DECLARATION OF CONFORMITY
This product is marked
– Low voltage no. 2006/95/EC. (Standard: EN60335-2-40:2003 (incl. Corr.:2006) + A11:2004 + A12:2005 + A13:2012
+ A1:2006 + A2:2009 con EN 60335-1:2002 + A11:2004 + A1:2004 + A12:2006 + A2:2006 + A13:2008 + A14:2010 +
A15:2011).
– Electromagnetic compatibility no. 2004/108/EC, 92/31 EEC and 93/68 EEC. (Standard: EN55014-1 (2006) + A1(2009)
+ A2(2011), EN 55014-2 (1997) + A1(2001) + A2 (2008), EN 61000-3-2 (2006) + A1(2009) + A2(2009),
EN 61000-3-3 (2008)
– RoHS2 no.2011/65/EU.
– Regulation (EU) no. 206/2012, of 6 march 2012, concerning the specifications for ecodesign requirements of air
conditioners and fans.
– Regulation (EU) no. 626/2011, of 4 may 2011, concerning the labeling indicating the energy consumption of air
conditioners.
This declaration will become void in case of misuse and/or non observance though partial of manufacturer's installation
and/or operating instructions.
COOLING Models
OPERATING LIMITS
L
Maximum conditions
Outdoor temperature :
Room temperature
L
Minimum conditions
Outdoor temperature :
Room temperature
HEAT PUMP Models
OPERATING LIMITS
L
Cooling Maximum conditions
Outdoor temperature :
Room temperature
L
Cooling Minimum conditions
Outdoor temperature :
Room temperature
L
Heating Maximum conditions
Outdoor temperature :
Room temperature
L
Heating Minimum conditions
Outdoor temperature :
Tools required for installation (not supplied)
1.Standard screwdriver
2.Phillips head screwdriver
3.Knife or wire stripper
4.Tape measure
5.Level
6.Sabre saw or key hole saw
7.Hacksaw
8. Core bits ø 5
as it satisfies Directives:
43°C D.B.
:
32°C D.B. / 23°C W.B.
–15°C D.B.
:
19°C D.B. / 14°C W.B.
43°C D.B.
:
32°C D.B. / 23°C W.B.
19°C D.B.
:
19°C D.B. / 14°C W.B.
24°C D.B. / 18°C W.B.
:
27°C D.B.
–8°C D.B. / –9°C W.B.
19.Hammer
10.Drill
11. Tube cutter
12.Tube flaring tool
13.Torque wrench
14.Adjustable wrench
15.Reamer (for reburring)
16.Hex. key
37.4255.043.01
INSTALLATION INSTRUCTIONS
- Split system air conditioner -
Model Combinations
Combine indoor and outdoor units only as listed below.
Indoor Units
AW726CL
AW726CLF
AW735CL
AW735CLF
FC735CL
AW752CL
FC752CL
AW764CL
FC764CL
HEAT PUMP Models
Indoor Units
AW720HL
AW726HL
AW726HLF
AW735HL
AW735HLF
AW752HL
AW764HL
Power Supply:
230V / 1 / 50Hz *400 V / 3N / 50 Hz
REGULATION (EU) No. 517/2014 - F-GAS
The unit contains R410A, a fluorinated greenhouse gas with
a global warming potential (GWP) of 2087.50. Do not
release R410A into the atmosphere.
11/2014
COOLING Models
Outdoor Units
AE726SCL
AE735SCL
AE735SCL
AE752SCL
AE752SCL3 *
AE752SCL
AE752SCL3 *
AE764SCL3 *
AE764SCL3 *
Outdoor Units
AE720SH
AE726SH
AE735SH
AE752SH
AE764SH
AE764SH3 *
EG
I
F
D
E
P
GR
