Icom IC-R75 Service Manual page 25

[MAIN UNIT]
REF ORDER
NO. NO.
R883 7030003360 S.RESISTOR
R884 7030003510 S.RESISTOR
R885 7030003560 S.RESISTOR
R891 7030003560 S.RESISTOR
R892 7030003320 S.RESISTOR
R893 7030003480 S.RESISTOR
R894 7030003600 S.RESISTOR
R895 7030003380 S.RESISTOR
R896 7030003500 S.RESISTOR
R897 7030003320 S.RESISTOR
R898 7310002740 S.TRIMMER
R911 7030003320 S.RESISTOR
R912 7030003480 S.RESISTOR
R913 7030003320 S.RESISTOR
R914 7030003560 S.RESISTOR
R915 7030003560 S.RESISTOR
R1001 7030003520 S.RESISTOR
R1002 7030003320 S.RESISTOR
R1003 7030003700 S.RESISTOR
R1004 7030003500 S.RESISTOR
R1005 7030003720 S.RESISTOR
R1006 7030003460 S.RESISTOR
R1007 7030003360 S.RESISTOR
R1008 7030003720 S.RESISTOR
R1021 7030003560 S.RESISTOR
R1022 7030003630 S.RESISTOR
R1023 7030003660 S.RESISTOR
R1024 7030003640 S.RESISTOR
R1031 7030003360 S.RESISTOR
R1032 7030003720 S.RESISTOR
R1033 7030003440 S.RESISTOR
R1051 7030003490 S.RESISTOR
R1052 7030003520 S.RESISTOR
R1053 7030003400 S.RESISTOR
R1061 7030003680 S.RESISTOR
R1062 7030003600 S.RESISTOR
R1063 7030003440 S.RESISTOR
R1064 7030003780 S.RESISTOR
R1065 7030003520 S.RESISTOR
R1066 7030003600 S.RESISTOR
R1067 7030003740 S.RESISTOR
R1068 7030003560 S.RESISTOR
R1081 7030003360 S.RESISTOR
R1082 7030003440 S.RESISTOR
R1084 7030003640 S.RESISTOR
R1101 7030003440 S.RESISTOR
R1102 7030003460 S.RESISTOR
R1103 7030003440 S.RESISTOR
R1104 7030003500 S.RESISTOR
R1105 7030003480 S.RESISTOR
R1106 7030003200 S.RESISTOR
R1107 7030003460 S.RESISTOR
R1108 7030003440 S.RESISTOR
R1109 7030003440 S.RESISTOR
R1110 7030003480 S.RESISTOR
R1111 7030003200 S.RESISTOR
R1201 7030003660 S.RESISTOR
R1202 7030003480 S.RESISTOR
R1204 7030003640 S.RESISTOR
R1205 7030003640 S.RESISTOR
R1211 7030003640 S.RESISTOR
R1212 7030003630 S.RESISTOR
R1213 7030003630 S.RESISTOR
R1214 7030003630 S.RESISTOR
R1215 7030003630 S.RESISTOR
R1231 7030003400 S.RESISTOR
R1232 7030003400 S.RESISTOR
R1233 7030003400 S.RESISTOR
R1234 7030003400 S.RESISTOR
R1235 7030003400 S.RESISTOR
R1236 7030003400 S.RESISTOR
R1251 7030003680 S.RESISTOR
R1252 7030003680 S.RESISTOR
R1253 7030003680 S.RESISTOR
R1254 7310002720 S.TRIMMER
R1255 7030003400 S.RESISTOR
R1256 7030003640 S.RESISTOR
R1257 7030003560 S.RESISTOR
R1258 7030003520 S.RESISTOR
R1259 7030003520 S.RESISTOR
R1260 7030003320 S.RESISTOR
R1261 7030003480 S.RESISTOR
DESCRIPTION
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 101 V (100 Ω)
RV-150 (RH03A3A14X0FC) 103
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 684 V (680 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
RV-148 (RH03A3AS3X0DA) 472
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R1262 7030003550 S.RESISTOR
R1263 7030003610 S.RESISTOR
R1271 7030003640 S.RESISTOR
R1272 7030003440 S.RESISTOR
R1281 7030003680 S.RESISTOR
R1291 7030003550 S.RESISTOR
R1292 7030003400 S.RESISTOR
R1293 7030003400 S.RESISTOR
R1311 7030003520 S.RESISTOR
R1312 7030003620 S.RESISTOR
R1313 7030003580 S.RESISTOR
R1314 7030003640 S.RESISTOR
R1351 7030003200 S.RESISTOR
R1371 7030003520 S.RESISTOR
R1372 7030003640 S.RESISTOR
R1374 7030003520 S.RESISTOR
R1381 7030003280 S.RESISTOR
R1382 7030003480 S.RESISTOR
R1401 7070001060 RESISTOR
R1411 7030003320 S.RESISTOR
R1412 7030003560 S.RESISTOR
R1413 7030003680 S.RESISTOR
R1414 7030003320 S.RESISTOR
R1415 7030003320 S.RESISTOR
R1416 7030003320 S.RESISTOR
R1771 7030003540 S.RESISTOR
R1772 7030003620 S.RESISTOR
R1773 7030003640 S.RESISTOR
R1774 7030003580 S.RESISTOR
R2001 7030003560 S.RESISTOR
R2002 7030003360 S.RESISTOR
R2011 7030003560 S.RESISTOR
R2012 7030003680 S.RESISTOR
R2021 7030003510 S.RESISTOR
R2022 7030003440 S.RESISTOR
R2031 7030003640 S.RESISTOR
R2032 7030003640 S.RESISTOR
R2051 7030003640 S.RESISTOR
C101 4030011600 S.CERAMIC
C111 4030010210 S.CERAMIC
C121 4030006900 S.CERAMIC
C131 4030007070 S.CERAMIC
C132 4030007070 S.CERAMIC
C133 4030007040 S.CERAMIC
C134 4030007120 S.CERAMIC
C135 4030007040 S.CERAMIC
C136 4030007100 S.CERAMIC
C141 4030006900 S.CERAMIC
C151 4030010210 S.CERAMIC
C152 4030011600 S.CERAMIC
C161 4030008470 S.CERAMIC
C162 4030009880 S.CERAMIC
C163 4030009980 S.CERAMIC
C164 4030011600 S.CERAMIC
C170 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C171 4030011600 S.CERAMIC
C172 4030008650 S.CERAMIC
C173 4030010240 S.CERAMIC
C174 4030008650 S.CERAMIC
C175 4030010210 S.CERAMIC
C176 4030011600 S.CERAMIC
C181 4030011600 S.CERAMIC
C182 4030006860 S.CERAMIC
C183 4030009580 S.CERAMIC
C184 4030006870 S.CERAMIC
C185 4030007170 S.CERAMIC
C186 4030010020 S.CERAMIC
C187 4030011600 S.CERAMIC
C188 4030011600 S.CERAMIC
C201 4030011600 S.CERAMIC
C202 4030010020 S.CERAMIC
C203 4030007130 S.CERAMIC
C204 4030010020 S.CERAMIC
C205 4030009880 S.CERAMIC
C206 4030009880 S.CERAMIC
C207 4030009980 S.CERAMIC
C208 4030009980 S.CERAMIC
C209 4030011600 S.CERAMIC
C221 4030011600 S.CERAMIC
C222 4030010240 S.CERAMIC
5 - 6
DESCRIPTION
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERG2SJ 120
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
C1608 JB 1C 104KT-N
C3216 JB 1C 105M-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 330J-T-A
C1608 CH 1H 330J-T-A
C1608 CH 1H 180J-T-A
C1608 CH 1H 820J-T-A
C1608 CH 1H 180J-T-A
C1608 CH 1H 560J-T-A
C1608 JB 1E 103K-T-A
C3216 JB 1C 105M-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 272K-T-A
C1608 JB 1H 682K-T-A
C1608 JB 1H 152K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 332K-T-A
C1608 JB 1H 391K-T-A
C1608 JB 1H 332K-T-A
C3216 JB 1C 105M-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 681K-T-A
C1608 JB 1H 222K-T-A
C1608 CH 1H 221J-T-A
C1608 JB 1H 122K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 122K-T-A
C1608 CH 1H 101J-T-A
C1608 JB 1H 122K-T-A
C1608 JB 1H 682K-T-A
C1608 JB 1H 682K-T-A
C1608 JB 1H 152K-T-A
C1608 JB 1H 152K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 391K-T-A
S.=Surface mount
