Page 1 OWNER'S GUIDE Mondeo...
Page 2 Ford, and in spite of continuous market product monitoring, we cannot certify the suitability nor the safety of such products whether they are installed or intended for fitment in our vehicles. Ford is not liable for any damage caused by the use of non Ford parts and accessories.
Page 3 Filling station guide Opening the bonnet. Swivel the Ford badge in the radiator grille up wards. To unlock the bonnet, insert the key into the lock and turn first anticlockwise. Raise the bonnet slightly and turn the key fully clockwise.
Page 4: Table Of Contents
Contents Before driving Introduction Instrumentation Controls and features Seating and safety restraints Starting and driving Starting Driving Roadside emergencies Servicing Maintenance and care Capacities and specifications Index...
Page 5: Introduction
PREFACE helps maintain both its road Congratulations on acquiring your worthiness and its resale value. A new Ford. Please take the time to network of more than 10 000 Ford get well acquainted with your Dealers throughout Europe can vehicle by reading this handbook.
Page 6 Introduction FOR YOUR SAFETY AND Protecting the environment ENVIRONMENT PROTECTION We must all play our part in protecting the Warning symbols in environment. Correct this guide vehicle usage and the authorised disposal of waste cleaning and How can you reduce the risk of lubrication materials are significant personal injury and prevent steps towards this aim.
Page 7 Introduction Protection features for safer Extreme Hazard! Do not driving use a rearward facing child restraint on a seat The risk of injury from traffic protected by an air bag in front of accidents can never be completely eliminated, but it can be reduced with the aid of modern technology.
Page 8 Avoid using high engine speeds. You will then protect your engine, reduce fuel consumption, lower the engine noise level and help to reduce the environmental burden. We wish you safe and pleasurable driving with your Ford vehicle.
Page 9: Instrumentation
Instrumentation Page 19-20 Page 46 Page 42 Exterior light, front fog Direction Horn lights, rear fog lights indicators/ Page 52-53 main beam Page 21 Wiper lever Instrument lighting Page 8-18 dimmer Instrument cluster Page 21 Headlight levelling control Page 42 Steering wheel adjustment Page 50-51...
Page 10 Instrumentation Page 23 On some variants the appearance Heated front screen and location of some items may differ from those shown here, Page 24 however the page references Heated rear screen given still apply. Page 29 Ventilation vents Page 24 Analogue clock Page 24 Hazard flasher switch...
Page 11 Instrumentation Standard models ST 220 model INSTRUMENT CLUSTER There are different instrument cluster designs. The individual instruments, warning and indicator lights are described on the following pages.
Page 12 Illuminates when the ignition is switched on. It should extinguish as soon as the engine starts. If it does not, or if it illuminates whilst driving, switch off all unnecessary electrical equipment and drive immediately to the nearest Ford Dealer.
Page 13 Top up straight away if the level is low. Do not resume the journey if the oil level is correct, but have the engine checked by a Ford Dealer. Brake system warning light When the ignition is switched on (position II), the light illuminates briefly to confirm that the system is operational.
Page 14 If your vehicle has been equipped with factory fitted or original Ford towing equipment, the indicator light also warns of failure of the indicator bulbs on the trailer.
Page 15 If it illuminates when driving, it indicates a malfunction. Have this checked by a Ford Dealer. Normal braking (without ABS) will be maintained. Important notes on the use of the ABS system are to be found in the section Brakes in the chapter Driving.
Page 16 If both warning lights illuminate at the same time, stop the vehicle as soon as it is safe to do so. Have the braking system checked by a Ford Dealer before continuing your journey. Reduce vehicle speed gradually. Use the brake with great care.
Page 17 It should extinguish as soon as the engine starts. If it illuminates with the engine running, it indicates a malfunction. Have this checked by a Ford Dealer as soon as possible. If it flashes when driving, reduce the vehicle speed immediately.
Page 18 Instrumentation GAUGES Standard models ST 220 model...
Page 19 Instrumentation Temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the centre section. If the needle enters the red section, the engine is overheating. Switch off the ignition and determine the source of the problem once the engine has cooled down.
Page 20 (diameter, not the width) of the tyres is changed from those fitted at the factory, take the vehicle to your Ford Dealer to have the speedometer re programmed. If the speedometer is not re programmed, then it might not display the correct...
Page 21 Instrumentation Speedometer Odometer Registers the total mileage of the vehicle. Tripmeter The tripmeter can register the mileage of individual journeys. To reset, depress the button. Odometer Fuel gauge Tripmeter Reset button After refilling the tank fully, the needle will not move from the full position until the vehicle has travelled some distance.
Page 22: Controls And Features
Side and tail lights Turn one position clockwise. Headlights Turn two positions clockwise with the ignition switched on. The headlight beam direction can be adjusted to suit driving on the left or right hand side of the road. Please consult your Ford Dealer.
Page 23 Controls and features Parking lights Parking lights operate only when the ignition is switched off. Push in and turn anticlockwise. Front fog lights Switch on the exterior lights and pull out the control switch one position. The light in the switch will illuminate when the front fog lights are in use.
Page 24 Controls and features Instrument lighting dimmer This can be adjusted to vary the intensity of the instrument cluster lighting. Operates only when the exterior lights are switched on. Headlight levelling control The level of the headlight beams can be adjusted according to the vehicle load.
Page 25 Controls and features Without headlight levelling system With headlight levelling system Recommended headlight levelling control positions Load Control positions Persons Estate Load in Load in without luggage 4/5 door Front Rear with self self level. compartment* seats seats level. susp. susp.
Page 26 Controls and features Heated front and rear screen Use for quick defrosting or demisting of the front and rear screen. It should be switched on only if necessary. Heated front screen switch The system operates only when the engine is running. Press the switch to turn on or off.
Page 27 Controls and features Heated rear screen switch Switch on the ignition first. Press the switch to turn on or off. The light in the switch indicates operation. Electrically operated door mirrors also have a heating element to clear the glass. This system operates when the heated rear screen is switched on.
Page 28 Controls and features Air bag deactivation light The air bag deactivation light illuminates to indicate that the air bag system has switched off the passenger's front and side air bags. It illuminates briefly when the ignition is switched on. Thereafter, this light will only illuminate if the passenger seat is empty or occupied by a very light object and...
Page 29 Controls and features Remote luggage compartment release To open the luggage compartment, press the control button. Vehicle speed must be below 7 km/h and the vehicle must be unlocked. To open the luggage compartment from outside, refer to the section Luggage compartment.
Page 30 Controls and features HEATING AND VENTILATION Air interchange Outside air flows into the vehicle through air intakes forward of the front screen. Always keep the air intakes free of snow, leaves etc. to allow the heating and ventilation to function effectively.
Page 31 The fresh air filter should be replaced in line with Ford recommendations. Auxiliary heater – Diesel engine (depending on equipment fitted) The auxiliary heater, either...
Page 32 Controls and features Side windows defrosting/ Defrosting/ Centre vents demisting vents demisting vents (adjustable) Side vents (adjustable) Footwell front and rear Air distribution The air flow volume and direction can be regulated with the controls on the instrument panel and the controls on the side and centre vents.
Page 33 Controls and features When switched on, the air MANUAL AIR CONDITIONING conditioning system uses Note: The air conditioning system energy from the engine. This results only operates when the in a higher fuel consumption. In temperature is above +5 °C, the order to save energy and to reduce engine is running and the blower is fuel consumption, turn the air...
Page 34 Controls and features Blower The blower operates slowly when the switch is in the position shown. Low blower speed is the recommended position. To increase the blower speed, turn clockwise. The blower is off in the position OFF. With the blower turned off, the front screen may mist up in some weather conditions.
Page 35 Controls and features Switching on the air conditioning Press the switch to turn on or off. The light in the switch illuminates during operation. Refer to the note under Manual air conditioning. If the blower is turned to position OFF, the air conditioning will turn off.
Page 36 Controls and features Rapid heating of vehicle interior Set the distribution control to a position close to . Select a high blower setting. Suitable position in cold weather If the air flow in control position is not sufficient to demist the windows, select a position between .
Page 37 Controls and features Note: It is not recommended to use recirculated air for more than 30 minutes because there is no air exchange. Cooling with outside air At high external temperatures switch the air conditioning on. Turn the blower on. Set the temperature control to cold.
Page 38 Controls and features The air conditioning extracts ELECTRONIC AUTOMATIC humidity from the cooled air TEMPERATURE CONTROL (condensation). Therefore, it is Note: The air conditioning can completely normal if a small pool of operate only when the temperature water forms underneath the parked is above +5 °C, the engine is vehicle.
Page 39 Controls and features Recommended system settings The recommended system settings are 22 °C and AUTO mode. This setting is the best way to achieve and maintain a comfortable climate in the vehicle. Changing the temperature only affects the stable temperature desired, not the rate of heating and cooling.
Page 40 Controls and features Temperature Blue switch: lower temperature. Red switch: higher temperature. The recommended standard setting is 22 °C. The individual temperature can be set between 16 °C and 28 °C using the switches. In position LO (below 16 °C) the system will switch to permanent cooling, in HI (above 28 °C) to permanent heating, and not regulate a stable temperature.
Page 41 Controls and features Front screen All the air flows to the front screen and the side windows defrosting/ demisting vents. Footwell All the air flows to the front and rear footwell area. Any combination of settings can be selected simultaneously. To return to AUTO mode, press AUTO or switch off the switch(es) of the air distribution with...
Page 42 Controls and features Recirculating air Press the button to toggle between outside air and recirculated interior air. The light in the switch indicates the recirculating operation. Use recirculating air e.g. to shut out unpleasant odours from the outside. This function can be selected even if the Electronic Automatic Temperature Control is switched off.
Page 43 Controls and features Air conditioning In AUTO mode, the air conditioning will be switched on and off automatically to achieve and maintain comfort and support demisting. Press the A/C control to switch the air conditioning off. The light in the switch illuminates during operation.
Page 44 Controls and features II Ignition switched on, all STEERING COLUMN electrical circuits operational. CONTROLS Warning and indicator lights Steering column lock/ illuminate. This is the key position ignition switch when driving and must also be The combined steering column selected when being towed. lock/ignition switch has the III Starter motor activated.
Page 45 Controls and features Adjusting the steering wheel Never adjust the steering wheel when the vehicle is moving. Release the locking lever to adjust the height of the steering wheel and its distance from the driver. Return the lever to its original position to secure the wheel.
Page 46 Controls and features Automatic speed control The automatic speed control system should not be used in heavy traffic, on twisty roads or when the road surface is slippery. To switch on Press the ON switch. The automatic speed control system will not function until the vehicle is travelling over 40 km/h.
Page 47 Controls and features To switch off Press the OFF switch. The stored speed will be erased. To store a speed Press the switch. The set speed becomes the new stored speed. The indicator light in the instrument panel will illuminate.
Page 48 Controls and features To change speed Press the switch to accelerate. Press the switch to decelerate. The vehicle speed will change without the need to depress the accelerator pedal. The vehicle speed can be changed slightly by momentarily depressing the appropriate button. The set speed becomes the new stored speed.
Page 49 Controls and features Multi-function switch The following functions will operate only with the ignition switched on. Right direction indicator Move the lever up. Left direction indicator Move the lever down. Main/dipped beam Pull the lever towards the steering wheel. To return to dipped beam, pull the lever towards the steering wheel again.
Page 50 Controls and features Trip computer The following functions are available when the ignition is on: • Outside temperature • Remaining fuel range • Average fuel consumption • Average speed Controls • Info button Press to change between functions. You will hear an audible signal every time you press the button.
Page 51 Controls and features Outside temperature Shows the outside air temperature. Warning lights in the instrument cluster will illuminate in the following conditions: +4 ºC or lower: frost warning. 0 ºC or lower: danger of icy roads. Even if the temperature rises above +4 ºC there is no guarantee that the road is free of hazards caused by inclement...
Page 52 Controls and features Average fuel consumption Indicates the average fuel consumption since the function was last reset. Average speed Indicates the average speed since the function was last reset. Press the reset button to set to zero.
Page 53 Controls and features Radio remote control Select radio, CD or cassette mode on the radio. The following functions can be operated with the remote control. Volume Volume up: Pull the VOL+ switch towards the steering wheel. Volume down: Pull the VOL– switch towards the steering wheel.
Page 54 Controls and features • Move the SEEK switch towards the instrument panel: In radio mode, this will locate the next radio station down the frequency band. In CD mode, it will select the previous track. Memory seek or change CD Briefly press the "...
Page 55 Controls and features Wiper lever The following functions will operate only with the ignition switched on. Front screen • Single wipe Move the lever down. • Intermittent wiping Move the lever up one position. Intermittent wipe interval rotary switch: 1 = Short time interval 6 = Extended time interval •...
Page 56 Controls and features Once the wash/wipe cycle is completed, the wipers will pause and then perform one more cycle to clear the screen. Do not operate the washer for more than 10 seconds at a time, and never when the reservoir is empty.
Page 57 Controls and features OVERHEAD CONTROLS Door Interior lights activated The interior light switch has three positions: off, door activated and On some models, with the switch in the `Door activated' position, the interior lights will stay on for a while after the doors are shut. They go off immediately after the ignition is turned on.
Page 58 Controls and features Sun visors The sun visors can be released from the retention clips and swivelled towards the side window. The mirror cover can be slid open. Glasses holder Press to open. Sunroof The electric sunroof can be operated only when the ignition is switched on.
Page 59 Controls and features There are two ways of opening the sunroof - the rear of the sunroof lifts open or the sunroof opens from the front, sliding back under the roof. In order to change from one opening mode to the other, you have to close the sunroof first.
Page 60 Controls and features Note: The sunroof is connected to the vehicle's global opening/global closing function. For further information refer to the section Global opening/global closing. Sunroof anti-trap function The sunroof will stop automatically while closing and reverse some distance if there is an obstacle in the way.
Page 61 Controls and features Relearning function In case the sunroof does not close properly anymore, follow this relearning procedure: • Lift the rear of the sunroof as far as possible. Release the switch. • Press and hold the same switch again for 30 seconds until you see the sunroof move.
Page 62 When the rear of the sunroof is lifted, lift the rear all the way and then close the sunroof. Have the system checked by your Ford Dealer immediately. The anti trap function is not active during this procedure. Make sure that there are no obstacles in the way of the closing sunroof.
Page 63 Controls and features DOOR MOUNTED CONTROLS Manually adjustable outside rear-view mirrors Both outside rear view mirrors are adjustable from inside the vehicle. Electrically operated and heated outside rear-view mirrors Using the control unit, adjust Left Right the mirrors as required. After hand hand adjustment, return the switch...
Page 64 Controls and features Convex outside rear-view mirrors The rearward field of vision is increased to minimise blind spots at the rear corners of the vehicle. Objects seen in these mirrors will look smaller and appear further away than they actually are. Be careful not to overestimate the distance of the objects seen in the mirrors.
Page 65 Controls and features Power windows The windows can be operated only when the ignition is switched on. All windows are equipped with an anti trap function. Always remove the ignition key when leaving children alone in the vehicle, in order to avoid risk of injury through inadvertent operation of the power windows.
Page 66 Controls and features To open/close the windows automatically The windows can be opened or closed automatically. Briefly press button to open or button close to the second action point. Press again to stop the window. Note: All windows and the sunroof are connected to the vehicle's global opening/global closing function.
Page 67 Controls and features Window anti-trap function If any obstruction prevents the window from closing, it will automatically reverse its direction of travel for some distance. To override this protection function when there is a resistance, e.g. in the winter, proceed as follows: Careless closing of the windows can override the protection function and cause...
Page 68 Controls and features Resetting the memory After the battery has been disconnected from the vehicle it is necessary to reset the memory separately for each window: Press button until the window is fully closed. Hold the button for one more second. Release button and press again, two or three times, for one...
Page 69 Controls and features CONSOLE CONTROLS Manual transmission The reverse gear should be engaged only when the vehicle is stationary. To select reverse gear, lift the locking ring (1) and then move the gear lever towards the right and rear (2). Do not apply any undue lateral force to the gear lever when changing from 5th to...
Page 70 The Overdrive indicator light: automatic transmission flashes if a problem has been detected in the automatic transmission. If this happens, take your vehicle to the nearest Ford Dealer as soon as possible. 5 speed transmission 5-speed transmission (Durashift 5-tronic) This transmission allows you to...
Page 71 Controls and features Selector lever positions P = Park 4-speed transmission This position should be P = Park ....selected only when the vehicle is stationary. R = Reverse .
Page 72 Controls and features In emergencies the selector lever can be moved from the park 5-speed transmission position P mechanically. Refer to the section Emergency park P = Park ....position release lever (Automatic transmission).
Page 73 Controls and features Driving without overdrive results in higher fuel consumption. Depress the overdrive button again to reactivate. When the engine is switched on, the overdrive function is automatically selected. 2 = Gear 2 The automatic transmission remains permanently in second gear.
Page 74 Controls and features D = Drive 5-speed transmission The normal driving position. All five forward gears are electronically selected. +/– = Gears 1–5 When shifting manually, gears 1, 2, 3, 4 and 5 can be selected. For your safety and comfort, the automatic transmission will perform your manual gear selection when vehicle speed and engine speed are...
Page 75 Controls and features Manual shifting Manually selecting gears with the automatic transmission is similar to shifting with a manual transmission. This option can be selected when the vehicle is either stationary or in motion. Move the automatic gearshift lever to D, and then guide it to the right.
Page 76 Controls and features Cup holders Cup holders are located in the centre and floor console. Press to open. Push in to close. Do not place hot drinks in the cup holders while the vehicle is moving - there is a risk of scalding.
Page 77 Estate models only) can also be used to power 12 volt appliances having a current rating of maximum 10 amperes. However, if the engine is not running, this will accelerate battery discharging. When connecting appliances, use only specified connectors from the Ford Accessory range.
Page 78 Controls and features Handbrake Always apply the handbrake fully before leaving the vehicle. To apply the handbrake: • Press the foot brake pedal firmly. • While pressing the brake pedal, pull the handbrake lever up smartly to its fullest extent. •...
Page 79 Controls and features Rear ashtray (vehicles without Multimedia System) Swing out the ashtray. Push down the leaf spring to remove. Fuel filler flap Pull up the remote release lever beside the driver's seat. Open the filler flap and turn the cap anticlockwise.
Page 80 Controls and features LUGGAGE COMPARTMENT Luggage cover Do not place objects on the luggage cover. 5-door • Removal Detach the two lifting straps on the tailgate. Release the cover at its sides and pull it out horizontally without tilting it. •...
Page 81 A luggage net can be attached to the four retaining points on the load area floor. A luggage net can be obtained from your Ford Dealer. Close the tailgate properly to prevent it opening while you are driving. Driving with the...
Page 82 A first aid kit and warning triangle can be obtained from your Ford Dealer. Estate Storage for a first aid box and a warning triangle is located on the left hand side of the luggage compartment.
Page 83 Controls and features KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from Ford Dealers by stating the key number shown on the tag provided with the original keys. You should always carry a second key with you for emergencies.
Page 84 Controls and features Rear door childproof safety locks Turn the key in the rear doors outwards to activate the lock. The door cannot be opened from inside the vehicle. To deactivate the lock, turn the key inwards. Luggage compartment Your vehicle is equipped with a tailgate exterior release switch.
Page 85 Bonnet Swivel the Ford badge in the radiator grille to the side and turn the key first anticlockwise (1). Raise the bonnet slightly and turn the key fully clockwise (2) to open the bonnet.
Page 86 Controls and features CENTRAL DOOR LOCKING SYSTEM The central locking system can be activated from the driver's door. It operates only when the driver's door is closed. Other doors may still be open. It is activated from the outside with the key or from inside by depressing the locking button on the door handle.
Page 87 Controls and features To activate To activate double locking, turn the key in the driver's door to position (1) and then to position (2) within two seconds. The direction indicators will flash twice, provided all doors and the luggage compartment are closed. The vehicle is now double locked.
Page 88 Controls and features Radio frequency remote control The vehicle or luggage compartment will be opened if the button is pressed unintentionally, without the key being directed towards the vehicle (e.g. in your pocket). The system is operational one second after the ignition has been switched off.
Page 89 Controls and features To unlock the doors Pressing the button once deactivates the double locking and the anti theft alarm system and unlocks all doors. Note: If is pressed, but none of the doors, or the luggage compartment is opened and the ignition is not switched on for 45 seconds, central locking and the anti theft alarm system will...
Page 90 Controls and features Pressing and holding both buttons simultaneously for at least four seconds again will change the function back. To unlock the tailgate Press the button twice within three seconds. To lock Pressing the button once activates the central locking and the anti theft alarm system.
Page 91 Controls and features Key programming A maximum of four keys with radio frequency remote control can be programmed for your vehicle. 1. To programme new keys with radio frequency remote control turn the ignition key to position II four times within six seconds. 2.
Page 92 Controls and features Global opening/global closing The system automatically opens/ closes all windows and the sunroof from outside the vehicle. To close, press and hold the button for two seconds. Pressing any button stops the closing function. The anti trap function is also active during global closing.
Page 93 Controls and features Replacing the battery If the range of the transmitter in the key decreases gradually, the battery (type 3V CR 2032) should be replaced. Proceed as follows: • Carefully separate the transmitter unit from the key using a flat object (e.g.
Page 94 Two coded keys are needed to code a new key. Should you lose one key, take all your keys to your Ford Dealer who will replace the lost key at your own cost and reprogram it together with the remaining keys.
Page 95 If the engine does not start, a system malfunction has occurred. Have the system checked by a Ford Dealer immediately. To ensure a trouble free data exchange between the vehicle and key, do not shield the...
Page 96 Controls and features Key coding A maximum of eight keys can be coded using two other keys previously coded for your vehicle. Complete each of the following steps within five seconds. 1. Insert the first key in the ignition switch and turn to position II. 2.
Page 97 Controls and features If a key is lost, it is imperative to erase and recode the remaining keys. Consult your Ford Dealer if you now have only one valid key. Coding erasure With two keys coded for your vehicle you can make all the other coded keys unusable, e.g.
Page 98 Controls and features ANTI-THEFT ALARM SYSTEM The system acts as a deterrent to unauthorised persons who attempt to open the doors, bonnet or luggage compartment, or remove the radio. Activation The system is activated as soon as the vehicle is locked. Refer to the sections Central locking with double locking system and Radio frequency...
Page 99 Controls and features Alarm The alarm sounds for 30 seconds if an unauthorised person opens a door, the luggage compartment or the bonnet. The hazard flasher lights will flash for five minutes. Any attempt to start the engine or to remove the radio sounds the alarm again.
Page 100: Seating And Safety Restraints
Seating and safety restraints SEATS max. 30º Sitting in the correct position The seats, head restraints, seat belts, and air bags all contribute to the protection of the occupants. Optimal use of these components will give you added protection if you observe the following points: •...
Page 101 Seating and safety restraints Do not adjust the seats while the vehicle is moving. ST 220 seats The operation of the seat does not differ from the functions described below. Moving the seats forwards or backwards To adjust the position of a seat, pull up on the lever located at the inner front edge of the seat.
Page 102 Seating and safety restraints Adjusting the angle of the seatback Turn the handwheel at the side of the seat. When the seats are slid fully forward the seatbacks can be fully reclined. Adjusting the lumbar support Turn the handwheel located on the side of the seatback.
Page 103 Seating and safety restraints Seat (1) Forward and backward positioning of the seat. (2) Lowering/raising the front of the seat cushion. (3) Lowering/raising the rear of the seat cushion. Seatback (4) Adjustment of backrest inclination. Head restraints Adjust the head restraints so that the top is level with the top of your head.
Page 104 Seating and safety restraints To raise: Pull the head restraint up. To lower: Press the locking button and push the head restraint down. (Vehicles without Multimedia System) To adjust the angle: Swivel the head restraint forward or backward. To remove: Press the locking button and press in the button on the other side, for example, with a screwdriver.
Page 105 Seating and safety restraints Heated front seats The heated seats are operated by a switch located in the centre console. The light in the switch indicates operation. The maximum temperature is reached after five or six minutes. It is regulated thermostatically.
Page 106 Seating and safety restraints Returning the seatback to its upright position The seatback must engage in the latches on both sides. The seat belts must be forward of the seatback. Folding the seat cushion forwards (5-door and Estate models only) Pull the loop between the seat cushion and the seatback and fold the seat cushion forward.
Page 107 Seating and safety restraints Transporting luggage Luggage and other loads should be placed as low and as far forward as possible within the luggage compartment. Driving with the tailgate open is potentially dangerous as exhaust fumes may be drawn into the vehicle's interior.
Page 108 Seating and safety restraints Fastening the seat belts Pull the belt out steadily. It may lock if pulled sharply or if the vehicle is on a slope. The seat belt should cross the centre of the shoulder; the lap strap should fit tightly across the hips, not the stomach.
Page 109 Have the pretensioners serviced and disposed of by specially trained personnel only (Ford Dealer). The restraint system, with belt pretensioner in the front seat, helps to reduce the risk of serious injury in a head on collision.
Page 110 Seating and safety restraints Beltminder When the vehicle speed exceeds 5 km/h, the Beltminder warning light will illuminate and a chime will sound if the driver's safety belt is unbuckled. The Beltminder function becomes inoperative after buckling up. Do not sit on top of a buckled safety belt to avoid the Beltminder function.
Page 111 Seating and safety restraints 1. Turn the ignition switch to position II. Do not start the engine. 2. Wait until the Beltminder warning light turns off (approximately 1 2 minutes). • Steps 3 5 must be completed within 60 seconds or the procedure will have to be repeated.
Page 112 Belts subjected to strain - as a result of an accident - should be renewed and the anchorages checked by a Ford Dealer. Cleaning seat belts Use Ford Interior Cleaner or clean warm water. Dry naturally, away from artificial heat.
Page 113 Seating and safety restraints AIR BAG Air bags, in combination with a seat belt, can help reduce the risk of severe injuries in the event of a significant collision. The system The air bag system comprises the following: • dual stage inflatable nylon bags (air bags) with gas generators •...
Page 114 Seating and safety restraints Note: A loud bang will be heard when an air bag deploys and it is normal to see a cloud of harmless powdery residue. Front air bags Extreme Hazard! Do not use a rearward facing child restraint on a seat protected by an air bag in front of it! There is a risk of injury when the...
Page 115 Seating and safety restraints This is the ideal driving position and helps reduce the risk of injury from sitting too close to an inflating air bag. Front passengers should also sit as upright as possible to gain maximum air bag protection. Always wear the seat belt and keep sufficient distance between the driver and the...
Page 116 Seating and safety restraints The front air bags activate during major collisions which are either frontal or up to 30 degrees from the left or the right. The air bags inflate within a few thousandths of a second. They will deflate on contact with the front occupants thus cushioning forward body movement.
Page 117 Seating and safety restraints In most air bag deployments, the first stage is deployed to provide occupant restraint. The second stage is deployed afterwards. In the most severe crash events both stages are deployed to provide occupant restraint. The system increases the safety potential particularly for drivers who are not of a standard height or not in a...
Page 118 Injuries may result if the air bag is triggered inadvertently. Your Ford Dealer has technicians who have been carefully trained to service your vehicle. Side air bags...
Page 119 In case of a severe lateral collision, the air bag on the side affected by the collision will be inflated. The curtain air bags are not activated upon minor lateral collisions nor upon front or rear impacts. Only clean the roof lining with Ford cleaning products.
Page 120 Injuries may result if the side air bags are triggered inadvertently. Your Ford Dealer has technicians who have been specially trained to service your vehicle.
Page 121 Have the system checked by a Ford Dealer for your own safety. The manufacturer of the air bag(s) fitted in this vehicle recommends that the air bag be replaced after 15 years.
Page 122 Seating and safety restraints Child restraints Safety comment according to ECE R94.01 Extreme Hazard! Do not use a rearward facing child restraint on a seat protected by an airbag in front of it! Original text: Extreme Hazard! Do not use a Baby safety seat rearward facing child restraint on a seat protected by an airbag in...
Page 123 Note: • If the vehicle has been involved in an accident, have the child safety seat checked by a Ford Dealer as it might be damaged. • When the child seat is not being used, do not expose it to direct sunlight.
Page 124 Dealer. Please ask for the recommended child seats. Your vehicle is equipped with ISOFIX child seat attachments. Your Ford Dealer will be pleased to make them accessible. ISOFIX child seats not approved by Ford have not been validated by Ford, and neither the suitability nor...
Page 125 Seating and safety restraints • Children under four years and Child safety seat weighing between 9 and 18 kg should be carried in child safety seats on the rear seat. Driving direction • Children between 4 and 11 years Booster cushion and weighing between 15 and 36 kg should use a booster cushion on the rear seat.
Page 126 Seating and safety restraints Integrated booster cushion The booster cushion should be used for children from approximately 6 to 12 years, with a height of up to 150 cm and weighing between 22 and 36 kg. Pull the unlocking lever. Push the cushion to the back of the seat and push down on it until you feel the locking mechanism engage.
Page 127 Seating and safety restraints The raised seating position makes it possible to position the seat belt correctly. See illustration for correct position of seat belt. The shoulder strap should cross the centre of the shoulder; the lap strap should fit tightly across the hips, not the stomach.
Page 128 Seating and safety restraints 1. Insert the tongue into the buckle until a distinct click is heard. 2. Place the lap strap in the mould provided and tighten it. 3. Place the shoulder strap over the lap strap and tighten. Note: Refer also to the instructions provided together with the child safety seat.
Page 129: Starting
Starting GENERAL POINTS ON STARTING Do not operate the starter for longer than 30 seconds. Release the ignition key as soon as the engine has started. If the engine has not started, return the ignition key to position 0 and repeat the starting procedure.
Page 130 Starting STARTING THE ENGINE Clutch pedal Accelerator Vehicles with a petrol engine Cold/hot engine • Depress the clutch pedal fully and start the engine without touching the accelerator. At temperatures below -20 ºC, turn the ignition key to position II for at least one second before starting the engine.
Page 131 Starting 4 speed transmission Vehicles with automatic transmission The engine can be started only with Brake pedal the selector lever in the N or P position. Your vehicle is fitted with an additional selector lever locking device which operates when the selector lever is in the park position.
Page 132 Starting Clutch pedal Accelerator Vehicles with a diesel engine Cold/hot engine • Depress the clutch pedal without touching the accelerator. • Turn the key to position II and ensure the glow plug indicator light illuminates. • Wait until the light extinguishes Glow plug indicator light off before starting and continue cranking without pausing until the...
Page 133: Driving
Driving DRIVING WITH AUTOMATIC TRANSMISSION Moving off With the engine idling and the brake pedal depressed, move the selector lever to one of the driving positions. Release the brakes. The vehicle will start to move slowly in the selected direction. Depress the accelerator pedal to increase speed.
Page 134 Driving 4-speed transmission As an exception, position 2 may be used for initial drive off on icy or snow covered road surfaces. 5-speed transmission When the vehicle is stationary, only the manual gears 1 and 2 can be selected. In winter, second gear may be used for initial drive off on icy or snow covered surfaces.
Page 135 Driving Manual gear changes 4-speed transmission • Moving Select position 1 , release the handbrake and depress the accelerator pedal. Move the selector lever to position 2 and D as the road speed increases. • Changing down If the selector lever is moved from position D to position 2 while driving, the automatic transmission will change down to second gear...
Page 136 Driving Drive modes Fast off mode If you release the accelerator pedal 5-speed transmission quickly, e.g. when driving through a The transmission recognizes driving curve, the transmission stays in the conditions such as e.g. sporty, selected gear to avoid a sequence of stop and go, uphill or downhill down and upshifts.
Page 137 Fuel containing lead will cause permanent damage to the catalytic converter and HO2S sensor (heated exhaust gas oxygen sensor). Ford can accept no responsibility for damage caused by using leaded fuel. Although such damage is not covered by warranty, please...
Page 138 If the engine misfires or appears to lack normal performance while driving, drive at low speed to the nearest Ford Dealer. Do not use full throttle. Avoid all operating conditions which may lead to unburnt or partially burnt fuel passing into the catalyst particularly when the engine is hot.
Page 139 Driving Empty Avoid: • Running out of fuel. • Unnecessarily long engine cranking periods. • Running the engine with a disconnected spark plug. • Push starting or tow starting the vehicle with the engine at operating temperature; use jump leads. •...
Page 140 If your vehicle has a detachable towball arm, always remove it when driving without a trailer. Note: Mondeo ST 220 vehicles are not approved for trailer towing. Do not exceed a speed of 80 km/h if the trailer weight exceeds 1 000 kg.
Page 141 Driving It is recommended to use only original Ford tow bars and appropriate electrical kits which are available from Ford Dealers. The permissible nose weight, i.e. vertical weight on the tow ball, is 75 kg. In the interests of road safety,...
Page 142 Driving Above 1 000 metres, the stipulated maximum permitted gross train 3 000 m weight must be reduced by 10 % for 20 % 2 000 m every 1 000 metres in altitude. 10 % 1 000 m Example: Driving on a mountain road with a maximum altitude of 2 400 m means a 20% reduction of the gross train weight.
Page 143 Driving Detachable towball arm Removing the towball arm • Unhitch the trailer. • Remove the protection cap. Insert the key and unlock in an anticlockwise direction. • Pull off key with lock insert. • Slide lever 1 to the left and hold in this position.
Page 144 Driving Inserting the towball arm Special care should be taken when fitting the towball arm, as the safety of the vehicle and the trailer depends on this. The towball arm may only be inserted when completely unlocked. To mount the towball arm, remove the cover (Estate models only) from the rear bumper.
Page 145 If any of the above conditions cannot be met, do not use the tow bar and have it inspected by a Ford Dealer. Driving without a trailer • Remove the towball arm when it is not in use and secure it with the...
Page 146 Driving • Insert the plug into its seat after the towball arm has been removed. • Reinstall the cover (Estate models only). Insert the cover from underneath until it engages. Maintenance Keep the system clean. Periodically lubricate the lock with graphite. Remove the towball arm and protect the seat with the plug before steam cleaning...
Page 147 Roof racks with an appropriate fixing system are available from your Ford Dealer. Further details can be obtained from the fitting instructions supplied with the Ford roof rack. To fit the roof rack, the clips in the roof trim must be removed on 4 and 5 door models.
Page 148 Driving Estate with integral roof rack The side mounting rails are designed such that racks (for bicycles, skis etc.) from the Ford accessories range can be fitted. Loads should be evenly distributed on the cross rails and/or the side rails. Never place any loads directly onto the roof surface.
Page 149 Driving FUEL CONSUMPTION Length of journey/engine temperature To provide comparable reference data, fuel consumption is measured Frequent cold starts and short by all European vehicle distance driving leads to manufacturers under officially considerably increased fuel usage. approved and strictly controlled test conditions: EC Directive Traffic and road conditions 80/1268 EEC.
Page 150 • Check/adjust tyre pressures vehicle will also result in higher fuel consumption. regularly. • Have your vehicle serviced Hints for economical regularly, preferably by your Ford driving and preserving the Dealer. environment: Drive economically and use Avoiding damage to the vehicle...
Page 151 Have the braking system checked by a Ford Dealer before continuing your journey. Disc brakes Wet brake discs result in reduced braking efficiency.
Page 152 Driving Anti-lock Braking System (ABS) The anti lock braking system prevents the wheels from locking, even during heavy braking. As a result, the vehicle remains steerable helping you to avoid obstacles. Operation of the ABS The anti lock braking system is not employed during normal braking.
Page 153 Driving Braking with ABS Two important In an emergency, depress the clutch rules for braking pedal and apply full force in an emergency continuously on the brake pedal. with the anti lock The anti lock braking system will be braking system: activated immediately, thus allowing you to retain full steering control and, provided there is...
Page 154 Driving Electronic Stability Program (ESP) This system supports the vehicle's traction, stability and steerability in accelerating and braking, through a combination of engine and brake control. Drivers should never take unnecessary risks even though the traction control system offers inherently safer driving potential.
Page 155 During a malfunction the system will be switched off automatically. Have the system checked by a Ford Dealer. Switching off the ESP When driving in deep snow or sand you may find a benefit in switching the system off, for example to "rock"...
Page 156 Driving ULTRASONIC PARK DISTANCE SENSOR The system consists of ultrasonic sensors in the rear bumper, one controller and a display/buzzer located in the rear pillar trim. The system measures the distance to the closest obstacle when reversing and helps the driver to judge this distance correctly by visual and audible signals.
Page 157 Ford Dealer. Always remove the towball arm when it is not in use. green, green/yellow Vehicles with Original Ford towing intermittent slow equipment, whether fixed or detachable, will indicate the distance from the bumper to the obstacle.
Page 158: Roadside Emergencies
However, engine performance may be reduced. The vehicle can be driven at road speeds of up to 60 km/h on level surfaces. The engine warning light illuminates. Have the vehicle checked by a Ford Dealer immediately.
Page 159 Roadside emergencies FUEL INJECTION SYSTEM SHUT-OFF SWITCH (Duratec engines and 2.0 l DuraTorq DI 16V 85 kW (115 PS)) The vehicle is equipped with a switch that cuts off the fuel supply in the event of an accident. This is first and foremost for your own safety.
Page 160 There is a risk of injury due to the high voltage. Adjusting Xenon headlights The headlights can be adjusted for driving on the left or right hand side of the road i.e. when travelling abroad. This adjustment should only be carried out by a Ford Dealer.
Page 161 Roadside emergencies Headlight, side lights, direction indicators It is necessary to remove the light assembly to remove any of the bulbs. Removing the light assembly • Open the bonnet. • Remove the rotary clip on both ends of the radiator grille, and pull out the radiator grille.
Page 162 Roadside emergencies Side light 5 watt wedge base bulb Turn the cover anticlockwise, and remove. Using a flat bladed screwdriver, carefully prise out the socket. Pull out the lamp. Replace the bulb. When installing in the reverse order, pay attention to the guide tabs.
Page 163 Roadside emergencies Headlight – main beam H1, 55 watt halogen bulb Remove the wiring connector. Release the wire clip, and pull out the lamp. Replace the bulb. Install in the reverse order. Side repeater indicator 5 watt wedge base bulb Slide the light assembly downwards and pull it out.
Page 164 Roadside emergencies Fog lights H11, 55 watt halogen bulb Prise out the fog light bezel. Loosen the three Phillips screws, and pull out the light assembly. Remove the wiring connector. Pull the bulb out and replace it. Install in the reverse order. (vehicles with sports bumper) H3, 55 watt halogen bulb Loosen the Phillips screw in the fog...
Page 165 Roadside emergencies (ST 220 models) H7, 55 watt Loosen the Phillips screw in the fog light bezel. Prise out the ring around the lens and the fog light bezel. Loosen the two Phillips screws and pull out the light assembly. Remove the wiring connector.
Page 166 Roadside emergencies Rear lights (4-door and 5-door) Open the tailgate. From inside the luggage compartment, release the rotary clips of the rear light assembly cover. Remove the cover. Press the two red tabs towards eacht other and separate the assembly from the light housing. Turn the bulb anticlockwise under slight pressure, and remove it.
Page 167 Roadside emergencies Rear lights (Estate) Open the tailgate. From inside the luggage compartment, remove the top rear light assembly cover. The bottom cover is fastened with velcro. Pull the cover off. Unscrew the two wing nuts from the light assembly. Make sure the wing nuts do not fall into the opening.
Page 168 Roadside emergencies High mounted central brake light 5 watt wedge base bulbs (5x) 4 door: Pull the cover off. 5 door and Estate: Open the tailgate. Remove the two Phillips screws, and take off the cover. Remove the wiring connector, and take out the light assembly.
Page 169 Roadside emergencies Interior lights 10 watt festoon bulb Switch off the interior lights (left hand switch position). Prise out the light assembly in the recess at the side opposite the switch with a flat bladed screw driver. Remove the reflector. Front light: replace the bulb.
Page 170 Roadside emergencies Reading lights 5 watt wedge base bulb The bulbs can be replaced after the contact plate has been hinged back. Glove compartment light 5 watt wedge base bulb Pull the bulb out and replace it. Footwell light 5 watt wedge base bulb Pull the bulb out and replace it.
Page 171 Ford Dealer. Mini fuse A blown fuse can be identified by a break in the wire. All fuses are a push fit.
Page 172 Roadside emergencies Auxiliary fuse box This is located on the left hand side of the engine compartment. To check or replace a fuse, first pull off the battery cover (1). Then remove the cover of the fuse box (2) by releasing the catch and lifting up.
Page 173 Roadside emergencies The following fuses are identified by the See Owner's Guide" symbol in the fuse charts in your vehicle. Auxiliary fuse box Fuse Circuits protected 16/18 Conventional headlights: 7.5 A; Xenon headlights: 20 A Automatic transmission: 10 A Diode electronic module Diode air conditioning Diode engine cooling fan HO2S sensor...
Page 174 Roadside emergencies Symbols in the fuse boxes Symbol Definition Symbol Definition Dipped beam or See Owner's Guide parking light switch Passenger air bag Parking lights deactivation Air bag Interior lights Headlight washer Front wiper, front Dipped beam wiper switch Main beam or Rear wiper headlights Heated front screen/...
Page 175 Roadside emergencies Symbol Definition Symbol Definition Electrically operated outside rear view Cigar lighter mirrors, clock Rear power windows Hazard flasher Front power windows Horn Sunroof Door lock power Engine management Power seats or electronic module Heated seats Starter Heater blower Ignition/ignition switch Air conditioning, Fuel pump...
Page 176 Roadside emergencies Symbol Definition Symbol Definition Auxiliary heater/ Diesel glow plug Power point Injector pump relay/ fuel fired heater Battery sensing B+ feed Engine cooling fan Diode Automatic transmission Colour coding of mini fuses Colour coding of the fuses A1 Ampere Colour Ampere...
Page 177 Roadside emergencies CHANGING A WHEEL It is extremely important to observe the following precautions before jacking up the vehicle: Park your vehicle in such a position that neither the traffic nor you are hindered or endangered when changing the wheel. Alert other drivers by setting up a warning triangle.
Page 178 Roadside emergencies Spare wheel If the size of the spare wheel - rim or tyre - differs from the other fitted wheels, these rules must be followed: • Do not exceed 80 km/h. • Drive the shortest possible distances. • Do not fit more than one spare wheel on your vehicle at any one time.
Page 179 Roadside emergencies 4/5-door The spare wheel is located under the floor cover in the luggage compartment. • Raise the rear of the floor cover in the luggage compartment and remove it. • Completely unscrew the retaining device anticlockwise. • Lift out the spare wheel. •...
Page 180 Roadside emergencies • Completely unscrew the retaining device anticlockwise. • Lift out the spare wheel. • Remove the jack which is located beneath the spare wheel. • Install the defective wheel in the reverse order. Vehicle jack The vehicle jack must only be used to carry out wheel changes.
Page 181 Roadside emergencies Jacking points The jack must only be used on the jacking points specified below. The front jacking point is located approximately 27 cm from the front end of the sill (1). If you open up the Owner's Guide, it is approximately 27 cm wide.
Page 182 They are located in the glove compartment when the vehicle is delivered. Replacement locks and wheel nuts can be obtained by taking this certificate to your Ford Dealer.
Page 183 Roadside emergencies Fitting a wheel Alloy wheels must not be secured using wheel nuts for steel wheels. • Push the wheel onto the wheel studs. Screw on the wheel nuts and secure in a clockwise direction ensuring that the tapered end of the wheel nuts is facing the wheel.
Page 184 Roadside emergencies Stowing the defective wheel If your vehicle is equipped with a temporary spare tyre, carry out the following steps to stow the defective wheel. • Take the spacer out of the spare wheel well to stow it later in the luggage compartment.
Page 185 Roadside emergencies BATTERY Safety advice Always take the following precautions when handling a battery: • Wear eye protection. Do not let acid or lead particles get in contact with your skin or clothing. • Battery acid is caustic. Wear gloves and eye protection. Do not tilt the battery, acid might come out of the ventilation openings.
Page 186 Roadside emergencies • Keep children away from the battery acid. • When charging a battery explosive gas will be released. • Naked flames, sparks and smoking are prohibited. Avoid sparks when working with wires and electric equipment. Do not connect the battery poles. The resulting short circuit will produce sparks and could cause injury.
Page 187 The current and capacity of the new battery must correspond with that of the old battery or with the recommendations of Ford. Contact a Ford Dealer for the correct battery specifications. • With the ignition and all electrical equipment switched off, always remove the negative (–) cable first.
Page 188 Connect batteries with only the same nominal voltage (12 volts). Use jump leads with insulated clamps and adequate size cable. Do not disconnect the battery from the vehicle's electrical system. Suitable jump leads can be obtained from your Ford Dealer.
Page 189 Roadside emergencies To connect the leads • Position the vehicles so that they do not touch one another. • Switch off the engine. Switch off Flat any unnecessary electrical battery equipment. • Connect the positive (+) terminal of the flat battery to the positive (+) terminal of the booster battery (lead 1).
Page 190 Roadside emergencies To start the engine • Run the engine of the vehicle with the booster battery at moderately high speed. • Start the engine of the vehicle with the flat battery. • Run both vehicles for a further three minutes before disconnecting the leads.
Page 191 TOWING THE VEHICLE The vehicle is equipped with a screw in towing eye for the front and rear, for attaching a Ford or Motorcraft tow rope. The towing eye is stored with the jack in the luggage compartment, and must always be carried in the vehicle.
Page 192 Roadside emergencies When towing always drive off slowly and smoothly without jerking the towing vehicle. Excessive tow rope tension could result in damage to either vehicle. The ignition key must be set to position II when the vehicle is being towed so that the steering, direction indicator lights and brake lights are fully operational.
Page 193 Roadside emergencies Starting manual transmission vehicles by towing or pushing To prevent damage to the catalytic converter you must not push or tow start your vehicle when the engine is at operating temperature. Use jump leads and a booster battery. It is possible to start the cold engine by towing or pushing the vehicle.
Page 194 Roadside emergencies Towing vehicles with automatic transmission When a vehicle with an automatic transmission is towed, the selector lever must be in position N (neutral). Never tow a vehicle with automatic transmission faster than 50 km/h or further than 50 kilometres. If it is necessary to tow the vehicle a greater distance, the drive wheels must be lifted clear off the ground.
Page 195 Roadside emergencies 4 speed transmission Emergency park position release lever (automatic transmission) A mechanical emergency release lever is provided to enable the selector lever to be moved out of the park position P in the event of a discharged battery or electrical failure.
Page 196: Servicing
Service Guides. It is recommended that you General vehicle care always use a Ford Dealer. When an engine is washed, fuel, grease and oil residues are washed Things that you must do off.
Page 197 Maintenance and care Maintenance chart Keep oils, greases and vehicle fluids away from children. Follow the instructions Every day check: on the containers. Avoid skin contact with used engine oil. • Operation of all exterior and in terior lights. Replace burnt out or dim bulbs and make sure that all lenses are clean.
Page 198 Maintenance and care Opening the bonnet • Swivel the Ford badge in the radiator grille to the side and turn the key first anticlockwise (1). Raise the bonnet slightly, and turn the key fully clockwise (2) to open the bonnet. It is held by gas filled lift cylinders.
Page 199 Maintenance and care Duratec-HE 16V engine compartment Engine coolant Brake fluid reservoir reservoir Engine oil filler cap cleaner Power Battery steering reservoir Screen Engine oil Fuse box washer fluid dipstick reservoir For easy identification, filler caps and the engine oil dipstick are marked yellow/black.
Page 200 Maintenance and care Duratec-VE 24V engine compartment Power steering Engine oil reservoir filler cap cleaner Engine Brake fluid coolant reservoir reservoir Engine oil Fuse box dipstick Screen Battery washer fluid reservoir...
Page 201 Maintenance and care Duratec-ST V6 engine compartment Engine oil Power filler cap steering cleaner reservoir Brake fluid Engine coolant reservoir reservoir Engine oil Fuse box dipstick Battery Screen washer fluid reservoir...
Page 202 Maintenance and care DuraTorq DI/TDCi 16V engine compartment Engine coolant Brake fluid reservoir reservoir Engine oil filler cap cleaner Battery Power steering reservoir Screen Engine oil Fuse box washer fluid dipstick reservoir For easy identification, filler caps and the engine oil dipstick are marked yellow/black.
Page 203 Maintenance and care Engine oil dipstick The oil consumption of your engine is influenced by many factors. New engines reach the normal value only after approximately 5 000 km. Diesel and high performance engines consume slightly more. Duratec HE 16V engine Under high loads your engine will also consume more oil.
Page 204 Maintenance and care If it lies at the MIN mark refill using only engine oil meeting the Ford specification. Approximately 0.5 - 1 litre (Duratec HE engine 0.75 litre, diesel engine 2 litres)of engine oil will raise the level of the oil film on the dipstick from the MIN to the MAX mark.
Page 205 Add only brake fluid that meets the Ford specification. Refer to the chapter Capacities and specifications. Have the system checked for leakage by your Ford Dealer as soon as possible. Wipe the cap and the top of the reservoir clean with a dry cloth before unscrewing the cap from the reservoir.
Page 206 Take great care when adding coolant. Avoid spillage on any part of the engine. Add only coolant that meets the Ford Specification. For further details, refer to the chapter Capacities and specifications. Do not mix different colour or specification coolants.
Page 207 If it drops below the MIN mark, top up with the specified fluid. For further details, refer to the section Vehicle fluids. Automatic transmission fluid level Your Ford Dealer checks the fluid level in the automatic transmission when carrying out routine maintenance work on your vehicle.
Page 208 The current and capacity of the new battery must correspond with that of the old battery or with the recommendations of Ford. Contact a Ford Dealer for the correct battery specifications. Screen washer systems Front and rear washer systems are supplied from the same reservoir.
Page 209 Maintenance and care Headlight washer system Do not operate the washer for more than 10 seconds at a time, and never when the reservoir is empty. The headlight washer system operates when the exterior lights are switched on and the front screen washer is used.
Page 210 Traces of grease, silicone and fuel also prevent wiper blades from functioning properly. Ford cleaning solutions are recommended for cleaning wiper blades. Clean the wiper blade lips with water applied by a soft sponge.
Page 211 Maintenance and care TYRES For your safety Check the tyre pressures when you refuel, with the tyres cold (remember to include the spare tyre). Refer to the chapter Capacities and specifications for recommended tyre pressures. Observe the correct tyre pressures especially with high payloads and when driving at high speeds.
Page 212 Maintenance and care VEHICLE CARE Washing your vehicle Cleaning materials must not be disposed of in the household waste. Use your local authorised waste disposal facilities. Use only car washing areas that have ecologically harmless drainage systems. The most important element required to maintain the vehicle's paintwork is clean water.
Page 213 Maintenance and care Automatic car wash The best procedure is brushless washing in a good car wash installation. In installations operating with high water pressure, water might be forced into the vehicle's interior. Unscrew and remove the radio aerial before entering an automatic car wash.
Page 214 The underbody of your vehicle has been treated against corrosion. The underbody preservation should be checked regularly and, if necessary, touched up by your Ford Dealer. Cleaning wheels Depending on the distance travelled, clean the wheels weekly to avoid staining by brake dust. Use Ford Wheel Cleaner or warm water and a soft sponge.
Page 215 Maintenance and care Cleaning products For best results use the following products from the Ford Car Care Chemicals Programme: • Car Shampoo • Car Wax • Wax Polish • Wash & Wax • Finishing Polish • Plastic & Rubber Protector •...
Page 216 Maintenance and care Paint chip repair Paint damage from road chippings or minor scratches can be dealt with using Aerosol Paint Spray or Touch up paint from the Ford Accessory range. Observe the application instruction on each product. To retain vehicle warranty...
Page 217 It is recommended that you clean the instrument panel with a soft brush or use warm water and a non fluffy cloth. For special cleaning products, ask your Ford Dealer. Care of leather trim Use only suitable leather cleaning materials and detergents.
Page 218: Capacities And Specifications
Capacities and specifications Vehicle identification plate IDENTIFICATION NUMBERS Vehicle identification plate The vehicle identification plate is located on the lower section of the right hand front door pillar. This plate bears information on vehicle type, vehicle mass and it identifies various components.
Page 219 They are unnecessary and could lead to engine and/or catalytic converter damage which is not covered by Ford Warranty. When the filler cap is removed, a hissing noise may be heard. This is normal and should be disregarded.
Page 220 Do not use RME (bio diesel) do not attempt to start the en except in the case of those gine. Ford can accept no re proprietary diesel fuels which sponsibility for any damage contain a mix of up to 5 %.
Page 221 Capacities and specifications Engine data 1.8 l 1.8 l 2.0 l Duratec HE Duratec HE Duratec HE Engine type with cat. with cat. with cat. converter converter converter Cubic capacity 1798 1798 1999 Power output kW(PS) 81 (110) 92 (125) 107 (145) acc.
Page 222 Capacities and specifications Engine data 2.5 l 3.0 l 24V Engine type Duratec VE 24V Duratec ST V6 Cubic capacity 2495 2967 Power output kW(PS) 125 (170) 166 (226) acc. to EC Directives at rev/min 6000 6150 Maximum torque acc. to EC Directives at rev/min 4250 4900...
Page 223 Capacities and specifications Engine data 2.0 l 2.0 l 2.0 l Engine type DuraTorq DI DuraTorq DI DuraTorq TDCi 16V Cubic capacity 1998 1998 1998 Power output kW(PS) 66 (90) 85 (115) 96 (130) acc. to EC Directives at rev/min 4000 4000 3800...
Page 224 Capacities and specifications Fuel consumption according to EC Directive 80/1268/EEC Fuel consumption - litres/100 km Urban Total Reference emis Non urban environ Stage Axle weight acc. to Tyre size sions environment ment III/ ratio EC from ... to (g/km) Stage III/ Stage III/ Stage ...
Page 225 Capacities and specifications Fuel consumption according to EC Directive 80/1268/EEC Fuel consumption - litres/100 km Urban Total Reference emis Non urban environ Stage Axle weight acc. to Tyre size sions environment ment III/ ratio EC from ... to (g/km) Stage III/ Stage III/ Stage ...
Page 226 Capacities and specifications Fuel consumption according to EC Directive 80/1268/EEC Fuel consumption - litres/100 km Urban Total Reference emis Non urban environ Stage Axle weight acc. to Tyre size sions environment ment III/ ratio EC from ... to (g/km) Stage III/ Stage III/ Stage ...
Page 227 Capacities and specifications Fuel consumption according to EC Directive 80/1268/EEC Fuel consumption - litres/100 km Urban Total Reference emis Non urban environ Stage Axle weight acc. to Tyre size sions environment ment III/ ratio EC from ... to (g/km) Stage III/ Stage III/ Stage ...
Page 228 Capacities and specifications Fuel consumption according to EC Directive 80/1268/EEC Fuel consumption - litres/100 km Urban Total Reference emis Non urban environ Stage Axle weight acc. to Tyre size sions environment ment III/ ratio EC from ... to (g/km) Stage III/ Stage III/ Stage ...
Page 229 Capacities and specifications Gearshift speed data (km/h)* Manual transmission Engine Engine kw (PS) kw (PS) 1st gear 2nd gear 3rd gear 4th gear 5th gear 1.8 l 81 (110) 0 49 21 84 31 125 44 175 56 193/190** Duratec HE 16V 1.8 l 92 (125)
Page 230 Ford Warranty. increased emission levels. Ford Dealers are kept up to date regarding changes and Never top up above the improvements to the recommended MAX mark on the dipstick.
Page 231 WSA M2C 195 A. Brake and clutch fluid Use Motorcraft Brake Fluid Super DOT 4 or brake fluid meeting the Ford specification ESD M6C 57 A. Top up to the MAX mark if required. Use only brake fluid which is paraffin free.
Page 232 Capacities and specifications Please refer to the instructions on Screen washer fluid the container for the correct Fill the reservoir with Ford Screen concentration. Wash Concentrate 20 and water. If low outside temperatures prevail, Filling station guide use Ford Winter Screen Wash 20 For quick reference at the filling fluid.
Page 233 (where applicable). For further guidance Four passengers weigh consult your Ford Dealer. approximately 300 kg, i.e. 75 kg per Exceeding these values causes person as average. changes of the braking and driving behaviour of the vehicle and might cause accidents.
Page 234 Capacities and specifications Vehicle weight (kg) 4-door 5-door Estate 1.8 l Duratec-HE 81 kW (110 PS) Kerb weight 1374-1430 1384-1440 1432-1488 Payload 435-491 435- 491 542-598 Permissible gross weight 1865 1875 2030 Permissible roof rack weight 1.8 l Duratec-HE 92 kW (125 PS) Kerb weight 1373-1430 1384-1440...
Page 235 Capacities and specifications Vehicle weight (kg) 4-door 5-door Estate 2.5 l Duratec-VE 24V 125 kW (170 PS) Kerb weight 1458-1510 1467-1518 1518-1567 Payload 430-482 432-483 538-587 Permissible gross weight 1940 1950 2105 Permissible roof rack weight 2.5 l Duratec-VE 24V 125 kW (170 PS) Automatic transmission Kerb weight 1496-1574 1507-1581...
Page 236 Capacities and specifications Vehicle weight (kg) 4-door 5-door Estate 2.0 l DuraTorq TDCI 16V 96 kW (130 PS) Kerb weight 1492 1542 1501-1549 1554 1603 Payload 458-508 456-504 562 611 Permissible gross weight 2000 2005 2165 Permissible roof rack weight 2.0 l DuraTorq TDCi 16V 96 kW (130 PS) Automatic transmission Kerb weight 1540-1617...
Page 237 Capacities and specifications If winter tyres are used, tyre TYRES pressure must be raised by 0.1 bar. Tyre pressure Tyre pressures should be checked when the tyres are cold, before commencing a journey. The pressure for your spare tyre should be set to the highest value given for your vehicle/tyre size combination.
Page 238 Capacities and specifications • The tyre pressures must be Notes on tyre pressure increased to the values listed • The tyre pressures listed apply overleaf if you drive at high speed for cold tyres. for a prolonged period or • Tyre pressures need not be continuously.
Page 239 If the size (diameter) of the tyres is changed from those fitted at the factory, take the vehicle to your Ford Dealer to have the speedometer re programmed. If the speedometer is not re programmed, then it will no longer be accurate and will not display the correct speed.
Page 240 (front). Please ask your specified by the tyre manufacturer. Ford Dealer for recommended snow chains. You should attach a sticker with the reduced operational maximum Snow chains must only be fitted to speed on the instrument panel, in 205/55 R 16 and 6.5 J x 16"...
Page 241 Capacities and specifications 4-door 5-door Dimensions (mm) 4/5-door A = Maximum length 4731/4753*/4756** B = Overall width (including exterior mirrors) 1931 C = Overall height (kerb weight) 1429 1459/1415 1459** D = Wheelbase 2754 E = Track front 1522 rear 1537 * with Body Styling Kit **ST 220 models...
Page 242 Capacities and specifications Estate Dimensions (mm) Estate A = Maximum length 4804/4831*/4833** B = Overall width (including exterior mirrors) 1931 C1= Overall height (kerb weight) 1481 1514/1427 1514** C2= Overall height (kerb weight) 1441-1471 D = Wheelbase 2754 E = Track front 1522 rear...
Page 243 E = Centre of towball - side member F = Inner side of side member G = Centre of towball - centre 1. attachment point H = Centre of towball - centre 2. attachment point * All measurements refer to towing equipment officially released by Ford.
Page 244 G = Centre of towball - centre 1. attachment point H = Centre of towball - centre 2. attachment point I = Centre of towball - centre 3. attachment point * All measurements refer to towing equipment officially released by Ford.
Page 245 Capacities and specifications It is recommended that you use the Radio frequency remote control remote control only in the countries If the type approval of your remote listed. control is inspected, refer to the table below. Type approval of the remote control Country Official test number 433,92 MHz...
Page 246 Capacities and specifications Type approval of the remote control Country Official test number Buy label (Ref.No.: MÜ 20.039 091/97) 272/3 1998 IS 2732 00/01 IS 3017 00 433,92 MHz 5WK4 725/8686/8202/8687 433,92 MHz 5WK4 725/8686/8202 542/98 433,92 MHz 5WK4 725/8686/8202/8687 Ref.No.: 3K43D/3R1B9/SPLS RX9/98...
Page 247 Capacities and specifications Engine immobilisation system If the type approval of your engine immobilisation system is inspected, refer to the table below. Type approval of the engine immobilisation system Country Official test number CEPT SRD 9cA No label required RTT/D/X1142, RTT/D/X1438, RTT/D/X1616 53000.002516/98 1422 102 485A, 1422 102 1183 BAKOM 94.0056.K.P.
Page 248 Capacities and specifications Type approval of the engine immobilisation system Country Official test number CEPT I DGPGF/SEGR/ 2/04/332282/FO DGPGF/4/2/04/339553/PA TRA 24/5/221 TRA 24/5/109/2 IS 2855 00, IS 2855 01, IS 2855 02 No type approval necessary. 1206/179/45, L2431/10367-01l, L2431/10367-02l, L2431/10367-03l WT/122/98 NO95000140.R CEPT SRD 9cNL...
Page 249: Index
Index ABS. See Brakes Battery ....182 187 Booster battery ... . 186 187 Air bag .
Page 250 Index Capacities and specifications ..Dimensions ....238 239 Cassette and CD box ... . . Double locking .
Page 251 ......Ford Service ....
Page 252 Index Ice warning ..... . Lights Hazard flasher switch ... Identification numbers .
Page 253 Index Luggage compartment Paint damage ....Increasing load floor ..102 103 Parking ......Luggage cover .
Page 254 Index Screen washing/wiping Speed control ....43 44 Front screen washing system ..Automatic speed control light ..Front screen wiping .
Page 255 Index Tyres and wheels Warning lights ....8 17 Changing a wheel ..174 180 Warning signals, audible .

Ford mondeo Owner's Manual

Table of Contents

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ford mondeo

Summary of Contents for Ford mondeo

Table of Contents
