Specifi cations
Monitor Specifi cations
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DisplayPort: DisplayPort Connector:
DVI:
HDMI: HDMI Connector:
Display Colours
Synchronization Range
Viewing Angle
Image Formation Time
Resolutions Supported (Some systems may
not support all modes listed).
Active Display Area Landscape: Horiz.:
Portrait: Horiz.:
USB Hub
Headphone Output STEREO Mini Jack:
Power Supply
Current Rating
Power supply for option slot unit:
Available option board for option slot:
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1: Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current fl at panel technologies when displaying non-native resolutions full screen. In fl at panel technologies, each dot on the screen is actually
one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2: DISPLAYPORT2 complies with Standard V1.1a.
NOTE: Technical specifi cations are subject to change without notice.
MultiSync PA322UHD
Diagonal: 80.1 cm/31.5 inches
80.1 cm/31.5 inches
3840 x 2160
Digital RGB
DVI-D 24pin: Digital RGB
Digital RGB
1,073,741,824 (DisplayPort/HDMI 10 bit)
16,777,216 (DVI)
Horizontal: 31.5 kHz to 133.2 kHz
Vertical: 24 Hz to 120 Hz
Left/Right: ±88° (CR > 10)
Up/Down: ±88° (CR > 10)
10 ms (Gray to gray Typ)
640 x 480* 1 at 60 Hz to 85 Hz
1
720 x 400* at 70 Hz to 85 Hz
800 x 600* 1 at 56 Hz to 85 Hz
1
1024 x 768* at 60 Hz to 120 Hz
1152 x 870* 1 at 75 Hz
1
1280 x 1024* at 60 Hz to 120 Hz
1400 x 1050* 1 at 50 Hz to 120 Hz
1440 x 900* 1 at 60 Hz to 120 Hz
1
1920 x 1200* at 60 Hz
1920 x 2160* 1 at 60 Hz
3840 x 2160p at 24 Hz to 30 Hz (HDMI/DVI)
3840 x 2160p at 60 Hz......................................... NEC DISPLAY SOLUTIONS cites recommended
480P (720 x 480*
576P (720 x 576*
720P (1280 x 720*
1080P (1920 x 1080*
1080i (1920 x 1080 at 50 Hz to 120 Hz)
697.9 mm/27.5 inches
Vert.: 392.6 mm/15.5 inches
392.6 mm/15.5 inches
Vert.: 697.9 mm/27.5 inches
I/F: USB Specifi cation Revision 3.0
Port: Upstream 2
Downstream 3
Load Current: Maximum 0.9 A per port
Headphone Impedance 32 Ohm
AC 100-240 V ~ 50/60 Hz
1.51 - 0.6 A (with option)
16V/1.25 A
SB-01HC, SB-04HC
Landscape: 744.8 mm (W) x 468.4 - 618.4 mm (H) x 301.6 mm (D)
29.3 inches (W) x 18.4 - 24.3 inches (H) x 11.9 inches (D)
Portrait: 440.8 mm (W) x 765.4 mm (H) x 301.6 mm (D)
17.4 inches (W) x 30.1 inches (H) x 11.9 inches (D)
150 mm / 5.9 inches (Landscape orientation)
20.5 kg (45.2 lbs)
5°C to 35°C/41°F to 95°F
Humidity: 30% to 80%
Altitude: 0 to 16,404 Feet/0 to 5,000 m
-20°C to 60°C/-4°F to 140°F
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet/0 to 12,192 m
Notes
Active matrix; thin fi lm transistor (TFT) liquid crystal
display (LCD); 0.182 mm dot pitch; 350 cd/m
luminance; 1000:1 contrast ratio (typical).
DisplayPort Complies with Standard V1.2*
applicable to HDCP
DVI (HDCP)
HDMI (HDCP)
Depends on display card used.
Automatically
Automatically
1
at 60 Hz) resolution for optimal display performance.
1 at 50 Hz to 100 Hz)
1 at 50 Hz to 120 Hz)
1
at 30 Hz to 120 Hz)
English-26
2 white
2
,
