Icom IC-91A Service Manual page 37

• UT-121
(Optional product; [CODEC UNIT] for IC-91AD)
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1180002371 S.REG R1111N321B-TR-F
IC101 1130010920 S.IC AMBE-2020
IC102 1130011930 S.IC SN74LVC1G04DCKR
IC201 1130012511 S.IC SN74AHC2G74HDCT3
IC202 1110005430 S.IC CMX589AD5
IC203 1130011801 S.IC SN74AHC1G66HDBV3
IC300 1110005290 S.IC NJM2115V-TE1
IC301 1110005290 S.IC NJM2115V-TE1
IC350 1130011631 S.IC AD73311ARSZ
Q1 1510000581 S.TR 2SA1362-GR (TE85R F)
Q2 1590003280 S.TR UNR9211J-(TX)
Q50 1510000581 S.TR 2SA1362-GR (TE85R F)
Q51 1590001170 S.TR XP1501-(TX) AB
Q100 1530002280 S.TR 2SC4081 T106 S
Q200 1590003390 S.TR UNR9215J-(TX)
Q201 1590003390 S.TR UNR9215J-(TX)
Q202 1530002280 S.TR 2SC4081 T106 S
D100 1790001240 S.DIO MA2S728-(TX)
X100 6050012290 S.XTL CR-820 (16.384 MHz)
X200 6050012300 S.XTL CR-821 (9.8304 MHz)
R1 7030000180 S.RES MCR10EZHJ 22 (220)
R2 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R3 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R50 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R100 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R104 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R105 7030007280 S.RES ERJ2GEJ 331 X (330)
R106 7030004980 S.RES ERJ2GEJ 101 X (100)
R107 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R108 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R109 7030004990 S.RES ERJ2GEJ 221 X (220)
R202 7030010040 S.RES ERJ2GEJ-JPW
R203 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R204 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R205 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R206 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R207 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R208 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R209 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R210 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R211 7030006610 S.RES ERJ2GEJ 394 X (390 k)
R212 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R213 7030004980 S.RES ERJ2GEJ 101 X (100)
R214 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R215 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R216 7030004990 S.RES ERJ2GEJ 221 X (220)
R217 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R300 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R301 7030005310 S.RES ERJ2GEJ 124 X (120 k)
R302 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R303 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R304 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R305 7310004610 S.TRI EVM-2WSX80 B15 (104)
R306 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R307 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R310 7030005530 S.RES ERJ2GEJ 100 X (10)
R350 7030005010 S.RES ERJ2GEJ 681 X (680)
R351 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R352 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R353 7030004980 S.RES ERJ2GEJ 101 X (100)
R354 7030005240 S.RES ERJ2GEJ 473 X (47 k)
C1 4550007680 S.TAN TEESVP 0J 226M8R
C2 4550007600 S.TAN F920J106MPABMA
C3 4030016930 S.CER ECJ0EB1A104K
C50 4030017460 S.CER ECJ0EB1E102K
C51 4030017460 S.CER ECJ0EB1E102K
C52 4550006930 S.TAN TEESVP 0J 225M8R
C53 4030017460 S.CER ECJ0EB1E102K
C54 4030017460 S.CER ECJ0EB1E102K
C100 4030016930 S.CER ECJ0EB1A104K
C101 4030016930 S.CER ECJ0EB1A104K
C102 4030016930 S.CER ECJ0EB1A104K
C103 4030016930 S.CER ECJ0EB1A104K
C104 4030016930 S.CER ECJ0EB1A104K
C106 4030016930 S.CER ECJ0EB1A104K
C107 4030016930 S.CER ECJ0EB1A104K
C108 4030016930 S.CER ECJ0EB1A104K
C109 4030016930 S.CER ECJ0EB1A104K
DESCRIPTION M.
LOCATION
B 30.6/13.6
T 25.4/10.7
B 29.9/17.3
B 18.4/10.5
T
B
B
B
T
T
T
B
B
B 26.3/17.3
B 11.3/13.7
B
B 19.5/13.7
T
B 25.3/13.9
B 15.7/16.6
B 26.1/11.2
B
T
B
T
B
T
B 32.7/18.5
B
B 28.2/16.8
B 24.1/17.5
B 15.2/10.1
T 11.7/10.6
T 11.7/11.5
T 11.7/12.4
T 11.7/13.3
T 11.7/14.2
B
B
T
B
B
B
B
B 17.7/14.2
B 22.4/13.8
B 11.4/11.3
B
B
B
B
B
T
B 10.4/16.9
B
T
B
B
B
B
T
B
B
B 33.2/13.3
B
B
B
B
B
T 18.7/18.7
B 21.7/15.8
B 33.2/10.1
T 32.5/19.2
T
T 16.3/10.9
T
B
T
[MAIN UNIT]
REF ORDER
NO. NO.
C110 4030017420 S.CER ECJ0EC1H470J
H/V
C111 4030017460 S.CER ECJ0EB1E102K
C112 4030016930 S.CER ECJ0EB1A104K
C113 4030016930 S.CER ECJ0EB1A104K
C114 4030016930 S.CER ECJ0EB1A104K
C116 4030016930 S.CER ECJ0EB1A104K
C117 4030017460 S.CER ECJ0EB1E102K
6.3/13.4 C200 4030017460 S.CER ECJ0EB1E102K
6.1/11.7 C201 4030016930 S.CER ECJ0EB1A104K
17.5/3.5
C202 4030016930 S.CER ECJ0EB1A104K
5.6/16.6 C203 4030016930 S.CER ECJ0EB1A104K
5.9/4.7 C204 4030017460 S.CER ECJ0EB1E102K
C205 4030016930 S.CER ECJ0EB1A104K
C206 4030017030 S.CER ECJ0EB1A273K
15.2/2.7 C207 4030017030 S.CER ECJ0EB1A273K
18/2.2
C208 4030016930 S.CER ECJ0EB1A104K
26.1/7.9 C209 4030017400 S.CER ECJ0EC1H220J
28/3.7 C210 4030018860 S.CER ECJ0EB0J105K
C211 4030017460 S.CER ECJ0EB1E102K
C212 4030017760 S.CER ECJ0EB1H222K
9.3/13.7 C213 4030016930 S.CER ECJ0EB1A104K
C214 4030017460 S.CER ECJ0EB1E102K
C216 4030017460 S.CER ECJ0EB1E102K
C300 4030016930 S.CER ECJ0EB1A104K
26.9/1.6
C301 4030018860 S.CER ECJ0EB0J105K
C302 4030016930 S.CER ECJ0EB1A104K
C303 4030016930 S.CER ECJ0EB1A104K
C304 4030017490 S.CER C1608 JB 1A 105K-T
C310 4550007730 S.TAN TEESVJ 0J 106M8R
C350 4030016930 S.CER ECJ0EB1A104K
C351 4030016970 S.CER ECJ0EB1C223K
C352 4030016950 S.CER ECJ0EB1A473K
20.7/1.8 C353 4030016930 S.CER ECJ0EB1A104K
17/3.6
C354 4030016930 S.CER ECJ0EB1A104K
26.2/3.8 C355 4030017420 S.CER ECJ0EC1H470J
11.3/2.3 C356 4550006930 S.TAN TEESVP 0J 225M8R
31.9/16
C357 4030016930 S.CER ECJ0EB1A104K
12.8/5.8 C358 4030016930 S.CER ECJ0EB1A104K
C360 4030017460 S.CER ECJ0EB1E102K
28/18.5
J1 6510025550 S.CNR AXK824125WG
EP1 6910015370 S.BEA ACZ1005Y-102-T
EP100 6910015370 S.BEA ACZ1005Y-102-T
EP200 6910015370 S.BEA ACZ1005Y-102-T
EP201 6910015370 S.BEA ACZ1005Y-102-T
23/4.1
EP202 6910015370 S.BEA ACZ1005Y-102-T
24.7/2.3 EP203 6910015370 S.BEA ACZ1005Y-102-T
2.5/18.6 EP300 6910015370 S.BEA ACZ1005Y-102-T
3.3/11.1
EP350 6910015370 S.BEA ACZ1005Y-102-T
9.7/11.7 EP351 6910015370 S.BEA ACZ1005Y-102-T
15.9/13 EP352 6910015370 S.BEA ACZ1005Y-102-T
17.5/13
21.8/5.7
21.8/4
17.9/6.2
10.1/3.3
11.7/2.3
13.8/18
8.8/18.4
14.3/5
1.7/3.7
2.1/8.3
6.9/3.8
9.2/3.3
11.3/7.1
28.7/10
30.6/10
26.3/2.2
25.3/4.7
29.6/5.9
30.3/3.5
24.2/5.9
33.2/3.6
16/7.6
20.2/8.3
22.8/1.5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
7 - 13
DESCRIPTION M.
LOCATION
B
B 22.9/16.2
B
B 24.1/18.4
B 27.8/14.2
B 31.8/18.5
B 24.1/16.6
B 18.2/15.9
B 16.8/14.2
B 21.2/13.5
B
B
T 12.1/15.7
B
T
B
B
T 11.2/15.7
B 11.3/15.2
T 11.1/18.8
B
B
B 19.1/15.9
B
B
B
B
B
B
B
B
B
B
B
T
B
B
B
B
B
B 33.2/11.7
B 33.2/15.8
B
B
T 13.7/15.4
B
B
B
B
T
S.=Surface mount
H/V
29.1/7.3
26.4/19
13/17.5
17.8/8.3
2.3/18.4
2.5/17.7
2.9/12.3
24.7/3.2
5.2/13.9
7.5/13.9
23/2.3
18.9/7.1
10/4.9
9.9/15.7
2.2/14
3/5.9
2.1/9.2
1.7/4.6
8.7/4.9
2.8/2.8
2.8/1.9
13/2.7
7.2/2.4
9.6/1.8
4.7/4.2
5/1.4
10.8/8.2
13/15.9
15/12
8.8/11.7
23/3.2
4/6.3
6.2/5.6
11.3/3.4
