Icom IC-R75 Service Manual page 30

[PLL UNIT]
REF ORDER
NO. NO.
C99 4030006930 S.CERAMIC
C100 4030007080 S.CERAMIC
C101 4030006880 S.CERAMIC
C102 4030007020 S.CERAMIC
C103 4030006970 S.CERAMIC
C104 4030006880 S.CERAMIC
C105 4030006880 S.CERAMIC
C106 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C107 4030006880 S.CERAMIC
C108 4030006880 S.CERAMIC
C110 4030006880 S.CERAMIC
C111 4030006880 S.CERAMIC
C112 4030006880 S.CERAMIC
C113 4030006880 S.CERAMIC
C114 4030006880 S.CERAMIC
C115 4030006880 S.CERAMIC
C116 4030011600 S.CERAMIC
C117 4030011600 S.CERAMIC
C118 4030006880 S.CERAMIC
C119 4510004430 S.ELECTROLYTIC ECEV1CV220WR
C120 4030006850 S.CERAMIC
C121 4030011600 S.CERAMIC
C122 4030011600 S.CERAMIC
C123 4030011600 S.CERAMIC
C124 4030011600 S.CERAMIC
C125 4030007090 S.CERAMIC
C126 4550006250 S.TANTALUM
C127 4030011600 S.CERAMIC
C128 4030011600 S.CERAMIC
C151 4030006880 S.CERAMIC
C152 4030007040 S.CERAMIC
C153 4030006960 S.CERAMIC
C154 4030007070 S.CERAMIC
C155 4030006930 S.CERAMIC
C156 4030007040 S.CERAMIC
C157 4030006880 S.CERAMIC
C164 4030006880 S.CERAMIC
C165 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C167 4030011600 S.CERAMIC
C201 4030006880 S.CERAMIC
C202 4030006850 S.CERAMIC
C203 4030007120 S.CERAMIC
C204 4030009490 S.CERAMIC
C205 4030007070 S.CERAMIC
C206 4030010040 S.CERAMIC
C207 4030006880 S.CERAMIC
C214 4030006880 S.CERAMIC
C215 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C217 4030011600 S.CERAMIC
C305 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C310 4030007090 S.CERAMIC
C311 4030007090 S.CERAMIC
C312 4030007090 S.CERAMIC
C313 4030007090 S.CERAMIC
C314 4030007090 S.CERAMIC
C315 4030007090 S.CERAMIC
C316 4030007090 S.CERAMIC
C317 4030006880 S.CERAMIC
C318 4030006880 S.CERAMIC
C319 4030006880 S.CERAMIC
C320 4030006850 S.CERAMIC
C321 4030006880 S.CERAMIC
C322 4030006880 S.CERAMIC
C323 4030006880 S.CERAMIC
C324 4030006880 S.CERAMIC
C325 4030007100 S.CERAMIC
C326 4030006880 S.CERAMIC
C327 4030006880 S.CERAMIC
RL1 6330001320 RELAY
J2 6510019980 S.CONNECTOR 52808-1690
J3 6450000140 CONNECTOR
J4 6450000140 CONNECTOR
W1 7030003860 S.JUMPER
W2 7030003860 S.JUMPER
W18 7030003860 S.JUMPER
W19 7030003860 S.JUMPER
DESCRIPTION
C1608 CH 1H 020C-T-A
C1608 CH 1H 390J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 120J-T-A
C1608 CH 1H 060D-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 CH 1H 470J-T-A
TEMSVA 1A 106M-8L
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 CH 1H 180J-T-A
C1608 CH 1H 050C-T-A
C1608 CH 1H 330J-T-A
C1608 CH 1H 020C-T-A
C1608 CH 1H 180J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 471K-T-A
C1608 CH 1H 820J-T-A
C1608 JB 1H 821K-T-A
C1608 CH 1H 330J-T-A
C1608 JB 1H 561K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 560J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
AHY103
HSJ0807-01-010
HSJ0807-01-010
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
[PLL UNIT]
REF ORDER
NO. NO.
WS1 8970023350 M.OTHER
EP1 0910051124 PCB
EP2 6910012350 S.BEAD
EP3 6910012350 S.BEAD
EP4 6910012350 S.BEAD
EP5 6910012350 S.BEAD
EP6 6910012350 S.BEAD
EP7 6910012350 S.BEAD
EP8 6910012350 S.BEAD
5 - 11
DESCRIPTION
RX2240 1.5DCOAXIAL (4)/PL
B 5274D
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
S.=Surface mount
