- Page 1 Blackjack 29 - INCH BRUSHLESS RTR CATAMARAN PRB08011 Owners Manual • Bedienungsanleitung Manuel de l'utilisateur • Manuale dell'utente...
-
Page 2: Table Of Contents
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit http://www.horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury. -
Page 3: Water-Resistant Boat With Waterproof Electronics
Water-resistant Boat with Waterproof Electronics Your new Horizon Hobby boat has been designed and built with a combination of waterproof and water-resistant components to allow you to operate the product in calm, fresh water conditions. While the entire boat is highly water-resistant, it is not completely waterproof and your boat should NOT be treated like a submarine. -
Page 4: Introduction
Introduction ® Pro Boat RC models look as good as they perform. Our boats, which include everything from scale sailboats to fully licensed powerboats, exceed expectations and provide years of radio control fun and excitement. Whether your passion leads you towards the pure serenity of sailing or the all-out speed of a Deep-V, Pro Boat models fit your taste, budget and lifestyle. -
Page 5: Boat Stand Assembly
Boat Stand Assembly 1. Attach the side stand pieces to the end pieces as shown. 2. Use medium CA or epoxy adhesive to secure the side stand to the ends. 3. Allow the adhesive to dry before placing your boat on the stand. -
Page 6: Battery Charger
Battery Charger Choose a charger designed to charge the recomended NOTICE: Never charge a battery in the boat or damage ® Dynamite Reaction 7.4V 5000mAh 2S 50C Li-Po battery. may result. We recommend either the Dynamite Prophet ™ Sport Plus 50W AC/DC Charger or the Dynamite Prophet Sport Duo 2 X 50W charger. -
Page 7: Spektrum Dx2E Radio System
Spektrum DX2E Radio System For more information on the transmitter, go to www.spektrumrc.com and click on the support tab to find the full manual for the DX2E transmitter. 1. Steering Wheel controls direction (left/right) of the model. 2. Throttle Trigger controls speed. 3. -
Page 8: Binding
Binding The receiver will keep the binding to the transmitter until Binding is the process of programming the receiver to another binding is done. recognize the GUID (Globally Unique Identifier) code of a single specific transmitter. The included transmitter and If you encounter problems, obey binding instructions and receiver are bound at the factory. -
Page 9: Range Check
Range Check IMPORTANT: Perform a range check at the beginning of each boating session, after repair or after installation of new batteries. Ensure the receiver antenna is extended properly and all batteries are fully charged. 1. With the radio system powered on and connected, walk away from your boat 90 feet (32 m). -
Page 10: Boating Tips
Boating Tips If the propeller and rudder are blocked with debris or When running your boat for the first time, we vegetation, remove the boat from the water and remove recommend calm wind and water conditions so that you the debris before continuing operation. can learn how the boat responds to your control. -
Page 11: After Boating And Maintenance
After Boating and Maintenance • Drain water from inside the hull using the drain plug NOTICE: When you are finished boating, never leave the boat in direct sunlight or in a hot, enclosed area such as • Fully dry the inside and outside of the boat, including a car. -
Page 12: Prop Angle Adjustment
Prop Angle Adjustment Raising the prop strut increases speed, but also decreases steering response and increases cavitation. Lowering the drive strut increases steering response, but also increases steering sensitivity and decreases speed. 1. Loosen 2 bolts and 2 nuts from the drive strut on the rear of the boat. -
Page 13: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Boat will not respond to throttle but responds Throttle channel is reversed Reverse throttle channel on transmitter to other controls Damaged propeller, shaft or motor Replace damaged parts Extra noise or extra vibration Propeller is out of balance Balance or replace propeller Boat battery charge is low Completely recharge battery... -
Page 14: Limited Warranty
Problem Possible Cause Solution Do the Control Direction Test and adjust controls Controls reversed Transmitter settings are reversed on transmitter appropriately Motor overheats Blocked water cooler tubes Clean or replace water tubes ESC uses default soft Low Voltage Recharge boat battery or replace battery that is no Cutoff (LVC) longer performing Motor power pulses... -
Page 15: Warranty And Service Contact Information
Inspection or Services Non-Warranty Service If this Product needs to be inspected or serviced and is Should your service not be covered by warranty, service compliant in the country you live and use the Product in, will be completed and payment will be required without please use the Horizon Online Service Request submission notification or estimate of the expense unless the expense process found on our website or call Horizon to obtain a... -
Page 16: Compliance Information For The European Union
FCC Information This product contains a radio transmitter with wireless technology which has been tested and found to be This device complies with part 15 of the FCC rules. compliant with the applicable regulations governing Operation is subject to the following two conditions: a radio transmitter in the 2.400GHz to 2.4835GHz frequency range. -
Page 17: Replacement Parts
Moteur brushless A3650- A3650-2000kv, 6 poli, DYNM3910 Marine Motor 2000kv 2000kV, 6 pôles pour bateau marino Hull and Decals: Blackjack ProBoat Blackjack 29: Rumpf und Scafo e adesivi: Blackjack PRB281006 Coque avec décoration Dekorbogen ProBoat Blackjack 29: PRB281007 Canopy: Blackjack 29... - Page 18 Notes/...
- Page 19 42699 Created: 06/2014 ©2014 Horizon Hobby, LLC. Pro Boat, the Pro Boat logo, Blackjack, Dynamite, Reaction, Prophet, EC3, EC5 and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. Prb08011...
