SERVICE MANUAL

<SUPER DIGITAL INVERTER>
RAV-SP180AT2-UL
RAV-SP240AT2-UL
RAV-SP300AT2-UL
RAV-SP360AT2-UL
RAV-SP420AT2-UL
R410A
FILE NO. A09-010-2
Revised : Feb. 2010
REVISION 2 : Jan.2012
Re-edit version.( file volume down)
Contents have NOT been changed.
SPLIT TYPE
(2 HP)
(3 HP)
(4 HP)
(4, 5 HP)
(5 HP)
PRINTED IN JAPAN, Dec., 2009 ToMo
