MANUAL
CONGRATULATIONS
to the purchase of your new professional switch mode battery charger.
This charger is included in a series of professional chargers from CTEK SWEDEN AB and
represents the latest technology in battery charging.
SUPPLY PLUG*
CTEK COMFORT CONNECT
CHARGE CABLE
MODE
CTEK COMFORT CONNECT – eyelet M6
* Supply plugs may differ to suit your wall socket.
20015449F Manual MXS 3.6, EU. Print file 006.indd 3
MAINS CABLE
MXS 3.6
12V/3.6A
CTEK COMFORT CONNECT – clamp
CHARGING
1. Connect the charger to the battery.
2. Connect the charger to the wall socket. The Standby lamp will indicate that the mains
cable is connected to the wall socket. The error lamp will indicate if the battery clamps
are incorrectly connected. The reverse polarity protection will ensure that the battery
or charger will not be damaged.
3. Press the MODE-button to select charging program.
4. Follow the indication lamps through the charging process.
The battery is fully charged when
5. Stop charging at any time by disconnecting the mains cable from the wall socket or by
setting the charger on Standby.
DESULPHATION
BULK
ABSORPTION
ERROR LAMP
MODE-
MODE
BUTTON
STANDBY
SMALL
NORMAL
BATTERY
BATTERY
PROGRAM
PROGRAM
is lit.
FULLY CHARGED
PULSE , MAINTENANCE CHARGING
COLD
WEATHER
PROGRAM
EN • 3
2011-10-10 16:36:19
MXS 3.
12V/0.8‒3.
Advertisement
Table of Contents
Related Manuals for CTEK MXS 3.6
Summary of Contents for CTEK MXS 3.6
- Page 1 1. Connect the charger to the battery. This charger is included in a series of professional chargers from CTEK SWEDEN AB and 2. Connect the charger to the wall socket. The Standby lamp will indicate that the mains represents the latest technology in battery charging.
-
Page 2: Charging Program
STEP 4 PULSE 60Ah Maintaining the battery at 95–100% capacity. The charger monitors the battery voltage and gives a pulse when necessary to keep the battery fully charged. 75Ah 4 • EN 20015449F Manual MXS 3.6, EU. Print file 006.indd 4 2011-10-10 16:36:20... -
Page 3: Connect/Disconnect Charger To Battery
High voltage ripple could harm other equipment that is connected to the battery. CTEK battery chargers produce very clean voltage and current with low ripple. -
Page 4: Limited Warranty
A damage cable must be replaced by a CTEK representative. than CTEK SWEDEN AB or its authorised representatives. One of the screw holes in the • Never charge a damaged battery. - Page 5 RCD 000835541-0001 CTM1042686 EP09170640.8 pending RCD 000835541-0002 CTM 766840 pending US12/564360 pending D596126 SE528232 D596125 SE525604 RCD 001705138 pending US D29/378528 pending RCD 201030618223.7 pending US RE42303 US RE42230 EN • 7 20015449F Manual MXS 3.6, EU. Print file 006.indd 7 2011-10-10 16:36:23...
Need help?
Do you have a question about the MXS 3.6 and is the answer not in the manual?
Questions and answers
Unit shows that it is in standby mode. The yellow indicator light is on but cannot select a charging mode. Trickle charge required for car battery.
The CTEK MXS 3.6 is in standby mode with the yellow indicator light on because it is not detecting a proper connection to the battery. This may be due to one of the following reasons:
- The battery is not connected correctly.
- The battery’s Under Voltage Protection (UVP) is activated.
- The battery voltage is too low (less than 2V).
- There is a poor connection or faulty accessory.
To resolve the issue and select a charging mode for trickle charging:
1. Check the clamps are properly connected to the correct battery terminals.
2. Inspect the quick connector and ensure good contact.
3. Press and hold the RESET button for 10 seconds to disable UVP.
4. Try the charger on another battery to verify function.
5. Once the charger detects the battery properly, select the appropriate mode for trickle charging (if available on the unit).
If the issue persists, the charger may be faulty.
