Icom IC-R75 Service Manual page 29

[PLL UNIT]
REF ORDER
NO. NO.
R81 7030003560 S.RESISTOR
R83 7030003480 S.RESISTOR
R85 7030003430 S.RESISTOR
R86 7030003350 S.RESISTOR
R91 7030003260 S.RESISTOR
R92 7030003550 S.RESISTOR
R93 7030003510 S.RESISTOR
R94 7030003320 S.RESISTOR
R95 7030003280 S.RESISTOR
R96 7030003680 S.RESISTOR
R97 7030003440 S.RESISTOR
R98 7030003440 S.RESISTOR
R99 7030003440 S.RESISTOR
R100 7030003510 S.RESISTOR
R101 7030003370 S.RESISTOR
R102 7030003230 S.RESISTOR
R103 7030003370 S.RESISTOR
R104 7030003400 S.RESISTOR
R107 7030003280 S.RESISTOR
R108 7030003320 S.RESISTOR
R109 7030003360 S.RESISTOR
R110 7030003360 S.RESISTOR
R111 7030003490 S.RESISTOR
R112 7030003560 S.RESISTOR
R113 7030003360 S.RESISTOR
R114 7030003230 S.RESISTOR
R115 7030003670 S.RESISTOR
R116 7030003620 S.RESISTOR
R117 7030003300 S.RESISTOR
R151 7030003400 S.RESISTOR
R152 7030003720 S.RESISTOR
R153 7030005400 S.RESISTOR
R154 7030005400 S.RESISTOR
R155 7030005400 S.RESISTOR
R156 7030005400 S.RESISTOR
R157 7030005400 S.RESISTOR
R158 7030005400 S.RESISTOR
R159 7030005400 S.RESISTOR
R160 7030005400 S.RESISTOR
R161 7030005370 S.RESISTOR
R162 7030005370 S.RESISTOR
R163 7030005370 S.RESISTOR
R164 7030005390 S.RESISTOR
R165 7030005390 S.RESISTOR
R166 7030005390 S.RESISTOR
R167 7030005390 S.RESISTOR
R168 7030005390 S.RESISTOR
R169 7030005390 S.RESISTOR
R170 7030005380 S.RESISTOR
R171 7030005380 S.RESISTOR
R172 7030005380 S.RESISTOR
R178 7030003430 S.RESISTOR
R180 7030003440 S.RESISTOR
R181 7030003440 S.RESISTOR
R182 7030003440 S.RESISTOR
R183 7030003440 S.RESISTOR
R201 7030003400 S.RESISTOR
R202 7030003720 S.RESISTOR
R203 7030005400 S.RESISTOR
R204 7030005400 S.RESISTOR
R205 7030005400 S.RESISTOR
R206 7030005400 S.RESISTOR
R207 7030005400 S.RESISTOR
R208 7030005400 S.RESISTOR
R209 7030005400 S.RESISTOR
R210 7030005400 S.RESISTOR
R211 7030005370 S.RESISTOR
R212 7030005370 S.RESISTOR
R213 7030005370 S.RESISTOR
R214 7030005390 S.RESISTOR
R215 7030005390 S.RESISTOR
R216 7030005390 S.RESISTOR
R217 7030005390 S.RESISTOR
R218 7030005390 S.RESISTOR
R219 7030005390 S.RESISTOR
R220 7030005380 S.RESISTOR
R221 7030005380 S.RESISTOR
R222 7030005380 S.RESISTOR
R228 7030003430 S.RESISTOR
R230 7030003440 S.RESISTOR
R231 7030003440 S.RESISTOR
R232 7030003440 S.RESISTOR
DESCRIPTION
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 181 V (180 Ω)
ERJ3GEYJ 330 V (33 Ω)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 180 V (18 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 180 V (18 Ω)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 680 V (68 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 224 V (220 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-B (2 kΩ)
RR0816P-202-B (2 kΩ)
RR0816P-202-B (2 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-B (1 kΩ)
RR0816P-102-B (1 kΩ)
RR0816P-102-B (1 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 224 V (220 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-B (2 kΩ)
RR0816P-202-B (2 kΩ)
RR0816P-202-B (2 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-102-B (1 kΩ)
RR0816P-102-B (1 kΩ)
RR0816P-102-B (1 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
[PLL UNIT]
REF ORDER
NO. NO.
R233 7030003440 S.RESISTOR
R235 7030003440 S.RESISTOR
R236 7030003320 S.RESISTOR
C1 4030007070 S.CERAMIC
C3 4030006880 S.CERAMIC
C4 4030006880 S.CERAMIC
C5 4030007140 S.CERAMIC
C6 4030006880 S.CERAMIC
C7 4030006880 S.CERAMIC
C8 4030006880 S.CERAMIC
C9 4030007170 S.CERAMIC
C10 4030007030 S.CERAMIC
C11 4030006880 S.CERAMIC
C12 4030006910 S.CERAMIC
C13 4030007030 S.CERAMIC
C14 4030006880 S.CERAMIC
C15 4030006880 S.CERAMIC
C16 4030007120 S.CERAMIC
C21 4030006880 S.CERAMIC
C23 4030011600 S.CERAMIC
C24 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C25 4030011600 S.CERAMIC
C26 4030011600 S.CERAMIC
C27 4030011600 S.CERAMIC
C28 4030011600 S.CERAMIC
C29 4030011600 S.CERAMIC
C30 4030011600 S.CERAMIC
C31 4030011600 S.CERAMIC
C32 4030011600 S.CERAMIC
C33 4030011600 S.CERAMIC
C34 4030011600 S.CERAMIC
C35 4030011600 S.CERAMIC
C36 4030011600 S.CERAMIC
C37 4030007070 S.CERAMIC
C38 4030007010 S.CERAMIC
C39 4030011540 S.CERAMIC
C40 4030006980 S.CERAMIC
C41 4030007120 S.CERAMIC
C42 4030006930 S.CERAMIC
C43 4030007100 S.CERAMIC
C44 4030007010 S.CERAMIC
C50 4030006880 S.CERAMIC
C51 4030011600 S.CERAMIC
C52 4030006880 S.CERAMIC
C53 4030006880 S.CERAMIC
C54 4030006880 S.CERAMIC
C55 4030006880 S.CERAMIC
C56 4030007110 S.CERAMIC
C57 4030007090 S.CERAMIC
C58 4030007100 S.CERAMIC
C59 4030011840 S.CERAMIC
C60 4030009580 S.CERAMIC
C71 4550006250 S.TANTALUM
C72 4030011600 S.CERAMIC
C73 4030006850 S.CERAMIC
C74 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C75 4030007140 S.CERAMIC
C76 4610001830 S.TRIMMER
C77 4030007010 S.CERAMIC
C78 4030006880 S.CERAMIC
C79 4030006930 S.CERAMIC
C80 4030006880 S.CERAMIC
C81 4030006880 S.CERAMIC
C82 4030011600 S.CERAMIC
C83 4030006850 S.CERAMIC
C84 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C85 4030006850 S.CERAMIC
C86 4610001830 S.TRIMMER
C87 4030006950 S.CERAMIC
C88 4030006880 S.CERAMIC
C89 4030010780 S.CERAMIC
C90 4030006880 S.CERAMIC
C91 4030006880 S.CERAMIC
C92 4030006880 S.CERAMIC
C93 4030006880 S.CERAMIC
C94 4030011600 S.CERAMIC
C95 4030006880 S.CERAMIC
C96 4030007080 S.CERAMIC
C97 4030006990 S.CERAMIC
C98 4030007090 S.CERAMIC
5 - 10
DESCRIPTION
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 101 V (100 Ω)
C1608 CH 1H 330J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 121J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 221J-T-A
C1608 CH 1H 150J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 0R5C-T-A
C1608 CH 1H 150J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 820J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 CH 1H 330J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 750J-T-A
C1608 CH 1H 070D-T-A
C1608 CH 1H 820J-T-A
C1608 CH 1H 020C-T-A
C1608 CH 1H 560J-T-A
C1608 CH 1H 100D-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 680J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 560J-T-A
C1608 CH 1H 241J-T-A
C1608 JB 1H 681K-T-A
TEMSVA 1A 106M-8L
C1608 JB 1C 104KT-N
C1608 JB 1H 471K-T-A
C1608 CH 1H 121J-T-A
TZBX4N100BA110T00
C1608 CH 1H 100D-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 020C-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
TZBX4N100BA110T00 10P
C1608 CH 1H 040C-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 1R5C-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 CH 1H 390J-T-A
C1608 CH 1H 080D-T-A
C1608 CH 1H 470J-T-A
S.=Surface mount
