RoboPi v1.00
RoboPi Expansion Connectors
Raspberry Pi I/O header pins
RoboPi requires exclusive use of RX/TX
•
RoboPi makes the Raspberry Pi I2C available on a Mikronauts four-pin 3v3 I2C header
•
All other Raspberry Pi I/O pins are available for your use
•
Mikronauts EZasPi was designed to stack between RoboPi and Raspberry Pi for expansion
•
Mikronauts EZasPi (B) was designed to stack below the Raspberry Pi for more expansion
•
EXP1/EXP2/EXP3 3v3 Expansion Connectors
EXP1 is for Propeller pins P0-P7, and servo connectors 1-8
•
EXP2 is for Propeller pins P8-P15, and servo connectors 9-16
•
EXP3 is for Propeller pins P16-P23, and sensor connectors 1-8
•
Mikronauts 3v3 10 pin modules can be used in EXP1/EXP2/EXP3
•
You must not use the 3 pin servo connectors for pins used by a 10 pin module
•
PI-I2C Header
For using 3v3 I2C expansion modules with RoboPi
•
PROP-I2C Header
For using 3v3 I2C expansion modules with the Raspberry Pi
•
PROPPLUG Header
For programming RoboPi when it is not mounted on a Raspberry Pi
•
Intended for stand-alone RoboPi applications
•
DO NOT USE WHEN MOUNTED ON A RASPBERRY PI
•
http://Mikronauts.com
User Manual v0.85
7
Copyright 2014 William Henning
2014-01-27
