KitchenAid KSRV22FVBL00 Cabinet Parts page 14

For Models: KSRV22FVWH00, KSRV22FVBT00, KSRV22FVBL00, KSRV22FVSS00, KSRV22FVMS00
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 3196537 Screw
3 2194719 Retainer, Levers
4 2304772 Spring, Torsion
5 2196195 Pin
6 2180353 Door, Ice
7 2304355 Door Mechanism
Assembly
8 2205686 Mechanism Delay
9 Grille, Overflow
2206671W White
2206671T Biscuit
2206671B Black
W10171992 Nickel
10 2304317 Water Fitting
Assembly (Includes
Water Tube)
DISPENSER FRONT PARTS
(White) (Biscuit)
Illus. Part
No.
11
2180259 White
2180260 Biscuit
2180261 Black
2180261AP Apollo Grey
12 2180224 Guide, Ice
13 625834 Spacer, Switch (2)
14 2162361 Switch (2)
15 2322423 Bracket, Control
16
2180268 White
2180269 Biscuit
2180270 Black
2180270AP Apollo Grey
17 2321704 Control Board, LCD
18
(Black)
No. DESCRIPTION
Lever, Ice
Dispenser
Lever, Water
Dispenser
Fascia, Disp
(Not Available
Order #22)
14
(Stainless) (Monochromatic Stainless)
Illus. Part
No. No. DESCRIPTION
19 2305571 Gasket
20 Bezel, Disp
(Not Available,
Order #22)
21 489000 Screw
22 Front Cover
Assembly
(Includes Items
17, 18, 19, 20,
& 25)
W10136782 White
W10139724 Biscuit
W10139723 Black
W10159780 Nickel
23 2195051 Strain Relief
24 2304673 Bracket, Dispenser
25 489214 Screw
W10216586
