OPERATING INSTRUCTIONS
WARM AIR OIL FIRED FURNACE
SMO 112 FURNACES ARE AIR CONDITIONING READY!
THIS FURNACE SHALL BE INSTALLED BY A CERTIFIED INSTALLER AND
WHERE REQUIRED BY LAW, A LICENSED TECHNICIAN
IF YOUR SUMMERAIRE SMO112 OIL FURNACE HAS BEEN INSTALLED USING THE
APPROVED SS1-C TJERNLUND SIDEWALL POWER VENTOR; IT IS YOUR
RESPONSIBILITY TO KEEP THE AREA AROUND THE VENT TERMINAL FREE OF ICE,
______________________________
Installing Contractor
______________________________
Unit Model Number
SMO112
Save These Instructions For Reference
NOTICE TO HOMEOWNER
NOTICE TO HOMEOWNER
SNOW, AND DEBRIS
FOR SERVICE CALL:
INSTALLATION INFORMATION
________________________________
Installation Date
Summeraire Mfg.
Peterborough, Ontario
K9J 7B1
_____________________________
Telephone Number
_____________________________
Unit Serial Number
OCT., 2007R
Advertisement
Table of Contents
Related Manuals for SummerAire SMO112
Summary of Contents for SummerAire SMO112
-
Page 1: Operating Instructions
WHERE REQUIRED BY LAW, A LICENSED TECHNICIAN NOTICE TO HOMEOWNER IF YOUR SUMMERAIRE SMO112 OIL FURNACE HAS BEEN INSTALLED USING THE APPROVED SS1-C TJERNLUND SIDEWALL POWER VENTOR; IT IS YOUR RESPONSIBILITY TO KEEP THE AREA AROUND THE VENT TERMINAL FREE OF ICE,... - Page 2 CAUTION: NEVER BURN GARBAGE, REFUSE OR PAPER IN THE HEATING UNIT. NEVER LEAVE COMBUSTIBLE OR OTHER MATERIALS AROUND OR NEAR THE FURNACE. NOTE: AN OPTIONAL VESTIBULE IS AVAILABLE FOR THE SMO112 FURNACE THE VESTIBULE COMPLETELY ENCLOSES THE OIL BURNER IDENTIFY THE LOCATION OF YOUR BURNER / FURNACE POWER SWITCH OIL BURNER OPERATING INSTRUCTIONS • Use No 2 furnace oil ONLY...
- Page 3 RESTARTING BURNER AFTER EXTENDED SHUT DOWN. The complete oil burner should be checked and serviced by a qualified technician. • Check oil pump strainer • Replace oil filter cartridge • Check electrodes • Oil burner motor ( see lubrication section ) • Restart burner by following instructions in; “STARTING THE OIL BURNER” section. • If your furnace has been shut off for an extended period – contact your qualified service technician for start - up SUMMER FAN OPERATION During summer, continuous air circulation can be obtained by pulling / sliding the manual fan switch from the “Auto” position to the “On” position DUAL AIR OPERATION This furnace is equipped with a dual ( two ) speed blower system which allows partial air distribution at all times. When the thermostat calls for Heat, the Oil Burner starts and the HIGH speed quickly distributes warm air throughout the home. When the HIGH SPEED stops, the “LOW” speed continues operating, circulating the air to even the temperature throughout the house. If the “LOW” speed feature is not required / desired, operate the small “rocker” switch located on the power junction box. MAINTENANCE OIL FURNACE ANNUAL SERVICE The oil burner and furnace should be thoroughly cleaned and serviced annually by a qualified service technician, and where required by law, a licensed technician.
- Page 4 A DIRTY AIR FILTER CAUSES INEFFICIENCY AND HIGHER OPERATING COSTS Clean or replace filters each heating season, or as required. Filter specifications for the air filter installed in your Summeraire oil fired warm air furnace, are listed below. DO NOT SUBSTITUTE ! Note: Changing the type or size of filter used in your Summeraire furnace can seriously affect the op- eration of the furnace! AIR FILTER SPECIFICATIONS Filter size : 20” X 20” x 1” – CSA or ULC Certified /Approved Type: Throw – away / disposable.
- Page 5 Laundromats, Beauty Salons, etc. 11. Summeraire Mfg. shall not be responsible for any failure due to water damage and/ or Acts of God. 12. No Air Conditioning or Heat pump coil may be installed on the return air side of this furnace.
