RoboPi v1.00
Stand-Alone Operation Requirements
Supply 5V to RoboPi via one of:
pins 2 & 4 of the 2x13 pin Pi Header
•
"Pi5V" terminal of power selection header SV2 or SV3
•
Supply GND to RoboPi via one of:
pins 9 & 14 of the Pi Header
•
GND terminal of the external motor power screw terminal
•
If you will never mount your RoboPi on a Raspbery Pi, you could mount a two pin screw terminal on
pins 2 (5V) & 6 (GND) for supplying 5V.
Use a PropPlug to program your stand-alone RoboPi.
http://Mikronauts.com
User Manual v0.85
28
Copyright 2014 William Henning
2014-01-27
