Icom IC-91A Service Manual page 34

[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
C114 4030017460 S.CER ECJ0EB1E102K
C116 4030017640 S.CER ECJ0EC1H150J
C117 4030017460 S.CER ECJ0EB1E102K
C119 4030017460 S.CER ECJ0EB1E102K
C121 4030017460 S.CER ECJ0EB1E102K
C122 4030017460 S.CER ECJ0EB1E102K
C123 4030017330 S.CER ECJ0EF1C104Z
C124 4030017640 S.CER ECJ0EC1H150J
C125 4030017420 S.CER ECJ0EC1H470J
C126 4030017460 S.CER ECJ0EB1E102K
C129 4030017600 S.CER ECJ0EC1H080C
C130 4030017580 S.CER ECJ0EC1H060C
C131 4030017580 S.CER ECJ0EC1H060C
C132 4030017460 S.CER ECJ0EB1E102K
C133 4030017460 S.CER ECJ0EB1E102K
C135 4030017340 S.CER ECJ0EC1H010B
C136 4030017330 S.CER ECJ0EF1C104Z
C137 4030017400 S.CER ECJ0EC1H220J
C142 4030017330 S.CER ECJ0EF1C104Z
C143 4030017330 S.CER ECJ0EF1C104Z
C144 4030017610 S.CER ECJ0EC1H090C
C150 4030018860 S.CER ECJ0EB0J105K
C153 4030018860 S.CER ECJ0EB0J105K
C154 4030016790 S.CER ECJ0EB1C103K
C155 4030016950 S.CER ECJ0EB1A473K
C157 4030016950 S.CER ECJ0EB1A473K
C158 4030017460 S.CER ECJ0EB1E102K
C159 4030017460 S.CER ECJ0EB1E102K
C161 4030017460 S.CER ECJ0EB1E102K
C162 4030017460 S.CER ECJ0EB1E102K
C163 4030017460 S.CER ECJ0EB1E102K
C164 4030017460 S.CER ECJ0EB1E102K
C166 4030017460 S.CER ECJ0EB1E102K
C167 4030017460 S.CER ECJ0EB1E102K
C168 4030017460 S.CER ECJ0EB1E102K
C170 4030017460 S.CER ECJ0EB1E102K
C171 4030017460 S.CER ECJ0EB1E102K
C172 4030017440 S.CER ECJ0EC1H221J
C173 4030017440 S.CER ECJ0EC1H221J
C174 4030017730 S.CER ECJ0EB1E471K
C175 4030017730 S.CER ECJ0EB1E471K
C176 4030017460 S.CER ECJ0EB1E102K
C177 4030017460 S.CER ECJ0EB1E102K
C201 4030017630 S.CER ECJ0EC1H120J
C202 4030017500 S.CER ECJ0EC1H560J
C203 4030017580 S.CER ECJ0EC1H060C
C204 4030017660 S.CER ECJ0EC1H330J
C205 4030017680 S.CER ECJ0EC1H820J
C206 4030017400 S.CER ECJ0EC1H220J
C207 4030017710 S.CER ECJ0EC1H181J
C208 4030017600 S.CER ECJ0EC1H080C
C209 4030017430 S.CER ECJ0EC1H101J
C210 4030018860 S.CER ECJ0EB0J105K
C211 4030016930 S.CER ECJ0EB1A104K
C212 4030016930 S.CER ECJ0EB1A104K
C213 4030017460 S.CER ECJ0EB1E102K
C214 4030017460 S.CER ECJ0EB1E102K
C215 4030018860 S.CER ECJ0EB0J105K
C250 4030017660 S.CER ECJ0EC1H330J
C251 4030016790 S.CER ECJ0EB1C103K
C252 4030017460 S.CER ECJ0EB1E102K
C253 4030017620 S.CER ECJ0EC1H100C
C254 4030016790 S.CER ECJ0EB1C103K
C255 4030016790 S.CER ECJ0EB1C103K
C256 4030016930 S.CER ECJ0EB1A104K
C257 4030017620 S.CER ECJ0EC1H100C
C258 4030016790 S.CER ECJ0EB1C103K
C259 4030017460 S.CER ECJ0EB1E102K
C260 4030017660 S.CER ECJ0EC1H330J
C261 4030017420 S.CER ECJ0EC1H470J
C262 4030017420 S.CER ECJ0EC1H470J
C263 4030017420 S.CER ECJ0EC1H470J
C264 4030017420 S.CER ECJ0EC1H470J
C265 4030017420 S.CER ECJ0EC1H470J
C300 4030017460 S.CER ECJ0EB1E102K
C301 4030017390 S.CER ECJ0EC1H180J
C302 4030017640 S.CER ECJ0EC1H150J
C303 4030017670 S.CER ECJ0EC1H390J
C304 4030017380 S.CER ECJ0EC1H050B
C305 4030017400 S.CER ECJ0EC1H220J
C306 4030017650 S.CER ECJ0EC1H270J
C307 4030017420 S.CER ECJ0EC1H470J
C308 4030017630 S.CER ECJ0EC1H120J
C309 4030017690 S.CER ECJ0EC1H121J
C310 4030017400 S.CER ECJ0EC1H220J
C311 4030017460 S.CER ECJ0EB1E102K
C312 4030017380 S.CER ECJ0EC1H050B
C313 4030016790 S.CER ECJ0EB1C103K
C314 4030017460 S.CER ECJ0EB1E102K
H/V
M.
LOCATION
T 48.1/24.7
[USA], [USA-1] only T 48.5/25.9
T 41/20.3
B 48.4/20.8
T 46.3/17.7
T 42.9/15.7
T 43.8/15.7
T 39.9/16.4
T 35.9/15.5
T 34.3/12.5
T 32.2/14
T 39.4/17.6
T 38.5/17.6
T 41.3/14.1
T 29.9/12.7
T 29/12.9
T 41.9/20.3
T 48.4/16.9
T 39.2/20.3
T 40.1/20.3
[USA], [USA-1] only T 48.2/16
T 38.5/34.4
T 39.4/37.5
T 45.1/37.5
T 48.2/33.5
T 48.2/36.7
B 35/39.1
B 34.8/37.9
B 37.8/37.1
B 47.7/34
B 34/33.8
B 46/36.5
B 47.7/34.9
B 35.9/39.1
B 37.8/35.5
B 47.7/33.1
T 42.7/37.5
B 28.2/43.3
B 29.1/43.3
B 48.2/25.4
B 46.4/22.4
T 32.1/20.9
T 32.1/24.3
B 14.4/42
B 14.7/40.8
B 11.5/43.5
B 13.2/41.7
B 11.9/41.7
B 10.9/39.6
B 13.5/40.4
B 11.2/38.4
B 13.6/38.9
B 10.3/38.3
B 14.5/36.2
B 13.6/38
T 8.5/6.4
T 10.7/7.9
B 20.5/45.9
B 8.1/31.7
B 6.8/27
B 5/31.2
B 9.9/28.7
B 11.5/28.2
B 12.2/26.6
B 12.2/25.7
B 10.6/23.7
B 13.7/19.2
B 13.4/21.2
B 10.9/20
B 13.6/17.2
T 1.4/6.4
B 12.9/24.8
B 2.5/6.4
B 8/24.6
T 16.8/39.5
T 19.9/39.7
T 17.7/39.4
T 19.9/38.8
T 17.7/37.8
T 19.9/37.9
T 25.7/38.1
T 25.2/36.7
T 24.3/36.7
T 24.8/35.5
T 23.2/35.5
B 24.6/37.6
T 19/35.7
T 13.4/38.5
T 14.3/38.5
7 - 10
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
C315 4030017380 S.CER ECJ0EC1H050B
C316 4030016790 S.CER ECJ0EB1C103K
C317 4030017460 S.CER ECJ0EB1E102K
C318 4030016790 S.CER ECJ0EB1C103K
C319 4030016790 S.CER ECJ0EB1C103K
C320 4030017460 S.CER ECJ0EB1E102K
C321 4030017350 S.CER ECJ0EC1H020B
C322 4030017460 S.CER ECJ0EB1E102K
C323 4030017460 S.CER ECJ0EB1E102K
C324 4030017460 S.CER ECJ0EB1E102K
C325 4030017380 S.CER ECJ0EC1H050B
C326 4030017460 S.CER ECJ0EB1E102K
C327 4030016790 S.CER ECJ0EB1C103K
C328 4030017730 S.CER ECJ0EB1E471K
C329 4030017460 S.CER ECJ0EB1E102K
C330 4030017460 S.CER ECJ0EB1E102K
C331 4030017460 S.CER ECJ0EB1E102K
C332 4030017460 S.CER ECJ0EB1E102K
C333 4030017420 S.CER ECJ0EC1H470J
C334 4030017460 S.CER ECJ0EB1E102K
C335 4030017460 S.CER ECJ0EB1E102K
C336 4030016790 S.CER ECJ0EB1C103K
C337 4030017420 S.CER ECJ0EC1H470J
C338 4030017420 S.CER ECJ0EC1H470J
C339 4030017440 S.CER ECJ0EC1H221J
C400 4030017430 S.CER ECJ0EC1H101J
C401 4030017570 S.CER ECJ0EC1H040B
C402 4030018860 S.CER ECJ0EB0J105K
C403 4030017460 S.CER ECJ0EB1E102K
C404 4030016790 S.CER ECJ0EB1C103K
C405 4030017460 S.CER ECJ0EB1E102K
C407 4030017600 S.CER ECJ0EC1H080C
C408 4030017550 S.CER ECJ0EC1H1R5B
C409 4030017430 S.CER ECJ0EC1H101J
C410 4030017460 S.CER ECJ0EB1E102K
C411 4030017380 S.CER ECJ0EC1H050B
C412 4030018860 S.CER ECJ0EB0J105K
C413 4030017460 S.CER ECJ0EB1E102K
C414 4030016790 S.CER ECJ0EB1C103K
C415 4030017460 S.CER ECJ0EB1E102K
C416 4030017420 S.CER ECJ0EC1H470J
C417 4030017460 S.CER ECJ0EB1E102K
C418 4030017460 S.CER ECJ0EB1E102K
C419 4030017430 S.CER ECJ0EC1H101J
C420 4030017530 S.CER ECJ0EC1H0R5B
C421 4030017660 S.CER ECJ0EC1H330J
C422 4030017430 S.CER ECJ0EC1H101J
C423 4030017610 S.CER ECJ0EC1H090C
C424 4030017460 S.CER ECJ0EB1E102K
C425 4030017460 S.CER ECJ0EB1E102K
C450 4030017550 S.CER ECJ0EC1H1R5B
C451 4030017430 S.CER ECJ0EC1H101J
C452 4030017460 S.CER ECJ0EB1E102K
C453 4030017380 S.CER ECJ0EC1H050B
C454 4030018860 S.CER ECJ0EB0J105K
C455 4030017460 S.CER ECJ0EB1E102K
C456 4030016790 S.CER ECJ0EB1C103K
C457 4030017460 S.CER ECJ0EB1E102K
C459 4030017460 S.CER ECJ0EB1E102K
C460 4030017430 S.CER ECJ0EC1H101J
C461 4030017460 S.CER ECJ0EB1E102K
C462 4030017530 S.CER ECJ0EC1H0R5B
C463 4030017660 S.CER ECJ0EC1H330J
C464 4030017440 S.CER ECJ0EC1H221J
C465 4030017430 S.CER ECJ0EC1H101J
C466 4030017580 S.CER ECJ0EC1H060C
C468 4030017460 S.CER ECJ0EB1E102K
C469 4030017460 S.CER ECJ0EB1E102K
C470 4030017420 S.CER ECJ0EC1H470J
C471 4030017420 S.CER ECJ0EC1H470J
C472 4030017420 S.CER ECJ0EC1H470J
C473 4030017420 S.CER ECJ0EC1H470J
C474 4030017460 S.CER ECJ0EB1E102K
C475 4030017730 S.CER ECJ0EB1E471K
C500 4030017380 S.CER ECJ0EC1H050B
C501 4030017460 S.CER ECJ0EB1E102K
C502 4030017390 S.CER ECJ0EC1H180J
C503 4030017460 S.CER ECJ0EB1E102K
C504 4030017570 S.CER ECJ0EC1H040B
C505 4030017460 S.CER ECJ0EB1E102K
C506 4030017460 S.CER ECJ0EB1E102K
C507 4030017460 S.CER ECJ0EB1E102K
C508 4030017460 S.CER ECJ0EB1E102K
C509 4030017390 S.CER ECJ0EC1H180J
C510 4030017350 S.CER ECJ0EC1H020B
C511 4030017390 S.CER ECJ0EC1H180J
C512 4030017440 S.CER ECJ0EC1H221J
C513 4030017460 S.CER ECJ0EB1E102K
C514 4030017630 S.CER ECJ0EC1H120J
C515 4030017460 S.CER ECJ0EB1E102K
C516 4030017460 S.CER ECJ0EB1E102K
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V
M.
LOCATION
T 12/36
T 11.5/38.8
T 6.4/37.6
T 9.7/38.8
T 3.6/39.6
T 6.4/36.7
T 6.4/35.8
T 2.3/35.5
T 3.5/36
T 1.1/31.6
T 3.9/30.6
T 1.2/28.9
T 1.2/29.8
T 3/26.3
T 2/9.2
T 1.8/13.2
T 21.5/38.6
T 21.5/39.5
T 1.2/26.1
T 2.3/6.4
T 29.5/38.4
B 22.5/43.8
B 7.3/40
B 9.1/40
T 2.4/12.3
B 20.9/41
B 21.1/39.6
B 15.6/40
B 19/37.9
B 16.8/40.9
B 16.8/40
B 19.4/36.7
B 19.4/35.8
B 14.5/35.3
B 15.5/38.4
B 17.3/34.4
B 14/32.1
B 15.2/31.4
B 13.5/29.1
B 13.5/30
B 16.9/28.3
B 18.4/28.9
B 13.6/28.2
B 13.6/27.3
B 17.3/25.8
B 15.9/22.4
B 14.3/22.4
B 17.3/24.2
B 16.2/19.6
B 18.3/21.2
B 22.6/35.8
B 24.2/33.7
B 20.2/33.7
B 21.7/34.6
B 19/33.6
B 24.2/31.9
B 24.1/29.2
B 24.2/31
B 22.8/27.2
B 19.6/21.5
B 24.1/28.3
B 20.6/26.1
B 21.9/23.5
B 20.8/20.8
B 19.8/22.7
B 18.9/26.4
B 17.5/42.5
B 23.7/10.7
B 25.5/10.6
B 24.6/10.6
B 21.9/3.6
B 22.6/5.5
B 22.6/7.3
B 21.1/29.7
T 31.7/33.5
T 28.8/37.2
T 27.6/33.6
T 27.3/32.7
T 32.1/32.3
T 29.1/31.3
T 28.6/30
T 30.1/28
T 28/24.3
T 28.7/29.1
T 31/28
T 28/23.4
T 27.9/27.3
T 28/20.4
T 30.8/21.4
T 28.6/17.7
T 28.6/19.5
S.=Surface mount
