of tire. 1.
  • Page 200 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.

  • Page 201: Tire Pressure Monitoring System (Tpms)

    Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
  • Page 202 Tires, Wheels and Loading The Tire Pressure Monitoring System is NOT a substitute for manually checking tire pressure. The tire pressure should be checked periodically (at least monthly) using a tire gauge, see Inflating your tires in this chapter. Failure to properly maintain your tire pressure could increase the risk of tire failure, loss of control, vehicle rollover and personal injury.
  • Page 203 Tires, Wheels and Loading To restore the full functionality of the Tire Pressure Monitoring System, have the damaged road wheel/tire repaired and remounted on your vehicle. For additional information, refer to Changing tires with TPMS in this section. When you believe your system is not operating properly The main function of the Tire Pressure Monitoring System is to warn you when your tires need air.
  • Page 204 Tires, Wheels and Loading Low Tire Possible Customer Action Required Pressure cause Warning Light Flashing Warning Spare tire in Your temporary spare tire is in Light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.

  • Page 205: Vehicle Loading

    SNOW TIRES AND CHAINS Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
  • Page 206 Tires, Wheels and Loading Vehicle Curb Weight – is the weight of your new vehicle when you picked it up from your authorized dealer plus any aftermarket equipment. Payload – is the combined weight of cargo and passengers that the vehicle is carrying.
  • Page 207 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
  • Page 208 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
  • Page 209 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
  • Page 210 Tires, Wheels and Loading 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs. 4. The resulting figure equals the available amount of cargo and luggage load capacity.

  • Page 211: Trailer Towing

    Tires, Wheels and Loading 1,400 - (2 x 220) - (9 x 100) = 1,400 - 440 - 900 = 60 lb. Now you have the load capacity to transport the cement and your friend home. In metric units, the calculation would be: 635 kg - (2 x 99 kg) - (9 x 45 kg) = 635 - 198 - 405 = 32 kg.
  • Page 212 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weight Engine Maximum Trailer weight Tongue GCWR-lb. (kg) range-lb. (kg) load-lb. (kg) (0-Maximum) (0-Maximum) 3.5L Class I 7350 (3334) 0–2000 (0-907) 0–200 (0–91) towing (standard) 3.5L Class II 8500 (3855) 0–3500 (0–1588) 0–350 (0–159) towing (optional) GCWR (Gross Combined Weight Rating)/Trailer Weight...
  • Page 213 Tires, Wheels and Loading Hitches Do not use hitches that clamp onto the vehicle’s bumper or attach to the axle. You must distribute the load in your trailer so that 10%–15% of the total weight of the trailer is on the tongue. Safety chains Always connect the trailer’s safety chains to the hook retainers on the hitch.
  • Page 214 Tires, Wheels and Loading Trailer tow connector (equipped on vehicles with a Class II trailer tow/prep package) The trailer tow connector is located under the rear bumper, on the driver’s side of the vehicle. Refer to the following chart for information regarding the factory-equipped trailer tow connector: Trailer tow connector Color...

  • Page 215: Recreational Towing

    Tires, Wheels and Loading Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...
  • Page 216 Tires, Wheels and Loading All Wheel Drive (AWD) vehicles: Tow your All Wheel Drive vehicle with all four wheels on the ground or with all four wheels off the ground using a vehicle transport trailer. Do not tow your All Wheel Drive vehicle with the front wheels off the ground (by using a tow dolly) and the rear wheels on the ground.

  • Page 217: Driving

    Driving STARTING Positions of the ignition 1. LOCK, locks the automatic transaxle gearshift lever and allows key removal. This position also shuts the engine and all electrical accessories off without locking the steering wheel. To lock the steering wheel, remove the key then turn the steering wheel.
  • Page 218 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
  • Page 219 Driving • Make sure the gearshift is in P (Park). 3. Turn the key to 3 (RUN) without turning the key to 4 (START). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights.
  • Page 220 Driving Note: If the engine does not start on the first try, turn the key to LOCK, wait 10 seconds and try again. If the engine still fails to start, press the accelerator to the floor and try again; this will allow the engine to crank with the fuel shut off in case the engine is flooded with fuel.
  • Page 221 Driving Prior to using the engine block heater, follow these recommendations for proper and safe operation: • For your safety, use an outdoor extension cord that is product certified by Underwriter’s laboratory (UL ) or Canadian Standards Association (CSA). Use only an extension cord that can be used outdoors, in cold temperatures, and is clearly marked Suitable for Use with Outdoor Appliances.

  • Page 222: Brakes

    Driving Depending on the type of factory installed equipment, your engine block heater system may consume anywhere between 400 watts or 1000 watts of energy per hour. Your factory installed block heater system does not have a thermostat; however, maximum temperature is attained after approximately 3 hours of operation.
  • Page 223 Driving ABS warning lamp The ABS lamp in the instrument cluster momentarily illuminates when the ignition is turned on. If the light does not illuminate during start up, remains on or flashes, the ABS may be disabled and may need to be serviced. Even when the ABS is disabled, normal braking is still effective.

  • Page 224: Traction Control™/Advancetrac

    Driving Push the parking brake pedal downward again to release the parking brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. Note: If the vehicle is driven with the parking brake applied, a chime will sound.
  • Page 225 Driving AdvanceTrac with RSC stability enhancement feature will restore full engine power and torque to each wheel. If the AdvanceTrac with RSC system is activated excessively in a short period of time, the brake portion of the system will disable to allow the brakes to cool down.
  • Page 226 Driving During Roll Stability Control™ (RSC) events the “sliding car” icon in the instrument cluster will flash momentarily. Driving conditions that may activate AdvanceTrac with RSC include: • Emergency lane-change • Taking a turn too fast • Quick maneuvering to avoid an accident, pedestrian or obstacle AdvanceTrac with RSC button and icon functionality The AdvanceTrac with RSC system automatically turns on each time the engine is started, even if it was turned off when the engine was last...
  • Page 227 Driving Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage. The occurrence of a AdvanceTrac with RSC event is an indication that at least some of the tires have exceeded their ability to grip the road;...

  • Page 228: Transmission Operation

    Driving AUTOMATIC TRANSMISSION OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the RUN position unless brake pedal is depressed. If you cannot move the gearshift lever out of P (Park) with ignition in the RUN position and the brake pedal depressed: 1.
  • Page 229 Driving If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer as soon as possible. Automatic Transaxle Adaptive Learning Your transaxle is equipped with an adaptive learning strategy found in the vehicle computer.
  • Page 230 Driving • Move the gearshift lever into the desired gear To put your vehicle in P (Park): • Come to a complete stop • Move the gearshift lever and securely latch it in P (Park) Always set the parking brake fully and make sure the gearshift is latched in P (Park).
  • Page 231 Driving • O/D OFF lamp in the instrument cluster is illuminated. • To return to O/D (overdrive mode), press the transmission control switch. The O/D OFF lamp in the instrument cluster will not be illuminated. • O/D (overdrive) is automatically returned each time the key is turned off.
  • Page 232 Driving To help avoid personal injury, always use caution when in R (Reverse) and when using the RSS. This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
  • Page 233 Driving the driver to disable the system only when the ignition is ON and the gear selector is in R (Reverse). Refer to Message center in the Driver Controls chapter for more information. Keep the RSS sensors (located on the rear bumper/fascia) free from snow, ice and large accumulations of dirt (do not clean the sensors with sharp objects).
  • Page 234 Driving Basic operating principles • Drive slower in strong crosswinds which can affect the normal steering characteristics of your vehicle. • Be extremely careful when driving on pavement made slippery by loose sand, water, gravel, snow or ice. If your vehicle goes off the edge of the pavement •...
  • Page 235 Driving If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer. Do not spin the wheels at over 35 mph (56 km/h). The tires may fail and injure a passenger or bystander.
  • Page 236 Driving Do not drive your AWD vehicle in deep sand for an extended period of time. This will cause the AWD system to overheat. If the rear tires stop spinning while the front tires spin in deep sand, turn off the vehicle and allow the AWD system to cool down for a minimum of 15 minutes.
  • Page 237 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
  • Page 238 Any modifications to a vehicle that raise the center of gravity can make it more likely the vehicle will rollover as a result of a loss of control. Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder or luggage racks).
  • Page 239 Driving DRIVING THROUGH WATER If driving through deep or standing water is unavoidable, proceed very slowly especially when the depth is not known. Never drive through water that is higher than the bottom of the wheel rims (for cars) or the bottom of the hubs (for trucks).

  • Page 240: Roadside Emergencies

    Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
  • Page 241 1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles. To obtain reimbursement information, U.S.

  • Page 242: Hazard Flasher Switch

    Roadside Emergencies HAZARD FLASHER CONTROL The hazard flasher is located on the instrument panel by the radio. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Push in the flasher control and all front and rear direction signals will flash.

  • Page 243: Fuses And Relays

    Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
  • Page 244 Roadside Emergencies To remove the fuse panel cover, press in the tabs on both sides of the cover, then pull the cover off. To reinstall the fuse panel cover, place the top part of the cover on the fuse panel, then push the bottom part of the cover until it clicks into place.
  • Page 245 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Passenger front smart window Not used (Spare) Family entertainment system (FES)/Rear seat control, SYNC Driver front smart window Keypad illumination, 2nd row seat, Tire Pressure Monitoring System (TPMS), Brake Shift Interlock (BSI)
  • Page 246 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Demand lamps/Interior lamps Instrument panel cluster Ignition switch Radio Instrument panel cluster Overdrive cancel switch Automatic dimming rear view mirror Not used (Spare) Not used (Spare) Steering angle sensor Rear park assist, AWD, Heated seat module PATS transceiver...
  • Page 247 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
  • Page 248 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 40A** Cooling fan (vehicles with trailer tow) 60A** Cooling fan (vehicles without trailer tow) 40A** Cooling fan (trailer tow only) 30A** Rear heated seats 10A* Alternator 20A* Trailer tow parking lamps —...
  • Page 249 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 10A* VPWR 2 – PCM 15A* VPWR 4 – PCM — Not used 10A* A/C clutch — Not used — A/C clutch relay — Rear window defroster relay 40A** Rear window defroster —...

  • Page 250: Changing Tires

    Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — Not used 40A** Blower motor 20A** Cigar lighter/Power point 20A** Cigar lighter/Power point 20A** Cigar lighter/Power point — Not used 15A* Fuel pump — Not used — Not used 10A* Stop lamps —...
  • Page 251 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
  • Page 252 Roadside Emergencies 3. Full-size dissimilar spare without label on wheel When driving with the full-size dissimilar spare tire/wheel, do not: • Exceed 70 mph (113 km/h) • Use more than one dissimilar spare tire/wheel at a time • Use commercial car washing equipment •...
  • Page 253 Roadside Emergencies Removing the spare tire and jack 1. Lift the carpeted load floor panel located in the rear of the vehicle. 2. Remove the spare tire cover (if equipped). 3. Remove the wing nut securing the spare tire by turning it counterclockwise.
  • Page 254 Roadside Emergencies Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel. 1.
  • Page 255 Roadside Emergencies 3. Align the slot on top of the jack with the sheet metal flange indicated by the jack locator triangle next to the tire you are changing. Turn the jack handle clockwise until the wheel is completely off the ground.

  • Page 256: Lug Nut Torque

    20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.

  • Page 257: Jump Starting

    Roadside Emergencies Note: Inspect the wheel pilot hole prior to installation. If there is visible corrosion in wheel pilot hole, remove loose particles by wiping with clean rag and apply grease. Apply grease only to the wheel pilot hole surface by smearing a “dime” (1 square cm) sized glob of grease around the wheel pilot surface (1) with end of finger.
  • Page 258 Roadside Emergencies 4. Check all battery terminals and remove any excessive corrosion before you attach the battery cables. Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect from any electrical surges.
  • Page 259 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
  • Page 260 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
  • Page 261 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.

  • Page 262: Wrecker Towing

    It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. On FWD vehicles, if your vehicle is to be towed from the front, ensure proper wheel lift equipment is used to raise the front wheels off the ground.
  • Page 263 • Maximum distance is 50 miles (80 km). • Maximum speed is not to exceed 35 mph (56 km/h). Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.

  • Page 264: Customer Assistance

    Relationship Center at 1-800-521-4140. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
  • Page 265 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
  • Page 266 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the BBB...
  • Page 267 You are not bound by the decision but may choose to accept it. If you choose to accept the BBB AUTO LINE decision then Ford must abide by the accepted decision as well. If the arbitrator has decided in...
  • Page 268 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
  • Page 269 Customer Assistance If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your authorized dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
  • Page 270 (Items in this catalog may be purchased by credit card, check or money order.) Obtaining a French owner’s guide French Owner’s Guides can be obtained from your authorized dealer or by writing to: Ford Motor Company of Canada, Limited Service Publications CHQ202 The Canadian Road P.O. Box 2000 Oakville, ON, Canada...

  • Page 271: Reporting Safety Defects (U.s. Only)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...

  • Page 272: Cleaning

    Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
  • Page 273 Cleaning WAXING • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product. • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area.
  • Page 274 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
  • Page 275 Cleaning WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly. If the wipers do not wipe properly, substances on the vehicle’s glass or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, water repellent coatings, tree sap, or other organic contamination;...
  • Page 276 Cleaning INSTRUMENT PANEL/INTERIOR TRIM AND CLUSTER LENS Clean the instrument panel, interior trim areas and cluster lens with a clean and damp white cotton cloth, then with a clean and dry white cotton cloth; you may also use Motorcraft Dash & Vinyl Cleaner (ZC-38-A) on the instrument panel and interior trim areas.
  • Page 277 Cleaning • If a ring forms on the fabric after spot cleaning, clean the entire area immediately (but do not oversaturate) or the ring will set. • Do not use household cleaning products or glass cleaners, which can stain and discolor the fabric and affect the flame retardant abilities of the seat materials.
  • Page 278 Cleaning FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.

  • Page 279: Maintenance And Specifications

    Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide to find out which parts and services are covered.
  • Page 280 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel near the steering column. 2. Go to the front of the vehicle and release the secondary hood latch that is located under the front center of the hood.

  • Page 281: Engine Compartment

    Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.5L V6 engine 1. Engine coolant reservoir 2. Power steering fluid reservoir 3. Brake fluid reservoir 4. Battery 5. Power distribution box 6. Air filter assembly 7. Transaxle fluid dipstick 8. Engine oil dipstick 9.
  • Page 282 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16-A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.

  • Page 283: Engine Oil

    Maintenance and Specifications Poor wiper quality can be improved by cleaning the wiper blades and the windshield, refer to Windows and wiper blades in the Cleaning chapter. To prolong the life of the wiper blades, it is highly recommended to scrape off the ice on the windshield before turning on the wipers.
  • Page 284 Maintenance and Specifications 3. Set the parking brake and ensure the gearshift is securely latched in P (Park). 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level dipstick. • 3.5L V6 engine 6.
  • Page 285 Maintenance and Specifications • 3.5L V6 engine • If required, add engine oil to the engine. Refer to Adding engine oil in this chapter. • Do not overfill the engine with oil. Oil levels above this mark may cause engine damage.
  • Page 286 Change your engine oil and filter according to the appropriate schedule listed in scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.

  • Page 287: Battery

    Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
  • Page 288 Maintenance and Specifications Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.

  • Page 289: Engine Coolant

    Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the intervals listed in scheduled maintenance information.
  • Page 290 This damage would not be covered under your vehicle’s warranty. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, or DEX-COOL brand with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine...
  • Page 291 Maintenance and Specifications • A large amount of water without engine coolant may be added, in case of emergency, to reach a vehicle service location. In this instance, the cooling system must be drained and refilled with a 50/50 mixture of engine coolant and distilled water as soon as possible.
  • Page 292 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
  • Page 293 Maintenance and Specifications • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate freeze protection at the temperatures in which you drive in the winter months. If you drive in extremely hot climates: •...

  • Page 294: Fuel Information

    Maintenance and Specifications Continued operation will increase the engine temperature: • The engine will completely shut down. • Steering and braking effort will increase. Once the engine temperature cools, the engine can be re-started. Take your vehicle to an authorized dealer as soon as possible to minimize engine damage.
  • Page 295 Maintenance and Specifications The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out and injure you or others. If you do not use the proper fuel filler cap, excessive vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in serious personal injury.
  • Page 296 Maintenance and Specifications • Be particularly careful if you are taking “Antabuse” or other forms of disulfiram for the treatment of alcoholism. Breathing gasoline vapors, or skin contact could cause an adverse reaction. In sensitive individuals, serious personal injury or sickness may result. If fuel is splashed on the skin, promptly wash skin thoroughly with soap and water.
  • Page 297 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford, Motorcraft or other certified fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
  • Page 298 Maintenance and Specifications Choosing the right fuel Use only UNLEADED fuel or UNLEADED fuel blended with a maximum of 10% ethanol. Your vehicle was not designed to run on E85 fuels that are blended with a maximum of 85% ethanol. The use of leaded fuel is prohibited by law and could damage your vehicle.
  • Page 299 Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the Right Fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
  • Page 300 Maintenance and Specifications The advertised capacity is the amount of the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty.
  • Page 301 Maintenance and Specifications Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy under current driving conditions. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy.
  • Page 302 Maintenance and Specifications • Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in scheduled maintenance information. Conditions • Heavily loading a vehicle may reduce fuel economy at any speed. • Carrying unnecessary weight may reduce fuel economy (approximately 1 mpg [0.4 km/L] is lost for every 400 lb [180 kg] of weight carried).
  • Page 303 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
  • Page 304 Maintenance and Specifications On board diagnostics (OBD-II) Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD-II). The OBD-II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
  • Page 305 Maintenance and Specifications If the Service engine soon indicator is on or the bulb does not work, the vehicle may need to be serviced. Refer to the On board diagnostics (OBD-II) description in this chapter. If the vehicle’s engine or transmission has just been serviced, or the battery has recently run down or been replaced, the OBD-II system may indicate that the vehicle is not ready for I/M testing.
  • Page 306 Maintenance and Specifications 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C). 2. While the engine idles, turn the steering wheel left and right several times.
  • Page 307 Maintenance and Specifications TRANSAXLE FLUID Checking automatic transaxle fluid Refer to your scheduled maintenance information for scheduled intervals for fluid checks and changes.Your transaxle does not consume fluid. However, the fluid level should be checked if the transaxle is not working properly, i.e., if the transaxle slips or shifts slowly or if you notice some sign of fluid leakage.

  • Page 308: Air Filter(S)

    Maintenance and Specifications The transmission fluid should be within the cross-hatch area if at normal operating temperature 149°F (65°C). High fluid level Fluid levels above the safe range may result in transaxle failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage.
  • Page 309 Maintenance and Specifications To reduce the risk of vehicle damage and/or personal burn injuries do not start your engine with the air cleaner removed and do not remove it while the engine is running. Changing the air filter element 1. Release the clamps that secure the air filter housing cover.

  • Page 310: Part Numbers

    PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
  • Page 311 Maintenance and Specifications 2008 MKX (mkx) Owners Guide (post-2002-fmt) USA (fus)
  • Page 312 Maintenance and Specifications 2008 MKX (mkx) Owners Guide (post-2002-fmt) USA (fus)

  • Page 313: Engine Data

    Maintenance and Specifications ENGINE DATA Engine 3.5L-DOHC V6 engine Displacement 3.5L Required fuel 87 octane Firing order 1–4–2–5–3–6 Spark plug gap (0.052–0.056 inch) 1.32–1.42 mm Ignition system Coil on plug Compression ratio 10.3:1 Engine drivebelt routing • 3.5L V6 Engine 1.
  • Page 314 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
  • Page 315 Maintenance and Specifications The Vehicle Identification Number (VIN) contains the following information: 1. World manufacturer identifier 2. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint System 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6.

  • Page 316: Accessories

    GENUINE LINCOLN ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Lincoln Accessories are available for your vehicle through your local Lincoln or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
  • Page 317 Accessories Peace of mind Mobile-Ease™ hands-free communication system TripTunes™ advanced portable audio solution Remote start Vehicle security systems Wheel locks For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety Compliance Certification label).

  • Page 318: Index

    Index Axle lubricant specifications ..311 Accessory delay ......81 AdvanceTrac ......224 Battery ........287 Air cleaner filter ....308–310 acid, treating emergencies ..287 Air conditioning ......60 jumping a disabled battery ..257 maintenance-free ....287 Airbag supplemental restraint replacement, specifications ...310 system ......157, 166, 169 servicing ........287 and child safety seats ....159 description ....157, 166, 169...
  • Page 319 .......293 idle speed control ....287 Cupholder(s) ......139 lubrication specifications ..311 Customer Assistance ....240 refill capacities ......311 Ford Extended Service service points ......281 Plan ..........268 starting after a collision ..242 Getting assistance outside the Engine block heater ....220 U.S. and Canada .....269 Getting roadside assistance ...240...
  • Page 320 Index filter, specifications ..286, 310 Gas mileage recommendations ....286 (see Fuel economy) ....299 refill capacities ......311 Gauges .........14 specifications ......311 Event data recording ....6 Exhaust fumes ......220 Hazard flashers ......242 Head restraints ....130, 137 Headlamps ........64 Fail safe cooling ......293 aiming ........66 Family entertainment system ..30 autolamp system .......64...
  • Page 321 Index positioning .......250 english/metric button ....98 system check button ....98 storage ........250 warning messages ....100 Jump-starting your vehicle ..257 Mirrors ........81–82 automatic dimming rearview mirror ........82 Keyless entry system ....123 fold away ........83 autolock ........111 heated ........83 keypad ........123 programmable memory ..119 locking and unlocking doors ..124 side view mirrors (power) ..82 programming entry code ..123...
  • Page 322 Index fluid, specifications ....311 Safety Compliance Certification Label ....314 Power Windows ......80 Satellite Radio Information ..28 Seats ..........130 child safety seats ....176 Radio ..........17 climate control ......135 easy access/easyout feature ..134 Rear seat entertainment front seats .......130, 134 system ..........30 heated ........140 Relays ........243 memory seat ....119, 134...
  • Page 323 Index inflating ........188 label .........200 USB port ........25 replacing ........192 rotating ........194 safety practices .......193 sidewall information ....195 Vehicle Identification Number snow tires and chains ....205 (VIN) ..........314 spare tire ......251, 253 Vehicle loading ......205 terminology ......187 Ventilating your vehicle ...220 tire grades .......187 treadwear ......186, 191 Towing ........211...

Table of Contents
