KitchenAid KSRV22FVBL00 Cabinet Parts page 6

For Models: KSRV22FVWH00, KSRV22FVBT00, KSRV22FVBL00, KSRV22FVSS00, KSRV22FVMS00
(White)
FREEZER LINER PARTS
(Biscuit) (Black)
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 2212321 Slide, Ice Maker
3 W10180062 Cover, Ice Maker
4 2198641 Bracket, Cover
5 2309634 Shelf, Wire
6 489478 Screw
7 842534 Clip, Air Duct (2)
8 2163762 Cup, Shelf Mount.
9 2312034 Wire Basket
10 1115373 Switch, Rocker Arm
11 2309633 Shelf, Wire
12 2312040 Shelf, Wire
13 2198587 Cover, Emitter
14 2220398 P.C. Board
Emitter
15 W10173569 Cover, Receiver
16 2255114 P.C. Board
Receiver
17 2305582 Trim, Basket
18 2198633 Flipper
19 2198635 Spring
20 2198634 Pin
6
(Stainless) (Monochromatic Stainless)
W10216586
