MAXDATA Notebook User Manual page 39

Chapter 2 — Adding Memory (authorised service personel only!)
Rem oving a m em ory card
1. Remove the battery. For
instructions, see Chapter 5,
When to Replace the Battery.
2. Remove the three screws that
fasten the LED panel to the
case.
3. Using your thumbs, rotate and lift
the LED panel as shown. Be
careful not to pull too hard, as
this piece is connected to the
main board.
4. Gently remove the keyboard and
place it as shown. Do not strain
the cable that connects the
keyboard to the computer.
5. Locate the memory chip. Pull the
tabbed latches in the direction of
the arrows. The card will pop up
slightly.
6. Pull upwards on the card and
then slide the card out.
1
2
3
6
6
5
5
34
3
4
