Function #5 - Add New Unit - PTI Falcon Installation And Operation Manual

Function #5 - Add New Unit allows you to add a new unit into the PTI Falcon memory and
assign it an access code. If PTI door alarms are in use, you will also specify the physical
manner in which the alarm switch from the unit is wired. Proceed as follows:
Enter the Building Number for the unit that you wish to
assign. The building size must have been previously set with
Function #4.
Enter the Unit Number for the unit that you wish to assign.
The unit number must be in the range of one to the size
specified for the building.
Enter the Access Code for the unit. Access codes may be
up to eight digits in length. Leading zeros will be ignored.
This is the number that the user must enter at the remote
access keypads to gain entry.
The following two steps will only need to be performed if you have PTI door
alarms in operation:
Enter the control unit number to which the door is wired. This
number must be provided by the alarm system installer and
represents the number of the alarm multiplexer box to which
the unit is wired.
Enter the door number for the unit. This is the physical
terminal number for the alarm switch wire within the
multiplexer box. This number must also be provided by the
alarm system installer.
After specifying all data for a unit, the screen will indicate
" Do More?" . If you wish to immediately enter data for
another unit, press "#" for YES and you will go back to the
first step above, otherwise press "*" for NO.
Function #5 -
Add New Unit?
Building (1-32)
Number: 1
Unit (1-Size)
Number: 150
Enter Access
Code: 12345678
Control
Unit = 3
Door
Number = 37
Do More?
