SERVICE MANUAL
OUTDOOR UNIT
<SUPER DIGITAL INVERTER>
RAV-SP1104AT8-E1
RAV-SP1104AT8J-E1
RAV-SP1404AT8-E1
RAV-SP1404AT8J-E1
RAV-SP1604AT8-E1
RAV-SP1604AT8J-E1
R410A
SPLIT TYPE
RAV-SP1104AT8-TR1
RAV-SP1104AT8J-TR1
RAV-SP1404AT8-TR1
RAV-SP1404AT8J-TR1
RAV-SP1604AT8-TR1
RAV-SP1604AT8J-TR1
PRINTED IN JAPAN, Oct., 2016 ToMo
FILE NO. A10-1611

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAV-SP1104AT8-E1 and is the answer not in the manual?

Questions and answers

Related Manuals for Toshiba RAV-SP1104AT8-E1

Summary of Contents for Toshiba RAV-SP1104AT8-E1

  • Page 1 FILE NO. A10-1611 SERVICE MANUAL SPLIT TYPE OUTDOOR UNIT <SUPER DIGITAL INVERTER> RAV-SP1104AT8-E1 RAV-SP1104AT8-TR1 RAV-SP1104AT8J-E1 RAV-SP1104AT8J-TR1 RAV-SP1404AT8-E1 RAV-SP1404AT8-TR1 RAV-SP1404AT8J-E1 RAV-SP1404AT8J-TR1 RAV-SP1604AT8-E1 RAV-SP1604AT8-TR1 RAV-SP1604AT8J-E1 RAV-SP1604AT8J-TR1 R410A PRINTED IN JAPAN, Oct., 2016 ToMo...

  • Page 2: Table Of Contents

    CONTENTS PRECAUTION FOR SAFETY ....................6 REFRIGERANT R410A ......................11 1. SPECIFICATIONS ......................13 1-1. Outdoor Unit ............................ 13 1-2. Operation Characteristic Curve ....................14 2. CONSTRUCTION VIEWS (EXTERNAL VIEWS) .............. 15 2-1. Outdoor Unit ............................ 15 3. OUTDOOR UNIT REFRIGERATING CYCLE DIAGRAM ..........18 4.
  • Page 3 Toshiba Carrier Corporation or, alternatively, he or she has been instructed in such matters by an individual or individuals who have been trained and is thus thoroughly acquainted with the knowledge related to this work.
  • Page 4 Definition of Protective Gear When the air conditioner is to be transported, installed, maintained, repaired or removed, wear protective gloves and ‘safety’ work clothing. In addition to such normal protective gear, wear the protective gear described below when undertaking the special work detailed in the table below.
  • Page 5 Warning Indications on the Air Conditioner Unit [Confirmation of warning label on the main unit] Confirm that labels are indicated on the specified positions If removing the label during parts replace, stick it as the original. Warning indication Description WARNING WARNING ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK HAZARD...

  • Page 6: Precaution For Safety

    Precaution for Safety WARNING Before starting to repair the air conditioner, read carefully through the Service Manual, and repair the air conditioner by following its instructions. Only qualified service person (∗1) is allowed to repair the air conditioner. Repair of the air conditioner by unqualified person may give rise to a fire, electric shocks, injury, water leaks and/or other problems.
  • Page 7 Even if the circuit breaker has been set to the OFF position before the service panel is removed and the electrical parts are repaired, you will still risk receiving an electric shock. For this reason, short-circuit the high-voltage capacitor terminals to discharge the voltage before proceeding with the repair work.
  • Page 8 The refrigerant used by this air conditioner is the R410A. Check the used refrigerant name and use tools and materials of the parts which match with it. For the products which use R410A refrigerant, the refrigerant name is indicated at a position on the outdoor unit where is easy to see.
  • Page 9 Once the repair work has been completed, check for refrigerant leaks, and check the insulation resistance and water drainage. Then perform a trial run to check that the air conditioner is running properly. After repair work has finished, check there is no trouble. If check is not executed, a fire, electric shock or injury may be caused.
  • Page 10 (∗1) Refer to the “Definition of Qualified Installer or Qualified Service Person.” Declaration of Conformity Manufacturer: TOSHIBA CARRIER CORPORATION 336 Tadehara, Fuji-shi, Shizuoka-ken 416-8521 JAPAN TCF holder: TOSHIBA CARRIER EUROPE S.A.S Route de Thil 01120 Montluel FRANCE Hereby declares that the machinery described below: Generic Denomination: Air Conditioner Model/type:...

  • Page 11: Refrigerant R410A

    Refrigerant R410A This air conditioner adopts a new HFC type refrigerant (R410A) which does not deplete the ozone layer. 1. Safety Caution Concerned to Refrigerant R410A The pressure of R410A is high 1.6 times of that of the former refrigerant (R22). Accompanied with change of refrigerant, the refrigerating oil has been also changed.
  • Page 12 4. Tools 1. Required Tools for R410A Mixing of different types of oil may cause a trouble such as generation of sludge, clogging of capillary, etc. Accordingly, the tools to be used are classified into the following three types. 1) Tools exclusive for R410A (Those which cannot be used for conventional refrigerant (R22)) 2) Tools exclusive for R410A, but can be also used for conventional refrigerant (R22) 3) Tools commonly used for R410A and for conventional refrigerant (R22) The table below shows the tools exclusive for R410A and their interchangeability.

  • Page 13: Specifications

    1. SPECIFICATIONS 1-1. Outdoor Unit RAV-SP 1104AT8 (J)-E1 1404AT8 (J)-E1 1604AT8 (J)-E1 Model Outdoor unit RAV-SP 1104AT8 (J)-TR1 1404AT8 (J)-TR1 1604AT8 (J)-TR1 Power supply 3 phase 4wired (3N-4pole) 380V – 415V 50Hz (Power exclusive to outdoor required.) Compressor Type Hermetic compressor Motor (kW) 3.75...

  • Page 14: Operation Characteristic Curve

    1-2. Operation Characteristic Curve • Operation characteristic curve, 50Hz <Super Digital Inverter> RAV-SP1104AT8(J)-E1, -TR1 RAV-SP1404AT8(J)-E1, -TR1 RAV-SP1604AT8(J)-E1, -TR1 <Cooling> <Heating> SP160 SP160 SP160 SP140 SP140 SP140 SP110 SP110 SP110 • Conditions • Conditions Indoor : DB20˚C Indoor : DB27˚C/WB19˚C Outdoor : DB7˚C/WB6˚C Outdoor : DB35˚C Air flow : High Air flow : High...

  • Page 15: Construction Views (External Views)

    2. CONSTRUCTION VIEWS (EXTERNAL VIEWS) 2-1. Outdoor Unit RAV-SP1104AT8(J)-E1, -TR1, RAV-SP1404AT8(J)-E1, -TR1, RAV-SP1604AT8(J)-E1, -TR1 – 15 –...
  • Page 16 RBC-TWP30E2, RBC-TWP50E2 (Simultaneous Twin) Inner diameter Ø C Inner Inner diameter Ø D diameter Ø D Model (RBC-) Liquid side Ø9.5 Ø6.4 TWP30E2 Gas side Ø15.9 Ø12.7 Liquid side Ø9.5 Ø9.5 TWP50E2 Gas side Ø15.9 Ø15.9 – 16 –...
  • Page 17 RBC-TRP100E (Simultaneous Triple) <Gas side> Header assembly Inner diameter Ø15.9 1 pc. <Liquid side> Branch pipe assembly Inner diameter Ø9.52 1 pc. Insulator Gas side socket Liquid side socket Ø15.9 Ø12.7 Ø9.5 Ø6.4 Ø15.9 Ø25.4 Ø9.5 Ø12.7 (External (External (External (External diameter) diameter)

  • Page 18: Outdoor Unit Refrigerating Cycle Diagram

    3. OUTDOOR UNIT REFRIGERATING CYCLE DIAGRAM TO sensor TS sensor TL sensor Pressure switch Strainer TE sensor Check joint Capillary Cooling: High pressure Ø4 ×Ø3 (6 pcs.) Heating: Low pressure Heat exchanger Distributor Refrigerant pipe Ø8, 2 rows, 52 stages TD sensor at liquid side Ø9.5 FP1.45, flat fin...

  • Page 19: Wiring Diagram

    4. WIRING DIAGRAM 4-1. Outdoor Unit RAV-SP1104AT8(J)-E1, -TR1, RAV-SP1404AT8(J)-E1, -TR1, RAV-SP1604AT8(J)-E1, -TR1 – 19 –...

  • Page 20: Specifications Of Electrical Parts

    5. SPECIFICATIONS OF ELECTRICAL PARTS 5-1. Outdoor Unit Parts name Type Specifications Compressor DA422A3F-27M — Outdoor fan motor ICF-280-A100-1 DC 280 V, 100 W 4-way valve coil STF-01AJ502E1 AC 220 – 240 V, 50/60 Hz PMV coil UKV-A038 DC 12 V High pressure switch ACB-4UB83W OFF : 4.15 MPa...

  • Page 21: Refrigerant R410A

    6. REFRIGERANT R410A This air conditioner adopts the Refrigerant R410A HFC 6. When an air conditioning system charged with a (R410A) which does not damage the ozone layer. large volume of refrigerant is installed in a small room, it is necessary to exercise care so that, The working pressure of the Refrigerant R410A even when refrigerant leaks, its concentration R410A is 1.6 times higher than conventional...
  • Page 22 Table 6-2-1 Thicknesses of annealed copper pipes Thickness (mm) Nominal diameter Outer diameter (mm) R410A 0.80 0.80 0.80 0.80 12.7 0.80 0.80 15.9 1.00 1.00 1. Joints For copper pipes, flare joints or socket joints are used. Prior to use, be sure to remove all contaminants. a) Flare Joints Flare joints used to connect the copper pipes cannot be used for pipings whose outer diameter exceeds 20 mm.
  • Page 23 c) Insertion of Flare Nut d) Flare Processing Make certain that a clamp bar and copper pipe have been cleaned. By means of the clamp bar, perform the flare processing correctly. Use either a flare tool for R410A or conventional flare tool. ØD Flare processing dimensions differ according to the type of flare tool.
  • Page 24 Fig. 6-2-2 Relations between flare nut and flare seal surface 2. Flare Connecting Procedures and Precautions a) Make sure that the flare and union portions do not have any scar or dust, etc. b) Correctly align the processed flare surface with the union axis. c) Tighten the flare with designated torque by means of a torque wrench.

  • Page 25: Tools

    6-3. Tools 6-3-1. Required Tools Refer to the “Refrigerant R410A 4. Tools” 6-4. Recharging of Refrigerant When it is necessary to recharge refrigerant, charge the specified amount of Refrigerant R410A according to the following steps. Recover the refrigerant, and check no refrigerant remains in the equipment.

  • Page 26: Brazing Of Pipes

    1) Be sure to make setting so that liquid can be charged. 2) When using a cylinder equipped with a siphon, liquid can be charged without turning it upside down. It is necessary for charging refrigerant under condition of liquid because R410A is mixed type of refrigerant. Accordingly, when charging refrigerant from the refrigerant cylinder to the equipment, charge it turning the cylinder upside down if cylinder is not equipped with siphon.
  • Page 27 2. Characteristics required for flux 6-5-3. Brazing • Activated temperature of flux coincides with As brazing work requires sophisticated techniques, the brazing temperature. experiences based upon a theoretical knowledge, it must be performed by a person qualified. • Due to a wide effective temperature range, flux is hard to carbonize.

  • Page 28: Instructions For Re-Use Piping Of R22 Or R407C

    Operation System age of the pipe at the worst. • In the concurrent twin system, when TOSHIBA- specified branching pipe is used, it can be reused. ∗ Pipe diameter and thickness (mm) Branching pipe model name: RBC-TWP30E2, RBC-TWP50E2, RBC-TRP100E.
  • Page 29 6-6-5. Final Installation Checks Is there no scratch or dent on the existing pipes? Existing pipe: NO * Use a new pipes. Is it possible to operate the existing air conditioner? ∗ After the existing air conditioner operated in cooling mode for approx.
  • Page 30 6-6-6. Handling of Existing Pipe 6-6-7. Recovery Method of Refrigerant When using the existing pipe, carefully check it for • Use the refrigerant recovery switch SW801 on the the following: P.C. board of the outdoor unit to recover refriger- ant when the indoor unit or outdoor unit is moved. •...

  • Page 31: Circuit Configuration And Control Specifications

    7. CIRCUIT CONFIGURATION AND CONTROL SPECIFICATIONS 7-1. Outdoor Unit Control 7-1-1. Print Circuit Board, MCC-1596 (Compressor IPDU) CN851 CN101 (Red) (White) Connector for MCC-1597 (CN505) Connector for MCC-1597 (CN502) CN13 (Black) Terminal for power relay Electric circuit protective fuse (500V, 31.5A) CN12 (White) Terminal for MCC-1600 (CN17)
  • Page 32 7-1-2. Print Circuit Board, MCC-1597 (Fan Motor IPDU) CN750 CN700 CN500 (White) (Blue) (Red) Fan motor output (Upper side) Fan motor output (Lower side) Connector for MCC-1600 (CN23) and reactor CH68 CN504 CN602 F500 (Blue) (Black) Connector for MCC-1599 Connector for MCC-1600 (CN51) Electric circuit protective fuse (CN802) (250V, 15A)
  • Page 33 7-1-3. Print Circuit Board, MCC-1599 (Interface (CDB)) CN708 CN608 (Blue) (White) Connector for power relay coil Connector for MCC-1600 (CN50) CN02 (Red) CN802 (White) Connector for MCC-1600 (CN10 and CN19) Connector for MCC-1597 (CN504) CN700 (Yellow) Power supply protective fuse (250V, 3.15A) 4-way valve connector Temp.sensor connector...
  • Page 34 7-1-4. Print Circuit Board, MCC-1600 (Noise Filter) CN05 CN16 (Red) CN10 (Red) (Red) ower supply terminal (L1) erminal for power relay erminal for MCC-1599 (CN02) and Terminal for PTC thermistor aristor protective fuse (250V, 6.3A) CN06 (White) ower supply terminal (L2) CN17 (White) erminal for...

  • Page 35: Outline Of Main Controls

    7-2. Outline of Main Controls 1. PMV (Pulse Motor Valve) control 1) PMV is controlled between 30 and 500 pulses during operation. 2) In cooling operation, PMV is usually controlled with the temperature difference between TS sensor and TC sensor aiming 1 to 4K as the target value. 3) In heating operation, PMV is usually controlled with the temperature difference between TS sensor and TE sensor aiming –1 to 4K as the target value.
  • Page 36 3. Outdoor fan control Revolution frequency allocation of fan taps [rpm] SP110 to SP160 Down — — 3-1) Cooling fan control The outdoor fan is controlled by TL sensor, TO sensor and the operation frequency. The outdoor fan is controlled by every 1 tap of DC fan control (14 taps). Only for 60 seconds after the operation has started, the maximum fan tap corresponding to the zone in the following table is fixed and then the fan is controlled by temperature of TL sensor.
  • Page 37 4. Coil heating control 1) This control function heats the compressor by turning on the stopped compressor instead of a case heater. It purposes to prevent stagnation of the refrigerant inside of the compressor. 2) As usual, turn on power of the compressor for the specified time before a test run after installation; otherwise a trouble of the compressor may be caused.
  • Page 38 7. Current release value shift control Current release control value (I I I I I 1) 1) This control purposes to prevent troubles of the electronic parts such as the compressor Temperature range SP110 SP140 SP160 driving elements and the compressor during 47°C ≤...
  • Page 39 10. Defrost control 1) In heating operation, defrost operation is performed when TE sensor satisfies any condition in A zone to D zone. 2) During defrosting operation, it finishes if TE sensor continued 12°C or higher for 3 seconds or continued 7°C ≤...

  • Page 40: Troubleshooting

    8. TROUBLESHOOTING 8-1. Summary of Troubleshooting <Wired remote controller type> 1. Before troubleshooting 1) Required tools/instruments • screwdrivers, spanners, radio cutting pliers, nippers, push pins for reset switch – • Tester, thermometer, pressure gauge, etc. 2) Confirmation points before check a) The following operations are normal.
  • Page 41 <Wireless remote controller type> 1. Before troubleshooting 1) Required tools/instruments • screwdrivers, spanners, radio cutting pliers, nippers, etc. – • Tester, thermometer, pressure gauge, etc. 2) Confirmation points before check a) The following operations are normal. 1. Compressor does not operate. •...

  • Page 42: Troubleshooting

    8-2. Troubleshooting 8-2-1. Outline of judgment The primary judgment to check whether a trouble occurred in the indoor unit or outdoor unit is carried out with the following method. Method to judge the erroneous position by flashing indication on the display part of the indoor unit (sensors of the receiving part) The indoor unit monitors the operating status of the air conditioner, and the blocked contents of self-diagnosis are displayed restricted to the following cases if a protective circuit works.
  • Page 43 Lamp indication Check code Cause of trouble occurrence Operation Timer Ready Heat exchanger sensor (TCJ) error ⎫ ⎪ Heat exchanger sensor (TC) error Indoor unit sensor error ⎬ ⎪ ⎭ Alternate flash Heat exchanger sensor (TA) error Discharge temp. sensor (TD) error ⎫...
  • Page 44 8-2-2. Others (Other than Check Code) Lamp indication Check code Cause of trouble occurrence Operation Timer Ready — During test run Simultaneous flash Operation Timer Ready Disagreement of cool/heat — (Automatic cool/heat setting to automatic cool/heat prohibited model, or setting of heating to cooling-only model) Alternate flash –...
  • Page 45 8-2-3. Monitor Function of Remote Controller Switch Calling of sensor temperature display <Contents> Each data of the remote controller, indoor unit and outdoor unit can be understood by calling the service monitor mode from the remote controller. <Procedure> TEST Push buttons simultaneously for 4 seconds to call the service monitor mode.
  • Page 46 8-2-4. Check Code List (Outdoor) : Go on, : Flash, : Go off ALT (Alternate): Alternate flashing when there are two flashing LED SIM (Simultaneous): Simultaneous flashing when there are two flashing LED Sensor lamp part Remote Automatic Operation controller Block indication Representative defective position Detection...
  • Page 47 : Go on, : Flash, : Go off ALT (Alternate): Alternate flashing when there are two flashing LED SIM (Simultaneous): Simultaneous flashing when there are two flashing LED Sensor lamp part Remote Automatic Operation controller Block indication Representative defective position Detection Explanation of error contents reset...
  • Page 48 Error mode detected by indoor unit Operation of diagnostic function Judgment and measures Check Status of Cause of operation Condition code air conditioner 1. Check cables of remote controller and communication adapters. No communication from remote Stop Displayed when controller (including wireless) and •...
  • Page 49 Error mode detected by outdoor unit The check code has been ramified from 4 series and after. The ramified check code is displayed only when both the indoor unit and the outdoor unit are 4 series and after. (Ex. Combination of RAV-SM1404UTP-E with RAV-SP1404AT8-E1) When the indoor unit is 3 series and before, the conventional check code is displayed.
  • Page 50 Operation of diagnostic function Check code Indoor unit Status of Judgment and measures Cause of operation Condition air conditioner before after 3 series 4 series Displayed when 1. Check outdoor P.C. board (MCC-1596). Current detection circuit error Stop error is detected (AC current detection circuit) 1.
  • Page 51 Error mode detected by remote controller or central controller (TCC-LINK) Operation of diagnostic function Judgment and measures Status of Check code Cause of operation Condition air conditioner Power supply error of remote controller, Indoor EEPROM error 1. Check remote controller inter-unit wiring. No communication with master indoor unit 2.
  • Page 52 8-2-5. Diagnostic Procedure for Each Check Code (Outdoor Unit) 1) This section describes the diagnostic method for each check code displayed on the remote controller. 2) In some cases, a check code indicates multiple symptoms. In this case, confirm LED display on the outdoor P.C. board to narrow the contents to be confirmed. 3) The check code on the remote controller is displayed only when the same error occurred continuously by multiple times while LED of the outdoor P.C.
  • Page 53 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [F04] <Display 1> <Display 2> [Discharge temp. sensor (TD) error] Is CN603 connection normal? Correct connector. Sensor error → Replace Is resistance value of TD sensor normal? Check outdoor P.C.
  • Page 54 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [F08] <Display 1> <Display 2> [Outside air temp. sensor (TO) error] Correct connector. Is CN602 connection normal? Sensor error → Replace Is resistance value of TO sensor normal? Check outdoor P.C.
  • Page 55 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [F31] <Display 1> <Display 2> [EEPROM error] Check outdoor P.C. board (MCC-1599). Defect → Replace [H01] <Display 1> <Display 2> [Compressor break down] Is power supply voltage normal? Correct power supply line.
  • Page 56 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [H03] <Display 1> <Display 2> [Current detection circuit error] Check outdoor P.C. board (MCC-1596). Defect → Replace <Display 1> <Display 2> [Power supply error (Vdc)] → Refer to [P05] column. [H04] <Display 1>...
  • Page 57 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [L29] ∗ There is a possibility that it is one of the following errors. Confirm LED on outdoor P.C. board to judge which error it is. Communication error between MCU, Heat sing temp.
  • Page 58 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P03] <Display 1> <Display 2> [Discharge temp. error] Repair defective position. Is there no gas leak? Recharge refrigerant. Is refrigerant charge amount adequate? Repair defective position.
  • Page 59 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P04] Heating operation Are connections of Does the heating indoor fan connectors,capacitors normally operate? and fan motor normal? Is there any element which blocks indoor heat exchanger? Elimination of Repair...
  • Page 60 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P05] <Display 1> <Display 2> [Power supply error (Voltage error)] Is there no open phase Correct wiring. of the power supply? Is there no down or up of power supply voltage? Confirm electric construction, etc.
  • Page 61 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P20] <Display 1> <Display 2> [High pressure protective operation] Is valve fully opened? Open valve fully. Reset the power supply and then perform test run Cooling season matching to the season.
  • Page 62 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P22] <Display 1> <Display 2> [Fan system error] Is there no problem on power supply voltage? Check wiring construction. (342 to 457V) Ask repair of power supply. Does the fan rotate without trouble when rotating shaft of fan motor with hands during power-OFF? Is there no problem on coil resistance of fan motor?
  • Page 63 Temperature sensor Temperature – Resistance value characteristic table TA, TC, TCJ, TE, TS, TO sensors TD, TL sensors Representative value Representative value Resistance value (kΩ Ω Ω Ω Ω ) Resistance value (kΩ Ω Ω Ω Ω ) Temperature Temperature (°C) (°C) (Minimum value)
  • Page 64 Table Inspection of outdoor unit main parts Parts name Checking procedure Compressor Measure the resistance value of each winding by using the tester. (Model : DA422A3F-27M) Position Resistance value Red – White White – Black 0.79 ± 0.04 Ω White Black Black –...

  • Page 65: Setup At Local Site And Others

    9. SETUP AT LOCAL SITE AND OTHERS 9-1. Calling of Error History <Contents> The error contents in the past can be called. <Procedure> TEST Push buttons simultaneously for 4 seconds or more to call the service check mode. TEMP. ON / OFF Service Check goes on, the CODE No.
  • Page 66 Indoor unit power-ON sequence Power ON • The unit without power feed waits entirely → Waiting status is released by system start • Reboot when power is fed on the way <By feed unit> <Automatic address judgment> Not normal 3 minutes elapse Gr construction check Normal ∗...

  • Page 67: Outdoor Unit

    9-3. Outdoor Unit 9-3-1. Various Setting on Outdoor Unit (Existing piping, Power save, Cooling-only, etc.) The following settings are available by DIP switch setup and jumper line setup. Function Set position Control contents Turn the switch to ON when mounting a duct to the discharge port of the outdoor unit.
  • Page 68 9-3-2. Service Support Function (LED Display, Switch Operation) 1. Outline A various setup and operation check can be performed by DIP switches at 3 positions (SW802, SW803, SW804) and the pushdown button switches (SW800, SW801) at 2 positions. Operation part Part No.
  • Page 69 9-3-3. Others 1. Selection of LED display (SW800, SW803 operation) 1) Display selection list The displayed contents of LED D800 to D804 on the outdoor control P.C. board can be exchanged by operation of SW803. Switch Function / Contents Refer Error display (Error generating at present) Refer to SW803...
  • Page 70 2) Error display The error which is generating at present and the latest error (Latest error information including present) can be confirmed by lighting LED D800 toD804 on the outdoor control P.C. board. a) When all DIP switch SW803 are OFF, the status of error which is generating at present is displayed. b) <1>...
  • Page 71 3) Sensor, current, compressor operation frequency, PMV opening display The values detected by the controller, such as temperature sensor or current value are simply confirmed. (Legend) D800 D801 D802 D803 D804 D805 : Go off, : Go on (Yellow) (Yellow) (Yellow) (Yellow) (Yellow) (Green) Temperature sensor (°C) Compressor Current...
  • Page 72 4) Specific operation for maintenance check (SW801, SW804) The following specific operations for the maintenance check are performed by operation of SW801 or SW804. a) Select DIP switch SW804. (See table below) b) Push the pushdown button switch SW801 for approx. 1 second. c) The following functions start.
  • Page 73 SW804 Operation when pushdown button switch SW801 is pushed 4-way valve relay operation (For RY700, CN70 check) SW804 Turn on 4-way valve power relay (RY700). When pushing SW801 again or when 2 minutes elapsed, the operation returns to the normal control. [CAUTION] Although these operations can Heater output relay operation...

  • Page 74: Address Setup

    10. ADDRESS SETUP 10-1. Address Setup Procedure When an outdoor unit and an indoor unit are connected, or when an outdoor unit is connected to each indoor unit respectively in the group operation even if multiple refrigerant lines are provided, the automatic address setup completes with power-ON of the outdoor unit.

  • Page 75: Address Setup & Group Control

    10-2. Address Setup & Group Control <Terminology> Indoor unit No. : N - n = Outdoor unit line address N (Max. 30) - Indoor unit address n (Max. 64) Group address : 0 = Single (Not group control) 1 = Master unit in group control 2 = Sub unit in group control Master unit (= 1) : The representative of multiple indoor units in group operation sends/receives signals to/from the remote controllers and sub indoor units.
  • Page 76 10-2-2. Automatic Address Example from Unset Address (No miswiring) 1. Standard (One outdoor unit) 1) Single (Master/Sub) Individual 2) Group operation (Twin, Triple operation) (Multiple outdoor units = Miltiple indoor units only with serial communication) Sub/Header Sub/Header Sub/Follower Master/Header Sub/Follower Sub/Follower Only turning on source power supply (Automatic completion) •...
  • Page 77 10-2-3. Automatic Address Example from Unset Address (No miswiring) 1. Standard (One outdoor unit) 1) Single 2) Twin 3) Triple (SP160 only) (1-1) (1-2) (1-1) (1-2) (1-3) Individual Master/Header Sub/Follower Sub/Header Master/Follower Sub/Follower (Master/Header) Only turning on source power supply (Automatic completion) 2.

  • Page 78: Remote Controller Wiring

    10-3. Remote Controller Wiring • Strip off approx. 9 mm the wire to be connected. Wiring diagram • For single system, use non polarity, 2 core wire is used for wiring of the remote controller. (0.5 mm² to 2.0 mm² wires) Terminal block for remote controller Terminal block wiring of indoor unit...

  • Page 79: Address Setup (Manual Setting From Remote Controller)

    10-4. Address Setup (Manual setting from remote controller) In case that addresses of the indoor units will be (Example of 2-lines cabling) determined prior to piping work after cabling work (Real line: Cabling, Broken line: Refrigerant pipe) • Set an indoor unit per a remote controller. Outdoor Outdoor 1 2 3...

  • Page 80: Confirmation Of Indoor Unit No. Position

    10-5. Confirmation of Indoor Unit No. Position 1. To know the indoor unit addresses though position of the indoor unit body is recognized • In case of individual operation (Wired remote controller : indoor unit = 1 : 1) (Follow to the procedure during operation) <Procedure>...
  • Page 81 <Maintenance/Check list> Aiming in environmental preservation, it is strictly recommended to clean and maintain the indoor/outdoor units of the operating air conditioning system regularly to secure effective operation of the air conditioner. It is also recommended to maintain the units once a year regularly when operating the air conditioner for a long time.

  • Page 82: Replacement Of The Service P.c. Board (4316V417) Mcc-1599

    11. REPLACEMENT OF THE SERVICE P.C. BOARD MCC-1599 1. Setting the jumper wires and DIP switches Part name Function Setting J800 to J803 Model switching Cut these jumper wires according to the following table. Jumper wire Set these jumper wires to the settings of the P.C. board J804 to J811 Settings before replacement...

  • Page 83: How To Exchange Compressor

    12. HOW TO EXCHANGE COMPRESSOR 12-1. Exchanging Procedure of Compressor (Outline) START Open PMV forcedly and then recover refrigerant Has refrigerant recovery work been done? using a refrigerant recovery unit. Turn off the leakage breaker. Never recover the refrigerant to the outdoor unit. For the refrigerant recovery work during reinstallation Remove the defective compressor.

  • Page 84: Installation Manual

    13. INSTALLATION MANUAL ACCESSORY PARTS AND REFRIGERANT INSTALLATION OF NEW REFRIGERANT AIR CONDITIONER Accessory Parts • The R410A refrigerant is more susceptible to impurities such as water, oxide membranes, oils, and fats. Part name Q’ty Shape Usage With the adoption of the new refrigerant, the refrigerating oil has also been changed. Be careful not to let water, dust, conventional refrigerant, and/or conventional refrigerating oil enter the refrigerating Hand this directly to the customer.
  • Page 85 - 61 - INSTALLATION CONDITIONS Pipe cutter Cutting pipes R22 (Conventional tools) Welding machine and nitrogen Welding pipes R22 (Conventional tools) cylinder Before installation Air purge Refrigerant charging measure Charging refrigerant R22 (Conventional tools) • To purge air, use a vacuum pump. Be sure to prepare to the following items before •...
  • Page 86 Installation Location Install the outdoor unit in a location where the • When using an air conditioner under low outside Serial installation of two or more units discharge air is not blocked. temperature conditions (Outside temp:-5 °C or When an outdoor unit is installed in a location that is lower) in COOL mode, prepare a duct or wind CAUTION always exposed to strong winds like a coast or on...
  • Page 87 - 63 - Obstacle also at the above unit Serial installation in front and rear • As shown in the figure below, install the foundation • When collectively draining discharged water and vibration-proof rubber pads to directly support the completely, use a drain pan. Open above and to the right and left of the unit.
  • Page 88 REFRIGERANT PIPING Flaring Tightening of Connecting Part Cut the pipe with a pipe cutter. Align the centers of the connecting pipes and fully Be sure to remove burrs that may cause a gas leak. tighten the flare nut with your fingers. Then fix the Insert a flare nut into the pipe, and then flare the nut with a wrench as shown in the figure and tighten Knockout of Pipe Cover...
  • Page 89 - 65 - Refrigerant Pipe Length CAUTION Single Do not put the crescent wrench on the cap or cover. Allowable pipe length (m) Height difference (Indoor-outdoor H) (m) The valve may break. Total length L Indoor unit: Upper Outdoor unit: Lower If applying excessive torque, the nut may break according to some installation conditions.
  • Page 90 AIR PURGING Use the vacuum pump, vacuum pump adapter, and gauge Valve handling precautions manifold correctly referring to the manuals supplied with • Open the valve stem until it strikes the stopper. each tool before using them. It is unnecessary to apply further force. Check that the vacuum pump oil is filled up to the specified •...
  • Page 91 - 67 - ELECTRICAL WORK Wiring between Indoor Unit and Outdoor Unit The dashed lines show on-site wiring. Outdoor unit Indoor unit • Be sure to clamp the power wires and indoor/outdoor Wired remote controller WARNING connecting wires with a banding band along the Input power Α...
  • Page 92 Wiring diagram Single system, Twin system, Triple system Stripping length power cord and connecting wire Indoor/outdoor Power supply wire * For details on the remote controller wiring/installation, refer to the Installation Manual enclosed with the remote connecting wire controller. Earth Earth 1 2 3 L1 L2 L3 N...
  • Page 93 - 69 - EARTHING ANNUAL MAINTENANCE • For an air conditioning system that is operated on a regular basis, cleaning and maintenance of the indoor/outdoor Connect the earth line properly following applicable technical standards. units are strongly recommended. Connecting the earth line is essential to preventing electric shock and to reducing noise and electrical charges on the As a general rule, if an indoor unit is operated for about 8 hours daily, the indoor/outdoor units will need to be outdoor unit surface due to the high-frequency wave generated by the frequency converter (inverter) in the outdoor cleaned at least once every 3 months.
  • Page 94 FUNCTIONS TO BE IMPLEMENTED LOCALLY TROUBLESHOOTING Handling Existing Pipe Recovering Refrigerant You can perform fault diagnosis of the outdoor unit with the LEDs on the P.C. board of the outdoor unit in addition to using the check codes displayed on the wired remote controller of the indoor unit. When using the existing pipe, carefully check for the •...
  • Page 95 - 71 - APPENDIX Display mode 1 Display mode 2 Cause D800 D801 D802 D803 D804 D800 D801 D802 D803 D804 Normal Discharge (TD) sensor error Work instructions * Pipe diameter and thickness (mm) Heat exchanger (TE) sensor error The existing R22 and R407C piping can be reused for Pipe outer diameter Ø6.4 Ø9.5 Ø12.7 Ø15.9 Ø19.0...
  • Page 96 Was largely discolored oil or a large quantity • In the concurrent twin system, when TOSHIBA has of remains discharged? (When the oil Clean the pipes or use new pipes. specified that branching pipe is to be used, it can be deteriorates, the color of the oil changes to a muddy or black color.)

  • Page 97: Detachments

    14. DETACHMENTS 14-1. Outdoor Unit RAV-SP1104AT8, RAV-SP1404AT8, RAV-SP1604AT8 series Part name Procedure Remarks Common procedure WARNING Stop operation of the air conditioner and turn off breaker switch. CAUTION Ensure wearing of gloves when performing any work in order to avoid injury from parts, etc. 1.
  • Page 98 Part name Procedure Remarks 1. Detachment Discharge port cabinet Heat exchanger Motor base 1) Carry out the operation in 1. of above. 2) Remove the screws fixing the inverter assembly, the discharge port cabinet and the partition board. (ST1T Ø4 × 8, 4 pcs.) 3) Remove the screws for the discharge port cabinet and the bottom plate.
  • Page 99 Part name Procedure Remarks 1. Detachment Side cabinet Discharge port cabinet Side cabinet 1) Carry out the operation in 1. of above. Inverter ass’y 2) Remove the screws fixing the inverter assembly and the side cabinet. (ST1T Ø4 × 10, 3 pcs.) 3) Remove the screws for the side cabinet and the valve fixing plate.
  • Page 100 Part name Procedure Remarks 1. Detachment Inverter assembly 1) Carry out the operation in 1. of , 1. of above. 2) Remove the connectors connected to the Fan IPDU board, the connector connected to other components from the control board Cut the Cut the Cut the...
  • Page 101 Part name Procedure Remarks 1. Detachment Interface board (Control board) 1) Carry out the operation in 1. of , and MCC-1599 1. of above. 2) Remove lead wires and connectors to other components from the interface board (control board). CN01 : Indoor/Outdoor connection terminal (5P: White) CN02 : Power relay (3P: Red) CN600 : TS sensor (3P: White, tube: Gray)
  • Page 102 Part name Procedure Remarks 1. Detachment Fan-IPDU board FAN-IPDU board MCC-1597 1) Carry out the operation in 1. of , and 1. of above. 2) Remove lead wires and connectors to other components from the Fan-IPDU board. CN500 : Connection between reactor and noise filter board (7P, Red) CN502 : Compressor IPDU board (3P, White) CN504 : Interface board (5P, Blue)
  • Page 103 Part name Procedure Remarks 1. Detachment Noise filter Fan-IPDU boardg board 1) Perform the operation in 1. of ,1. of MCC-1600 1.-2 of and 1.-2 of 2) Remove the screws (3 positions) fixing the inverter assem- bly (front). Then slide the inverter assembly (front) upwardly and remove.
  • Page 104 Part name Procedure Remarks 1. Detachment Compressor IPDU board 1) Carry out the operation in 1. of , 1. of MCC-1596 1. of , 1. of and 1. of 2) Remove the screw (4 positions) fixing the inverter assembly (IPDU). 3) Remove the lead wire and connector to other components from the compressor IPDU board.
  • Page 105 Part name Procedure Part name Fan motor 1) Carry out works of item 1 of and work of 2) Remove the flange nut fixing the fan motor and the propeller Propeller fan Propeller fan Propeller fan fan. • The flange nut is loosened by turning it clockwise. Loosened by Loosened by Loosened by...
  • Page 106 Part name Procedure Remarks 1. Removal of defective compressor Compressor Compressor 1) Recover the refrigerant gas. Piping panel (Front) Piping panel (Front) Piping panel (Front) lead 2) Carry out work of item 1 of , 1 of and 1 of 3) Remove the piping panel (Front).
  • Page 107 Part name Procedure Remarks 2. Mounting of compressor Compressor Compressor lead 1) Mount the compressor in the reverse Wrap the ferrite core with the compressor lead wire for 1 time. procedure for removal. (Continued) Compressor lead Compressor lead Compressor lead NOTE •...
  • Page 108 Part name Procedure Remarks 1. Detachment PMV coil Concave part PMV main unit 1) Carry out work of item 1 of 2) Turn the coil while pulling upward and then remove the coil from the PMV main unit. 2. Attachment 1) Surely match the positioning projection of the coil with the concave part of PMV main unit and then fix it.

  • Page 109: Exploded Views And Parts List

    15. EXPLODED VIEWS AND PARTS LIST Outdoor Unit RAV-SP1104AT8-E1, RAV-SP1104AT8J-E1, RAV-SP1104AT8-TR1, RAV-SP1104AT8J-TR1 – 109 –...
  • Page 110 43148170 ACCUMULATOR ASS'Y 43148188 ACCUMULATOR 43151301 SWITCH, PRESSURE 43160612 LEAD ASSY, COMPRESSOR 43147194 BONNET, 5/8 IN 4311M659 MARK, TOSHIBA 4314G266 CONDENSER ASSY, DOWN 4314G268 CONDENSER ASSY, DOWN 4314G269 CONDENSER ASSY, UP 4314G271 CONDENSER ASSY, UP 4314N023 VALVE, PLUS, MODULAING, UKV-25D100...
  • Page 111 Inverter Assembly RAV-SP1104AT8-E1, RAV-SP1104AT8J-E1, RAV-SP1104AT8-TR1, RAV-SP1104AT8J-TR1 718, 719 718, 719 721 710 – 111 –...
  • Page 112 Model name RAV-SP Location Part No. Description 1104AT8-E1 1104AT8J-E1 1104AT8-TR1 1104AT8J-TR1 43F58288 REACTOR 43154177 RELAY 43158207 REACTOR 43153006 PTC-THERMISTOR 43050425 SENSOR ASSY, SERVICE 43150319 SENSOR ASSY, SERVICE 43160565 TERMINAL BLOCK, 3P, 20A 43160579 TERMINAL 43F60859 FUSE BLOCK, 30A, 250V 4316V416 PC BOARD ASSY, MCC-1596, COMP-IPDU 4316V391 PC BOARD ASSY, MCC-1597, FAN-IPDU...
  • Page 113 Outdoor Unit RAV-SP1404AT8-E1, RAV-SP1404AT8J-E1, RAV-SP1404AT8-TR1, RAV-SP1404AT8J-TR1 – 113 –...
  • Page 114 43148170 ACCUMULATOR ASS'Y 43148188 ACCUMULATOR 43151301 SWITCH, PRESSURE 43160612 LEAD ASSY, COMPRESSOR 43147194 BONNET, 5/8 IN 4311M659 MARK, TOSHIBA 4314G266 CONDENSER ASSY, DOWN 4314G268 CONDENSER ASSY, DOWN 4314G269 CONDENSER ASSY, UP 4314G271 CONDENSER ASSY, UP 4314N023 VALVE, PLUS, MODULAING, UKV-25D100...
  • Page 115 Inverter Unit RAV-SP1404AT8-E1, RAV-SP1404AT8J-E1, RAV-SP1404AT8-TR1, RAV-SP1404AT8J-TR1 718, 719 718, 719 721 710 – 115 –...
  • Page 116 Model name RAV-SP Location Part No. Description 1404AT8-E1 1404AT8J-E1 1404AT8-TR1 1404AT8J-TR1 43F58288 REACTOR 43154177 RELAY 43158207 REACTOR 43153006 PTC-THERMISTOR 43050425 SENSOR ASSY, SERVICE 43150319 SENSOR ASSY, SERVICE 43160565 TERMINAL BLOCK, 3P, 20A 43160579 TERMINAL 43F60859 FUSE BLOCK, 30A, 250V 4316V416 PC BOARD ASSY, MCC-1596, COMP-IPDU 4316V391 PC BOARD ASSY, MCC-1597, FAN-IPDU...
  • Page 117 Outdoor Unit RAV-SP1604AT8-E1, RAV-SP1604AT8J-E1, RAV-SP1604AT8-TR1, RAV-SP1604AT8J-TR1 – 117 –...
  • Page 118 43148170 ACCUMULATOR ASS'Y 43148188 ACCUMULATOR 43151301 SWITCH, PRESSURE 43160612 LEAD ASSY, COMPRESSOR 43147194 BONNET, 5/8 IN 4311M659 MARK, TOSHIBA 4314G266 CONDENSER ASSY, DOWN 4314G268 CONDENSER ASSY, DOWN 4314G269 CONDENSER ASSY, UP 4314G271 CONDENSER ASSY, UP 4314N023 VALVE, PLUS, MODULAING, UKV-25D100...
  • Page 119 Inverter Unit RAV-SP1604AT8-E1, RAV-SP1604AT8J-E1, RAV-SP1604AT8-TR1, RAV-SP1604AT8J-TR1 718, 719 718, 719 721 710 – 119 –...
  • Page 120 Model name RAV-SP Location Part No. Description 1604AT8-E1 1604AT8J-E1 1604AT8-TR1 1604AT8J-TR1 43F58288 REACTOR 43154177 RELAY 43158207 REACTOR 43153006 PTC-THERMISTOR 43050425 SENSOR ASSY, SERVICE 43150319 SENSOR ASSY, SERVICE 43160565 TERMINAL BLOCK, 3P, 20A 43160579 TERMINAL 43F60859 FUSE BLOCK, 30A, 250V 4316V416 PC BOARD ASSY, MCC-1596, COMP-IPDU 4316V391 PC BOARD ASSY, MCC-1597, FAN-IPDU...
  • Page 121 WARNINGS ON REFRIGERANT LEAKAGE Check of Concentration Limit The room in which the air conditioner is to be installed requires a design that in the event of refrigerant gas leaking out, its concentration will not exceed a set limit. The refrigerant R410A which is used in the air conditioner is safe, without the toxicity or combustibility of ammonia, and is not restricted by laws to be imposed which protect the ozone layer.
  • Page 122 TOSHIBA CARRIER CORPORATION 72-34 Horikawa-cho, Saiwai-ku, Kawasaki-shi, Kanagawa 212-8585, JAPAN Copyright © 2016 TOSHIBA CARRIER CORPORATION, ALL Rights Reserved.
