Function #20 - Set Relay Times - PTI Falcon Installation And Operation Manual

Function #20 - Set Relay Times is available only on systems with PTI door alarms. It allows
you to set the length of the relay closure time for alarm relays and for entrance and exit
keypad relays. The times are set in tenths of a second for the alarm relays and eighths of a
second for the keypad relays. In addition, Function #20 allows you to specify the number of
remotes that are present on the PTI Falcon system.
After selecting Function #20, the display will ask you for the
Business Hours setting for the siren relay (in tenths of a
second). In the example shown, 100 is entered to specify 10
seconds. If an alarm occurs during the programmed
business hours, the siren will sound for 10 seconds and then
automatically shut down.
The display will the ask you for the After Hours setting for the
siren relay (in tenths of a second). In the example shown,
6000 is entered to specify ten minutes. If an alarm occurs
outside of the programmed business hours, the siren will
sound for ten minutes and then shut off.
The display will then ask you for the keypad relay time (in
eighths of a second). In the example shown, 40 is entered to
specify five seconds. When a customer enters a valid code
into an entrance or exit keypad, the keypad relay will close
for five seconds and then release.
The display will then ask for the number of remotes that exist
on the system. This will usually be the number of remote
keypads plus the number of door alarm control boxes. Your
installer can verify this number for you. Do not enter less
than the installed number or the PTI Falcon will not
communicate with some remote devices. You can enter more than the installed number
up to a maximum of fifteen, but the PTI Falcon will then waste time attempting to
communicate to nonexistent remotes.
Function #20 -
Set Relay Times?
Bus Hrs = 00600
New Val = 100
Aft Hrs = 03000
New Val = 6000
Keypad Time = 16
New Val = 40
# of Remotes = 15
New Val = 5
47
