• ADJUSTMENT FREQUENCY LIST
NOTE: Adjustment frequency may difer depending on the
transceiver.
ADJUSTMENT ITEM
REFERENCE
FREQUENCY [FR]
IDLING [id] 5.0 V
FINAL [Po] 5.0 V
IDLING [Id] 7.4 V
HIGH
LOW
FINAL [Po] 7.4 V
HIGH
LOW
IDLING [Id] 13.5 V
HIGH
LOW
FINAL [Po] 13.5 V
HIGH
LOW
FMDEVIATION [FMV]
[FMR]
DIGITAL
†
DEVIATION [DVV]
†
[DVR]
TONE DEVIATION
[DTMF]
[CT]
[DTMF]
*[USA] version.
†Necessary for the IC-91AD or when UT-121 is installed into
the
IC-91A.
FREQUENCY (MHz)
440.0
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
VHF 145.0 (146.0)*
UHF 435.0 (445.0)*
ADJUSTMENT ITEM
RXBPF
(A_BAND) [TrA]
RXBPF
(B_BAND) [TrB]
FM/WFM S-METER
(A_BAND) [S3A]
FM S-METER
(B_BAND) [S3B]
6 - 7
FREQUENCY (MHz)
30.1
49.9
50.1
75.9
76.1
90.1
117.9
118.1
146.1
173.9
174.1
222.1
159.9
260.1
305.1
149.1
350.1
349.1
350.1
440.1
469.9
470.1
535.1
599.9
600.1
800.1
999.9
118.1
146.1
173.9
350.1
440.1
469.9
1.01
15.1
40.1
60.1
87.5
145.1
220.1
305.1
435.1
535.1
800.1
VHF 145.1
UHF 435.1
