Icom IC-R75 Service Manual page 27

[MAIN UNIT]
REF ORDER
NO. NO.
C882 4030011600 S.CERAMIC
C891 4030011600 S.CERAMIC
C892 4030006880 S.CERAMIC
C893 4030006880 S.CERAMIC
C894 4030011600 S.CERAMIC
C895 4030007050 S.CERAMIC
C896 4030011600 S.CERAMIC
C897 4030006880 S.CERAMIC
C911 4030011600 S.CERAMIC
C912 4030007170 S.CERAMIC
C913 4030011600 S.CERAMIC
C914 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C1001 4030011600 S.CERAMIC
C1002 4030006880 S.CERAMIC
C1003 4030011600 S.CERAMIC
C1004 4030007170 S.CERAMIC
C1005 4030007170 S.CERAMIC
C1006 4030006880 S.CERAMIC
C1007 4030007130 S.CERAMIC
C1008 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1009 4030011600 S.CERAMIC
C1010 4030011600 S.CERAMIC
C1021 4030011600 S.CERAMIC
C1022 4030006900 S.CERAMIC
C1023 4030006900 S.CERAMIC
C1024 4030011600 S.CERAMIC
C1031 4030011600 S.CERAMIC
C1051 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1061 4030006880 S.CERAMIC
C1062 4030007130 S.CERAMIC
C1063 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1064 4030011600 S.CERAMIC
C1065 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1066 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C1067 4510004430 S.ELECTROLYTIC ECEV1CV220WR
C1081 4030006880 S.CERAMIC
C1085 4030006880 S.CERAMIC
C1089 4030006880 S.CERAMIC
C1090 4030011600 S.CERAMIC
C1101 4030011600 S.CERAMIC
C1102 4030011600 S.CERAMIC
C1103 4030011600 S.CERAMIC
C1201 4030006900 S.CERAMIC
C1202 4030006900 S.CERAMIC
C1211 4030009980 S.CERAMIC
C1212 4030010020 S.CERAMIC
C1213 4030008650 S.CERAMIC
C1214 4030010040 S.CERAMIC
C1215 4030011600 S.CERAMIC
C1216 4030011600 S.CERAMIC
C1217 4030011600 S.CERAMIC
C1231 4030006880 S.CERAMIC
C1251 4030011600 S.CERAMIC
C1253 4030010760 S.CERAMIC
C1254 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C1255 4030006900 S.CERAMIC
C1256 4030011600 S.CERAMIC
C1257 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1258 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1259 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1260 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1261 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1262 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C1271 4030006880 S.CERAMIC
C1272 4030011600 S.CERAMIC
C1281 4030006900 S.CERAMIC
C1282 4030006900 S.CERAMIC
C1292 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1293 4030011600 S.CERAMIC
C1294 4030011600 S.CERAMIC
C1295 4510004590 ELECTROLYTIC 16 MV 470 HC
C1296 4510004590 ELECTROLYTIC 16 MV 470 HC
C1311 4030006900 S.CERAMIC
C1312 4030006900 S.CERAMIC
C1321 4030006900 S.CERAMIC
C1351 4030006900 S.CERAMIC
C1352 4030006900 S.CERAMIC
C1353 4510004510 ELECTROLYTIC 25 MV 470 HC
C1361 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C1362 4030011600 S.CERAMIC
C1363 4030011600 S.CERAMIC
C1364 4030011600 S.CERAMIC
DESCRIPTION
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 220J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 221J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 221J-T-A
C1608 CH 1H 221J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 101J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 CH 1H 101J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 152K-T-A
C1608 JB 1H 122K-T-A
C1608 JB 1H 332K-T-A
C1608 JB 1H 561K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 331J-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
[MAIN UNIT]
REF ORDER
NO. NO.
C1365 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1371 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C1372 4030011600 S.CERAMIC
C1373 4030011600 S.CERAMIC
C1374 4030011600 S.CERAMIC
C1375 4510004590 ELECTROLYTIC 16 MV 470 HC
C1376 4030010210 S.CERAMIC
C1381 4030011600 S.CERAMIC
C1382 4030011600 S.CERAMIC
C1391 4510004590 ELECTROLYTIC 16 MV 470 HC
C1392 4030011600 S.CERAMIC
C1393 4030011600 S.CERAMIC
C1394 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1401 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1402 4030011600 S.CERAMIC
C1403 4030011600 S.CERAMIC
C1404 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1411 4030011600 S.CERAMIC
C1412 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C1413 4030011600 S.CERAMIC
C1414 4510004430 S.ELECTROLYTIC ECEV1CV220WR
C1415 4030006860 S.CERAMIC
C1416 4030006900 S.CERAMIC
C1417 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C1418 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C1419 4030011600 S.CERAMIC
C1420 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1421 4030011600 S.CERAMIC
C1422 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C1502 4030006880 S.CERAMIC
C1521 4030006880 S.CERAMIC
C1601 4030011600 S.CERAMIC
C1602 4030011600 S.CERAMIC
C1603 4030011600 S.CERAMIC
C1751 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1752 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1753 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1754 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1755 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1756 4030011600 S.CERAMIC
C1771 4030011600 S.CERAMIC
C2001 4030006860 S.CERAMIC
C2011 4030010760 S.CERAMIC
C2012 4030007070 S.CERAMIC
C2013 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C2014 4030011600 S.CERAMIC
C2015 4030006900 S.CERAMIC
C2016 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C2021 4030006860 S.CERAMIC
C2022 4030007080 S.CERAMIC
C2023 4030007020 S.CERAMIC
C2024 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C2031 4030006860 S.CERAMIC
C2032 4030006860 S.CERAMIC
C2033 4030006860 S.CERAMIC
C2034 4030006860 S.CERAMIC
C2035 4030011600 S.CERAMIC
C2036 4030011600 S.CERAMIC
C2041 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C2042 4030011600 S.CERAMIC
C2051 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
RL121 6330000180 RELAY
RL141 6330000180 RELAY
CP731 6910009670 S.CHECK P
J101 6510021460 CONNECTOR
J111 6510007020 CONNECTOR
J411 6510007020 CONNECTOR
J491 6510007020 CONNECTOR
J781 6450001560 CONNECTOR
J782 6450001560 CONNECTOR
J783 6450001560 CONNECTOR
J784 6450001560 CONNECTOR
J811 6510007020 CONNECTOR
J881 6450001560 CONNECTOR
J882 6450001560 CONNECTOR
J883 6450001560 CONNECTOR
5 - 8
DESCRIPTION
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C3216 JB 1C 105M-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 CH 1H 331J-T-A
C1608 CH 1H 330J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 390J-T-A
C1608 CH 1H 120J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
MZ-12HG
MZ-12HG
HK3-S-T
PT-C02P01
TMP-J01X-V6
TMP-J01X-V6
TMP-J01X-V6
PD-72
PD-72
PD-72
PD-72
TMP-J01X-V6
PD-72
PD-72
PD-72
S.=Surface mount
