[DISPLAY BOARD]
REF ORDER
NO. NO.
Q71 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q81 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
R11 7030000320 S.RESISTOR
R12 7030003360 S.RESISTOR
R21 7030000320 S.RESISTOR
R22 7030003360 S.RESISTOR
R31 7030000320 S.RESISTOR
R32 7030003360 S.RESISTOR
R41 7030000320 S.RESISTOR
R42 7030003360 S.RESISTOR
R51 7030000320 S.RESISTOR
R52 7030003360 S.RESISTOR
R61 7030000320 S.RESISTOR
R62 7030003360 S.RESISTOR
R71 7030000320 S.RESISTOR
R72 7030003360 S.RESISTOR
R81 7030000320 S.RESISTOR
R82 7030003360 S.RESISTOR
C101 4030008630 S.CERAMIC
J101 6510019980 S.CONNECTOR 52808-1690
DS11 5040002510 S.LED
DS12 5040002510 S.LED
DS13 5040002510 S.LED
DS21 5040002510 S.LED
DS22 5040002510 S.LED
DS23 5040002510 S.LED
DS31 5040002510 S.LED
DS32 5040002510 S.LED
DS33 5040002510 S.LED
DS41 5040002510 S.LED
DS42 5040002510 S.LED
DS43 5040002510 S.LED
DS51 5040002510 S.LED
DS52 5040002510 S.LED
DS53 5040002510 S.LED
DS61 5040002510 S.LED
DS62 5040002510 S.LED
DS63 5040002510 S.LED
DS71 5040002510 S.LED
DS72 5040002510 S.LED
DS73 5040002510 S.LED
DS81 5040002510 S.LED
DS82 5040002510 S.LED
DS83 5040002510 S.LED
DS101 5030001690 LCD
EP1 0910051372 PCB
EP2 8930049630 LCD CONTACT SRCN-2240-SP-N-W
[MAIN UNIT]
REF ORDER
NO. NO.
IC391 1110003970 S.IC
IC551 1130007570 S.IC
IC552 1130007570 S.IC
IC561 1160000130 S.IC
IC562 1160000130 S.IC
IC731 1110003140 IC
IC811 1110002600 S.IC
IC1001 1110003200 S.IC
IC1101 1110002600 S.IC
IC1201 1130009100 S.IC
IC1211 1110003870 S.IC
IC1251 1110003300 S.IC
IC1281 1130009100 S.IC
IC1291 1110003090 IC
IC1361 1180000970 S.IC
DESCRIPTION
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 221 V (220 Ω)
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 221 V (220 Ω)
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 221 V (220 Ω)
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 221 V (220 Ω)
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 221 V (220 Ω)
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 221 V (220 Ω)
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 221 V (220 Ω)
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 221 V (220 Ω)
C1608 JF 1C 104Z-T-A
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
TLYE1002
HLC7395-012400
B 5303B
DESCRIPTION
µPC1658G-E1
BU4094BCFV-E2
BU4094BCFV-E2
TD62783AF (TP1)
TD62783AF (TP1)
LA1150N
MC1496 D
TA31136FN (EL)
MC1496 D
BU4052BCFV-E2
NJM2058M-T1
M5282FP 70CD
BU4052BCFV-E2
LA4425A
AN78L05M-(E1)
[MAIN UNIT]
REF ORDER
NO. NO.
IC1371 1180001530 IC
IC1391 1180001250 S.IC
IC1401 1180001070 S.IC
IC1411 1110001400 S.IC
IC1601 1130007570 S.IC
IC1602 1130007570 S.IC
IC1603 1160000130 S.IC
IC1751 1120002510 S.IC
IC1771 1130005720 S.IC
IC2001 1110004940 S.IC
Q151 1590000680 S.TRANSISTOR DTC114EUA T106
Q381 1560000720 S.FET
Q382 1560000720 S.FET
Q383 1590001960 S.TRANSISTOR XP4311 (TX)
Q391 1590001960 S.TRANSISTOR XP4311 (TX)
Q411 1530003150 S.TRANSISTOR 2SC4673D-TD
Q441 1560000640 S.FET
Q442 1560000640 S.FET
Q471 1580000620 S.FET
Q472 1590001960 S.TRANSISTOR XP4311 (TX)
Q721 1580000620 S.FET
Q731 1560000560 S.FET
Q732 1510000510 S.TRANSISTOR 2SA1576A T106R
Q733 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q734 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q735 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q736 1590000680 S.TRANSISTOR DTC114EUA T106
Q737 1590001960 S.TRANSISTOR XP4311 (TX)
Q801 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q891 1580000620 S.FET
Q911 1560000560 S.FET
Q912 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q1001 1560000560 S.FET
Q1031 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q1051 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q1061 1590001960 S.TRANSISTOR XP4311 (TX)
Q1063 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q1064 1590001960 S.TRANSISTOR XP4311 (TX)
Q1065 1590001960 S.TRANSISTOR XP4311 (TX)
Q1066 1590001960 S.TRANSISTOR XP4311 (TX)
Q1311 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q1381 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q1382 1590000680 S.TRANSISTOR DTC114EUA T106
Q1771 1510000510 S.TRANSISTOR 2SA1576A T106R
Q1772 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q2021 1590000680 S.TRANSISTOR DTC114EUA T106
D141 1750000300 S.DIODE
D142 1750000300 S.DIODE
D151 1750000450 S.DIODE
D172 1790000620 S.DIODE
D181 1750000450 S.DIODE
D182 1790000620 S.DIODE
D202 1790000620 S.DIODE
D221 1750000450 S.DIODE
D222 1790000620 S.DIODE
D242 1790000620 S.DIODE
D261 1750000450 S.DIODE
D262 1790000620 S.DIODE
D282 1790000620 S.DIODE
D301 1750000450 S.DIODE
D302 1790000620 S.DIODE
D322 1790000620 S.DIODE
D341 1750000440 S.DIODE
D342 1790000620 S.DIODE
D371 1790000620 S.DIODE
D372 1790000620 S.DIODE
D381 1790000620 S.DIODE
D382 1790000620 S.DIODE
D391 1790000620 S.DIODE
D392 1790000620 S.DIODE
D491 1750000430 S.DIODE
D711 1790000620 S.DIODE
D712 1790000620 S.DIODE
D713 1790000620 S.DIODE
D714 1790000620 S.DIODE
D731 1790001210 S.DIODE
D732 1750000550 S.DIODE
D761 1790000620 S.DIODE
5 - 3
DESCRIPTION
PQ30RV31
TA7808F (TE16L)
TA7805F (TE16L)
µPC1555G2-T1
BU4094BCFV-E2
BU4094BCFV-E2
TD62783AF (TP1)
DS14C232TM
TC7W04F (TE12L)
MC13022ADWR3
2SK2171-4-TD
2SK2171-4-TD
2SK1740-TA
2SK1740-TA
3SK131-T2 MAS
3SK131-T2 MAS
2SK882-GR (TE85L)
3SK131-T2 MAS
2SK882-GR (TE85L)
2SK882-GR (TE85L)
1SS302 (TE85R)
1SS302 (TE85R)
1SV265-TL
MA77 (TX)
1SV265-TL
MA77 (TX)
MA77 (TX)
1SV265-TL
MA77 (TX)
MA77 (TX)
1SV265-TL
MA77 (TX)
MA77 (TX)
1SV265-TL
MA77 (TX)
MA77 (TX)
1SV263-TL
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
HSB88WSTR
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
1SS375-TL
1SS355 TE-17
MA77 (TX)
S.=Surface mount
